Component Location Index
For the driver's power seat, refer to the Driving Position Memory System (DPMS)
Component Location Index, see DRIVER POSITION MEMORY SYSTEM (DPMS)
Scheme 175
Scheme 176
Scheme 177
Scheme 178
- Remove the power seat adjustment switch knobs and recline cover from the front passenger's power seat, then remove the power seat switch (see «FRONT SEAT DISASSEMBLY/REASSEMBLY»(/acura/mdx/ii-2006-2010/remont/seats/#seats__front-seat-disassemblyreassembly) ).
- Disconnect the 12P connector from the power seat adjustment switch (A).
- Reinstall the adjustment switch knobs to the switch.
- Check for continuity between the terminals in each switch position according to the table.
- If the continuity is not as specified, replace the switch.
Scheme 179
Scheme 180
Scheme 181
Scheme 182
Scheme 183
- Remove the front passenger's power seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/seats/#seats__front-seat-removalinstallation) ).
- Remove the power seat adjustment switch (B) (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/seats/#power-seats) ) and disconnect the 12P connector (A) from the switch.
- At the power seat adjustment switch 12P connector, test the motor by applying battery power and ground to the terminals according to the table. Slide motor: Recline motor: Front up-down motor: Rear up-down motor
- If the motor does not run or fails to run smoothly, check for an open in the front passenger's seat wire harness between the power seat adjustment switch and each motor. If the wire harness is OK, replace the appropriate motor (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/seats/#power-seats) ). NOTE: The slide and up-down motors are not available separately because of the part of seat linkage, refer to the seat linkage disassembly/ reassembly (see «FRONT SEAT LINKAGE DISASSEMBLY/REASSEMBLY»(/acura/mdx/ii-2006-2010/remont/seats/#seats__front-seat-linkage-disassemblyreassembly) ).
