Power Windows Acura RDX I

Scheme 1

Auto Reverse Operation

The system is composed of the power window master switch, the front passenger's power window switch, the driver's power window motor and the front passenger's power window motor.

The power window motor incorporates a pulser, which generates pulses during the motor's operation and sends the pulses to the power window control unit. As soon as the power window control unit detects no pulses from the pulser, the power window control unit makes the power window motor stop and reverse. If the window is more than halfway closed, it will reverse to the half open position. If the window is less than halfway closed, it will stop and reverse about 2 inches. This is to prevent pinching an obstacle during auto-up operation. The auto reverse operation is not active when the switch is held in the up position.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Resetting the Power Window Control Unit

Note. The clear procedure must be done prior to the learn procedure even if the auto function is working.

Resetting the driver's or passenger's power windows is required when any of the following have occurred

1. Power window control unit (built into the driver's master switch) is replaced
2. Power window regulator replacement or repair
3. Power window motor replacement or repair
4. Window run channel replacement or repair
5. Driver's or passenger's door glass replacement or repair
6. Power is removed from the power window control unit while the power window is moving.

Scheme 6

1. Turn the ignition switch ON (II)
2. Move the driver's or passenger's window all the way down by using the driver's window DOWN switch.
3. Open the driver's or front passenger's door. NOTE: Steps 4-7 must be done within 5 seconds of each other.
4. Turn the ignition switch OFF.
5. Push and hold the driver's or passenger's window DOWN switch.
6. Turn the ignition switch ON (II).
7. Release the driver's or passenger's window DOWN switch.
8. Repeat step 4-7 three more times.
9. Wait 1 second.
10. Confirm that AUTO UP and AUTO DOWN do not work. If AUTO UP and AUTO DOWN work, go back to step 1.
11. Move the driver's or passenger's window all the way down by using the driver's or passenger's window DOWN switch.
12. Pull up and hold the driver's or passenger's window UP switch until the window reaches the fully closed position, then continue to hold the switch for 1 second.
13. Confirm that the power window control unit is reset by using the driver's or passenger's window AUTO UP and AUTO DOWN functions. If the window still does not work in AUTO, repeat the procedure several times, paying close attention to the 5 second time limit between steps.

Power Window Master Switch Input Test

Note. The power window control unit is built into the power window master switch.

Scheme 7

1. Remove the power window master switch (A) (see «POWER WINDOW SWITCH REPLACEMENT»(/acura/rdx/i-2006-2009/remont/windows/#power-windows) ).
2. Reconnect the driver's door wire harness (B) to the driver's door sub harness (C).
3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, make the following input tests at the connector. If a test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the power window master switch must be faulty; replace it.
4. With the master switch still disconnected, make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 20 RED Connect the No. 20 and the No. 15 terminals and No. 21 and No. 22 terminals momentarily with jumper wires Check driver's power window motor operation: The window should go down. Blown No. 26 (20 A) fuse in the under-dash fuse/relay box Faulty driver's power window motor An open in the wire Poor ground (G501) 21 LT BLU Connect the No. 21 and the No. 15 terminals and No. 20 and No. 22 terminals momentarily with jumper wires Check driver's power window motor operation: The window should go up. 2 PUR Under all conditions Check for continuity between the No. 2 terminal and No. 3 terminal of the front passenger's power window switch 14P connector: There should be continuity. An open in the wire 13 LT GRN *1 ORN *2 Under all conditions Check for continuity between the No. 13 terminal and No. 3 terminal of the left rear power window switch 14P connector: There should be continuity. An open in the wire 12 GRN Under all conditions Check for continuity between the No. 12 terminal and No. 3 terminal of the right rear power window switch 14P connector: There should be continuity. An open in the wire 8 BRN Ignition switch ON (II) Measure the voltage to ground: There should be less than 1 V. Faulty MICU An open in the wire NOTE: *1 : '07 model *2 : '08-'09 models
5. Reconnect the 22P connector to the power window master switch. Turn the ignition switch ON (II), and make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the control unit must be faulty; replace the power window master switch. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 4 LT GRN Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Blown No. 1 (7.5 A) fuse in the under-dash fuse/relay box An open in the wire 1 YEL Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 4 (P/W) (40 A) fuse in the under-hood fuse/relay box Faulty power window relay An open in the wire 15 WHT Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 26 (20 A) fuse in the under-dash fuse/relay box An open in the wire 11 BRN Under all conditions Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G501) An open in the wire 22 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G501) An open in the wire 7 RED Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Faulty driver's power window master switch A short to ground in the wire 5 GRN Ignition switch ON (II), and driver's power window switch moving up or down Measure the voltage between the No. 5 and No. 7 terminals: There should be 0 V-about 5 V-0 V-about 5 V repeatedly (a digital voltmeter should read about 2.5 V while the window moves). Faulty driver's power window motor An open in the wire A short to ground in the wire 6 ORN Ignition switch ON (II), and driver's power window switch moving up or down Measure the voltage between the No. 6 and No. 7 terminals: There should be 0 V-about 5 V-0 V-about 5 V repeatedly (a digital voltmeter should read about 2.5 V while the window moves).
6. Reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/rdx/i-2006-2009/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).

Front Passenger's Power Window Switch Input Test

Note. The power window control unit is built into the front passenger's power window switch.

Scheme 8

1. Remove the front passenger's power window switch (A) (see «FRONT PASSENGER'S»(/acura/rdx/i-2006-2009/remont/windows/#power-windows) ).
2. Reconnect the front passenger's door wire harness to the front passenger's door sub harness.
3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, make the following input tests at the connector. If a test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the front passenger's power window switch must be faulty; replace it.
4. With the switch still disconnected, make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 3 PUR Under all conditions Check for continuity between the No. 3 terminal and No. 2 terminal of the power window master switch 22P connector: There should be continuity. An open in the wire 14 RED Connect the No. 14 and the No. 7 terminals and No. 8 and No. 1 terminals momentarily with jumper wires Check front passenger's power window motor operation: The window should go down. Blown No. 30 (20 A) fuse in the under-dash fuse/relay box Faulty front passenger's power window motor An open in the wire Poor ground (G505) 8 YEL Connect the No. 8 and the No. 7 terminals and No. 14 and No. 1 terminals momentarily with jumper wires Check front passenger's power window motor operation: The window should go up.
5. Reconnect the 14P connector to the front passenger's power window switch. Turn the ignition switch ON (II), and make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the control unit must be faulty; replace the front passenger's power window switch. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 7 GRN Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 30 (20 A) fuse in the under-dash fuse/relay box An open in the wire 1 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G505) An open in the wire 2 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G505) An open in the wire 6 RED Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. A short to ground in the wire 5 BLU Ignition switch ON (II), and front passenger's power window switch moving up or down Measure the voltage between the No. 5 and No. 6 terminals: There should be 0 V-about 5 V-0 V-about 5 V repeatedly (a digital voltmeter should read about 2.5 V while the window moves). Faulty front passenger's power window motor An open in the wire A short to ground in the wire 4 YEL Ignition switch ON (II), and front passenger's power window switch moving up or down Measure the voltage between the No. 4 and No. 6 terminals: There should be 0 V-about 5 V-0 V-about 5 V repeatedly (a digital voltmeter should read about 2.5 V while the window moves).
6. Reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/rdx/i-2006-2009/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).

Scheme 9

1. Remove the left rear power window switch (see «REAR PASSENGER'S»(/acura/rdx/i-2006-2009/remont/windows/#power-windows) ).
2. Disconnect the 14P connector (A) from the left rear power window switch (B).
3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary and recheck the system. If the terminals look OK, go to step 4.
4. With the connector still disconnected, make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 3 LT GRN Power window master switch 22P connector disconnected Check for continuity between the No. 3 terminal and power window master switch 22P connector No. 13 terminal: There should be continuity. An open in the wire Check for continuity to ground: There should be continuity. A short to ground in the wire 8 RED Connect the No. 8 terminal to battery power with a jumper wire, and connect the No. 14 terminal to ground. Check the left rear power window motor operation: The motor should run (the window should go down). Faulty left rear power window motor An open in the wire 14 BLU Connect the No. 14 terminal to battery power with a jumper wire, and connect the No. 8 terminal to ground. Check the left rear power window motor operation: The motor should run (the window should go up). Faulty left rear power window motor An open in the wire
5. Reconnect the connector to the left rear power window switch, and make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the left rear power window switch must be faulty; replace it. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 1 BLK Ignition switch ON (II) and left rear power window switch pushed UP or DOWN Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G601) An open in the wire 7 WHT Ignition switch ON (II) and left rear power window switch pushed UP or DOWN Measure the voltage to ground: There should be battery voltage. Blown No. 33 (20 A) fuse in the under-dash fuse/relay box Faulty power window relay An open in the wire

Scheme 10

1. Remove the right rear power window switch (see «REAR PASSENGER'S»(/acura/rdx/i-2006-2009/remont/windows/#power-windows) ).
2. Disconnect the 14P connector (A) from the right rear power window switch (B).
3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary and recheck the system. If the terminals look OK, go to step 4.
4. With the connector still disconnected, make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 3 GRN Power window master switch 22P connector disconnected Check for continuity between the No. 3 terminal and power window master switch 22P connector No. 12 terminal: There should be continuity. An open in the wire Check for continuity to ground: There should be continuity. A short to ground in the wire 8 RED Connect the No. 8 terminal to battery power with a jumper wire, and connect the No. 14 terminal to body ground. Check the right rear power window motor operation: The motor should run (the window should go down). Faulty right rear power window motor An open in the wire 14 BLU Connect the No. 14 terminal to battery power with a jumper wire, and connect the No. 8 terminal to body ground. Check the right rear power window motor operation: The motor should run (the window should go up). Faulty right rear power window motor An open in the wire
5. Reconnect the connector to the right rear power window switch, and make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the right rear power window switch must be faulty; replace it. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 1 BLK Ignition switch ON (II) and right rear power window switch pushed UP or DOWN Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G561) An open in the wire 7 PUR Ignition switch ON (II) and left rear power window switch pushed UP or DOWN Measure the voltage to ground: There should be battery voltage. Blown No. 32 (20 A) fuse in the under-dash fuse/relay box Faulty power window relay An open in the wire

Scheme 11

Scheme 12

1. Remove the power window master switch (see «POWER WINDOW SWITCH REPLACEMENT»(/acura/rdx/i-2006-2009/remont/windows/#power-windows) ), and disconnect the connectors.
2. Test the motor in each direction by connecting battery power and ground to the power window master switch 22P connector according to the table.
3. If the motor does not run or fails to run smoothly, go to step 4.
4. Disconnect the 6P connector from the driver's power window motor.
5. Check for continuity between the power window master switch 22P connector No. 20 and No. 21 terminals and the driver's power window motor 6P connector No. 1 and No. 4 terminals, respectively. POWER WINDOW MASTER SWITCH 22P CONNECTOR No. 20 terminal No. 21 terminal DRIVER'S POWER WINDOW MOTOR 6P CONNECTOR No. 1 terminal No. 4 terminal
6. If the wire harness is OK, replace the driver's power window motor. Pulser Test
7. Do the power window master switch input test No. 5, No. 6, No. 7, and No. 11 terminals (see «POWER WINDOW MASTER SWITCH INPUT TEST»(/acura/rdx/i-2006-2009/remont/windows/#power-windows__power-window-master-switch-input-test) ).

Scheme 13

Scheme 14

Scheme 15

1. Remove the passenger's power window switch (see «FRONT PASSENGER'S»(/acura/rdx/i-2006-2009/remont/windows/#power-windows) ), and disconnect the connectors.
2. Test the motor in each direction by connecting battery power and ground to the passenger's power window switch 14P connector according to the table.
3. If the motor does not run or fails to run smoothly, go to step 4.
4. Disconnect the 6P or 2P connector from the passenger's power window motor.
5. Check for continuity between the passenger's power window switch 14P connector No. 8 and No. 14 terminals and the passenger's power window motor 6P connector No. 1 and No. 4 terminals. Front passenger's door FRONT PASSENGER'S POWER WINDOW SWITCH 14P CONNECTOR No. 8 terminal No. 14 terminal FRONT PASSENGER'S POWER WINDOW MOTOR 4P CONNECTOR No. 4 terminal No. 1 terminal Rear door REAR POWER WINDOW SWITCH 14P CONNECTOR No. 8 terminal No. 14 terminal REAR POWER WINDOW MOTOR 2P CONNECTOR No. 2 terminal No. 1 terminal
6. If the wire harness is OK, replace the appropriate power window motor.

Scheme 16

Scheme 17

Scheme 18

1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
2. Disconnect the 22P connector (A) from the power window master switch.
3. Remove the driver's door sub harness (B) from the power window master switch.
4. Remove the three screws from the door panel, then pull up on the door pocket (C) to release the clips.
5. Remove the three screws and the power window master switch (A) from the door panel.
6. Remove the four screws and the power window master switch (A).
7. Install the switch in the reverse order of removal.
8. After replacement, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/rdx/i-2006-2009/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).

Scheme 19

Scheme 20

1. Removal the front passenger's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
2. Disconnect the 14P connector (A) from the power window switch.
3. Remove the front passenger's door sub harness (B) from the power window switch.
4. Remove the three screws from the door panel, then pull up on the door pocket (C) to release the clips.
5. Remove the three screws and the power window switch (A) from the door panel.
6. Remove the four screws and the power window switch.
7. Install the switch in the reverse order of removal.
8. After replacement, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/rdx/i-2006-2009/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).

Scheme 21

1. Removal the door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#doors__rear-door-panel-removalinstallation) ).
2. Disconnect the 14P connector from the power window switch (A).
3. Remove the screws and the power window switch from the door panel.
4. Remove the four screws and the power window switch.
5. Install the switch in the reverse order of removal.
