Power Moonroof Acura RDX I

Sun Roof/t-Top/convertible Top 5 illustrations ~778 words

Scheme 30

Scheme 30: Component Location Index
Scheme 30: Component Location Index

Resetting the Moonroof Control Unit

Note. Perform resetting the moonroof control unit with all the doors and tailgate closed. The clear procedure must be done first.

Resetting the moonroof is required when any of the following has occurred

  1. The moonroof was moved manually while the battery was dead or disconnected.
  2. The moonroof motor was replaced with a new one.
  3. Any of components related to the moonroof were replaced.
  1. Wind deflector
  2. Moonroof glass
  3. Moonroof seal
  4. Moonroof glass bracket
  5. Moonroof cables, etc.

To reset the moonroof control unit, do these steps

  1. Close the doors.
  2. Turn the ignition switch OFF.
  3. Press in and hold the tilt switch, and turn the ignition switch ON (II).
  4. Release the tilt switch, and turn the ignition switch OFF.
  5. Repeat steps 2 and 3 four times.
  6. Confirm the auto open/close function does not work. If the auto open/close function does work, repeat the clear procedure.
  7. Press and hold the moonroof open switch for 3 additional seconds after the moonroof is fully opened.
  8. Press and hold the moonroof close switch for 3 additional seconds after the moonroof is fully closed (tilted).
  9. Confirm that the moonroof control unit is reset by using the moonroof AUTO OPEN and AUTO CLOSE function.

Scheme 31

Scheme 31: Circuit Diagram
Scheme 31: Circuit Diagram

Moonroof Control Unit Input Test

Note. If the moonroof works OK manually, but will not work in AUTO, or reverses frequently (obstacle detection), do the moonroof calibration (see RESETTING THE MOONROOF CONTROL UNIT ) before proceeding with the input test.

Scheme 32

Scheme 32: Moonroof Control Unit Input Test
Scheme 32: Moonroof Control Unit Input Test
  1. Turn the ignition switch OFF.
  2. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
  3. Disconnect the 14P connector (A) from the moonroof control unit (B).
  4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
  5. Reconnect the connector to the control unit, and make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 6. SYMPTOM CHART Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained 7 GRN Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 24 (20 A) fuse in the under-dash fuse/relay box An open in the wire 13 LT GRN Ignition switch ON (II) Measure the voltage to ground: There should be battery voltage. Blown No. 1 (7.5 A) fuse in the under-dash fuse/relay box Faulty junction box An open in the wire 8 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V. Poor ground (G501) An open in the wire 9 PUR Moonroof switch in AUTO OPEN or AUTO CLOSE position Measure the voltage between the No. 7 and No. 9 terminals: There should be battery voltage. Poor ground (G501) Faulty moonroof switch An open in the wire 3 LT GRN Moonroof switch in TILT position Measure the voltage between the No. 7 and No. 3 terminals: There should be battery voltage. Poor ground (G501) Faulty moonroof switch An open in the wire 2 YEL Moonroof switch in CLOSE position Measure the voltage between the No. 7 and No. 2 terminals: There should be battery voltage. Poor ground (G501) Faulty moonroof switch An open in the wire 4 LT BLU Moonroof switch in OPEN position Measure the voltage between the No. 7 and No. 4 terminals: There should be battery voltage. Poor ground (G501) Faulty moonroof switch An open in the wire
  6. Check the PCM DTCs. If there is no DTC, jump the SCS line with the HDS, then disconnect PCM connector A (44P), and the moonroof control unit/motor 14P connector.
  7. Make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the control unit must be faulty; replace the moonroof control unit/motor.
CavityWireTest conditionTest: Desired resultPossible cause if result is not obtained
6BLUUnder all conditionsCheck for continuity between the No. 6 terminal and PCM connector A (44P) No. 29 terminal: There should be continuity.Faulty junction box An open in the wire
Check for continuity between the No. 6 terminal and body ground: There should be no continuity.A short to ground in the wire
12BRNUnder all conditionsCheck for continuity between the No. 12 terminal and MICU connector N (14P) No. 10 terminal: There should be continuity.An open in the wire
Check for continuity between the No. 12 terminal and body ground: There should be no continuity.A short to ground in the wire

SYMPTOM CHART

Scheme 33

Scheme 33: Moonroof Switch Test/Replacement
Scheme 33: Moonroof Switch Test/Replacement

Scheme 34

Scheme 34
Scheme 34
  1. Carefully pry off the lens with a small screwdriver (see «FRONT INDIVIDUAL MAP LIGHT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/interiorillumination-lights/#interior-lights) ).
  2. Pull down the roof console (A) holding the center part of the roof console.
  3. Carefully push out the moonroof switch (B) from behind the roof console, then disconnect the 7P connector (C) from the switch.
  4. Check for continuity between the terminals in each switch position according to (Scheme 34).
  5. If the continuity check is not as specified, check the bulb. If the bulb is OK, replace the switch.
