Dashboard & Instrument Panel Acura RDX I

Dashboard Side Trim Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 30

1. Using a trim tool, pry up on the front bottom edge of the dashboard side trim (A) to release the clips. Gently pull out the trim to detach the clips, then remove the trim.
2. Install the trim in the reverse order of removal, and note these items

1. If the clips are damaged or stress-whitened, replace them with new ones.
2. Push the clips into place securely.

Left Driver's Dashboard Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 31

1. Remove the dashboard side trim, left side (see «DASHBOARD SIDE TRIM REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-side-trim-removalinstallation) )
2. Gently pull out the left driver's dashboard panel (A) to release the clip and hook (B), then remove the panel.
3. Install the panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clip and hook into place securely.

Passenger's Dashboard Trim Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 32

1. Remove the dashboard side trim, right side (see «DASHBOARD SIDE TRIM REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-side-trim-removalinstallation) ).
2. Gently pull out the trim panel (A) to release the clips, then remove the panel.
3. Install the panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Right Driver's Dashboard Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 33

1. Gently pull out the right driver's dashboard center panel (A) to release the clip, then remove the panel.
2. Install the panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Panel Trim Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 34

1. Remove these items: Right driver's dashboard panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__passengers-dashboard-trim-panel-removalinstallation) ) Passenger's dashboard trim panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__passengers-dashboard-trim-panel-removalinstallation) )
2. Gently pull out the center panel trims (A) to release the clips, then remove the trims.
3. Install the trims in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Instrument Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 35

1. Remove these items: Right driver's dashboard panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__passengers-dashboard-trim-panel-removalinstallation) ) Left driver's dashboard panel (see «DASHBOARD SIDE TRIM REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-side-trim-removalinstallation) )
2. Release the tilt/telescopic lock lever, and adjust the steering wheel to full tilt down position and to the full telescopic out position.
3. Remove the screws (A).
4. Gently pull out the instrument panel (B) to release the clips (C), then remove the panel.
5. Install the panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 36

1. Remove these items: Right driver's dashboard panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__passengers-dashboard-trim-panel-removalinstallation) ) Passenger's dashboard trim panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__passengers-dashboard-trim-panel-removalinstallation) ) Center panel trim (see «CENTER PANEL TRIM REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__center-panel-trim-removalinstallation) )
2. Remove the center panel (A). Remove the screws (B). Gently pull out the panel to release the clips (C, D), then remove the panel. Disconnect the climate switch connectors (E), hazard warning switch connector (F) and audio switch connectors (G).
3. Install the panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely. Make sure the connectors are plugged in properly.

Driver's Dashboard Undercover Removal/Installation

Note. Take care not to scratch the dashboard, and related parts.

Scheme 37

1. Remove the driver's dashboard undercover (A). Turn the lock knob (B) 90°. Gently pull down the right side edge to detach the clips.
2. Install the undercover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Driver's Switch Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 38

1. Remove the driver's switch panel (A). Pull out the bottom of the panel to release the clips, and pull it down to release the hooks (B). Disconnect the power mirror switch connector (C) and VSA OFF switch connector (D).
2. Install the panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely. Make sure the connectors are plugged in properly.

Dashboard Side Vent Removal/Installation

Note. Take care not to scratch the dashboard, and related parts.

Scheme 39

1. Remove the driver's switch panel (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ). For of the right side outlet: Detach the hook of the glove box damper and release the glove box stop on each side from the dashboard by pushing them inside (see step 2 under «Glove Box Removal/Installation»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ).
2. Push the back of the dashboard side vent (A) by hand from the driver's switch panel or glove box opening to release the hooks (B) on the side vent. Gently pull out the side vent to remove it.
3. Install the side vent in the reverse order of removal.

Passenger's Dashboard Undercover Removal/Installation

Note. Take care not to scratch the dashboard, and related parts.

Scheme 40

1. Remove the passenger's dashboard undercover (A). Gently pull down the front edge to detach the clips. Pull the cover away to release the pins (B) of the cover from the holders.
2. Install the undercover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Glove Box Removal/Installation

Note. Take care not to scratch the dashboard, and related parts.

Scheme 41

Scheme 42

1. Remove the bolts.
2. Detach the hook (A) of the glove box damper. While holding the glove box (B), push in on the stops (C) to release them from the glove box.
3. Install the glove box in the reverse order of removal.

Glove Box Damper Replacement

Note. Take care not to scratch the dashboard, and related parts.

Scheme 43

1. Remove these items: Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ) Dashboard side lid right side (see step 4 on «DASHBOARD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-replacement) )
2. Detach the clip of the glove box damper (A) by pinching it to release from inside the dashboard, then remove the damper.
3. Install the damper in the reverse order of removal.

Glove Box Striker Replacement

Note. Take care not to scratch the dashboard, and related parts.

Scheme 44

1. Detach the hook of the glove box damper and release the glove box stop on each side from the dashboard by pushing them inside (see step 2 on «GLOVE BOX REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ).
2. Remove the screws, then remove the glove box striker (A).
3. Install the striker in the reverse order of removal.

Center Upper Dashboard Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 45

1. Pry upon the edge of the center upper dashboard panel (A) with a trim tool to detach the clips. Gently pull out panel to release the clips from the dashboard.
2. Install the panel in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.

Upper Dashboard Panel Removal/Installation

Special Tools Required

1. KTC trim tool set SOJATP2014 *
2. Trim pad remover, Snap-on A 177A or equivalent, commercially available Available through the American Honda Tool and Equipment Program; call 888-424-6857 SRS components are located in this area. Review the SRS component locations (see «COMPONENT LOCATION INDEX»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ) and the precautions and procedures (see «PRECAUTIONS AND PROCEDURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ) before doing repairs or service.

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to bend or scratch the dashboard, and related parts.

Scheme 46

Scheme 47

1. Remove these items: Center upper dashboard panel (see «GLOVE BOX STRIKER REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-striker-replacement) ) Right driver's dashboard panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__passengers-dashboard-trim-panel-removalinstallation) ) Dashboard side trim, both sides (see «DASHBOARD SIDE TRIM REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-side-trim-removalinstallation) ) Passenger's dashboard trim panel (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__passengers-dashboard-trim-panel-removalinstallation) ) Center panel (see «CENTER PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__center-panel-removalinstallation) ) Instrument panel (see «CENTER PANEL TRIM REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__center-panel-trim-removalinstallation) ) Gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) )
2. Disconnect the front passenger's airbag 4P connector and three mounting nuts of the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
3. Remove the screws.
4. Detach the clips along the front edge of the upper dashboard panel (A). Gently pull up the panel to release the hooks from the dashboard (B).
5. If necessary, remove the front passenger's airbag from the upper dashboard panel (see step 5 under «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
6. Install the panel in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.

Column Cover Removal/Installation

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 48

1. Release the tilt/telescopic lock lever, and adjust the steering wheel to full tilt down position and to the full telescopic out position.
2. Turn the steering wheel to left and remove the screw (A). Release the hook (B) of the upper column cover (C) while pushing the cover from the front side.
3. Turn the steering wheel to the right and remove the screw (D). Release the hook (E) of the upper column cover is in the same as the step 2.
4. Separate the upper column cover from the lower column cover by pulling up it lightly. Release the hooks (F) of the cover to remove it from the lower column cover (G).
5. Remove the screws (H, I), and remove the lower column cover from the steering column.
6. Install the covers in the reverse order of removal, and push the hooks into place securely.

Dashboard Replacement

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Have an assistant help you when removing and installing the dashboard. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ,and wait at least 3 minutes before beginning work.
2. Remove these items: Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-column-removal-and-installation) ) Driver's switch panel (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ) Upper dashboard panel (see «UPPER DASHBOARD PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__upper-dashboard-panel-removalinstallation) ) Center panel (see «CENTER PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__center-panel-removalinstallation) ) Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ) Passenger's dashboard undercover (see «DASHBOARD SIDE VENT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-side-vent-removalinstallation) ) Gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ) Audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/entertainment-systems/#audio-system) ) Navigation display unit, with navigation system (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/navigation-system/#navigation-system__navigation-display-unit-removalinstallation) ) Audio-HVAC display unit, without navigation system (see «AUDIO-HVAC SUBDISPLAY UNIT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/entertainment-systems/#audio-system) ) Front center speaker (see «SPEAKER TEST/REPLACEMENT»(/acura/rdx/i-2006-2009/remont/entertainment-systems/#audio-system) ) Audio-HVAC subdisplay unit, with navigation system (see «AUDIO-HVAC SUBDISPLAY UNIT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/entertainment-systems/#audio-system) ) Sunlight sensor (see «SUNLIGHT SENSOR TEST»(/acura/rdx/i-2006-2009/remont/automatic-hvac-system/#hvac) ) In-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR TEST»(/acura/rdx/i-2006-2009/remont/automatic-hvac-system/#hvac) ) A-pillar trim, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) Kick panel, both sides (see step 4 under «FRONT DOOR SILL AREA»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__front-door-sill-area) ) Driver's side
3. Using a KTC trim tool, pry up on the front bottom edge of the dashboard side lid (A) to release the clips. Gently pull out to release the hooks (B), then remove the lid. Repeat on the other side of the dashboard.
4. Remove the screws, then remove the GPS antenna bracket (A) (with navigation system), then push the antenna out through the hole in the dashboard. Center
5. Detach the wire harness clip (A) from the center upper dashboard panel opening.
6. Detach the wire harness clips (A) from center panel opening. Passenger's side
7. Disconnect the antenna 2P connector (A), and detach the wire harness clips (B) from the glove box opening.
8. Carefully pry the glove box light (C) from the inside of the dashboard, and detach the wire harness clips (D).
9. From the front of the dashboard (A), remove the screws (B) and bolts (C).
10. Lift up on the dashboard (A) to release it from the guide pins (B), then carefully remove the dashboard through the front door opening. NOTE: Lay the dashboard on its front or back. Do not rest it on the lower console opening or you may damage it.
11. Install the dashboard in the reverse order of removal, and note these items: Make sure the dashboard fits onto the guide pins correctly. Before tightening the bolts, make sure the wire harnesses are not pinched. Make sure the connectors are plugged in properly. Reconnect the negative cable to the battery. Enter the anti-theft codes for the audio system and the navigation system (if equipped). Set the clock (on vehicles without navigation). Check for any DTCs that may have been set during repairs, and clear them.

Dashboard/Steering Hanger Beam Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Have an assistant help you when removing and installing the dashboard. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard, and related parts.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. Do the battery terminal disconnection procedure(see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) , and wait at least 3 minutes before beginning work.
2. Remove these items: Front seats, both sides ('07-08 models & '09 model)(see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-column-removal-and-installation) ) Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ) Passenger's dashboard undercover (see «DASHBOARD SIDE VENT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-side-vent-removalinstallation) ) In-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR TEST»(/acura/rdx/i-2006-2009/remont/automatic-hvac-system/#hvac) ) A-pillar trim, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) Kick panel, both sides (see step 4 under «FRONT DOOR SILL AREA»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__front-door-sill-area) ) Dashboard side lid, passenger's side (see step 4 under «DASHBOARD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__dashboard-replacement) ) Driver's side
3. From under the dash, disconnect the left side wire harness connectors (A), engine compartment wire harness connectors (B), are the roof wire harness connector (C).
4. From under the dash, disconnect the driver's door wire harness connectors (A), and the left TPMS subharness connector (B). Center
5. From under the dash, disconnect the A/T gear position indicator panel light/park pin switch connector (A), A/T shift lock solenoid connector (B), SRS control unit connector A (C), yaw rate-lateral acceleration sensor connector (D), SRS wire harness connector (E).
6. From under the dash, disconnect the HandsFreeLink control unit connector (A). Using a TORX T30 bit, remove the ground bolt (B), and release the wire harness clips (C). Passenger's side
7. From under the dash, disconnect the XM receiver connector or AcuraLink control unit connectors (with navigation system) (A), engine compartment wire harness connectors (B), antenna connector (C), and the right side wire harness connectors (D).
8. From under the dash, disconnect the right TPMS subharness connector (A), and the front passenger's door wire harness connectors (B).
9. From under the dash, disconnect the climate control unit connector (A), and release the wire harness clip (B).
10. Detach the clip, then remove the rear heater joint (A).
11. Remove the bolts (A, B), and remove the center brackets (C) from the dashboard center frame (D).
12. Remove the bolts of the A/T lever bracket (A), then separate the A/T lever bracket from the center frame (B) by moving to the driver's side. Do not disconnect of the A/T shift cable.
13. From the driver's side: Remove the bolt (A) from brake pedal bracket, and remove the nut (B) from the body.
14. From passenger's side: Remove the bolts (C) from the holes of the steering hanger beam.
15. Remove the caps (D), then remove the bolts (E, F), and lift up on the dashboard/steering hanger beam (G) to release it from the guide pins (H) on the body. NOTE: Before removing the dashboard/steering hanger beam, make sure all the harnesses have been disconnected.
16. Carefully remove the dashboard/steering hanger beam through the front door opening or you may damage it.
17. Install the dashboard/steering hanger beam in the reverse order of removal, and note these items: Reinstall the center brackets on the center frame, and slightly tighten the mounting bolts. Reinstall the dashboard on the body. After tightening the dashboard mounting bolts and nut, tighten the center bracket mounting bolts and center frame mounting bolts. Make sure the dashboard/steering hanger beam fits onto the guide pins correctly. Apply liquid thread lock to the bolts securing the center bracket and the dashboard before reinstallation. Before tightening the bolts, make sure the wire harnesses are not pinched. Make sure the connectors are plugged in properly. Reconnect the negative cable to the battery. Enter the anti-theft codes for the audio system and the navigation system (if equipped). Set the clock (on vehicles without navigation). Check for any DTCs that may have been set during repairs, and clear them.
