Rear Damper Gusset Replacement

Note. Take care not to scratch the body.

Scheme 1

Scheme 1: Rear Damper Gusset Replacement

Remove these items: Cargo area side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-area) ). Floor side spacer (see «CARGO AREA LID»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim) ).
Remove the bolts (A) and nuts (B), then remove the rear damper gusset (C).
Install the gusset in the reverse order of removal.

After loosening the subframe mounting bolts, be sure to replace them with new ones.
When installing, align both installation reference holes in the subframe with both reference holes in the body using a screwdriver or tapered punch as a guide.

Scheme 2

Note. After removing the subframe mounting bolts, be sure to replace them with new ones. When installing, align both installation reference holes in the subframe with the reference holes in the body using a screwdriver or tapered punch as a guide.
