General Information Acura RDX I

Scheme 1

Scheme 2

Scheme 3

Paint Code

PAINT CODE REFERENCE

Scheme 4

Scheme 5

Scheme 6

PAINT CODE REFERENCE

Identifying Vehicle Identification Number ('09 Model). Scheme 7

Identifying Engine Number ('09 Model). Scheme 8

Identifying Transmission Number ('09 Model). Scheme 9

PAINT CODE REFERENCE

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Emission Group Identification

Example

'07 Model

Scheme 14

'08-09 Models

Scheme 15

'07 Model FEDERAL and CANADA

THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5 REGULATIONS APPLICABLE TO 2007 MODEL YEAR NEW LIGHT-DUTY TRUCKS AND CALIFORNIA REGULATIONS APPLICABLE TO 2007 MODEL YEAR NEW LEV II ULEV LIGHT-DUTY TRUCKS.

Identifying Test Group And Evaporative Family. Scheme 16

Lift and Support Points

Note. If you are going to remove heavy components such as suspension or the fuel tank from the rear of the vehicle, first support the front of the vehicle with tall safety stands. When substantial weight is removed from the rear of the vehicle, the center of gravity can change, causing the vehicle to tip forward on the lift.

Scheme 17

1. Position the lift blocks (A) under the vehicle's front support points (B) and rear support points (C).
2. Raise the lift a few inches, and rock the vehicle gently to be sure it is firmly supported.
3. Raise the lift to its full height, and inspect the vehicle support points for solid contact with the lift blocks.

Safety Stands

To support the vehicle on safety stands, use the same support points (B and C) as for a vehicle lift. Always use safety stands when working on or under any vehicle that is supported only by a jack.

Scheme 18

1. When lifting the front of the vehicle, set the parking brake. When lifting the rear of the vehicle, put the shift lever in the P position.
2. Block the wheels that are not being lifted.
3. Position the floor jack under the front jacking bracket (A) or the rear jacking bracket (B). Center the jacking bracket on the jack lift platform (C), and jack up the vehicle high enough to fit the safety stands under it.
4. Position the safety stands under the support points and adjust them so the vehicle is level.
5. Lower the vehicle onto the stands.

Towing

If the vehicle needs to be towed, call a professional towing service. Never tow the vehicle behind another vehicle with a rope or chain. It is very dangerous.

Emergency Towing

There are three popular methods of towing a vehicle.

Flat-bed Equipment - The operator loads the vehicle on the back of a truck. This is the only way of transporting the vehicle.

To accommodate flat-bed equipment, the vehicle is equipped with front towing hooks (A), front tie down hook slots (B), and rear tie down hook slots (C).

The towing hook can be used with a winch to pull the vehicle onto the truck, and the tie down hook slots can be used to secure the vehicle to the truck.

Front

Scheme 19

Rear

Scheme 20

Wheel Lift Equipment - The tow truck uses two pivoting arms that go under the tires (front or rear) and lift them off the ground. The other two wheels remain on the ground. Never tow the vehicle with wheel lift equipment.

Sling-type Equipment - The tow truck uses metal cables with hooks on the ends. These hooks go around parts of the frame or suspension, and the cables lift that end of the vehicle off the ground. The vehicle's suspension and body can be seriously damaged if this method of towing is attempted. This method of towing the vehicle is unacceptable.

The only recommended way of towing the vehicle is on a flat-bed truck.

Note. Towing the vehicle with only two wheels on the ground will damage parts of the SH-AWD system. If the vehicle is damaged, it should be transported on a flat-bed truck or trailer. Trying to lift or tow the vehicle by the bumpers will cause serious damage. The bumpers are not designed to support the vehicle's weight.

Parts Marking

To deter vehicle theft, certain major components are marked with the vehicle identification number (VIN). Original parts have self-adhesive labels. Replacement body parts have generic self-adhesive labels. These labels should not be removed. The original engine or transmission VIN plates are not transferable to the replacement engine or transmission.

Note. Be careful not to damage the parts marking labels during body repair. Mask the labels before repairing the part.

Precautions for Super Handling All Wheel Drive (SH-AWD) System

This vehicle is equipped with the Super Handling All Wheel Drive (SH-AWD) system. The SH-AWD system distributes driving torque between the front and rear wheels when accelerating and when wheel spin occurs.

The SH-AWD system does not have a manual switch to disable the AWD system. Whenever service work requires spinning the front or rear wheels with the engine, always lift and support the vehicle so all four wheels are off the ground.
