SRS (supplemental Restraint System) Acura RDX I

Scheme 1

Scheme 2

General Precautions

Please read the following precautions carefully before servicing the airbag system. Observe the instructions described in this manual, or the airbags could accidentally deploy and cause damage or injuries.

Scheme 3

1. Except when doing electrical inspections, always turn the ignition switch to LOCK (0), ground the SCS line with the HDS to take the PCM out of active status, disconnect the negative cable from the battery, then wait for 3 minutes before starting work. NOTE: The SRS memory is not cleared even if the ignition switch is turned OFF or the battery cables are disconnected from the battery.
2. Use replacement parts which are manufactured to the same standards and quality as the original parts. Do not install used SRS parts. Use only new parts when making SRS repairs.
3. Carefully inspect any SRS part before you install it. Do not install any part that shows signs of being dropped or improperly handled, such as dents, cracks or deformation.
4. Before removing any of the SRS parts (including the disconnection of the connectors), always disconnect the SRS connector.
5. Use only a digital multimeter to check the system. If it is not a Honda multimeter, make sure its output is 10 mA (0.01 A) or less when switched to the lowest value in the ohmmeter range. A tester with a higher output could cause accidental deployment and possible injury.
6. Do not put objects on the front passenger's airbag.
7. The original audio system and navigation system have a coded theft protection circuit. Be sure to get the anti-theft codes and write down the XM audio presets (if equipped) before disconnecting the negative cable from the battery.
8. Before returning the vehicle to the customer, enter the audio system and the navigation system code (if equipped). Set the clock (on vehicles without navigation).

Cable Reel Alignment

1. Misalignment of the cable reel could cause an open in the wiring, making the SRS system, remote steering wheel controls, and the horn inoperative. Center the cable reel whenever the following is performed (see step 6 ). Installation of the steering wheel Installation of the cable reel Installation of the steering column Other steering-related adjustment or installation
2. Do not disassemble the cable reel.
3. Do not apply grease to the cable reel.
4. If the cable reel shows any signs of damage, replace it with a new one. For example, if it does not rotate smoothly, replace the cable reel.

Airbag Handling and Storage

Do not disassemble an airbag. It has no serviceable parts. Once an airbag has been deployed, it cannot be repaired or reused.

For temporary storage of an airbag during service, observe the following precautions.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Store the removed airbag with the pad surface up. Never put anything on the airbag.
2. To prevent damage to the airbag, keep it away from any oil, grease, detergent, or water.
3. Store the removed airbag on a secure, flat surface away from any high heat source (exceeding 200°F/93°C).
4. Never do electrical tests on the airbags, such as measuring resistance.
5. Do not position yourself in front of the airbag during removal, inspection, or replacement.
6. For proper disposal of a damaged airbag, refer to airbag disposal (see «AIRBAG AND TENSIONER DISPOSAL»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__airbag-and-tensioner-disposal) ).
7. The side curtain airbag inflator assembly is a long, jointed part containing an inflator (A), a flexible bag (B), and brackets (C).
8. When removing or installing the side curtain airbag inflator assembly, never handle the flexible bag (B).

SRS Unit, Front and Side Impact Sensors, Driver's Seat Position Sensor, Front Passenger's Weight Sensors, and Roll Rate Sensor

Scheme 9

Scheme 10

1. Turn the ignition switch to LOCK (0), disconnect the negative cable from the battery, then wait for 3 minutes before starting installation or replacement of the SRS unit, or disconnecting the connectors from the SRS unit and any SRS component.
2. Be careful not to bump or impact the SRS unit, front impact sensors, side impact sensors, or the roll rate sensor whenever the ignition switch is ON (II), or for at least 3 minutes after the ignition switch is turned OFF.
3. During installation or replacement, be careful not to bump (by impact wrench, hammer, etc.) the area around the SRS unit, front impact sensors, the side impact sensors, or the roll rate sensor. The airbags could accidentally deploy and cause damage or injury.
4. After a collision where a front airbags, a side airbags, a side curtain airbags, or a seat belt tensioners were deployed, go to «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) . After a collision where the airbags, the side airbags, or the side curtain airbags did not deploy, inspect for any damage or any deformation on the SRS unit, front impact sensors, the side impact sensors, and the roll rate sensor. If there is any damage, replace the SRS unit and/or the sensors.
5. Do not disassemble the SRS unit, front impact sensors, side impact sensors, driver's seat position sensor, front passenger's weight sensors, or the roll rate sensor.
6. Be sure the SRS unit, front impact sensors, side impact sensors, and the roll rate sensor are installed securely with the mounting bolts torqued to 9.8 N.m (1.0 kgf.m, 7.2 lbf.ft)
7. Do not spill water or oil on the SRS unit or the side impact sensors, and keep them away from dust.
8. Store the SRS unit, front impact sensors, side impact sensors, and the roll rate sensor in a cool (less than 104°F/40°C) and dry (less than 80 % relative humidity, no moisture) area.

Wiring Precautions

Some of the SRS wiring can be identified by special yellow outer covering, and SRS connectors can be identified by their yellow color. Observe the instructions.

Scheme 11

Scheme 12

1. Never attempt to modify, splice, or repair SRS wiring. If there is an open or damage in SRS wiring, replace the harness.
2. Be sure to install the harness wires so they do not get pinched or interfere with other parts.
3. Make sure all SRS ground locations are clean, and grounds are securely fastened for optimum metal-to-metal contact. Poor grounds can cause intermittent problems that are difficult to diagnose.
4. Do not use any silicone based cleaners or lubricants on any SRS connectors or terminals.

Scheme 13

Scheme 14

1. When using electrical test equipment, insert the probe of the tester into the wire side of the connector. Do not insert the probe of the tester into the terminal side of the connector, and do not tamper with the connector.
2. Use a U-shaped probe. Do not insert the probe forcibly.
3. Use specified service connectors in troubleshooting. Using improper tools could cause an error in inspection due to poor metal-to-metal contact.

Spring-loaded Lock Connector

Some SRS system connectors have a spring-loaded lock.

Disconnecting

To release the lock, pull the spring-loaded sleeve (A) toward the stop (B) while holding the opposite half of the connector. Then pull the connector halves apart. Be sure to pull on the sleeve and not on the connector.

Scheme 15

Connecting

To reconnect, hold the pawl-side connector, and press on the back of the sleeve-side connector in the direction shown. As the two connector halves are pressed together, the sleeve (A) is pushed back by the pawl (B). Do not touch the sleeve.

Scheme 16

To release the lock, pull the spring-loaded sleeve (A) toward the stop (B) while holding the opposite half of the connector. Then pull the connector halves apart. Be sure to pull on the sleeve and not on the connector half.

Scheme 17

Hold both connector halves, and press them firmly together until the projection (A) of the sleeve-side connector clicks.

Scheme 18

Opening the SRS Unit Shorting Connectors for Diagnosis

Special Tools Required

SRS short canceller 070AZ-SAA0100

Note. To prevent damaging of the connector cavity, insert the short canceller straight into the cavity from the terminal side. Before installing the short canceller, wash it with electrical contact cleaner or neutral detergent, then dry it with compress air. Do not use the short canceller if it is damaged. Make sure to remove the short canceller before reconnection.

When SRS unit connectors A (28P), B (28P), or C (16P) are disconnected, a short circuit is created in the connector by its own function to prevent an airbag deployment. The circuit may need to be open when diagnosis is done on the system. Insert the short canceller (T/N 070AZ-SAA0100) in the specified cavities when it is necessary to keep the circuit open for diagnosis.

Scheme 19

Terminal numbers are shown from the wire side of the female terminals. Insert the short canceller(s) into the cavities on the terminal side of the connector.

Scheme 20

Scheme 21

Scheme 22

Seats with Side Airbags

Seats with side airbags have a "SIDE AIRBAG" label on the seat-back.

Scheme 23

1. When cleaning, use a damp cloth to clean the seat. Do not soak the seat with liquid. Do not spray steam on the seat.
2. Do not repair a torn or frayed seat-back cover. Replace the seat-back cover.
3. After a collision where the side airbag was deployed, replace the side airbag and seat frame with new parts. If the seat-back cushion is split, it must be replaced.
4. Never put aftermarket accessories on the seat (covers, pads, seat heaters, lights, etc.).

Disconnecting System Connectors

Turn the ignition switch to LOCK (0), disconnect the negative cable from the battery, and wait at least 3 minutes before beginning the following procedures.

1. Before disconnecting the cable reel 4P connector (1), disconnect the driver's airbag 4P connector (2).
2. Before disconnecting SRS unit connector B from the SRS unit, disconnect both seat belt tensioner 4P connectors and both seat belt buckle tensioner 4P connectors (3, 4, 5, 6).

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Disconnect the negative cable from the battery, and wait at least 3 minutes. Driver's Airbag
2. Remove the access panel (A) from the steering wheel, then disconnect the driver's airbag 4P connector (B) from the cable reel. Front Passenger's Airbag
3. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ).
4. Remove the dashboard upper panel (see «GLOVE BOX STRIKER REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-striker-replacement) ).
5. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag. Side Airbag
6. Disconnect both side airbag 2P connectors (A) from the SRS wire harness. Side Curtain Airbag
7. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
8. Disconnect both SRS wire harness 2P connectors (A) from the side curtain airbags. Seat Belt Tensioner
9. Remove the front and rear door sill trim (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) )
10. Remove the B-pillar lower trim (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ), then disconnect both SRS wire harness 4P connectors (A) from the seat belt tensioners. Seat Belt Buckle Tensioner
11. Disconnect both SRS wire harness 4P connectors (A) from the seat belt buckle tensioners. SRS Unit
12. Disconnect both seat belt tensioner connectors and both seat belt buckle tensioner connectors.
13. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
14. Disconnect SRS unit connector A (28P), SRS unit connector B (28P) and SRS unit connector C (16P) from the SRS unit.

Scheme 31

DTC (Diagnostic Trouble Codes)

The self-diagnostic function of the SRS system allows it to locate the causes of system problems and then store this information in memory. For easier troubleshooting, this data can be retrieved via a data link circuit.

1. When you turn the ignition switch ON (II), the SRS indicator comes on. If it goes off after 6 seconds, the system is normal, and is not currently detecting any abnormality.
2. If there is an abnormality, the system locates and defines the problem, stores this information in memory, and turns the SRS indicator on. The data remains in the memory even when the ignition switch is turned off or if the battery is disconnected.
3. The data is stored in memory as a diagnostic trouble code (DTC).
4. The "x" at the end of each DTC denotes a numeric character (0 thru 9) or an alpha character (A thru F) that is displayed on the HDS.
5. DTCs are either latching or resetting depending on the malfunction. With resetting DTCs, the SRS indicator goes off the next time the ignition switch is turned ON and the system is normal, but the DTC is still stored. With latching DTCs, the SRS indicator does not turn OFF until the malfunction is repaired and the DTC is cleared.
6. When you connect the HDS to the data link connector (DLC), you can retrieve a more detailed DTC in the Honda Systems "SRS" menu.
7. After reading and recording the DTC, proceed with the troubleshooting procedure for that code.

Precautions

1. Use only a digital multimeter to check the system. If it's not a Honda multimeter, make sure its output is 10 mA (0.01 A) or less when switched to the smallest value in the ohmmeter range. A tester with a higher output could damage the airbag circuit or cause accidental airbag deployment and possible injury.
2. Whenever the ignition switch is ON (II), or has been turned OFF for less than 3 minutes, be careful not to bump the SRS unit; the airbags could accidentally deploy and cause damage or injuries.
3. Before you remove the dashboard wire harness, floor wire harness, or the side curtain wire harness, disconnect the driver's airbag connector, the front passenger's airbag connector, both side airbag connectors, both side curtain airbag connectors, both seat belt tensioner connectors, and both seat belt buckle tensioner connectors.
4. Make sure the battery is sufficiently fully charged. If the battery is dead or low, measuring values may not be correct.
5. Do not touch a tester probe to the terminals in the SRS unit or harness connectors, and do not connect the SRS unit terminals or the sensor terminals with a jumper wire. Use only the backprobe set and the multimeter. Backprobe spring-loaded lock type connectors correctly.

Scheme 32

1. Make sure the ignition switch is OFF.
2. Connect the HDS to the data link connector (DLC) (A).
3. Turn the ignition switch ON (II).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
5. Use the HDS to check for DTCs.
6. Read and record the DTC.
7. Turn the ignition switch to LOCK (0), and wait for 10 seconds.
8. Disconnect the HDS from the DLC.
9. Do the troubleshooting procedure for the DTC.

Clear the DTC Memory With the HDS

Note. Make sure the battery is fully charged before you begin.

1. Make sure the ignition switch is OFF.
2. Connect the HDS to the data link connector (DLC) (A).
3. Turn the ignition switch ON (II).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
5. In the SRS MENU of the HDS, select SRS, then DTC to clear DTC(s).
6. Turn the ignition switch to LOCK (0), and wait for 10 seconds.
7. Disconnect the HDS from the DLC.

Clear the DTC Memory Using the MES Connector Without the HDS

Special Tools Required

SCS Service Connector 07PAZ-001010A

Note. Make sure the battery is fully charged before you begin.

To clear the DTC(s) from the SRS unit, use the HDS or the following procedure.

Scheme 33

1. Make sure the ignition switch is OFF.
2. Connect the SCS service connector (A) to the yellow MES 2P connector (B). Do not use a jumper wire.
3. Turn the ignition switch ON (II).
4. The SRS indicator will come on for about 6 seconds, and then go off. Remove the SCS service connector from the MES connector (2P) within 4 seconds after the indicator goes off.
5. The SRS indicator will come on again. Reconnect the SCS service connector to the MES connector (2P) within 4 seconds after the indicator comes on.
6. When the SRS indicator goes off, remove the SCS service connector from the MES connector (2P) within 4 seconds.
7. The SRS indicator blinks two times, indicating that the memory has been cleared.
8. Turn the ignition switch to LOCK (0), then wait for 10 seconds.
9. Turn the ignition switch ON (II) again. If the SRS indicator comes on for 6 seconds, and then goes off, the system is OK.

Troubleshooting Intermittent Failures

If there was a malfunction, but it does not recur, it will be stored in the memory as an intermittent failure, and the SRS indicator may come on depending on this malfunction detected.

Note. Make sure the battery connections are good and the battery is sufficiently charged. A faulty cable reel can cause intermittent DTCs related to the driver's airbag. Check all of the connections in the circuit for the DTC you are troubleshooting

After checking the DTC, troubleshoot as follows

1. Make sure the ignition switch is OFF.
2. Connect the HDS to the data link connector (DLC).
3. Turn the ignition switch ON (II).
4. Make sure the HDS connections with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
5. In the SRS MENU on the HDS, select SRS then DTC to clear the DTC(s).
6. Read the DTC (see "Reading the DTC").
7. Clear the DTC memory (see "How to clear DTC Memory Clear Procedure").
8. Set the parking brake, then start the engine, and let it idle.
9. The SRS indicator comes on for about 6 seconds and then goes off.
10. Shake the related wire harnesses and the connectors, and check for loose connections, poor pinfits, and poor grounds.
11. Take a test-drive (quick acceleration, quick braking, and cornering), turn the steering wheel fully left and right, and hold it there for 5 to 10 seconds. If the problem recurs, the SRS indicator will come on.
12. If you cannot duplicate the concern, ask the client about the conditions when it occurred, or ask the client to demonstrate the concern.
13. If you cannot duplicate the intermittent failure, the system is OK at this time.

Checking the Front Passenger's Weight Sensors after a Vehicle Collision

1. Position the front passenger's seat to the rearmost position, adjust the recliner to the forward most position. Do not move the seat from this position.
2. Drive the vehicle, accelerate to 20 mph (36 km/h), then stop on level ground.
3. Make sure the ignition switch is OFF.
4. Connect the HDS to the data link connector (DLC) (A).
5. Turn the ignition switch ON (II).
6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
7. From the SRS inspection menu, select Seat Weight Sensor, then Misc Test, then "SEAT OUTPUT CHK." and follow the prompts until the front passenger's weight sensors operation check has been completed.

ODS Unit Initialization

When a seat-back cover, seat-back cushion, and/or ODS unit is replaced, initialize the ODS by doing the procedure.

Note. A new (uninitialized) ODS unit installed with a faulty ODS sensor can cause DTC 85-71 and 85-78.

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Make sure the front passenger's seat is dry. Set the seat-back in a normal position, and make sure there is nothing on the seat.
3. Make sure the ignition switch is OFF and the MES connector is not shorted.
4. Connect the HDS to the data link connector (DLC) (A).
5. Turn the ignition switch ON (II).
6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
7. From the HDS Main Menu, select SRS, then SRS then Calibration. In the Calibration Menu, select ODS INITIALIZATION. Follow the screen prompts to initialize the ODS unit.
8. Turn the ignition switch to LOCK (0).
9. Disconnect the HDS from the DLC.

Note. If the ODS fails to initialize after several attempts, replace the OPDS sensor/seat-back (foam pad) and retry. If the ODS continues to fail to initialize, replace the ODS unit (see ODS UNIT REPLACEMENT ).

ODS Unit Calibration

When you replace the front passenger's weight sensors or the ODS unit, calibrate the ODS.

While calibrating the front passenger's weight sensor unit, observe these precautions

1. Make sure all components of the front passenger's seat are correctly installed.
2. Make sure nothing is on or under the front passenger's seat.
3. Make sure there is nothing in the front passenger's seat-back pocket.
4. Keep the windows closed.
5. Do all calibration procedures, except test-driving in the service bay.
6. Make sure the vehicle is on level ground.
7. Keep the A/C and the heater off.
8. Do not touch the front passenger's seat until you are prompted to or when you have completed the calibration.
9. Do not expose the front passenger's seat to sudden temperature changes. Position the front passenger's seat to the rearmost position, and adjust the recliner to the forward most position. Do not move the seat from this position. Make sure the ignition switch is OFF. Connect the HDS to the data link connector (DLC) (A), Turn the ignition switch ON (II). Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ). Drive the vehicle, and accelerate to 20 mph (36 km/h), then stop on level ground. From the Main Menu, select SRS, then Calibration, then Misc Test, then select "SWS INITIALIZATION," and follow the prompts until the calibration is complete.

ODS Unit Operation Check

Check the ODS operation after any of these actions.

1. Replacement of front passenger's seat component(s) (except ODS unit and/or weight sensors)
2. After a vehicle collision

Pre-Operation Check Set-up

1. Make sure all the components of the front passenger's seat are correctly installed.
2. Position the front passenger's seat to the rearmost position. Adjust the seat recline to the forward most position. Do not move the seat from this position.
3. Make sure nothing is on or under the front passenger's seat.
4. Make sure there is nothing in the front passenger's seat-back pocket.
5. Keep the windows closed.
6. Do all calibration procedures except test-driving in the service bay.
7. Make sure the vehicle is on level ground.
8. Turn the heater and the A/C off.
9. Do not touch the front passenger's seat during the calibration.
10. Do not expose the front passenger's seat to sudden temperature changes.
11. Make sure all after market devices such as amplifies, fluorescent light, air purifiers, CB or HAM radios, etc. are turned off.

After Replacing Front Passenger's Seat Component(s)

1. Make sure the ignition switch is OFF.
2. Connect the HDS to the data link connector (DLC) (A).
3. Turn the ignition switch ON (II).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
5. Drive the vehicle, accelerate to 20 mph (36 km/h), then stop on level ground.
6. From the HDS Main Menu, select SRS, then Misc Test, then Inspection. In the HDS Inspection Menu, select "SEAT OUTPUT CHK." The weight (TO) of the front passenger's seat is recorded by the HDS.

Driver's Seat Position Sensor Operation Check

Check the driver's seat position after any of these actions.

Scheme 34

1. Driver's seat position sensor replacement
2. Cover plate (front side of driver's seat slide rail) replacement Make sure the driver's seat is at its fall forward position. Make sure the ignition switch is OFF. Connect the HDS to the data link connector (DLC) (A). Turn the ignition switch ON (II). Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ). From the HDS Main Menu, select SRS then Parameter Information, then Buckle Switch, Seat Position Sensor. Using a piece of tape (A), mark a line on the seat's outer cover (B), where the front riser cover meets the seat riser (C). The driver's seat position sensor should read "NEAR." Move the seat back in small increments (about 0.2 in., 5 mm) until the driver's seat position sensor reads "NOT NEAR." The seat should be about 1 in. (25 mm) from the front. NOTE: It takes a few seconds for the HDS to display changes, so wait about 5 seconds between each move. If the driver's seat position sensor does not work as described above, check the driver's seat position sensor or the cover plate for damage, and replace parts as needed. Turn the ignition switch to LOCK (0), and disconnect the HDS from the DLC.

DTC Troubleshooting Index

DTC TROUBLESHOOTING INDEX

DTC TROUBLESHOOTING INDEX

Symptom Troubleshooting Index

SYMPTOM TROUBLESHOOTING INDEX

Airbags

The SRS is a safety device which, when used with the seat belt, is designed to help protect the driver and front passenger in a frontal impact exceeding a certain set limit. The system consists of the SRS unit, including safing sensor and impact sensor (A), the cable reel (B), the driver's airbag (C), the front passenger's airbag (D), side airbags (E), side curtain airbags (F), seat belt tensioners (G), seat belt buckle tensioners (H), side impact sensors (first) (I), front impact sensors (J), roll rate sensor (K) and side impact sensors (second) (L), since the driver's and front passenger's airbags use the same sensors, both normally inflate at the same time. However, it is possible for only one airbag to inflate. This can occur when the severity of a collision is at the margin, or threshold, that the SRS unit determines whether or not the airbags will deploy. In such cases, the seat belt will provide sufficient protection, and the supplemental protection offered by the airbag would be minimal.

Front Passenger's Weight Sensors

The ODS unit (M) is in the front passenger's seat-back. The front passenger's weight sensors (N) are part of the seat. The weight sensors detect the weight on the seat, and sends the information to the ODS unit. If the total weight is about 65 lbs

(30 kg) or less, the ODS unit sends a signal to the SRS unit to prevent the font passenger's airbag from deploying. When the front passenger's airbag is disabled, the passenger airbag cutoff indicator on the center panel comes on to alert the driver that the front passenger's airbag will not deploy in a front-end collision.

Driver's Seat Position Sensor

The driver's seat position sensor (O) is under the driver's seat on the left side. When the driver's seat is moved to its full forward position, the deployment of the driver's airbag is moderated to decrease its force of impact during a front-end collision.

Scheme 35

Roll Rate Sensor

The roll rate sensor is located under the front passenger's seat. It detects the amount of roll of the vehicle and sends the information to the SRS unit. The SRS unit uses this information to determine if a vehicle rollover is imminent. If so, it deploys both side curtain airbags and the front seat belt tensioners.

Side Airbag Cutoff Indicator/ODS Operation

The indicator comes on if the front passenger's seat is occupied by a small adult or child who is leaning into the deployment path, or an object (grocery bag, briefcase, purse, etc.) is in the seat. The OPDS sensor determines the front passenger's size and location, and it sends this information to the ODS unit. When the indicator comes on, the passenger's side airbag is off and will not deploy; there is no problem with the side airbag. If the passenger sits upright or moves to another seat, or you remove the object from the seat, the light should go off. There will be some delay between the occupant's repositioning and when the indicator will turn on or off.

Passenger Airbag Cutoff Indicator

The indicator comes on if the weight of the front passenger is about 65 lbs (30 kg) or less. This indicates the passenger's front airbag is off and will not deploy. The front airbag is shut off to reduce the chance of airbag-caused injuries.

SRS Operation

The main circuit in the SRS unit senses and judges the force of impact and, if necessary, ignites the inflator charges. If battery voltage is too low or power is disconnected due to the impact, the voltage regulator and the back-up power circuit will keep voltage at a constant level.

Seat Belt Tensioners and Seat Belt Buckle Tensioners

1. A front impact sensor side impact sensor or the roll rate sensor must activate and send electric signals to the microprocessor.
2. The microprocessor must compute the signals and send them to the tensioners.
3. The charges must ignite and deploy the tensioners.

Driver's and Front Passenger's Airbag(s)

1. A front impact sensor must activate and send electric signals to the microprocessor.
2. The microprocessor must compute the signals and send them to the airbag inflator(s).
3. The inflators that receives the signals must ignite and deploy the airbags.

Side Airbag(s)

1. Aside impact sensor must activate and send electric signals to the microprocessor.
2. The microprocessor must compute the signals and send them to the side airbag inflator(s). However, the microprocessor cuts off the signals to the front passenger's side airbag if the SRS unit determines that the front passenger's head is in the deployment path of the side airbag.
3. The inflator that receives the signal must ignite and deploy the side airbag.

Side Curtain Airbag(s)

1. Side impact sensor or the roll rate sensor must activate and send electrical signals to the microprocessor.
2. The microprocessor must compute the signals and send them to the side curtain airbag and side airbag inflator(s).
3. The inflator that receives the signals must ignite and deploy the side curtain airbag and side airbag at the same time.

Scheme 36

Self-diagnostic System

A self-diagnostic circuit is built into the SRS unit; when the ignition switch is turned ON (II), the SRS indicator comes on and goes off after about 6 seconds if the system is operating normally.

If the indicator does not come on, or does not go off after 6 seconds, or if it comes on while driving, it indicates an abnormality in the system. The system must be inspected and repaired as soon as possible.

For better serviceability, the SRS unit memory stores a DTC that relates to the cause of the malfunction, and the unit is connected to the data link connector (DLC). This information can be read with the HDS when it is connected to the DLC (see GENERAL TROUBLESHOOTING INFORMATION ).

Note. Before you disconnect the negative cable from the battery for troubleshooting, make sure you have the anti-theft code for the audio system and the navigation system (if equipped).

Scheme 37

SRS UNIT REFERENCE

Note. BLU, BRN, GRN, GRY or ORN wire may be substituted for the wire colors in this table.

Scheme 38

SRS UNIT REFERENCE

Note. BLU, BRN, GRN, GRY or ORN wire may be substituted for the wire colors in this table.

Scheme 39

SRS UNIT REFERENCE

Note. BLU, BRN, GRN, GRY or ORN wire may be substituted for the wire colors in this table.

SRS Circuit Diagram (1 of 4). Scheme 40

SRS Circuit Diagram (2 of 4). Scheme 41

SRS Circuit Diagram (3 of 4). Scheme 42

SRS Circuit Diagram (4 of 4). Scheme 43

DTC 11 -1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Airbag First Inflator; DTC 11 -2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Driver's Airbag First Inflator; DTC 11-4x ("x" can be 0 thru 9 or A thru F): Open in Driver's Airbag Second Inflator; DTC 11-5x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Driver's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ) , and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 44

Scheme 45

Scheme 46

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-1x, 11-2x, 11-4x, or 11-5x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0), Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead J to the cable reel.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-1x, 11 2x, 11-4x, or 11-5x indicated? YES - Go to step 9 . NO - Open in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
11. Connect the SRS inflator simulator (2 0, connectors) and simulator lead J to the dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory.
14. Read the DTC. Is DTC 11-1x, 11-2x, 11-4x, or 11-5x indicated? YES - Go to step 15 . NO - Open in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
18. Measure the resistance between the terminals of both SRS simulator lead. There should be 1 ohms or less. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the dashboard wire harness; replace the dashboard wire harness.

DTC 11 -3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Airbag First Inflator; DTC 11 -6x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100
3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 47

Scheme 48

Scheme 49

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-3x or 11-6x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead J to the cable reel.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-3x or 11-6x indicated? YES - Go to step 9 . NO - Short in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
11. Connect the SRS inflator simulator (2 0, connectors) and the simulator lead to the dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory.
14. Read the DTC. Is DTC 11-3x or 11-6x indicated? YES - Go to step 15 . NO - Short in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
18. Connect a SRS short canceller (070AZ-SAA0100) to No. 7 and No. 8 terminals and No. 1 and No. 2 terminals of the SRS unit connector A (28P) (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__opening-the-srs-unit-shorting-connectors) ).
19. Measure the resistance between the terminals of both SRS simulator leads. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the dashboard wire harness; replace the dashboard wire harness.

DTC 11-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Airbag First Inflator; DTC 11-Ax ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 50

Scheme 51

Scheme 52

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-8x or 11-Ax indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
5. Connect the SRS inflator simulator (2 0. connectors) and simulator lead J to the cable reel.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-8x or 11-Ax indicated? YES - Go to step 9 . NO - Short to power in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
11. Connect the SRS inflator simulator (2 ohms connectors) and the simulator lead to the dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear DTC memory.
14. Read the DTC. Is DTC 11-8x or 11-Ax indicated? YES - Go to step 15 . NO - Short to power in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
15. Turn the ignition switch to LOCK (0).Disconnect the negative cable from the battery, then wait for 3 minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
18. Reconnect the negative cable to the battery.
19. Turn the ignition switch ON (II).
20. Measure the voltage between each terminal of the SRS simulator lead and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the dashboard wire harness; replace the dashboard wire harness.

DTC 11-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Airbag First Inflator; DTC 11-Bx ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 53

Scheme 54

Scheme 55

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-9x or 11-Bx indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0).Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead J to the cable reel.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-9x or 11-Bx indicated? YES - Go to step 9 . NO - Short to ground in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
11. Connect the SRS inflator simulator (2 ohms connectors) and the simulator lead to the dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory.
14. Read the DTC. Is DTC 11-9x or 11-Bx indicated? YES - Go to step 15 . NO - Short to ground in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 .
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
18. Measure the resistance between each terminal of the SRS simulator lead and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Airbag First Inflator; DTC 12-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Front Passenger's Airbag First Inflator; DTC 12-4x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Airbag Second Inflator; DTC 12-5x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 56

Scheme 57

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 12-1x, 12-2x, 12-4x, or 12-5x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness.
5. Connect the SRS inflator simulator (2 0, connectors) and simulator lead J to the dashboard wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-1 x, 12-2 x, 12-4 x, or 12-5 x indicated? YES - Go to step 9 . NO - Open in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
12. Measure the resistance between the terminals of both SRS simulator leads. There should be 1 ohms or less. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P). Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Airbag First Inflator; DTC 12-6x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100
3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 58

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 12-3x or 12-6x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead J to dashboard wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-3x or 12-6x indicated? YES - Go to step 9 . NO - Short in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
12. Connect a SRS short canceller (070AZ-SAA0100) to No. 9 and No. 10 terminals, and the No. 3 and No. 4 terminals of the SRS unit connector A (28P) (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__opening-the-srs-unit-shorting-connectors) ).
13. Measure the resistance between the terminals of both SRS simulator leads. There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Airbag First Inflator; DTC 12-Ax ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 59

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 12-8x or 12-Ax indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to troubleshooting Intermittent Failures (see «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) ). If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0).. Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the front passenger's airbag 4P connector (A) from dashboard wire harness.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead J to the dashboard wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-8x or 12-Ax indicated? YES - Go to step 9 . NO - Short to power in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
12. Reconnect the negative cable to the battery.
13. Turn the ignition switch ON (II).
14. Measure the for voltage between each terminal of the SRS simulator lead and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Airbag First Inflator; DTC 12-Bx ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 60

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 12-9x or 12-Bx indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the front passenger's airbag 4P connector (A) from dashboard wire harness.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead J to the dashboard wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-9x or 12-Bx indicated? YES - Go to step 9 . NO - Short to ground in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
12. Measure the resistance between each terminal of the SRS simulator lead and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the dashboard wire harness; replace the dashboard wire harness.

DTC 21 -1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Tensioner; DTC 21-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Driver's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 61

Scheme 62

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-1x 1 or 21-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt tensioner.
5. Connect the SRS inflator simulator (2 0. connectors) and simulator lead K to the floor wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-1x or 21-2x indicated? YES - Go to step 9 . NO - Open in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the front passenger's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Measure the resistance between the No. 1 and the No. 2 terminals of SRS unit connector B (28P). There should be 2.0-3.0 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 21-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 63

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-3X indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt tensioner.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-3x indicated? YES - Go to step 9 . NO - Short in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the front passenger's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 1 and the No. 2 terminals of SRS unit connector B (28P). There should bean open circuit or at least 1 Mohms. Is the resistance as specified ? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the SRS wire harness; replace the SRS wire harness.

DTC 21-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 64

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt tensioner.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-8x indicated? YES - Go to step 9 . NO - Short to power in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the front passenger's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the voltage between the No. 1 terminal of SRS unit connector B (28P) and body ground, and between the No. 2 terminal and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 21 -9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 65

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-9x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt tensioner.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-9x indicated? YES - Go to step 9 . NO - Short to ground in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the front passenger's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 1 terminal of SRS unit connector B (28P) and body ground, and between the No. 2 terminal and body ground. There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 22-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Tensioner; DTC 22-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 66

Scheme 67

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-1x or 22-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt tensioner.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-1x or 22-2x indicated? YES - Go to step 9 . NO - Open in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the driver's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Measure the resistance between the No. 3 and the No. 4 terminals of SRS unit connector B (28P). There should be 2.0-3.0 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 22-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 68

Scheme 69

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-3x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt tensioner.
5. Connect the SRS inflator simulator (2 0. connectors) and simulator lead K to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-3x indicated? YES - Go to step 9 . NO - Short in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the driver's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 3 and the No. 4 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the SRS wire harness; replace the SRS wire harness.

DTC 22-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 70

Scheme 71

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt tensioner.
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-8x indicated? YES - Go to step 9 . NO - Short to power in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the driver's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the voltage between the No. 3 terminal of SRS unit connector B (28P) and body ground, and between the No. 4 terminal and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 22-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 72

Scheme 73

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-9x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt tensioner.
5. Connect the SRS inflator simulator (2 0, connectors) and simulator lead K to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-9x indicated? YES - Go to step 9 . NO - Short to ground in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt buckle tensioner 4P connectors (see step 11 ) and the driver's seat belt tensioner 4P connector (see step 10 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 3 terminal of SRS unit connector B (28P) and body ground, and between the No. 4 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 27-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Tensioner; DTC 27-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Driver's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 74

Scheme 75

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 27-1 x or 27-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 0, connectors) and simulator lead K to the SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 27- 1x or 27-2x indicated? YES - Go to step 9 . NO - Open in the driver's seat belt buckle tensioner; replace the driver's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the front passenger's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Measure the resistance between the No. 7 and No. 8 terminals of SRS unit connector B (28P). There should be 2.0-3.0 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 27-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 76

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 27-3x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 27-3x indicated? YES - Go to step 9 . NO - Short in the driver's seat belt buckle tensioner; replace the driver's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the front passenger's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 7 and No. 8 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the SRS wire harness; replace the SRS wire harness.

DTC 27-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 77

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 27-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 27-8x indicated? YES - Go to step 9 . NO - Short to power in the driver's seat belt buckle tensioner; replace the driver's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the front passenger's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the voltage between the No. 7 terminal of SRS unit connector B (28P) and body ground, and the No. 8 terminal and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 27-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 78

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 27-9x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the driver's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 27-9x indicated? YES - Go to step 9 . NO - Short to ground in the driver's seat belt buckle tensioner; replace the driver's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the front passenger's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 7 terminal of SRS unit connector B (28P) and body ground, and the No. 8 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 28-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Tensioner; DTC 28-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Front Passenger's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 79

Scheme 80

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 28-1 x or 28-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to the SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 28-1 x or 28-2x indicated? YES - Go to step 9 . NO - Open in the front passenger's seat belt buckle tensioner; replace the front passenger's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the driver's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Measure the resistance between the No. 9 and No. 10 terminals of SRS unit connector B (28P). There should be 2.0-3.0 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 28-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 81

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 28-3x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 0, connectors) and simulator lead K to SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 28-3x indicated? YES - Go to step 9 . NO - Short in the front passenger's seat belt buckle tensioner; replace the front passenger's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the driver's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 9 and No. 10 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the SRS wire harness; replace the SRS wire harness.

DTC 28-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 82

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 28-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 28-8x indicated? YES - Go to step 9 . NO - Short to power in the front passenger's seat belt buckle tensioner; replace the front passenger's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the driver's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the voltage between the No. 9 terminal of SRS unit connector B (28P) and body ground, and the No. 10 terminal and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 28-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Seat Belt Buckle Tensioner

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 83

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 28-91 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 4P connector (A) from the front passenger's seat belt buckle tensioner connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead K to SRS wire harness connector.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 28-9x indicated? YES - Go to step 9 . NO - Short to ground in the front passenger's seat belt buckle tensioner; replace the front passenger's seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and the driver's seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the simulator lead from the SRS wire harness.
13. Measure the resistance between the No. 9 terminal of SRS unit connector B (28P) and body ground, and the No. 10 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 31 - 1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Side Airbag Inflator; DTC 31-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Driver's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 84

Scheme 85

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-1x or 31-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the driver's side airbag (B).
5. Connect the SRS inflator simulator (2 connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-1x indicated? YES - Go to step 9 . NO - Open in the driver's side airbag inflator; replace the driver's side airbag (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be 1.0 ohms or less. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 31-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300
3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 86

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-3x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the driver's side airbag (B).
5. Connect the SRS inflator simulator (2 0, connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-3x indicated? YES - Go to step 9 . NO - Short to another wire in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS Unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Connect the SRS short canceller (070AZ-SAA0100) to the No. 17 and No. 18 terminals of the SRS unit connector B (28P) (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__opening-the-srs-unit-shorting-connectors) ).
14. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the SRS wire harness; replace the SRS wire harness.

DTC 31-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 87

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the driver's side airbag (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-8x indicated? YES - Go to step 9 . NO - Short to power in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the voltage between each terminal of the black SRS simulator lead (A) and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 31-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 88

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) )and Battery Terminal disconnection and Reconnection (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-9x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3-minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the driver's side airbag (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-9x indicated? YES - Go to step 9 . NO - Short to ground in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between each terminal of the black SRS simulator lead (A) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 32-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Front Passenger's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 89

Scheme 90

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-1x or 32-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the front passenger's side airbag (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-1 x or 32-2x indicated? YES - Go to step 9 . NO - Open in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be 1.0 ohms or less. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 32-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300
3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 91

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-3x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the front passenger's side airbag (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-3x indicated? YES - Go to step 9 . NO - Short to another wire in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 oh page 24-23).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Connect the SRS short canceller (070AZ-SAA0100) to the No. 19 and No. 20 terminals of SRS unit connector B (28P) (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__opening-the-srs-unit-shorting-connectors) ).
14. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the SRS wire harness; replace the SRS wire harness.

DTC 32-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 92

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the front passenger's side airbag (B).
5. Connect the SRS inflator simulator (2 0, connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-8x indicated? YES - Go to step 9 . NO - Short to power in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the voltage between each terminal of the black SRS simulator lead (A) and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 32-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Side Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 93

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-9x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the SRS wire harness 2P connector (A) from the front passenger's side airbag (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-91 indicated? YES - Go to step 9 . NO - Short to ground in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between each terminal of the black SRS simulator lead (A) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 33-1x ("x" can be 0 thru 9 or A thru F): Open in Left Side Curtain Airbag Inflator; DTC 33-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 94

Scheme 95

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-1 x or 33-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the left side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the left side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-1 x or 33-2x indicated? YES - Go to step 9 . NO - Open in the left side curtain airbag; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be 1.0 ohms or less. Is the resistance as specified? YES - Faulty SRS unit or poor connection at the SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 33-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300
3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedure (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 96

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-3x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the left side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the left side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-31 indicated? YES - Go to step 9 . NO - Short to another wire in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Connect the SRS short canceller (070AZ-SAA0100) to the No. 21 and No. 22 terminals of SRS unit connector B (28P) (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__opening-the-srs-unit-shorting-connectors) ).
14. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to another wire in the SRS wire harness; replace the SRS wire harness.

DTC 33-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 97

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the left side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the left side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 0, connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-8x indicated? YES - Go to step 9 . NO - Short to power in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect the SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the voltage between each terminal of the black SRS simulator lead (A) and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 33-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 98

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-9x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the left side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the left side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-9x indicated? YES - Go to step 9 . NO - Short to ground in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0).Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between each terminal of the black SRS simulator lead (A) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 34-1 x ("x" can be 0 thru 9 or A thru F): Open in Right Side Curtain Airbag Inflator; DTC 34-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 99

Scheme 100

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-1 x or 34-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the right side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the right side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-1x or 34-2x indicated? YES - Go to step 9 . NO - Open in the right side curtain airbag inflator, replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be 1.0 ohms or less. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 34-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300
3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 101

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-3x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the right side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the right side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-31 indicated? YES - Go to step 9 . NO - Short to another wire in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Connect the SRS short canceller (070AZ-SAA0100) to the No. 23 and No. 24 terminals of SRS unit connector B (28P) (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__opening-the-srs-unit-shorting-connectors) ).
14. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short in the SRS wire harness; replace the SRS wire harness.

DTC 34-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 102

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-8x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the right side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the right side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-8x indicated? YES - Go to step 9 . NO - Short to power in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch ON (II).
15. Measure the for voltage between each terminal of the black SRS simulator lead (A) and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness; replace the SRS wire harness.

DTC 34-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 103

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-9x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Remove the right side quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ), then disconnect the SRS wire harness 2P connector (A) from the right side curtain airbag connector (B).
5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead L to the SRS wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-9x indicated? YES - Go to step 9 . NO - Short to ground in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the SRS wire harness 2P connector.
13. Measure the resistance between each terminal of the black SRS simulator lead (A) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness; replace the SRS wire harness.

DTC 41-1x ("x" can be 0 thru 9 or A thru F): No Signal from the Left Front Impact Sensor

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 41-1x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the negative cable from the battery, then wait for 3 minutes.
5. Check the connections between SRS unit connector A (28P) and the SRS unit, between the engine compartment wire harness 2P connector and the left front impact sensor (see «COMPONENT LOCATION INDEX»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ), and at connector C205 (see «ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__engine-compartment-wire-harness-left-branch) ). Are the connections OK ? YES - Go to step 6 . NO - Repair the poor connections and retest. If DTC 41-1x is still present, go to step 6 .
6. Disconnect the engine compartment wire harness 2P connector (A) from the left front impact sensor.
7. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
8. Measure the resistance between the No. 15 and No. 27 terminals of SRS unit connector A (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 9 . NO - Short in the engine compartment wire harness or dashboard wire harness; replace the faulty harness.
9. Measure the resistance between the No. 15 terminal of SRS unit connector A (28P) and body ground, and between the No. 27 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 10 . NO - Short to ground in the dashboard wire harness or the engine compartment wire harness; replace the faulty harness.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch ON (II).
12. Measure the for voltage between the No. 15 terminal of SRS unit connector A (28P) and body ground, and between the No. 27 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Go to step 13 . NO - Short to power in the engine compartment wire harness or the dashboard wire harness; replace the faulty harness.
13. Turn the ignition switch to LOCK (0).
14. Connect the SRS inflator simulator (jumper connector) and the black lead (A) of simulator lead L to the engine compartment wire harness 2P connector (B).
15. Measure the resistance between the No. 15 and No. 27 terminals of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES - Faulty left front impact sensor or SRS unit; replace the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Poor connection at C205, open in engine compartment wire harness, or open in dashboard wire harness. Inspect C205 (see «ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__engine-compartment-wire-harness-left-branch) ). If it is OK, replace the faulty harness.

DTC 42-1 x ("x" can be 0 thru 9 or A thru F): No Signal from the Right Front Impact Sensor

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 42-1 x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the negative cable from the battery, then wait for 3 minutes.
5. Check the connections between SRS unit connector A (28P) and the SRS unit, between the engine compartment wire harness 2P connector and the right front impact sensor (see «COMPONENT LOCATION INDEX»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ), and at connector C303 (see «ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__engine-compartment-wire-harness-right-branch) ). Are the connections OK? YES - Go to step 6 . NO - Repair the poor connections and retest. If DTC 42-1x is still present, go to step 6 .
6. Disconnect the engine compartment wire harness 2P connector (A) from the right front impact sensor.
7. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
8. Measure the resistance between the No. 16 and No. 28 terminals of SRS unit connector A (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 9 . NO - Short in the engine compartment wire harness or dashboard wire harness; replace the faulty harness.
9. Measure the resistance between the No. 16 terminal of SRS unit connector A (28P) and body ground, and between the No. 28 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 10 . NO - Short to ground in the dashboard wire harness or the engine compartment wire harness; replace the faulty harness.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch ON (II).
12. Measure the for voltage between the No. 16 terminal of SRS unit connector A (28P) and body ground, and between the No. 28 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Go to step 13 . NO - Short to power in the engine compartment wire harness or dashboard wire harness; replace the faulty harness.
13. Turn the ignition switch to LOCK (0).
14. Connect the SRS inflator simulator (jumper connector) and the black lead (A) of simulator lead L to the engine compartment wire harness 2P connector (B).
15. Measure the resistance between the No. 16 and No. 28 terminals of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified ? YES - Faulty right front impact sensor or SRS unit; replace the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Poor connection at C303, open in engine compartment wire harness, or open in dashboard wire harness. Inspect C303 (see «ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__engine-compartment-wire-harness-right-branch) ). If it is OK, replace the faulty harness.

DTC 41-2x, 41-8x, 41 -9x, 41-Ax, 41-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Front Impact Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is 41-2x, 41-8x, 41-9x, 41-Ax, 41-Bx indicated? YES - Replace the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 42-2x, 42-8x, 42-9x, 42-Ax, 42-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Front Impact Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is 42-2x, 42-8x,42-9x, 42-Ax, 42-Bx indicated? YES - Replace the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 43-1x ("x" can be 0 thru 9 or A thru F): No Signal from the Left Side Impact Sensor (first)

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 43-1 x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the negative cable from the battery, then wait for 3 minutes.
5. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
6. Disconnect the SRS main harness 4P connector (A) from the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
7. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
8. Measure the resistance between the No. 25 and No. 26 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 9 . NO - Short in the SRS wire harness; replace the SRS wire harness.
9. Measure the resistance between the No. 25 terminal of SRS unit connector B (28P) and body ground, and between the No. 26 terminal and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES - Go to step 10 . NO - Short to ground in the SRS wire harness; replace the SRS wire harness.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch ON (II).
12. Measure the for voltage between the No. 25 terminal of SRS unit connector B (28P) and body ground, and between the No. 26 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Go to step 13 . NO - Short to power in the SRS wire harness; replace the SRS wire harness.
13. Turn the ignition switch to LOCK (0).
14. Connect the SRS inflator simulator (jumper connector) and the black lead (A) of simulator lead L to the left side impact sensor 4P connector (B).
15. Measure the resistance between the No. 25 and No. 26 terminals of SRS unit connector B (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES - Faulty left side impact sensor (first) or SRS unit; replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 44-1x ("x" can be 0 thru 9 or A thru F): No Signal from the Right Side Impact Sensor (first)

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and wait for 10 seconds.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 44-1 x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait for 3 minutes.
6. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
7. Disconnect the SRS wire harness 4P connector (A) from the right side impact sensor (first) (see step 2 ).
8. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
9. Measure the resistance between the No. 27 and No. 28 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 10 . NO - Short in the SRS wire harness; replace the SRS wire harness.
10. Measure the resistance between the No. 28 terminal of SRS unit connector B (28P) and body ground, and between the No. 27 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 11 . NO - Short to ground in the SRS wire harness; replace the SRS wire harness.
11. Reconnect the negative cable to the battery.
12. Turn the ignition switch ON (II).
13. Measure the voltage between the No. 28 terminal of SRS unit connector B (28P) and body ground, and between the No. 27 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Go to step 14 . NO - Short to power in the SRS wire harness; replace the SRS wire harness.
14. Turn the ignition switch to LOCK (0).
15. Connect the SRS inflator simulator (jumper connector) and the black lead (A) of simulator lead L to the right side impact sensor 4P connector (B).
16. Measure the resistance between the No. 27 and No. 28 terminals of SRS unit connector B (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES - Faulty right side impact sensor (first) or SRS unit; replace the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 43-2x, 43-8x, 43-9x, 43-Ax, 43-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Side Impact Sensor (first)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 43-2x, 43-8x, 43-9x, 43-Ax, or 43-Bx indicated? YES - Replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 44-2x, 44-8x, 44-9x, 44-Ax, 44-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Side Impact Sensor (first)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 44-2x, 44-8x, 44-9x, 44-Ax, or 44-Bx indicated? YES - Replace the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 45-1 x ("x" can be 0 thru 9 or A thru F): No Signal from the Left Side Impact Sensor (second)

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and wait for 10 seconds.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 45-1x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Read the DTC. Is DTC 43-1x also indicated? YES - Faulty left side impact sensor (second); replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. Disconnect the negative cable from the battery, then wait for 3 minutes.
7. Disconnect SRS wire harness 4P connector (A) from the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
8. Disconnect the SRS wire harness 4P connector (A) from the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
9. Measure the resistance between the No. 1 and No. 2 terminals of left side impact sensor (second) 2P connector. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 10 . NO - Short in the SRS wire harness; replace the SRS wire harness.
10. Measure the resistance between the No. 1 terminal of left side impact sensor (second) 2P connector and body ground, and between the No. 2 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 11 . NO - Short to ground in the SRS wire harness; replace the SRS wire harness.
11. Reconnect the negative cable to the battery.
12. Turn the ignition switch ON (II).
13. Measure the for voltage between the No. 1 terminal of left side impact sensor (second) 2P connector and body ground, and between the No. 2 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Go to step 14 . NO - Short to power in the SRS wire harness; replace the SRS wire harness.
14. Turn the ignition switch to LOCK (0).
15. Connect the SRS inflator simulator (jumper connector) and red lead (A) of simulator lead L to the left side impact sensor (first) 2P connector (B).
16. Measure the resistance between the No. 1 and No. 2 terminals of left side impact sensor (second) 2P connector. There should be 0-1.0 ohms. Is the resistance as specified? YES - Faulty left side impact sensor (second) or poor connection at left side impact sensor (second) 2P connector. Check the connection; If the connection is OK, replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 46-1x ("x" can be 0 thru 9 or A thru F): No Signal from the Right Side Impact Sensor (second)

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and wait for 10 seconds.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 46- 1x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait for 3 minutes.
6. Disconnect the SRS wire harness 2P connector (A) from the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
7. Disconnect the SRS wire harness 4P connector (A) from the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
8. Measure the resistance between the No. 1 and No. 2 terminals of right side impact sensor (second) 2P connector. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 9 . NO - Short in the SRS wire harness; replace the SRS wire harness.
9. Measure the resistance between the No. 1 terminal of right side impact sensor (second) 2P connector and body ground, and between the No. 2 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 10 . NO - Short to ground in the SRS wire harness; replace the SRS wire harness.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch ON (II).
12. Measure the voltage between the No. 1 terminal of right side impact sensor (second) 2P connector and body ground, and between the No. 2 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Go to step 13 . NO - Short to power in the SRS wire harness; replace the SRS wire harness.
13. Turn the ignition switch to LOCK (0).
14. Connect the SRS inflator simulator (jumper connector) and the red lead (A) of simulator lead L to the right side impact sensor (first) 4P connector (B).
15. Measure the resistance between the No. 1 and No. 2 terminals of right side impact sensor (second) 2P connector. There should be 0-1.0 ohms. Is the resistance as specified? YES - Faulty right side impact sensor (second) or poor connection at right side impact sensor (second) 2P connector. Check the connection; If the connection is OK, replace the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC 45-2x, 45-8X, 45-9x, 45-Ax, 45-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Side Impact Sensor (second)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 45-2x, 45-8x, 45-9x, 45-Ax, or 45-Bx indicated? YES - Replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 46-2x, 46-8x, 46-9x, 46-Ax, 46-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Side Impact Sensor (second)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 46-2x, 46-8x, 46-9x, 46-Ax, or 46-Bx indicated? YES - Replace the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 51-xx, 52-xx, 53-xx, 54-xx, 55-xx, 57-xx ("x" can be 0 thru 9 or A thru F): Internal Failure of the SRS unit

Note. Before troubleshooting any of these DTCs, check the battery/system voltage, if the voltage is low, repair the charging system or replace the battery before troubleshooting the SRS. If the battery/system voltage is now OK, ask the customer if the battery ever went dead. A dead battery may trigger one of these DTCs. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is 51-xx, 52-xx, 53-xx, 54-xx, 55-xx, or 57-xx indicated? YES - Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC Ex-xx ("x" can be 0 thru 9 or A thru F): Control Operation Recorded; DTC Fx-xx ("x" can be 0 thru 9 or A thru F): Airbags and/or Tensioners Deployment Recorded

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ). DTC E2-11: Front passenger's airbag did not deploy by SWS operation. DTC E4-11: Front left side airbag did not deploy by OPDS operation. DTC F1-11: Driver's airbag and/or driver's seat belt tensioner deployed. DTC F2-11: Front passenger's airbag and/or front passenger's seat belt tensioner deployed. DTC F3-11: Driver's side airbag, left side curtain airbag, and/or driver's seat belt tensioner deployed. DTC F4-11: Front passenger's side airbag, right side curtain airbag, and/or front passenger's seat belt tensioner deployed. DTC F5-11: Both or only one side curtain airbag, seat belt tensioner, and seat belt buckle tensioner deployed. DTC F6-11: Left side curtain airbag or right side curtain airbag deployed.

The SRS unit must be replaced after any airbags and/or tensioners have deployed (see AIRBAG AND TENSIONER DISPOSAL ).

Note. DTC E2-11 is set if the system triggered airbag deployment but the front passenger's airbag was prevented from deploying because of the seat weight sensor. DTC E4-11 is set if the system triggered passenger's side airbag deployment but the airbag was prevented from deploying by the ODS. Replace the right side impact sensor (see SIDE IMPACT SENSOR (FIRST) REPLACEMENT ).

DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), then buckle and unbuckle the driver's seat belt several times.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 61-1x indicated? YES - Go to step 4 . NO - intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. From the system selection menu on the HDS select SRS, then select SRS again, then select PARAMETER INFORMATION, then Buckle Switch, Seat Position Sensor and check the status on the HDS screen for FRONT LEFT SEAT BELT BUCKLE SWITCH. If UNBUCKLED is indicated only when the driver's seat belt is buckled, go to step 5 . If BUCKLED is indicated only when the driver's seat belt is unbuckled, go to step 12 . If OPEN is indicated only when the driver's seat belt is buckled and unbuckled, go to step 20 .
5. Turn the ignition switch to LOCK (0).
6. Disconnect the driver's seat wire harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
7. Buckle the driver's seat belt. Check resistance between the No. 1 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES - Go to step 8 . NO - Replace the driver's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then clear the DTC.
8. Disconnect the negative cable from the battery, then wait for 3 minutes.
9. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
10. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
11. Measure the resistance between the No. 12 terminal of SRS unit connector B (28P) and the No. 1 terminal of the driver's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness, driver's seat wire harness or poor connection at C701 (see «SRS WIRE HARNESS (LEFT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-left-branch) ). Check the connection; if the connection is OK, replace the faulty harness.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the driver's seat wire harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
14. Unbuckle the driver's seat belt.
15. Measure the resistance between the No. 2 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES - Go to step 16 . NO - Replace the driver's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then erase the DTC.
16. Disconnect the negative cable from the battery, then wait for 3 minutes.
17. Disconnect the seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
18. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
19. Measure the resistance between the No. 11 terminal of SRS unit connector B (28P) and the No. 2 terminal of the driver's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness, driver's seat wire harness or poor connection at C701 (see «SRS WIRE HARNESS (LEFT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-left-branch) ). Check the connection; if the connection is OK, replace the faulty harness.
20. Turn the ignition switch to LOCK (0).
21. Disconnect the driver's seat wire harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
22. Unbuckle the driver's seat belt.
23. Measure the resistance between the No. 3 terminal of the driver's power seat wire harness 3P connector and body ground. There should be 0-1 . Is the resistance as specified? YES - Replace the driver's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then clear the DTC. NO - Open in the SRS wire harness or poor connection at C701 (see «SRS WIRE HARNESS (LEFT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-left-branch) ). Check the connection; if the connection is OK, replace the driver's sear wire harness or poor ground connection at G551 (see «SRS WIRE HARNESS (LEFT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-left-branch) ). If G551 is OK, replace the faulty harness.

DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 148

Scheme 149

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), then buckle and unbuckle the driver's seat belt several times.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 61-2x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the driver's seat wire harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
6. Turn the ignition switch ON (II).
7. From the system selection menu on the HDS, select SRS, then select SRS again, then select PARAMETER INFORMATION, then Buckle Switch, Seat Position Sensor and check the status on the HDS screen for FRONT LEFT SEAT BELT BUCKLE SWITCH. Is OPEN indicated on the HDS? YES - Replace the driver's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then erase the DTC. NO - Go to step 8 .
8. Turn the ignition switch to LOCK (0).
9. Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect the seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connector (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Measure the resistance between the No. 1 terminal of the driver's seat wire harness 3P connector and body ground. There should be an open circuit or at lest 1 Mohms. Is the resistance as specified? YES - Go to step 13 . NO - Short to ground in the SRS main harness or driver's seat wire harness; replace the faulty harness.
13. Measure the resistance between the No. 2 terminals of the driver's seat wire harness 3P connector and body ground. There should be an open circuit or at least 1 Mohms. Is there continuity? YES - Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the driver's seat wire harness; replace the driver's seat wire harness.

DTC 62-1 x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), then buckle and unbuckle the front passenger's seat belt several times.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 62-1x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. From the system selection menu on the HDS, select SRS, then select SRS again, then select PARAMETER INFORMATION, then Buckle Switch, Seat Position Sensor and check the status on the HDS screen for FRONT RIGHT SEAT BELT BUCKLE SWITCH. If UNBUCKLED is indicated only when the front passenger's seat belt is buckled, go to step 5 . If BUCKLED is indicated only when the front passenger's seat belt is unbuckled, go to step 12 . If OPEN is indicated only when the front passenger's seat belt is buckled and unbuckled, go to step 20 .
5. Turn the ignition switch to LOCK (0).
6. Disconnect the ODS unit harness 3P connector from the front passenger's seat belt buckle switch 3P connector (A).
7. Buckle the front passenger's seat belt. Check resistance between the No. 1 and No. 3 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Is the resistances specified? YES - Go to step 8 . NO - Replace the front passenger's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then erase the DTC.
8. Disconnect the negative cable from the battery, then wait for 3 minutes.
9. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
10. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
11. Measure the resistance between the No. 16 terminal of SRS unit connector B (28P) and the No. 1 terminal of the ODS unit harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). IMO-Open in the SRS wire harness, ODS unit harness or poor connection at C703. Check the connection; if the connection is OK, replace the faulty harness.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the ODS unit harness 3P connector from the front passenger's seat belt buckle switch 3P connector (A).
14. Unbuckle the front passenger's seat belt.
15. Measure the resistance between the No. 2 and No. 3 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES - Go to step 16 . NO - Replace the front passenger's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then clear the DTC.
16. Disconnect the negative cable from the battery, then wait for 3 minutes.
17. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
18. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
19. Measure the resistance between the No. 15 terminal of SRS unit connector B (28P) and the No. 2 terminal of the ODS unit harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES - Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness, ODS unit harness or poor connection at C703. Check the connection; if the connection is OK, replace the faulty harness.
20. Turn the ignition switch to LOCK (0).
21. Disconnect the ODS unit harness 3P connector from the front passenger's seat belt buckle switch 3P connector (A).
22. Unbuckle the front passenger's seat belt.
23. Measure the resistance between the No. 3 terminal of the ODS unit harness 3P connector and body ground. There should be 0-1 ohms. Is the resistance as specified? YES - Replace the front passenger's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then clear the DTC. NO - Open in the SRS wire harness, ODS unit harness, poor connection at C703 and poor ground connection at G552 (see «SRS WIRE HARNESS (RIGHT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-right-branch) ). C703 and G552 connection is OK, replace the faulty harness.

DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in Front Passenger's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 156

Scheme 157

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), then buckle and unbuckle the front passenger's seat belt several times.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 62-2x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the ODS unit harness 3P connector from the front passenger's seat belt buckle switch 3P connector (A).
6. Turn the ignition switch ON (II).
7. From the system selection menu on the HDS, select SRS, then select SRS again, then select PARAMETER INFORMATION, then Buckle Switch, Seat Position Sensor and check the status on the HDS screen for FRONT RIGHT SEAT BELT BUCKLE SWITCH. Is OPEN indicated on the HDS? YES - Replace the front passenger's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), then clear the DTC. NO - Go to step 8 .
8. Turn the ignition switch to LOCK (0).
9. Disconnect the negative cable from the battery, then wait for 3 minutes.
10. Disconnect both seat belt tensioner 4P connectors (see step 10 ) and both seat belt buckle tensioner 4P connectors (see step 11 ).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
12. Measure the resistance between the No. 1 terminal of the ODS unit harness 3P connector and body ground. There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES - Go to step 13 . NO - Short to ground in the SRS wire harness or ODS unit harness; replace the faulty harness.
13. Measure the resistance between the No. 2 terminal of the ODS unit harness 3P connector and body ground. There should be an open circuit or at least 1 Mohms. Is there continuity? YES - Faulty SRS unit; Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness or ODS unit harness; replace the faulty harness.

DTC 71-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Position Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 158

Scheme 159

Scheme 160

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 71-1x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Check the connection between the driver's seat wire harness 2P connector and the driver's seat position sensor (see «COMPONENT LOCATION INDEX»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
4. Clear the DTC memory.
5. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 71-1x indicated? YES - Go to step 6 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
6. Turn the ignition switch to LOCK (0).. Disconnect the negative cable from the battery, then wait for 3 minutes.
7. Disconnect the driver's seat wire harness 2P connector from the driver's seat position sensor (A).
8. Connect the No. 1 and No. 2 terminals of the driver's seat wire harness 2P connector with a jumper wire.
9. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
10. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
11. Measure the resistance between the No. 5 and No. 6 terminals of SRS unit connector B (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES - Faulty driver's seat position sensor or SRS unit; replace the driver's seat position sensor (see «DRIVER'S SEAT POSITION SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness or the driver's seat wire harness; replace the faulty harness.

DTC 71-21: Short in Driver's Seat Position Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 161

Scheme 162

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 71-21 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the driver's seat wire harness 2P connector from the driver's seat position sensor (A) (see «COMPONENT LOCATION INDEX»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
5. Reconnect the negative cable to the battery.
6. Clear the DTC memory.
7. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 71-21 indicated? YES - Go to step 8 . NO - Faulty driver's seat position sensor; replace the driver's seat position sensor (see «DRIVER'S SEAT POSITION SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
8. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
9. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
10. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
11. Measure the resistance between the No. 5 and No. 6 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 12 . NO - Short in the SRS wire harness or the driver's seat wire harness; replace the faulty harness.
12. Measure the resistance between the No. 5 terminal of SRS unit connector B (28P) and body ground, and between the No. 6 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Faulty driver's seat position sensor or the SRS unit; replace the driver's seat position sensor (see «DRIVER'S SEAT POSITION SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the SRS wire harness or the drivers seat wire harness; replace the faulty harness.

DTC 71-22: Short to Power in Driver's Seat Position Sensor

Note. Use the HDS to confirm the driver's seat position before proceeding with troubleshooting (see DRIVER'S SEAT POSITION SENSOR OPERATION CHECK ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 163

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 71-22 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Disconnect the driver's seat wire harness 2P connector from the driver's seat position sensor (A).
5. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
6. Disconnect SRS unit connector B (28P) from the SRS unit (see step 14 ).
7. Measure the voltage between the No. 5 terminal of SRS unit connector B (28P) and body ground, and between the No. 6 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Faulty driver's seat position sensor or SRS unit; replace the driver's seat position sensor (see «DRIVER'S SEAT POSITION SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the SRS wire harness or the driver's seat wire harness; replace the faulty harness.

DTC 81-61,85-61: No Signal from ODS Unit; DTC 81-62,85-62: Response Data Error from the ODS Unit

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

1. Make sure nothing is on the front passenger's seat.
2. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 81-61, 85-61, 81-62, or 85-62 indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Check the connection between the ODS unit harness 18P connector and the ODS unit (see step 4 ). Is the connection OK? YES - Go to step 5 . NO - Repair the poor connection and retest. If DTC 81-61, 81-62, 85-61, or 85-62 is still present, go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. Check the No. 9 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES - Go to step 7 . NO - Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short in the No. 9 (7.5 A) fuse circuit (dashboard wire harness, SRS wire harness, or ODS unit harness).
7. Disconnect the ODS unit harness 18P connector (A) from the ODS unit.
8. Turn the ignition switch ON (II).
9. Measure the voltage between the No. 1 terminal of the ODS unit harness 18P connector and body ground. There should be battery voltage. Is there battery voltage? YES - Go to step 10 . NO - Open in the dashboard harness, SRS wire harness, or ODS unit harness; Check for poor connection at C405 and C703 (see «SRS WIRE HARNESS (RIGHT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-right-branch) ). If connection is OK, replace the faulty harness.
10. Turn the ignition switch to LOCK (0).
11. Measure the resistance between the No. 12 terminal of the ODS unit harness 18P connector and body ground. There should be 0-1.0 ohms. Is the resistance as specified? YES - Go to step 12 . NO - Open in the SRS wire harness, ODS unit harness or poor ground connection at G552 (see «SRS WIRE HARNESS (RIGHT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-right-branch) ). If G552 is OK, replace the faulty harness.
12. turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
13. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
14. Measure the resistance between the No. 14 terminal of SRS unit connector A (28P) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 15 . NO - Short to ground in the dashboard wire harness, SRS main harness, or ODS unit harness '07- 08 models),or front passenger's seat wire harness ('09 model); replace the faulty harness.
15. Turn the ignition switch ON (II), and measure the voltage between the No. 14 terminal of SRS unit connector A (28P) and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Go to step 16 . NO - Short to power in the dashboard wire harness, floor wire harness, front passenger's seat subharness, or ODS unit harness; replace the faulty harness.
16. Measure the resistance between the No. 14 terminal of SRS unit connector A (28P) and the No. 7 terminal of the ODS unit harness 18P connector. There should be 0-1.0 ohms. Is the resistance as specified? YES - Faulty ODS unit or SRS unit; replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the dashboard wire harness, SRS wire harness or ODS unit harness. Check for poor connection at C405 and C703 (see «SRS WIRE HARNESS (RIGHT BRANCH)»(/acura/rdx/i-2006-2009/remont/body-electrical/#connectors-and-harnesses__srs-wire-harness-right-branch) ). If the connection is OK, replace the faulty harness.

DTC 81-71,81-78: ODS Unit Does Not Calibrate - DTC 85-71,85-78: ODS Unit Not Initialized

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ) and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is 81-71, 81-78 , 85-71 or 85-78 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Calibrate the ODS unit (see «ODS UNIT CALIBRATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-calibration) ) or initialize the ODS unit (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
4. Turn the ignition switch to LOCK (0), then wait for 10 seconds.
5. Turn the ignition switch to ON (II), then wait for 10 seconds. (see «ODS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
6. Read DTC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). Does the SRS indicator stay on, and is 81-71, 81-78 , 85-71 or 85-78 indicated? YES - Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) . If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. GO to Troubleshooting Intermittent Failures (see «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) ). If another DTC is indicated , troubleshoot the DTC.

DTC 81-4x, 81-63,81-64 ("x" can be 0 thru 9 or A thru F): Internal Failure of the ODS Unit (SWS)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 81-4x, 81-63, or 81-64 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Initialize the ODS unit (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
4. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES - The symptom is OK at this time. NO - Go to step 5 .
5. Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
6. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES - The symptom is OK. NO - Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).

DTC 81-79: Front Passenger's Weight Sensors Initial Check Failure

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 81-79 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0).
4. Make sure nothing is on the front passenger's seat.
5. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES - The system is OK. NO - Remove the front passenger's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ) and the front passenger's weight sensors (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ), then reinstall them. Calibrate the ODS unit (see «ODS UNIT CALIBRATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-calibration) ). Retry the troubleshooting. If DTC 81-79 is still present, replace the front passenger's weight sensors.

DTC 82-1x ("x" can be 0 thru 9 or A thru F): No Signal from the Inner Side Front Passenger's Weight Sensor; DTC 83-2x ("x" can be 0 thru 9 or A thru F): No Signal from the Outer Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 82-1 x indicated? YES - Replace the inner outer side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 85-4x, 85-64 ("x" can be 0 thru 9 or A thru F): Internal Failure of the ODS Unit; DTC 85-63: ECU (ODS Unit) Serial ID Code Inconsistent/Internal Failure of the ODS Unit

Note. An incorrect ODS unit can cause DTC 85-63. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 85-4x, 85-63, or 85-64 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Initialize the ODS unit (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
4. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES - The system is OK. NO - Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ) and retest. If the problem is still present, replace the OPDS sensor/seat-back (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-back-coverpad-replacement) ).

DTC 85-79: OPDS Sensor Initial Check Failure

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 85-79 indicated? YES - Turn the ignition switch to LOCK (0), and go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Make sure nothing is on the front passenger's seat.
4. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES - The system is OK. NO - Go to step 5 .
5. Initialize the ODS unit (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
6. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES - The system is OK. NO - Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ) and retest. If the problem is still present, replace the OPDS sensor/seat-back (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-back-coverpad-replacement) ).

DTC 86-1x, 86-2x ("x" can be 0 thru 9 or A thru F): Faulty OPDS Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 170

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 86-1x or 86-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC. NOTE: Aftermarket devices (fluorescent lights, laptop computers, etc.) used near the front passenger's seat-back can interfere with the seat-back sensors and cause a false DTC 86-1x or 86-2x. If one of these devices was used, erase the DTC, operate the device near the seat-back, and recheck for DTCs. If DTC 8G-1x or 86-2x is set, erase it, and do not use the device near the seat-back.
3. Check the connection at the OPDS sensor harness connectors (A) and the ODS unit connector (B). Is the connection OK? YES - Go to step 4 . NO - Repair the poor connection, and clear the DTC.
4. Replace the OPDS sensor/seat-back foam (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-back-coverpad-replacement) ), and initialize the ODS (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
5. Clear the DTC memory, then check for DTC 86-1x or 86-2x. Is DTC 86-1 x or 86-2x indicated? YES - Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - The system is OK.

DTC 92-1x ("x" can be 0 thru 9 or A thru F): Open in Passenger's Airbag Cutoff Indicator

Note. Information marked with an asterisk ( *) applies to models with the navigation system. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 171

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 92-1x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Disconnect audio display panel 20P connector A, or navigation switch panel 6P connector B (see «CENTER PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__center-panel-removalinstallation) ).
4. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
5. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
6. Reconnect the negative cable to the battery.
7. Turn the ignition switch ON (II).
8. Measure the voltage between the No. 13 terminal of SRS unit connector A (28P) and body ground. There should be 0.5 V or less. Is the voltage as specified? YES - Faulty SRS unit or passenger's airbag cutoff indicator; replace the passenger's airbag cutoff indicator. If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to power in the dashboard wire harness; replace the dashboard wire harness.

DTC 92-2x ("x" can be 0 thru 9 or A thru F): Open or Short to Ground in Passenger's Airbag Cutoff Indicator

Note. Information marked with an asterisk ( *) applies to models with the navigation system. Before doing this troubleshooting procedure, review. SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ) and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 172

Scheme 173

Scheme 174

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and DTC 92-2x indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Disconnect audio display panel 20P connector A, or 'navigation switch panel 6P connector B (see «CENTER PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__center-panel-removalinstallation) ).
4. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
5. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
6. Measure the resistance between the No. 1 * or No. 17 terminal of the switch panel 6P* or 20P connector and the No. 13 terminal of SRS unit connector A (28P). There should be 0-1.0 ohms. With NAVI Without NAVI Is the resistance as specified? YES - Go to step 7 . NO - Open in the dashboard wire harness; replace the dashboard wire harness.
7. Measure the resistance between the No. 13 terminal of the SRS unit connector A (28P) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Replace the passenger's airbag cutoff indicator. If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Short to ground in the dashboard wire harness; replace the dashboard wire harness.

DTC A1-1x ("x" can be 0 thru 9 or A thru F): Faulty Power Supply (VA Line)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ) and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 175

Scheme 176

Scheme 177

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC A1- 1x indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Check the No. 9 (7.5 A) fuse in the under-dash fuse/ relay box. Is the fuse OK? YES - Go to step 6 . NO - Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short in the No. 9 (7.5 A) fuse circuit (dashboard wire harness, SRS wire harness, or ODS unit harness).
6. Disconnect the negative cable from the battery, then wait for 3 minutes.
7. Disconnect the SRS unit connector A (28P) from the SRS unit (see step 14 ).
8. Reconnect the negative cable to the battery.
9. Connect a voltmeter between the No. 17 terminal of SRS unit connector A (28P) and body ground. Turn the ignition switch ON (II), and measure the voltage. There should be battery voltage when the ignition is on. Is there battery voltage? YES - Faulty SRS unit or poor connection at SRS unit connector (A) 28P and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Go to step 10 .
10. Turn the ignition switch to LOCK (0).
11. Disconnect under-dash fuse/relay box connector O (4P).
12. Measure the resistance between the No. 4 terminal of under-dash fuse/relay box connector O (4P) and the No. 17 terminal of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES - Open in the under-dash fuse/relay box or poor contact between connector O (4P) and the under-dash fuse/relay box; check the connection. If the connection is OK, replace the under-dash fuse/ relay box (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-dash-fuserelay-box__removal-and-installation) ). NO - Open in the dashboard wire harness; replace the dashboard wire harness.

DTC A2-1x ("x" can be 0 thru 9 or A thru F): Faulty Power Supply (VB Line)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 178

Scheme 179

Scheme 180

1. Clear the No. 11 (10 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES - Go to step 2 . NO - Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a Short to ground in the dashboard wire harness or in the under-dash fuse/relay box No. 11 (10 A) fuse circuit; replace the dashboard wire harness. If the problem is still there, replace the under-dash fuse/ relay box (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-dash-fuserelay-box__removal-and-installation) ).
2. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
3. Disconnect SRS unit connector A (28P) from the SRS unit (see step 14 ).
4. Reconnect the negative cable to the battery.
5. Connect a voltmeter between the No. 18 terminal of SRS unit connector A (28P) and body ground. Turn the ignition switch ON (II), and measure the voltage. There should be battery voltage when the ignition on. Is there battery voltage? YES - Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit; check the connection. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Go to step 6 . 6. Turn the ignition switch to LOCK (0).
6. Turn the ignition switch to LOCK (0).
7. Disconnect under-dash fuse/relay box connector O (4P).
8. Measure the resistance between the No. 1 terminal of the under-dash fuse/relay box connector O (4P) and the No. 18 terminal of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES - Open in the under-dash fuse/relay box or poor connection between connector O (4P) and the under-dash fuse/relay box; check the connection. If the connection is OK, replace the under-dash fuse/ relay box (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-dash-fuserelay-box__removal-and-installation) ). NO - Open in the dashboard wire harness; replace the dashboard wire harness.

DTC B1-1x ("x" can be 0 thru 9 or A thru F): No Signal from the Roll Rate Sensor

Special Tools Required

1. SRS inflator simulator 07SAZ-TB4011A
2. SRS simulator lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC B1-11 indicated? YES - Go to step 3 . NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait for 3 minutes.
4. Check the connections between the SRS wire harness 2P connector and the roll rate sensor (see «COMPONENT LOCATION INDEX»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). Is the connection OK? YES - Go to step 5 . NO - Repair the poor connection and retest. If the DTC B1-11 is still present, go to step 5 .
5. Disconnect the SRS wire harness 2P connector (A) from the roll rate sensor.
6. Disconnect SRS unit connector C (28P) from the SRS unit (see step 14 ).
7. Measure the resistance between the No. 4 and No. 8 terminals of SRS unit connector C (16P). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 8 . NO - Short in the SRS wire harness; replace the SRS wire harness.
8. Measure the resistance between the No. 4 terminal of SRS unit connector C (16P) and body ground, and between the No. 8 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES - Go to step 9 . NO - Short to ground in the SRS wire harness; replace the SRS wire harness.
9. Reconnect the battery negative cable.
10. Turn the ignition switch ON (II).
11. Measure the for voltage between the No. 4 terminal of SRS unit connector C (16P) and body ground, and between the No. 8 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES - Go to step 12 . NO - Short to power in the SRS wire harness; replace the SRS wire harness.
12. Turn the ignition switch to LOCK (0).
13. Connect the SRS inflator simulator (jumper connector) and the black lead (A) of simulator lead L to the SRS wire harness 2P connector (B).
14. Measure the resistance between the No. 4 and No. 8 terminals of SRS unit connector C (16P). There should be 0-1.0 ohms or less. Is the resistance as specified? YES - Faulty roll rate sensor or SRS unit; replace the roll rate sensor (see «ROLL RATE SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Open in the SRS wire harness; replace the SRS wire harness.

DTC B1-2x, B1-8x, B1-9x, BI-Ax, BI-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Roll Rate Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION )and Battery Terminal disconnection and Reconnection (see BATTERY TERMINAL DISCONNECTION AND RECONNECTION ).

1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is B1-2x, B1-8x, B1-9x, B1-Ax or B1-Bx indicated? YES - Replace the roll rate sensor (see «ROLL RATE SENSOR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

SRS indicator does not come on

1. Turn the ignition switch to LOCK (0), and wait for 10 seconds. (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ).
2. Turn the ignition switch to ON (II) and Check that the SRS indicator comes on for about 6 seconds and then goes off. Does the HDS to the system is OK at this time.? YES - Intermittent failure, the system is OK at this time. NO - Go to step 3.
3. Connect the HDS to the data link connector (DLC) (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communucate , troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
5. Do the gauge control module self-diagnostic function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__self-diagnostic-function) ). Does the SRS indicator come on? YES - Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Faulty gauge control module; replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ).

SRS indicator stays on, but no DTCs are stored

Note. Before doing this troubleshooting procedure, make sure the battery is fully charged . If the battery voltage is low, SRS indicator may stay on.

1. Start the engine, and see if the malfunction indicator lamp (MIL) stays on. Does the MIL stay ON? YES - Go to the MIL Circuit Troubleshooting (see «MIL CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system) ). NO - Go to step 2.
2. Connect the HDS to the data link connector (DLC) (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
3. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit. (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
4. Select Body Electrical status with the HDS.
5. Check the DTCs in the Gauge Menu with the HDS. Is DTC B1187 indicated? YES - Go to the troubleshooting for DTC B1187 (see «DTC B1187: GAUGE CONTROL MODULE LOST COMMUNICATION WITH THE SRS UNIT (SRS MESSAGE)»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__dtc-b1187-gauge-control-module-lost) ). NO - Go to step 6.
6. Do the gauge control module self diagnostic function «SELF-DIAGNOSTIC FUNCTION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__self-diagnostic-function) ). Does the SRS indicator come on? YES - Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Faulty gauge control module; replace the gauge control module. (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ).

Side airbag cutoff indicator stays on

1. Make sure nothing is on the front passenger's seat.
2. Make sure the seat-back is dry.
3. Turn the ignition switch ON (II), and see if the SRS indicator comes on. Does the SRS indicator come on? YES - Go to the " «SRS INDICATOR STAY ON, BUT NO DTCS ARE STORED»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__srs-indicator-stays-on-but-no) ." NO - Go to step 4.
4. Connect the HDS to the DLC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ).
5. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
6. Select Body Electrical status with the HDS.
7. Check the DTCs in the Gauge Menu with the HDS. Is DTC B1187 indicated? YES - Go to the troubleshooting for DTC B1187 (see «DTC B1187: GAUGE CONTROL MODULE LOST COMMUNICATION WITH THE SRS UNIT (SRS MESSAGE)»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__dtc-b1187-gauge-control-module-lost) ). NO - Go to step 8.
8. Do the gauge control module self diagnostic function «SELF-DIAGNOSTIC FUNCTION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__self-diagnostic-function) ). Does the side airbag cutoff indicator flash? YES - Initialize the ODS unit (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ). If problem is still present, replace the OPDS sensor/seat-back: '07-08 models (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-back-coverpad-replacement) , '09 model (see «'09 MODEL»(/acura/rdx/i-2006-2009/remont/seats/#seats) . If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Faulty gauge control module; replace the gauge control module. (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ).

Side airbag cutoff indicator does not come on

Note. If the SRS indicator also stays on, go to SRS INDICATOR STAYS ON, BUT NO DTCS ARE STORED .

1. Turn the ignition to LOCK (0), and wait for 10 seconds.
2. Turn the ignition switch to ON (II), and check that the side airbag cutoff indicator comes on for about 6 seconds. Does the side airbag cutoff indicator come on? YES - Intermittent failure, the system is OK at this time. NO - Go to step 3.
3. Connect the HDS to the data link connector DLC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate ,troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
5. Do the gauge control module self diagnostic function «SELF-DIAGNOSTIC FUNCTION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__self-diagnostic-function) ). Does the side airbag cut off indicator come on? YES - Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Faulty gauge control module; replace the gauge control module. (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ).

Passenger's airbag cutoff indicator stays on or comes on suddenly

Note. Under the following conditions, the passenger's airbag cutoff indicator stays on or comes on suddenly.

1. No one is sitting the front passenger's seat, but there is an object on the seat more than 5 kg (11 lbs).
2. The seat belt is buckled, but no one is sitting on the front passenger's seat.
3. Someone who is less than 30 kg (66 lbs) is sitting on the front passenger's seat.
4. Someone who is more than 30 kg (66 lbs) but is supporting some of their body weight on their legs, feet, arms, or hands.

1. Check for these items, then recheck the passenger's airbag cutoff indicator. The front passenger's seat is/was installed correctly. Nothing is/was on the front passenger's seat. Nothing is/was under the front passenger's seat. Nothing is/was in the front passenger's seat-back pocket. Whoever was sitting on the passenger's seat was sitting in the proper sitting position. Someone who is more than 30kg (65 Ibs) but is supporting some of their body weight on their legs, feet, arms, or hands, which may be resting on the floor or an arm rest. The seat weight sensors may not sense the correct weight of the passenger. Does the passenger's airbag cutoff indicator stay on? YES - Go to step 2 . NO - Troubleshooting is complete.
2. Connect the HDS to the DLC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ).
3. Turn the ignition switch to ON (II).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
5. Select the INSPECTION menu on the HDS, then select AFTER REPLACING FRONT PASSENGER'S SEAT COMPONENT(S), and follow the prompts. Does the passenger's airbag cutoff indicator stay on? YES - Go to step 6. NO - Troubleshooting is complete.
6. Select the INSPECTION menu on the HDS, then select AFTER A VEHICLE COLISION, and follow the prompts. Does the passenger's airbag cutoff indicator stay on? YES - Faulty SRS unit, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ). NO - Troubleshooting is complete.

Component Replacement/Inspection After Deployment

Note. Before doing any SRS repairs, use the HDS SRS menu method to check for DTCs. Check the front passenger's weight sensors after a vehicle collision (see CHECKING THE FRONT PASSENGER'S WEIGHT SENSORS AFTER A VEHICLE COLLISION ). After a vehicle collision, do the ODS UNIT OPERATION CHECK . Do not replace the ODS unit unless it is physically damaged or a specific DTC was found daring troubleshooting.

After a collision where the seat belt tensioners deployed, replace these items

1. SRS unit
2. Seat belt tensioners
3. Seat belt buckle tensioners
4. Front impact sensors

After a collision where the front airbag(s) deployed, replace these items

1. SRS unit
2. Deployed airbag(s)
3. Seat belt tensioners
4. Seat belt buckle tensioners
5. Front impact sensors

After a collision where the side airbag(s) deployed, replace these items

1. SRS unit
2. Deployed side airbag(s)
3. Side impact sensor(s) (first) for the side(s) that deployed
4. Side impact sensor(s) (second) for the side(s) that deployed
5. B-pillar lower trim
6. Complete seat frame
7. Side airbag bracket

After a collision where a side curtain airbag has deployed, replace the items for the side(s) that deployed

1. SRS unit
2. Deployed side curtain airbag(s)
3. Seat belt tensioner(s)
4. Side impact sensor(s) (first)
5. Side impact sensor(s) (second)
6. Roll rate sensor
7. Roof trim
8. A-pillar trim
9. B-pillar lower trim
10. C-pillar trim
11. Front grab handle
12. Rear grab handle
13. All related trim clips
14. Sunvisor

After a moderate to severe side or rear collision, inspect for any damage on the side curtain airbag or other related components. Replace the components as needed.

Scheme 187

Scheme 188

During the repair process, inspect these areas

1. Inspect all the SRS wire harnesses. Replace, do not repair, any damaged harnesses.
2. Inspect the cable reel for heat damage. If there is any damage, replace the cable reel.

After the vehicle is completely repaired, turn the ignition switch ON (II). If the SRS indicator comes on for about 6 seconds and then goes off, the SRS is OK. If the indicator does not function properly, use the HDS SRS Menu Method to read the DTC (see DTC (DIAGNOSTIC TROUBLE CODES) ). If you cannot retrieve a code, do the SRS Symptom Troubleshooting.

Checking and Adjusting the Headliner/Pillar Trim Overlap

To prevent the side curtain airbag from deploying and damaging the pillar trim, the overlap between the headliner and pillar trim must be less then 0.3 in. (8 mm). To check the overlap, do this

Scheme 189

Scheme 190

Scheme 191

Scheme 192

1. Install the headliner (A) and the pillar trim (B).
2. Using masking tape on the headliner, mark the upper edge of each pillar trim.
3. Remove the pillar trim, and measure the headliner overlap. If the overlap is less than 0.3 in. (8 mm), remove the tape, and install the pillar trim. If the overlap is more than 0.3 in. (8 mm), go to step 4 .
4. Carefully trim the headliner with a utility knife, reducing the overlap to less than 0.3 in. (8 mm).
5. Remove the tape, and install the pillar trim.

Scheme 193

Scheme 194

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ), then wait for 3 minutes before starting work.
2. Remove the access panel (A) from the steering wheel, then disconnect the driver's airbag 4P connector (B) from the cable reel.
3. Using a TORX T30 bit, remove the two TORX bolts (A) and discard them.
4. Disconnect the horn switch connector (1P), then remove the driver's airbag (B).

Does the passenger's airbag cutoff indicator stay on?

YES - Go to step 2 .

NO - Troubleshooting is complete.

Scheme 195

Scheme 196

1. Connect the horn switch connector (1P) (A) to the driver's airbag.
2. Place the new driver's airbag (B) in the steering wheel, and secure it with new TORX bolts (C).
3. Connect the cable reel 4P connector (A) to the driver's airbag 4P connector, then install the access panel (B) on the steering wheel.
4. Do the battery terminal reconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ).
5. After installing the airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off. Make sure the horn works.

Scheme 197

Scheme 198

Scheme 199

Scheme 200

1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
2. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ).
3. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag, then remove the three nuts (B).
4. Remove the dashboard upper panel/front passenger's airbag assembly (see «UPPER DASHBOARD PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__upper-dashboard-panel-removalinstallation) ). If you are replacing a deployed airbag, go to step 6 to install a new airbag and a new dashboard upper panel.
5. Cut the four parts of the lid as shown (A), and detach the front passenger's airbag. NOTE: Always replace the upper dashboard panel whenever you remove the airbag from the panel. Replace the airbag if the airbag mounting hooks or its housing is damaged.
6. Insert the hooks (A) of the front passenger's airbag housing into the new upper dashboard panel, then insert the other hooks (B) into the panel. NOTE: Make sure there are no objects between the airbag and the upper panel. Make sure the airbag is fully seated, and make sure the upper panel is not deformed or damaged after the airbag is in place. Do not use tools when detaching the front passenger's airbag in order to protect it.
7. Reinstall the dashboard upper panel/front passenger's airbag assembly (see «UPPER DASHBOARD PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__upper-dashboard-panel-removalinstallation) ).
8. Install the three mounting nuts (A) to secure the airbag.
9. Reconnect the dashboard wire harness 4P connector (B) to the front passenger's airbag connector (Scheme 200)
10. Reinstall the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__glove-box-removalinstallation) ).
11. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
12. After installing the airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Scheme 201

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ), then wait for 3 minutes before starting work.
2. Disconnect the side airbag harness 2P connector (A).
3. Remove the seat assembly: '07-08 models (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ), '09 model «'09 MODEL»(/acura/rdx/i-2006-2009/remont/seats/#seats) ) and seat-back cover : '07-'08 models (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-back-coverpad-replacement) ), '09 model (see «'09 MODEL»(/acura/rdx/i-2006-2009/remont/seats/#seats) ).
4. Remove the TORX bolts (A) and mounting nut (B), then remove the side airbag (C) and side airbag bracket (D).

Scheme 202

Installation

Note. If the side airbag lid is secured by tape, remove the tape. Do not open the lid of the side airbag cover. Use new mounting bolts tightened to the specified torque. When you replace a side airbag, make sure that the seat-back cover is installed properly. Improper installation may prevent proper deployment. Be sure to install the harness wires so that they are not pinched or interfering with other parts.

Scheme 203

1. Place the new side airbag and the side airbag module bracket on the seat-back frame (A). Tighten the side airbag mounting nut (B) and TORX bolt (C).
2. Install the seat-back cover in the reverse order of removal (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-back-coverpad-replacement) ).
3. Install the seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ), then connect the side airbag harness 2P connector.
4. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
5. Move the front seat and the seat-back through their full ranges of movement, making sure the harness wires are not pinched or interfering with other parts.
6. After installing the side airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Removal

Note. Review the interior trim replacement procedure before doing repair or service (see TRIM REMOVAL/INSTALLATION - PILLAR AREAS ). Removal of the side curtain airbag must be done according to Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ). The side curtain airbag system consists of many components. When the side curtain airbag has been deployed, go to component Replacement/Inspection After Deployment, and replace all of the parts listed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ).

Scheme 204

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ) , then wait for 3 minutes before starting work.
2. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
3. Disconnect the side curtain airbag 2P connector (A) from the SRS wire harness.
4. Remove the mounting bolts (A) and clips (B) from the bracket. Replace the bolt.
5. Remove the hook (C) from the protector.

Scheme 205

Note. Installation of the side curtain airbag must be done according to the precautions and procedures section (see PRECAUTIONS AND PROCEDURES ). If the airbag is frayed, or has any other visible damage, replace it. Do not attempt to repair an airbag. When you install the airbag, make sure it is not twisted, and that it is not caught between the inflator bracket by the bracket bolts. Make sure that the side curtain airbag inflator retainer is installed properly. Otherwise the airbag could incorrectly deploy and cause damage or injuries. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.

Scheme 206

Scheme 207

1. Place the new side curtain airbag assembly on the side of the roof. Tighten the side curtain airbag mounting bolts (A).
2. Connect the side curtain airbag 2P connector (A) to the side curtain airbag. Left side shown; right side is similar.
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
4. Connect the HDS, and erase the DTCs (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
5. After installing the side curtain airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.
6. Install all removed parts.
7. Confirm proper headliner/pillar trim overlap (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ).

Airbag and Tensioner Disposal

Special Tools Required

Deployment tool 07HAZ-SG00500

Before scrapping any airbags, side airbags, side curtain airbags, seat belt tensioners, or seat belt buckle tensioner (including those in a whole vehicle to be scrapped), the part(s) must be deployed. If the vehicle is still within the warranty period, the Acura District Parts & Service Manager must give approval and/or special instruction before deploying the part(s). Only after the part(s) have been deployed (as the result of vehicle collision, for example), can they be scrapped. If the parts appear intact (not deployed), treat them with extreme caution. Follow this procedure.

Deploying Airbags in the Vehicle

If an SRS equipped vehicle is to be entirely scrapped, its airbags, side airbags, side curtain airbags, seat belt tensioners, and seat belt buckle tensioner should be deployed while still in the vehicle. These parts should not be considered as salvageable parts and should never be installed in another vehicle.

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

1. Turn the ignition switch to LOCK (0), then disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
2. Confirm that each airbag, side airbag, side curtain airbag, seat belt tensioner, or seat belt buckle tensioner is securely mounted.
3. Confirm that the deployment tool is functioning properly by following the check procedure on the tool label. Driver's Airbag
4. Remove the access panel (A) from the steering wheel then disconnect the driver's airbag 4P connector (B) from the cable reel. Front Passenger's Airbag
5. Remove the glove box, then disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag. Side Airbag
6. Disconnect the side airbag 2P connector (A) from the SRS wire harness. Side Curtain Airbag
7. Disconnect the SRS wire harness 2P connector (A) from the side curtain airbag. Seat Belt Tensioner
8. Disconnect the SRS wire harness 4P connector (A) from the seat belt tensioner. Pull the seat belt out all the way and cut it. Seat Belt Buckle Tensioner
9. Disconnect the SRS wire harness 4P connector (A) from the seat belt buckle tensioner.
10. Cut off each connector, and strip the ends of the wires. Twist each pair of unlike colored wires together, and clip an alligator clips (A) from the deployment tool to each pair. Place the deployment tool at least 30 feet (10 meters) away from the vehicle. NOTE: The driver's and front passenger's airbags have dual inflators. Twist each pair of unlike colored wires together, and clip an alligator clip to each pair.
11. Connect a 12 volt battery to the tool. If the green light on the tool comes on, the igniter circuit is defective and cannot deploy the component. Go to «DISPOSAL OF DAMAGED COMPONENTS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__disposal-of-damaged-components) . If the red light on the tool comes on, the component is ready to be deployed.
12. Push the tool's deployment switch. The airbags and tensioners should deploy (deployment is both highly audible and visible: A loud noise and rapid inflation of the bag, followed by slow deflation). If the components deploy and the green light on the tool comes on, continue with this procedure. If a component does not deploy, and the green light comes ON, its igniter is defective. Go to «DISPOSAL OF DAMAGED COMPONENTS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__disposal-of-damaged-components) . During deployment, the airbags can become hot enough to burn you. Wait for 30 minutes after deployment before touching the airbags.
13. Dispose of the complete airbag. No part of it can be reused. Place it in a sturdy plastic bag (A), and seal it securely. Dispose of the deployed airbag according to your local regulations.

Scheme 215

Deploying Components Out of the Vehicle

If an intact airbag or tensioner has been removed from a scrapped vehicle, or has been found defective or damaged during transit, storage, or service, it should be deployed as follows

Scheme 216

1. Confirm that the deployment tool is functioning properly by following the check procedure Deploying Airbags in the Vehicle on the tool label.
2. Position the airbag face up, outdoors, on flat ground, at least 30 feet (10 meters) from any obstacles or people.
3. Follow steps 9 through 12 of the in-vehicle deployment procedure.

Note. The driver's and front passenger's airbags have dual inflators. Twist each pair of unlike colored wires together, and clip an alligator clip to each pair.

Disposal of Damaged Components

1. If installed in a vehicle, follow the removal procedure for the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ), front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ), side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ), side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ), seat belt buckle tensioner (see «FRONT SEAT BELT BUCKLE»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts) ), and seat belt tensioner (see «FRONT SEAT BELT REPLACEMENT»(/acura/rdx/i-2006-2009/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
2. In all cases, make a short circuit by cutting, stripping, and twisting together the two inflator wires. NOTE: The driver's and front passenger's airbags have dual inflators. The like color wires go to the individual inflators.
3. Package the component in exactly the same packaging that the new replacement part came in.
4. Mark the outside of the box "DAMAGED AIRBAG NOT DEPLOYED," "DAMAGED SIDE AIRBAG NOT DEPLOYED," "DAMAGED SIDE CURTAIN AIRBAG NOT DEPLOYED," "DAMAGED SEAT BELT TENSIONER NOT DEPLOYED," or "DAMAGED SEAT BELT BUCKLE TENSIONER NOT DEPLOYED" so it does not get confused with your parts stock.
5. Contact your Acura District Parts and Service Manager for instructions on how and where to return it for disposal.

Deployment Tool Check

1. Connect the yellow clips to both the switch protector handles on the tool.
2. Push the operation switch: The green light should come on, indicating that the tool is operating properly and is ready for use. If the red light stays on, the tool is faulty, and another one must be used for the procedure.
3. Disconnect the tool clips and connectors from the protector handles and the battery.

Scheme 217

Scheme 218

1. Make sure the front wheels are aligned straight ahead.
2. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ) , then wait for 3 minutes before starting work.
3. Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
4. Disconnect the connector (A) from the cable reel, then remove the steering wheel bolt (B).
5. Confirm that the front wheels point straight ahead, then remove the steering wheel with a steering wheel puller (see step 6 under «STEERING WHEEL REMOVAL»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-wheel-removal) ). Do not tap on the steering wheel or steering column shaft when removing the steering wheel.
6. Remove the driver's under cover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ).
7. Remove the upper column cover and lower column cover (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__column-cover-removalinstallation) ).
8. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector (B), then disconnect the dashboard wire harness 20P connector (C) from the cable reel (D).
9. Release the lock tab (A) under the cable reel connector with a 90° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

1. Before installing the steering wheel, align the front wheels straight ahead.
2. If not already done, disconnect the negative cable from the battery, then wait for 3 minutes.
3. Set the turn signal canceling sleeve (A) so that the projections (B) are aligned vertically.
4. Carefully install the cable reel (A) on the steering column shaft. Then connect 20P connector (B) to the cable reel, and connect the 4P connector (C) to the dashboard wire harness 4P connector (D).
5. Install the steering column covers.
6. If necessary, center the cable reel (New replacement cable reels come centered ) . Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise (about three turns) until the arrow mark (A) on the cable reel label points straight up.
7. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown, and install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins(D) of the cable reel and tabs of the turn signal canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
8. Install a new steering wheel bolt (A), then reconnect the connectors.
9. Install the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
10. Reconnect the negative cable to the battery.
11. Clear the DTCs (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
12. After installing the cable reel, confirm proper system operation

1. Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.
2. After the SRS indicator has turned off, turn the steering wheel fully left and right to confirm the SRS indicator does not come on.
3. Make sure the horn works.
4. Make sure the cruise control buttons work.
5. Make sure the steering wheel audio controls work.
6. Make sure the voice control buttons work.
7. Make sure there are no DTCs.

Note. If you are only disconnecting SRS unit connector A, skip step 2.

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ), then wait for 3 minutes before starting work.
2. Disconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
3. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
4. Disconnect the SRS unit connector A (28P), SRS unit connector B (28P), SRS unit connector C (16P), and remove the TORX bolts (D), then pull out the SRS unit.

Scheme 225

Scheme 226

1. Install the new SRS unit (A) with TORX bolts (B), then connect the connectors (C) to the SRS unit; push them into position until they click. NOTE: Be sure the SRS unit is sitting squarely against it's bracket before torquing the TORX bolts.
2. Reconnect both seat belt tensioner connectors (see step 10 ) and both seat belt buckle tensioner connectors (see step 11 ).
3. Reconnect the negative cable to the battery.
4. Calibrate the ODS unit (see «ODS UNIT CALIBRATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-calibration) ).
5. Do the «ODS UNIT OPERATION CHECK»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-operation-check) .
6. After installing the SRS unit, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.
7. Reinstall all removed parts.

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ), then wait for 3 minutes before starting work.
2. Remove the front seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ).
3. Remove the front door sill inner trim.
4. Remove the lower B-pillar lower trim panel (see «B-PILLAR UPPER/LOWER TRIM»(/acura/rdx/i-2006-2009/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ).
5. Disconnect the SRS wire harness 4P connector from the side impact sensor (first).
6. Using a TORX T30 bit, remove the TORX bolt (A), then remove the side impact sensor (first) (B).

Scheme 227

Scheme 228

1. Install the new side impact sensor (first) with the TORX bolt (A), then connect the SRS wire harness 4P connector (B) to the side impact sensor (first).
2. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
3. After installing the side impact sensor (first) confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.
4. Reinstall all removed parts.

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ) , then wait for 3 minutes before starting work.
2. Disconnect the appropriate side curtain airbag 2P connector (see step 8 ).
3. Remove the rear seat and seat side bolster (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats) ).
4. Disconnect the SRS wire harness 2P connector from the side impact sensor (second).
5. Remove the TORX bolt (A) using a TORX T30 bit, then remove the side impact sensor (second) (B).

Scheme 229

Scheme 230

1. Install the new side impact sensor (second) with the TORX bolt (A), then connect SRS wire harness 2P connector (B) to the side impact sensor (second).
2. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
3. After installing the side impact sensor (second), confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.
4. Reinstall all removed parts.

Scheme 231

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ), then wait for 3 minutes before starting work.
2. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ).
3. Disconnect the SRS wire harness 2P connector (A) from the roll rate sensor.
4. Using a TORX T30 bit, remove the TORX bolt (B), then remove the roll rate sensor (C).

Scheme 232

1. Install the new roll rate sensor with a TORX bolt (A), then connect the SRS wire harness 2P connector (B) to the roll rate sensor (C).
2. Reconnect the negative cable to the battery.
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
4. After installing the roll rate sensor, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Note. Removal of the front passenger's weight sensors must be done according to Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ).

Scheme 233

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ).
2. Remove the front passenger's seat assembly section (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ).
3. Remove the cushion cover/pad from the seat cushion frame (see «FRONT SEAT FRAME REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-frame-replacement) ).
4. Remove the front passenger's seat cushion frame (see «FRONT SEAT FRAME REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-frame-replacement) ).
5. Using a TORX E18 socket, remove the TORX nuts (A) attaching the seat track (B) to the weight sensors (C).
6. Disconnect the sensor connectors (D) from the seat weight sensor, then remove the front passenger's weight sensors.

Note. Be sure to install the harness wires so they are not pinched or interfering with other parts.

Scheme 234

Scheme 235

1. Install the new front passenger's weight sensors under the seat track.
2. When tightening the TORX nuts (A), begin with the 1 and tighten them in crisscross pattern in two or more steps.
3. Torque the TORX nuts in the sequence shown in two or more steps.
4. Reassemble the front passenger's seat cushion cover/pad (see «FRONT SEAT CUSHION COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-cushion-coverpad-replacement) ).
5. Reinstall the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ).
6. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
7. Calibrate the ODS unit (see «ODS UNIT CALIBRATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-calibration) ).
8. After installing the front passenger's weight sensors, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come for about 6 seconds and then go off.

Scheme 236

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ), then wait for 3 minutes before starting work.
2. Disconnect the passenger's side airbag 2P connector (see step 5 ).
3. Remove the passenger's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ) and seat-back cover (see «FRONT SEAT-BACK COVER/PAD REPLACEMENT»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-back-coverpad-replacement) ).
4. Remove the cover (A), then disconnect the sensor connectors (B), from the ODS unit (C) and ODS unit 18P connector D.
5. Remove the two screws (E) and the ODS unit.

Scheme 237

1. Place the new ODS unit (A) on the seat-back frame. Tighten the two screws (B), and connect the sensor connectors (C) and ODS unit 18P connector (D) to the ODS unit. Reinstall the cover (E).
2. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
3. Install the seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ), then connect the side airbag 2P connector.
4. Reconnect the negative cable to the battery.
5. Set the seat-back in the normal position, and make sure there is nothing on the front passenger's seat.
6. Initialize the ODS unit (see «ODS UNIT INITIALIZATION»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__ods-unit-initialization) ).
7. After installing the ODS unit, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ).
2. Disconnect the driver's airbag 4P connector (see step 2 ), the front passenger's airbag 4P connector (see step 5 ), both seat belt tensioner 4P connectors (see step 10 ), and both seat belt buckle tensioner 4P connectors (see step 11 ).
3. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/exterior-body-panels/#bumpers__front-bumper-removalinstallation) ).
4. Disconnect the engine compartment wire harness 2P connector (A) from the front impact sensor. Using a TORX T30 bit, remove the TORX bolts (B), then remove the front impact sensor (C). Replace the bolts.

Scheme 238

Scheme 239

1. Install the new front impact sensor with new TORX bolts (A), then connect the engine compartment wire harness 2P connector (B) to the front impact sensor (C).
2. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
3. After installing the front impact sensor, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.
4. Reinstall all removed parts.

Note. Removal of the driver's seat position sensor must be performed according to the precautions/procedures described at the beginning of SRS section (see PRECAUTIONS AND PROCEDURES ). Do not turn the ignition switch ON (II), and do not connect the battery cable while removing the driver's seat position sensor.

Scheme 240

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__disconnection) ), then wait for 3 minutes before starting work.
2. Disconnect the driver's airbag 4P connector (see step 2 ).
3. Remove the driver's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ).
4. Disconnect the driver's seat wire harness or seat position sensor harness 2P connector (A) from the driver's seat position sensor.
5. Using a mounting nut (B), then remove the driver's seat position sensor.

Note. Be sure to install the harness so it is not pinched or interfere with other parts. Do not turn the ignition switch ON (II), and do not connect the battery cable while installing the driver's seat position sensor. After installing the driver's seat position sensor, make sure it is clean. Keep it away from dust.

Scheme 241

1. Install the new driver's seat position sensor with a mounting nut (A), then connect the driver's seat wire harness or seat position sensor harness 2P connector to the driver's seat position sensor (B).
2. Install the driver's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/seats/#seats__front-seat-removalinstallation) ).
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery__reconnection) ).
4. Check the operation of the driver's seat position sensor with the HDS (see «DRIVER'S SEAT POSITION SENSOR OPERATION CHECK»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system__drivers-seat-position-sensor-operation-check) ).

Passenger's Airbag Cutoff Indicator Illumination Bulb Test

Note. Information marked with an asterisk ( * ) applies to models with the navigation system.

Scheme 242

1. Remove the center panel (see «CENTER PANEL REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__center-panel-removalinstallation) ).
2. Check for continuity between the No. 2* or No. 18 and No. 6* or No. 20 terminals of the indicator. If there is no continuity, replace the bulb.
3. Reinstall the parts in the reverse order of removal.

See also:
• GLOVE BOX REMOVAL/INSTALLATION
• GLOVE BOX STRIKER REPLACEMENT
• HEADLINER REMOVAL/INSTALLATION
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
• TRIM REMOVAL/INSTALLATION - PILLAR AREAS
• CENTER CONSOLE REMOVAL/INSTALLATION
• DLC CIRCUIT TROUBLESHOOTING
• BATTERY TERMINAL DISCONNECTION AND RECONNECTION
• FRONT SEAT BELT REPLACEMENT
• FRONT SEAT BELT BUCKLE
• QUARTER PILLAR TRIM
• ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH)
• ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH)
• SRS WIRE HARNESS (LEFT BRANCH)
• SRS WIRE HARNESS (RIGHT BRANCH)
• FRONT SEAT REMOVAL/INSTALLATION
• FRONT SEAT-BACK COVER/PAD REPLACEMENT
• CENTER PANEL REMOVAL/INSTALLATION
• REMOVAL AND INSTALLATION
• SELF-DIAGNOSTIC FUNCTION
• GAUGE CONTROL MODULE REPLACEMENT
• MIL CIRCUIT TROUBLESHOOTING
• DTC B1187: GAUGE CONTROL MODULE LOST COMMUNICATION WITH THE SRS UNIT (SRS MESSAGE)
• '09 MODEL
• DISCONNECTION
• UPPER DASHBOARD PANEL REMOVAL/INSTALLATION
• RECONNECTION
• STEERING WHEEL REMOVAL
• DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• COLUMN COVER REMOVAL/INSTALLATION
• B-PILLAR UPPER/LOWER TRIM
• FRONT SEAT FRAME REPLACEMENT
• FRONT SEAT CUSHION COVER/PAD REPLACEMENT
• FRONT BUMPER REMOVAL/INSTALLATION
• AIRBAG AND TENSIONER DISPOSAL
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• CLEAR THE DTC MEMORY WITH THE HDS
• ODS UNIT REPLACEMENT
• 11-1X
• 11-3X
• 11-8X
• 11-9X
• 12-1X
• 12-3X
• 12-8X
• 12-9X
• 21-1X
• 21-3X
• 21-8X
• 21-9X
• 22-2X
• 22-3X
• 22-8X
• 22-9X
• 27-1X
• 27-3X
• 27-8X
• 27-9X
• 28-1X
• 28-3X
• 28-8X
• 28-9X
• 31-1X
• 31-3X
• 31-8X
• 31-9X
• 32-2X
• 32-3X
• 32-8X
• 32-9X
• 33-1X
• 33-3X
• 33-8X
• 33-9X
• 34-1X
• 34-3X
• 34-8X
• 34-9X
• 41-1X
• 41-2X
• 42-1X
• 42-2X
• 43-1X
• 43-2X
• 44-1X
• 44-2X
• 45-1X
• 45-2X
• 46-1X
• 46-2X
• 51-XX
• 61-1X
• 61-2X
• 62-1X
• 62-2X
• 71-1X
• 71-21
• 71-22
• 81-4X
• 81-61
• 81-71
• 81-79
• 82-1X
• 85-4X
• 85-79
• 86-1X
• 92-1X
• 92-2X
• A1-1X
• A2-1X
• B1-1X
• B1-2X
• EX-XX
• SIDE AIRBAG CUTOFF INDICATOR STAYS ON
• PASSENGER'S AIRBAG CUTOFF INDICATOR STAYS ON OR COMES ON SUDDENLY
• TROUBLESHOOTING INTERMITTENT FAILURES
• DTC (DIAGNOSTIC TROUBLE CODES)
• OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS
• DRIVER'S SEAT POSITION SENSOR OPERATION CHECK
• ODS UNIT CALIBRATION
• ODS UNIT INITIALIZATION
• SRS INDICATOR STAY ON, BUT NO DTCS ARE STORED
• CHECKING THE FRONT PASSENGER'S WEIGHT SENSORS AFTER A VEHICLE COLLISION
• ODS UNIT OPERATION CHECK
• CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP
• DISPOSAL OF DAMAGED COMPONENTS
