Electronic Throttle Control System Acura RDX I

Scheme 20

DTC P0122: TP Sensor A Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 21

Scheme 22

Scheme 23

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR A in the DATA LIST with the HDS. Is there about 0.3 V or less? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0122 and P0222 indicated at the same time? YES - Go to step 10 . NO - Go to step 5 .
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Jump the SCS line with the HDS.
8. Disconnect PCM connector C (44P).
9. Check for continuity between throttle body 6P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between the throttle body and the PCM (C20), then go to step 18 . NO - Go to step 23 .
10. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 11 .
11. Turn the ignition switch OFF.
12. Jump the SCS line with the HDS.
13. Disconnect PCM connector C (44P).
14. Disconnect the throttle body 6P connector.
15. Check for continuity between PCM connector terminal C12 and throttle body 6P connector terminal No. 2. Is there continuity? YES - Go to step 23 . NO - Repair open in the wire between the throttle body and the PCM (C12), then go to step 18 .
16. Turn the ignition switch OFF.
17. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
18. Reconnect all connectors.
19. Turn the ignition switch ON (II).
20. Reset the PCM with the HDS.
21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
22. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0122 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
23. Reconnect all connectors.
24. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
25. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0122 indicated? YES - Check for poor connections or loose terminals at TP sensor A and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P0123: TP Sensor A Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 24

Scheme 25

Scheme 26

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR A in the DATA LIST with the HDS. Is there about 4.8 V or more? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0123 and P0223 indicated at the same time? YES - Go to step 13 . NO - Go to step 5 .
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Turn the ignition switch ON (II).
8. Measure voltage between throttle body 6P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 18 . NO - Go to step 9 .
9. Turn the ignition switch OFF.
10. Jump the SCS line with the HDS.
11. Disconnect PCM connector C (44P).
12. Check for continuity between PCM connector terminal C20 and throttle body 6P connector terminal No. 1. Is there continuity? YES - Go to step 25 . NO - Repair open in the wire between the throttle body and the PCM (C20), then go to step 20 .
13. Turn the ignition switch OFF.
14. Disconnect the throttle body 6P connector.
15. Jump the SCS line with the HDS.
16. Disconnect PCM connector C (44P).
17. Check for continuity between PCM connector terminal C39 and throttle body 6P connector terminal No. 4. Is there continuity? YES - Go to step 25 . NO - Repair open in the wire between the throttle body and the PCM (C39), then go to step 20 .
18. Turn the ignition switch OFF.
19. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the PCM with the HDS.
23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0123 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
25. Reconnect all connectors.
26. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
27. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0123 indicated? YES - Check for poor connections or loose terminals at TP sensor A and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P0222: TP Sensor B Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 27

Scheme 28

Scheme 29

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR B in the DATA LIST with the HDS. Is there about 0.3 V or less? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0122 and P0222 indicated at the same time? YES - Go to step 10 . NO - Go to step 5 .
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Jump the SCS line with the HDS.
8. Disconnect PCM connector C (44P).
9. Check for continuity between throttle body 6P connector terminal No. 3 and body ground. Is there continuity? YES - Repair short in the wire between the throttle body and the PCM (C21), then go to step 18 . NO - Go to step 23 .
10. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 11 .
11. Turn the ignition switch OFF.
12. Jump the SCS line with the HDS.
13. Disconnect PCM connector C (44P).
14. Disconnect the throttle body 6P connector.
15. Check for continuity between PCM connector terminal C12 and throttle body 6P connector terminal No. 2. Is there continuity? YES - Go to step 23 . NO -Repair open in the wire between the throttle body and the PCM (C12), then go to step 18 .
16. Turn the ignition switch OFF.
17. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
18. Reconnect all connectors.
19. Turn the ignition switch ON (II).
20. Reset the PCM with the HDS.
21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
22. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0222 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
23. Reconnect all connectors.
24. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
25. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0222 indicated? YES - Check for poor connections or loose terminals at TP sensor A and the PCM. If the PCM was updated, substitute a known-good PCM (see «PAGE 11-8»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P0223: TP Sensor B Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 30

Scheme 31

Scheme 32

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR B in the DATA LIST with the HDS. Is there about 4.8 V or more? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0123 and P0223 indicated at the same time? YES - Go to step 13 . NO - Go to step 5 .
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Turn the ignition switch ON (II).
8. Measure voltage between throttle body 6P connector terminal No. 3 and body ground. Is there about 5 V? YES - Go to step 18 . NO - Go to step 9 .
9. Turn the ignition switch OFF.
10. Jump the SCS line with the HDS.
11. Disconnect PCM connector C (44P).
12. Check for continuity between PCM connector terminal C21 and throttle body 6P connector terminal No. 3. Is there continuity? YES - Go to step 25 . NO - Repair open in the wire between the throttle body and the PCM (C21), then go to step 20 .
13. Turn the ignition switch OFF.
14. Disconnect the throttle body 6P connector.
15. Jump the SCS line with the HDS.
16. Disconnect PCM connector C (44P).
17. Check for continuity between PCM connector terminal C39 and throttle body 6P connector terminal No. 4. Is there continuity? YES - Go to step 25 . NO - Repair open in the wire between the throttle body and the PCM (C39), then go to step 20 .
18. Turn the ignition switch OFF.
19. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the PCM with the HDS.
23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0223 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
25. Reconnect all connectors.
26. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
27. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0223 indicated? YES - Check for poor connections or loose terminals at TP sensor B and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 33

Scheme 34

Scheme 35

1. Turn the ignition switch ON (II).
2. Do the ETCS TEST in the INSPECTION MENU with the HDS. Is the RELAY circuit OK? YES - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the ETCS control relay and the PCM.[] NO - Go to step 3 .
3. Turn the ignition switch OFF.
4. Remove the ETCS control relay (F) from the under-hood fuse/relay box.
5. Test the ETCS control relay (see «POWER RELAY TEST»(/acura/rdx/i-2006-2009/remont/body-electrical/#relays__power-relay-test) ). Is the ETCS control relay OK? YES - Go to step 6 . NO - Replace the ETCS control relay, then go to step 13 .
6. Jump the SCS line with the HDS.
7. Disconnect PCM connector A (44P).
8. Check for continuity between PCM connector terminal A20 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A20) and the ETCS control relay, then go to step 13 . NO - Go to step 9 .
9. Disconnect PCM connector C (44P).
10. Turn the ignition switch ON (II).
11. Measure voltage between PCM connector terminal C1 and body ground. Is there battery voltage? YES - Repair short to power in the wire between the PCM (C1) and the ETCS control relay, then go to step 12 . NO - Go to step 18 .
12. Turn the ignition switch OFF.
13. Reconnect all connectors.
14. Turn the ignition switch ON (II).
15. Reset the PCM with the HDS.
16. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
17. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1658 indicated? YES - Check for poor connections or loose terminals at the ETCS control relay and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
18. Turn the ignition switch OFF.
19. Reconnect all connectors.
20. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1658 indicated? YES - Check for poor connections or loose terminals at the ETCS control relay and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1659 indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the ETCS control relay and the PCM.
4. Turn the ignition switch OFF.
5. Check the No.21 DBW (THROTTLE ACTUATOR CONTROL) (15 A) fuse in the under-hood fuse/relay box. Is the fuse OK? YES - Go to step 6 . NO - Go to step 17 .
6. Remove the ETCS control relay (F) from the under-hood fuse/relay box.
7. Test the ETCS control relay (see «POWER RELAY TEST»(/acura/rdx/i-2006-2009/remont/body-electrical/#relays__power-relay-test) ). Is the ETCS control relay OK? YES - Go to step 8 . NO - Replace the ETCS control relay, then go to step 23 .
8. Turn the ignition switch ON (II).
9. Measure voltage between ETCS control relay 4P connector terminal No. 4 and body ground. Is there battery voltage? YES - Go to step 10 . NO - Replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-hood-fuserelay-box) ), then go to step 22 .
10. Measure voltage between ETCS control relay 4P connector terminal No. 4 and body ground. Is there battery voltage? YES - Go to step 11 . NO - Replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-hood-fuserelay-box) ), then go to step 22 .
11. Turn the ignition switch OFF.
12. Jump the SCS line with the HDS.
13. Disconnect PCM connector C (44P).
14. Check for continuity between ETCS control relay 4P connector terminal No. 2 and PCM connector terminal C1. Is there continuity? YES - Go to step 15 . NO - Repair open in the wire between the PCM (CD and the ETCS control relay, then go to step 23 .
15. Disconnect PCM connector A (44P).
16. Check for continuity between ETCS control relay 4P connector terminal No. 3 and PCM connector terminal A20. Is there continuity? YES - Go to step 28 . NO - Repair open in the wire between the PCM (A20) and the ETCS control relay, then go to step 23 .
17. Remove the ETCS control relay (F) from the under-hood fuse/relay box.
18. Jump the SCS line with the HDS.
19. Disconnect PCM connector C (44P).
20. Check for continuity between PCM connector terminal C1 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (CD and the ETCS control relay, then go to step 23 . NO - Go to step 21 .
21. Check for continuity between ETCS control relay 4P connector terminal No. 1 and body ground. Is there continuity? YES - Replace the under-hood fuse/relay box (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-hood-fuserelay-box) ), then go to step 23 . NO - Go to step 28 .
22. Turn the ignition switch OFF.
23. Reconnect all connectors.
24. Turn the ignition switch ON (II).
25. Reset the PCM with the HDS.
26. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
27. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1659 indicated? YES - Check for poor connections or loose terminals at the ETCS control relay and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
28. Reconnect all connectors.
29. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
30. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1659 indicated? YES - Check for poor connections or loose terminals at the ETCS control relay and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P1683: Throttle Valve Default Position Spring Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 44

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
4. Turn the ignition switch OFF, and wait 10 seconds.
5. Turn the ignition switch ON (II).
6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1683 indicated? YES - Go to step 7 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
7. Turn the ignition switch OFF.
8. Remove the charge air cooler (see «CHARGE AIR COOLER REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ) and intake air duct (charge air cooler outlet tube) (see «TURBOCHARGER AND EXHAUST MANIFOLD REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ).
9. Push the throttle valve closed as shown.
10. Release the throttle valve. Does the throttle valve return? YES - Clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ), then go to step 12 and recheck. If DTC P1683 is indicated, go to step 11 . NO - Go to step 11 .
11. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
12. Turn the ignition switch ON (II).
13. Reset the PCM with the HDS.
14. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
15. Turn the ignition switch OFF, and wait 10 seconds.
16. Turn the ignition switch ON (II).
17. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1683 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P1684: Throttle Valve Return Spring Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 45

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
4. Turn the ignition switch OFF, and wait 10 seconds.
5. Turn the ignition switch ON (II).
6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1684 indicated? YES - Go to step 7 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
7. Turn the ignition switch OFF.
8. Remove the charge air cooler (see «CHARGE AIR COOLER REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ) and intake air duct (charge air cooler outlet tube) (see «TURBOCHARGER AND EXHAUST MANIFOLD REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ).
9. Push the throttle valve open as shown.
10. Release the throttle valve. Does the throttle valve return? YES - Clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ), then go to step 12 and recheck. If DTC P1684 is indicated, go to step 11 . NO - Go to step 11 .
11. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
12. Turn the ignition switch ON (II).
13. Reset the PCM with the HDS.
14. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
15. Turn the ignition switch OFF, and wait 10 seconds.
16. Turn the ignition switch ON (II).
17. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1684 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 46

Scheme 47

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Do the ETCS TEST in the INSPECTION MENU with the HDS.
4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7 . NO - Go to step 5 .
5. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS APP SENSOR A
6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM, then clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ).
7. Turn the ignition switch OFF.
8. Remove the charge air cooler (see «CHARGE AIR COOLER REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ) and intake air duct (charge air cooler outlet tube) (see «TURBOCHARGER AND EXHAUST MANIFOLD REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ).
9. Turn the ignition switch ON (II).
10. Clear the DTC with the HDS.
11. Do the ETCS TEST in the INSPECTION MENU with the HDS.
12. Visually check the throttle valve operation. Does the throttle valve operate smoothly? YES - Clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ), then go to step 22 and recheck. If DTC P2101 is indicated, go to step 19 . NO - Go to step 13 .
13. Turn the ignition switch OFF.
14. Disconnect the throttle body 6P connector.
15. Jump the SCS line with the HDS.
16. Disconnect PCM connector C (44P).
17. Connect throttle body 6P connector terminals No. 5 and No. 6 with a jumper wire.
18. Check for continuity between PCM connector terminals C3 and C4. Is there continuity? YES - Go to step 27 . NO - Repair open in the wires between the throttle body and the PCM (C3, C4), then go to step 21 .
19. Turn the ignition switch OFF.
20. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
21. Reconnect all connectors.
22. Turn the ignition switch ON (II).
23. Reset the PCM with the HDS.
24. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
25. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS APP SENSOR A
26. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ), and go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
27. Reconnect all connectors.
28. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
29. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS APP SENSOR A
30. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 29 . If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2118: Throttle Actuator Current Range/Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 48

Scheme 49

1. Jump the SCS line with the HDS.
2. Disconnect PCM connector C (44P).
3. Measure resistance between PCM connector terminals C3 and C4. Is there about 1.0 0, or less? YES - Go to step 4 . NO - Go to step 15 .
4. Disconnect the throttle body 6P connector.
5. At the throttle body side, measure resistance between throttle body 6P connector terminals No. 5 and No. 6 with the throttle fully closed. Is there about 1.0 0, or less? YES - Go to step 6 . NO - Repair short in the wires between the PCM C3 (ETCSM- line) and C4 (ETCSM+ line), then go to step 7 .
6. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
7. Reconnect all connectors.
8. Turn the ignition switch ON (II).
9. Reset the PCM with the HDS.
10. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
11. Turn the ignition switch OFF.
12. Turn the ignition switch ON (II).
13. Slowly press the accelerator pedal to the floor.
14. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2118 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
15. Reconnect all connectors.
16. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
17. Turn the ignition switch OFF.
18. Turn the ignition switch ON (II).
19. Slowly press the accelerator pedal to the floor.
20. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2118 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 17 . If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2122: APP Sensor A (TP Sensor D) Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Turn the ignition switch ON (II).
2. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor A and the PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 2 and No. 3. Is there about 5 V? YES - Go to step 7 . NO - Go to step 17 .
7. Turn the ignition switch OFF.
8. Jump the SCS line with the HDS.
9. Disconnect PCM connector A (44P).
10. Check for continuity between APP sensor 6P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A17) and APP sensor A, then go to step 24 . NO - Go to step 11 .
11. Connect APP sensor 6P connector terminal No. 1 to body ground with a jumper wire.
12. Check for continuity between PCM connector terminal A17 and body ground. Is there continuity? YES - Go to step 13 . NO - Repair open in the wire between the PCM (A17) and APP sensor A, then go to step 24 .
13. Reconnect PCM connector A (44P).
14. Connect APP sensor 6P connector terminals No. 1 and No. 3 with a jumper wire.
15. Turn the ignition switch ON (II).
16. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 29 . NO - Go to step 22 .
17. Turn the ignition switch OFF.
18. Jump the SCS line with the HDS.
19. Disconnect PCM connector A (44P)
20. Connect APP sensor 6P connector terminal No. 3 to body ground with a jumper wire.
21. Check for continuity between PCM connector terminal A25 and body ground. Is there continuity? YES - Go to step 30 . NO - Repair open in the wire between the PCM (A25) and APP sensor A, then go to step 24 .
22. Turn the ignition switch OFF.
23. Replace the accelerator pedal module (see «ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#electronic-throttle-control-system) ).
24. Reconnect all connectors.
25. Turn the ignition switch ON (II).
26. Reset the PCM with the HDS.
27. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
28. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2122 indicated? YES - Check for poor connections or loose terminals at APP sensor A and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
29. Turn the ignition switch OFF.
30. Reconnect all connectors.
31. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
32. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2122 indicated? YES - Check for poor connections or loose terminals at APP sensor A and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2123: APP Sensor A (TP Sensor D) Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 57

Scheme 58

Scheme 59

1. Turn the ignition switch ON (II).
2. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 4.9 V or more? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor A and the PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 2 and No. 3. Is there about 5 V? YES - Go to step 12 . NO - Go to step 7 .
7. Turn the ignition switch OFF.
8. Jump the SCS line with the HDS.
9. Disconnect PCM connector A (44P).
10. Connect APP sensor 6P connector terminal No. 2 to body ground with a jumper wire.
11. Check for continuity between PCM connector terminal A35 and body ground. Is there continuity? YES - Go to step 19 . NO - Repair open in the wire between the PCM (A35) and APP sensor A, then go to step 14 .
12. Turn the ignition switch OFF.
13. Replace the accelerator pedal module (see «ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#electronic-throttle-control-system) ).
14. Reconnect all connectors.
15. Turn the ignition switch ON (II).
16. Reset the PCM with the HDS.
17. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2123 indicated? YES - Check for poor connections or loose terminals at APP sensor A and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
19. Reconnect all connectors.
20. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2123 indicated? YES - Check for poor connections or loose terminals at APP sensor A and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2127: APP Sensor B (TP Sensor E) Circuit Low Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. Turn the ignition switch ON (II).
2. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor Band the PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 5 and No. 6. Is there about 5 V? YES - Go to step 7 . NO - Go to step 17 .
7. Turn the ignition switch OFF.
8. Jump the SCS line with the HDS.
9. Disconnect PCM connector A (44P).
10. Check for continuity between APP sensor 6P connector terminal No. 4 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A18) and APP sensor B, then go to step 24 . NO - Go to step 11 .
11. Connect APP sensor 6P connector terminal No. 4 to body ground with a jumper wire.
12. Check for continuity between PCM connector terminal A18 and body ground. Is there continuity? YES - Go to step 13 . NO - Repair open in the wire between the PCM (A18) and APP sensor B, then go to step 24 .
13. Reconnect PCM connector A (44P).
14. Connect APP sensor 6P connector terminals No. 4 and No. 6 with a jumper wire.
15. Turn the ignition switch ON (II).
16. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 29 . NO - Go to step 22 .
17. Turn the ignition switch OFF.
18. Jump the SCS line with the HDS.
19. Disconnect PCM connector A (44P).
20. Connect APP sensor 6P connector terminal No. 6 to body ground with a jumper wire.
21. Check for continuity between PCM connector terminal A24 and body ground. Is there continuity? YES - Go to step 30 . NO - Repair open in the wire between the PCM (A24) and APP sensor B, then go to step 24 .
22. Turn the ignition switch OFF.
23. Replace the accelerator pedal module (see «ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#electronic-throttle-control-system) ).
24. Reconnect all connectors.
25. Turn the ignition switch ON (II).
26. Reset the PCM with the HDS.
27. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
28. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2127 indicated? YES - Check for poor connections or loose terminals at APP sensor B and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
29. Turn the ignition switch OFF.
30. Reconnect all connectors.
31. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
32. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2127 indicated? YES - Check for poor connections or loose terminals at APP sensor Band the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2128: APP Sensor B (TP Sensor E) Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 67

Scheme 68

Scheme 69

1. Turn the ignition switch ON (II).
2. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 4.9 V or more? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at APP sensor B and the PCM.
3. Turn the ignition switch OFF.
4. Disconnect the APP sensor 6P connector.
5. Turn the ignition switch ON (II).
6. Measure voltage between APP sensor 6P connector terminals No. 5 and No. 6. Is there about 5 V? YES - Go to step 12 . NO - Go to step 7 .
7. Turn the ignition switch OFF.
8. Jump the SCS line with the HDS.
9. Disconnect PCM connector A (44P).
10. Connect APP sensor 6P connector terminal No. 5 to body ground with a jumper wire.
11. Check for continuity between PCM connector terminal A34 and body ground. Is there continuity? YES - Go to step 19 . NO - Repair open in the wire between the PCM (A34) and APP sensor B, then go to step 14 .
12. Turn the ignition switch OFF.
13. Replace the accelerator pedal module (see «ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#electronic-throttle-control-system) ).
14. Reconnect all connectors.
15. Turn the ignition switch ON (II).
16. Reset the PCM with the HDS.
17. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2128 indicated? YES - Check for poor connections or loose terminals at APP sensor B and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
19. Reconnect all connectors.
20. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2128 indicated? YES - Check for poor connections or loose terminals at APP sensor Band the PCM. If the PCM was updated, substitute a known-good PCM (see «PAGE 11-8»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2135: TP Sensor A/B Incorrect Voltage Correlation

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 70

Scheme 71

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Do the ETCS TEST in the INSPECTION MENU with the HDS.
4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2135 indicated? YES - Go to step 5 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
5. Turn the ignition switch OFF.
6. Remove the charge air cooler (see «CHARGE AIR COOLER REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ) and intake air duct (charge air cooler outlet tube) (see «TURBOCHARGER AND EXHAUST MANIFOLD REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ).
7. Turn the ignition switch ON (II).
8. Visually check the throttle valve operation while you clear the DTC with the HDS. Does the valve temporarily move to its fully closed position? YES - Go to step 15 . NO - Go to step 9 .
9. Turn the ignition switch OFF.
10. Jump the SCS line with the HDS.
11. Disconnect PCM connector C (44P).
12. Check for continuity between PCM connector terminals C20 and C21. Is there continuity? YES - Go to step 13 . NO - Go to step 22 .
13. Disconnect the throttle body 6P connector.
14. Check for continuity between PCM connector terminals C20 and C21. Is there continuity? YES - Repair short in the wires between the PCM C20 (TPSA line) and the C21 (TPSB line), then go to step 17 . NO - Go to step 15 .
15. Turn the ignition switch OFF.
16. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
17. Reconnect all connectors.
18. Turn the ignition switch ON (II).
19. Reset the PCM with the HDS.
20. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2135 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
22. Reconnect all connectors.
23. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2135 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM. If the PCM was updated, substitute a known-good PCM (see «PAGE 11-8»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2138: APP Sensor A/B (TP Sensor D/E) Incorrect Voltage Correlation

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 72

Scheme 73

1. Turn the ignition switch ON (II).
2. Clear the DTC with HDS.
3. Press the accelerator pedal to the floor.
4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2138 indicated? YES - Go to step 5 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the APP sensor and the PCM.
5. Check APP SENSOR A and APP SENSOR B in the DATA LIST with the HDS. Are they the same voltage? YES - Go to step 6 . NO - Go to step 12 .
6. Turn the ignition switch OFF.
7. Jump the SCS line with the HDS.
8. Disconnect PCM connector A (44P).
9. Check for continuity between PCM connector terminals A17 and A18. Is there continuity? YES - Go to step 10 . NO - Go to step 22 .
10. Disconnect the APP sensor 6P connector.
11. Check for continuity between PCM connector terminals A17 and A18. Is there continuity? YES - Repair short in the wires between PCM connector terminals A17 (APSA line) and A18 (APSB line), then go to step 14 . NO - Go to step 13 .
12. Turn the ignition switch OFF.
13. Replace the accelerator pedal module (see «ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#electronic-throttle-control-system) ).
14. Reconnect all connectors.
15. Turn the ignition switch ON (II).
16. Reset the PCM with the HDS.
17. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
18. Turn the ignition switch OFF.
19. Turn the ignition switch ON (II).
20. Press the accelerator pedal to the floor.
21. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2138 indicated? YES - Check for poor connections or loose terminals at the APP sensor A/B and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
22. Reconnect all connectors.
23. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
24. Turn the ignition switch OFF.
25. Turn the ignition switch ON (II).
26. Press the accelerator pedal to the floor.
27. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2138 indicated? YES - Check for poor connections or loose terminals at APP sensor A/B and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 24 . If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

DTC P2176: Throttle Actuator Control System Idle Position Not Learned

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). If DTC P2135 is stored at the same time as DTC P2176, troubleshoot DTC P2135 first, then recheck for DTC P2176.

Scheme 74

Scheme 75

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Turn the ignition switch OFF.
4. Turn the ignition switch ON (II), and wait 10 seconds.
5. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2176 indicated? YES - Go to step 6 . NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM, then clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ).
6. Turn the ignition switch OFF.
7. Remove the charge air cooler (see «CHARGE AIR COOLER REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ) and intake air duct (charge air cooler outlet tube) (see «TURBOCHARGER AND EXHAUST MANIFOLD REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/exhaust/#intake-manifold-and-exhaust-system) ).
8. Turn the ignition switch ON (II).
9. Clear the DTC with the HDS.
10. Visually check the throttle valve operation while doing the ETCS TEST in the INSPECTION MENU with the HDS. Does the throttle valve move to its fully closed position? YES - Go to step 11 . NO - Go to step 12 .
11. Check for sludge or carbon on the throttle valve. Is there sludge or carbon on the throttle valve? YES - Clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ), then go to step 21 . NO - Go to step 18 .
12. Turn the ignition switch OFF.
13. Disconnect the throttle body 6P connector.
14. Jump the SCS line with the HDS.
15. Disconnect PCM connector C (44P).
16. Connect throttle body 6P connector terminals No. 5 and No. 6 with a jumper wire.
17. Check for continuity between PCM connector terminals C3 and C4. Is there continuity? YES - Go to step 27 . NO- --Repair open in the wires between the throttle body and the PCM (C3, C4), then go to step 20 .
18. Turn the ignition switch OFF.
19. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system__throttle-body-removalinstallation) ).
20. Reconnect all connectors.
21. Turn the ignition switch ON (II).
22. Reset the PCM with the HDS.
23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
24. Turn the ignition switch OFF.
25. Turn the ignition switch ON (II), and wait 10 seconds.
26. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2176 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM, then clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ), and go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
27. Reconnect all connectors.
28. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ).
29. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2176 indicated? YES - Check for poor connections or loose terminals at the throttle body and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.

APP Sensor Signal Inspection

Note. This procedure checks the APP sensor in its fully closed position. In any other position, the APP sensor stores DTCs which are covered in other troubleshooting procedures. Check for Temporary DTCs or DTCs with the HDS before doing this procedure. If any DTCs are indicated, troubleshoot them first, then do this procedure. Press the accelerator pedal several times, to check its operation. If it does not operate smoothly, check the pedal. If you find a problem, replace the accelerator pedal module (see ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION ).

Scheme 76

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch ON (II).
3. Make sure the HDS communicates with the PCM. If it doesn't, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
4. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is 0 %, the APP sensor is OK. If it is not 0 %, update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 5 .
5. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is 0 %, the APP sensor is OK. If it is not 0 %, replace the accelerator pedal module (see «ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/engine-control-systems/#electronic-throttle-control-system) ), then go to step 1 .

Scheme 77

1. Disconnect the accelerator pedal module 6P connector (A).
2. Remove the accelerator pedal module (B). NOTE: The APP sensor is not available separately. Do not disassemble the accelerator pedal module.
3. Install the parts in the reverse order of removal.

See also:
• GENERAL TROUBLESHOOTING INFORMATION
• THROTTLE BODY REMOVAL/INSTALLATION
• PCM IDLE LEARN PROCEDURE
• PCM UPDATE
• SUBSTITUTING THE PCM
• PCM REPLACEMENT
• POWER RELAY TEST
• REMOVAL AND INSTALLATION
• CHARGE AIR COOLER REMOVAL AND INSTALLATION
• AIR CLEANER REMOVAL/INSTALLATION
• DLC CIRCUIT TROUBLESHOOTING
• ACCELERATOR PEDAL MODULE REMOVAL/INSTALLATION
