EGR System Acura MDX II

Auxiliary Emission Control Systems 19 illustrations ~3377 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

DTC P0401: EGR Insufficient Flow

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Go to step 5. NO - Go to step 7 .
  5. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D position Vehicle speed at 25 mph (40 km/h) or more, and engine speed between 1,100 rpm and 3,000 rpm During the drive, decelerate (with the throttle fully closed) for 5 seconds
  6. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Remove the engine cover, clean the intake manifold, and EGR ports with throttle plate and induction cleaner, then go to step 9 . NO - If the screen indicates PASSED, intermittent failure, the system is OK at this time. If the screen indicates EXECUTING, keep driving until a result comes on. If the screen indicates OUT OF CONDITION, go to step 5 and recheck.
  7. Turn the ignition switch OFF.
  8. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  9. Turn the ignition switch ON (II).
  10. Reset the PCM with the HDS.
  11. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/ii-2006-2010/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
  12. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D position Vehicle speed at 25 mph (40 km/h) or more, and engine speed between 1,100 rpm and 3,000 rpm During the drive, decelerate (with the throttle fully closed) for 5 seconds
  13. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0401 indicated? YES - Check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 15 . NO - Go to step 14.
  14. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs were indicated in step 13 , go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If the screen indicates EXECUTING, keep driving until a result comes on. If the screen indicates OUT OF CONDITION, go to step 12 .
  15. Reconnect all connectors, then update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).
  16. Test-drive under these conditions: Engine coolant temperature (ECT SENSOR 1) above 158°F (70°C) Transmission in D position Vehicle speed at 25 mph (40 km/h) or more, and engine speed between 1,100 rpm and 3,000 rpm During the drive, decelerate (with the throttle fully closed) for 5 seconds
  17. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0401 indicated? YES - Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 16 . If the PCM was substituted, go to step 1 . NO - Go to step 18.
  18. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs were indicated in step 17 , go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 16 . If the PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, go to step 16 .

DTC P0404: EGR Control Circuit Range/ Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 2

Scheme 2: DTC P0404: EGR Control Circuit Range/ Performance Problem
Scheme 2: DTC P0404: EGR Control Circuit Range/ Performance Problem

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Intermittent failure, the system is OK at this time. Clean any carbon build-up on the EGR valve with throttle plate and induction cleaner. NO - Go to step 5.
  5. Turn the ignition switch OFF.
  6. Disconnect the EGR valve 6P connector.
  7. At the sensor side, measure resistance between EGR valve 6P connector terminals No. 1 and No. 2. Is there 100 kohms, or more? YES - Go to step 25 . NO - Go to step 8.
  8. Measure resistance between EGR valve 6P connector terminals No. 1 and No. 3. Is there 100 kohms, or more? YES - Go to step 25 . NO - Go to step 9.
  9. Check for continuity between EGR valve 6P connector terminal No. 6 and body ground. Is there continuity? YES - Go to step 10. NO - Repair open in the wire between the EGR valve and G101, then go to step 26 .
  10. Jump the SCS line with the HDS.
  11. Disconnect PCM connector C (49P).
  12. Check for continuity between PCM connector terminal C10 and body ground. Is there continuity? YES -Repair short in the wire between the PCM (C10) and the EGR valve, then go to step 26 . NO - Go to step 13.
  13. Check for continuity between PCM connector terminal C10 and EGR valve 6P connector terminal No. 4. Is there continuity? YES - Go to step 14. NO - Repair open in the wire between the PCM (C10) and the EGR valve, then go to step 26 .
  14. Remove the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  15. Clean the intake manifold EGR port and the passage inside the EGR valve with throttle plate and induction cleaner.
  16. Install the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  17. Reconnect the EGR valve 6P connector.
  18. Reconnect PCM connector C (49P).
  19. Turn the ignition switch ON (II).
  20. Reset the PCM with the HDS.
  21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/ii-2006-2010/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
  22. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  23. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Go to step 32 . NO - Go to step 24.
  24. Turn the ignition switch OFF.
  25. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  26. Reconnect all connectors.
  27. Turn the ignition switch ON (II).
  28. Reset the PCM with the HDS.
  29. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/ii-2006-2010/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
  30. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  31. Do the EGR TEST in the INSPECTION MENU with the HDS.
  32. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0404 indicated? YES -Check for poor connections or loose terminals at the EGR valve and the PCM. If the connector and terminal fits are OK, go to step 34 . NO -Go to step 33.
  33. Monitor the OBD STATUS for DTC P0404 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs were indicated in step 32 , go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If the screen indicates EXECUTING, keep driving until a result comes on. If the screen indicates OUT OF CONDITION, go to step 30 .
  34. Reconnect all connectors, then update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).
  35. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  36. Do the EGR TEST in the INSPECTION MENU with the HDS.
  37. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0404 indicated? YES - Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 35 . If the PCM was substituted, go to step 1 . NO - Go to step 38.
  38. Monitor the OBD STATUS for DTC P0404 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs were indicated in step 37 , go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 35 . If the PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, go to step 35 .

DTC P0406: EGR Valve Position Sensor Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 7

Scheme 7: DTC P0406: EGR Valve Position Sensor Circuit High Voltage
Scheme 7: DTC P0406: EGR Valve Position Sensor Circuit High Voltage

Scheme 8

Scheme 8
Scheme 8
  1. Turn the ignition switch ON (II).
  2. Check the EGR VLS in the DATA LIST with the HDS. Is 4.88 V or more indicated? YES - Go to step 3. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect the EGR valve 6P connector.
  5. Turn the ignition switch ON (II).
  6. Measure voltage between EGR valve 6P connector terminals No. 2 and No. 3. Is there about 5 V? YES - Go to step 11 . NO - Go to step 7.
  7. Turn the ignition switch OFF.
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector C (49P).
  10. Check for continuity between PCM connector terminal C16 and EGR valve 6P connector terminal No. 2. Is there continuity? YES - Go to step 18 . NO - Repair open in the wire between the EGR valve and the PCM (C16), then go to step 13 .
  11. Turn the ignition switch OFF.
  12. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  13. Reconnect all connectors.
  14. Turn the ignition switch ON (II).
  15. Reset the PCM with the HDS.
  16. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/ii-2006-2010/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
  17. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0406 indicated? YES - Check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . NO - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) .
  18. Reconnect all connectors.
  19. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).
  20. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0406 indicated? YES - Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) .

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 9

Scheme 9: DTC P2413: EGR System Malfunction
Scheme 9: DTC P2413: EGR System Malfunction

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM. NO - Go to step 5.
  5. Turn the ignition switch OFF.
  6. Turn the ignition switch ON (II).
  7. Check the EGR VLS in the DATA LIST with the HDS. Is about 0 V indicated? YES - Go to step 8. NO - Go to step 21 .
  8. Turn the ignition switch OFF.
  9. Disconnect the EGR valve 6P connector.
  10. Turn the ignition switch ON (II).
  11. Measure voltage between EGR valve 6P connector terminal No. 3 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 12.
  12. Turn the ignition switch OFF.
  13. Jump the SCS line with the HDS.
  14. Disconnect PCM connector C (49P).
  15. Check for continuity between PCM connector terminal C12 and EGR valve 6P connector terminal No. 3. Is there continuity? YES - Go to step 52 . NO - Repair open in the wire between the EGR valve and the PCM (C12), then go to step 44 .
  16. Turn the ignition switch OFF.
  17. Jump the SCS line with the HDS.
  18. Disconnect PCM connector C (49P).
  19. Check for continuity between PCM connector terminal C34 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (C34) and the EGR valve, then go to step 44 . NO - Go to step 20.
  20. Check for continuity between PCM connector terminal C34 and EGR valve 6P connector terminal No. 1. Is there continuity? YES - Go to step 21. NO - Repair open in the wire between the PCM (C34) and the EGR valve, then go to step 44 .
  21. Turn the ignition switch OFF.
  22. If not already done, disconnect the EGR valve 6P connector.
  23. At the EGR valve side, measure resistance between EGR valve 6P connector terminals No. 1 and No. 2. Is there resistance of 100 kohms or more? YES - Go to step 43 . NO - Go to step 24.
  24. At the EGR valve side, measure resistance between EGR valve 6P connector terminals No. 1 and No. 3. Is there resistance of 100 kohms or more? YES - Go to step 43 . NO - Go to step 25.
  25. If not already done, jump the SCS line with the HDS.
  26. If not already done, disconnect PCM connector C (49P).
  27. Check for continuity between PCM connector terminal C10 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (C10) and the EGR valve, then go to step 44 . NO - Go to step 28.
  28. Check for continuity between PCM connector terminal C10 and EGR valve 6P connector terminal No. 4. Is there continuity? YES - Go to step 29. NO - Repair open in the wire between the PCM (C10) and the EGR valve, then go to step 44 .
  29. Check for continuity between EGR valve 6P connector terminal No. 6 and body ground. Is there continuity? YES - Go to step 30. NO - Repair open in the wire between the EGR valve and G101 (see «GROUND TO COMPONENTS INDEX»(/acura/mdx/ii-2006-2010/remont/body-electrical/#ground-distribution__ground-to-components-index) ), then go to step 44 .
  30. Reconnect PCM connector C (49P).
  31. At the EGR valve side, connect the battery positive terminal to EGR valve 6P connector terminal No. 4 with a jumper wire.
  32. Start the engine and let it idle, then connect the battery negative terminal to EGR valve 6P connector terminal No. 6 with a jumper wire. Does the engine stall or run rough? YES - Go to step 51 . NO - Go to step 33.
  33. Turn the ignition switch OFF.
  34. Remove the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  35. Clean the intake manifold EGR port at the passage inside the EGR valve with throttle plate and induction cleaner.
  36. Install the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  37. Reconnect all connectors.
  38. Turn the ignition switch ON (II).
  39. Reset the PCM with the HDS.
  40. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/ii-2006-2010/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
  41. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Go to step 49 . NO - Go to step 42.
  42. Turn the ignition switch OFF.
  43. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) ).
  44. Reconnect all connectors.
  45. Turn the ignition switch ON (II).
  46. Reset the PCM with the HDS.
  47. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/ii-2006-2010/remont/engine-control-systems/#idle-control-system__pcm-idle-learn-procedure) ).
  48. Do the EGR TEST in the INSPECTION MENU with the HDS.
  49. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2413 indicated? YES - Check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . NO - Go to step 50.
  50. Monitor the OBD STATUS for DTC P2413 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs were indicated in step 49 , go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If the screen indicates EXECUTING or OUT OF CONDITION, keep idling until a result comes on.
  51. Turn the ignition switch OFF.
  52. Reconnect all connectors.
  53. Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).
  54. Do the EGR TEST in the INSPECTION MENU with the HDS.
  55. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2413 indicated? YES - Check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the PCM was substituted, go to step 1 . NO - Go to step 56.
  56. Monitor the OBD STATUS for DTC P2413 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). If any other Temporary DTCs or DTCs were indicated in step 55 , go to the indicated «DTCs troubleshooting»(/acura/mdx/ii-2006-2010/remont/auxiliary-emission-control-systems/#egr-system) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EGR valve and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/mdx/ii-2006-2010/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ), then go to step 54 . If the PCM was substituted, go to step 1 . If the screen indicates EXECUTING or OUT OF CONDITION, go to step 54 and recheck.

Scheme 19

Scheme 19: EGR Valve Replacement
Scheme 19: EGR Valve Replacement
  1. Remove the engine cover (see step 1 on «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exhaust/#intake-manifold-and-exhaust-system) ).
  2. Remove the main under-hood fuse box.
  3. Disconnect the EGR valve connector (A).
  4. Remove the EGR valve (B).
  5. Install the parts in the reverse order of removal with a new gasket (C).
