Scheme 10: Component Location Index

Hood Opener Cable Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body and related parts.

Scheme 11

Scheme 11: Hood Opener Cable Replacement

Remove these items: Front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#bumpers__front-bumper-removalinstallation) ) Front inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ) Kick panel (see step 3 under «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) )
Disconnect the hood opener cable (A) from the hood latch (B) (see «HOOD LATCH REPLACEMENT»(/acura/rdx/i-2006-2009/remont/door-locks-anti-theft-systems/#openers) ), and remove the hood release handle (C) (see «HOOD RELEASE HANDLE REPLACEMENT TAILGATE LATCH REPLACEMENT»(/acura/rdx/i-2006-2009/remont/door-locks-anti-theft-systems/#openers) ). Take care not to kink the cable.
Using a clip remover, detach the clips, release the hood opener cable from the clip, and remove the grommet (D) from the body, then remove the hood opener cable from the vehicle. Take care not to kink the cable.
Install the cable in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Route the cable through the hole (I) in the body. Make sure the hood opens properly and locks securely.

Fuel Fill Door Opener Cable Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to scratch the body and related parts.

Scheme 12

Scheme 12: Fuel Fill Door Opener Cable Replacement

Scheme 13

Scheme 14

Remove these items: Rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats) ) Rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/rdx/i-2006-2009/remont/seats/#seats__seat-side-bolster) ) Front door sill trim, driver's (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Kick panels, driver's sides (see step 3 under «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Rear door sill trim, (see «REAR DOOR SILL AREA»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) Cargo area side trim panel, left side (see step 4 under «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-area) ) Fuel fill door opener (see «FUEL FILL DOOR OPENER REPLACEMENT»(/acura/rdx/i-2006-2009/remont/door-locks-anti-theft-systems/#openers) )
Pull the carpet back as needed.
Release the opener cable (A) from the clip (B) and hooks (C) of the wire harness bands. Remove the wire harness band (D) and cushion tape (E).
While pinching the hooks (A) from inside the vehicle, remove the grommet (B) from the body.
Release the hook (A), then remove the grommet (B) from the fuel fill door latch (C).
Remove the fuel fill door opener cable from the vehicle. Take care not to kink the cable.
Install the opener cable in the reverse order of removal, and note these items: Align the marks (A) on the opener cable (B) with the cable clip (C), wire harness band (D) and cushion tapes (E) as shown. Replace any damaged clips, and replace the cushion tape.

Scheme 15

Scheme 16

Scheme 16: Fuel Fill Door Opener Replacement

Scheme 17

Remove these items: Front seat, driver side (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ) Front door sill (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) )
Remove the bolts, then remove the fuel fill door opener (A) from the body.
Disconnect the fuel fill door opener cable (A), then remove the opener (B). Take care not to kink the cable.
Install the opener in the reverse order of removal, and note these items: Make sure the opener cable is connected properly. Make sure the fuel fill door opens properly and locks securely. Fix at the original position in the outer end of cable on the fuel fill door opener securely.

Scheme 18

Scheme 18: Hood Latch Replacement

Scheme 19

Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#bumpers__front-bumper-removalinstallation) ).
Detach the clips, then remove the hood lock cover (A).
Disconnect and detach the hood latch switch connector (A).
Remove the bolts, then remove the hood latch (B) from the body, and disconnect the hood opener cable (C) from the hood latch.
Install the latch in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Apply multipurpose grease to each location of the hood latch indicated by the arrows. Make sure the hood opener cable is connected properly and hood latch switch connector is plugged in properly. Adjust the hood latch alignment (see «HOOD ADJUSTMENT»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#hood) ). Make sure the hood opens properly and locks securely.

Scheme 20

Scheme 21

Scheme 21: Hood Release Handle Replacement Tailgate Latch Replacement

Remove the kick panel (see step 3 under «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ).
Remove the bolt, then remove the hood release handle (A) from the body.
Disconnect the hood opener cable (B) from the hood release handle. Take care not to kink the cable.
Install the hood release handle in the reverse order of removal, and note these items: Make sure the hood opener cable is connected properly. Make sure the hood opens properly.

Note. Put on gloves to protect your hands. If the tailgate latch doesn't open by pulling the tailgate handle or using the keyless entry transmitter, remove the maintenance lid (A) from the tailgate lower trim panel, then turn the emergency lever (B) clockwise as shown.

Scheme 22

Scheme 23

Remove the tailgate lower trim panel (see step 4 under «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-tailgate-area) ).
Disconnect the actuator connector (A) and latch switch connector (B), then remove the bolts.
Pull the tailgate latch (C) out, then remove the latch.
Install the latch in the reverse order of removal, and note these items: Make sure the connectors are plugged in properly. Make sure the tailgate opens properly and locks securely.
