Seat Belts Acura MDX I

Scheme 1

Front Seat Belt Replacement

SRS components are located in this area. Review the SRS component locations for the appropriate year

1. '03 model (see «2003 MODEL»(/acura/mdx/i-2000-2006/remont/airbag/#srs-supplemental-restraint-system) )
2. '04-'06 models (see «2004-2006 MODELS»(/acura/mdx/i-2000-2006/remont/airbag/#srs-supplemental-restraint-system) )

Also review the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or service.

Note. Check the front seat belts for damage, and replace them if necessary. If the seat belt tensioner has been deployed, replace the front seat belt protector.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Make sure you have the anti-theft code for the radio and the navigation system, and then write down the frequencies for the preset buttons.
2. Slide the front seat all the way forward.
3. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
4. Remove the upper anchor cover (A).
5. Driver's seat belt: Pull the lower anchor cover (A) up, and remove the lower anchor bolt (B).
6. Passenger's seat belt: Remove the rear riser cover (see step 4 in «FRONT SEAT REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/seats/#seats__front-seat-removalinstallation) ). Remove the bolt (A), and release the hook (B), then remove the lower anchor bracket (C) from the outer weight sensor (D). NOTE: Do not remove the seat belt anchor bolt (E) from the lower anchor bracket.
7. Remove the B-pillar lower trim: '03 model (see step 3 in «B-PILLAR - '03 MODEL»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__b-pillar-03-model) ) '04-06 models (see step 3 in «B-PILLAR - '04 -'06 MODELS»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__b-pillar-04-06-models) )
8. Remove the upper anchor bolt (A).
9. Disconnect the seat belt tensioner connector (B). Remove the retractor mounting ET screw (C), and on passenger's seat belt, remove the retractor bolt (D), then remove the front seat belt (E) and retractor (F).
10. If the seat belt tensioner has been deployed, replace the front seat belt protector (G).
11. Remove the B-pillar upper trim: '03 model (see step 5 in «B-PILLAR - '03 MODEL»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__b-pillar-03-model) ) '04-'06 models (see step 5 in «B-PILLAR - '04 -'06 MODELS»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__b-pillar-04-06-models) )
12. Remove the shoulder anchor adjuster (A).
13. Install the front seat belt and retractor in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolts before reinstallation. Tighten the bolts by hand first, then tighten to specification with a torque wrench. Check that the retractor locking mechanism functions (see «RETRACTOR»(/acura/mdx/i-2000-2006/remont/restraints-control-systems/#seat-belts) ). Assemble the washers, collars, and bushings of the upper and lower anchor bolts (Scheme 8), (Scheme 9) and (Scheme 10). If the seat belt tensioner has been deployed, replace the seat belt protector. Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt. Make sure the seat belt tensioner connector is plugged in properly. Reconnect the negative cable to the battery. Enter the anti-theft code for the radio and the navigation system, and then enter the customer's radio station presets. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ) and the Power Window Control Unit reset procedure (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/mdx/i-2000-2006/remont/windows/#power-windows) ).

Scheme 11

Scheme 12

Scheme 13

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/seats/#seats__front-seat-removalinstallation) ).
2. Remove the center cover: Driver's 8-way Power Seat - '03 model (see «'03 MODEL»(/acura/mdx/i-2000-2006/remont/seats/#seats__03-model) ) - '04-'06 models (see «'04-06 MODELS»(/acura/mdx/i-2000-2006/remont/seats/#seats__04-06-models) ) Passenger's 8-way Power Seat (see «FRONT SEAT DISASSEMBLY/REASSEMBLY - PASSENGER'S 8-WAY POWER»(/acura/mdx/i-2000-2006/remont/seats/#seats__front-seat-disassemblyreassembly-passengers-8-way) ) Passenger's Manual Seat (see «FRONT SEAT DISASSEMBLY/REASSEMBLY - PASSENGER'S MANUAL»(/acura/mdx/i-2000-2006/remont/seats/#seats__front-seat-disassemblyreassembly-passengers-manual) )
3. Disconnect the seat belt switch connector (A), and detach the connector clip, harness clip (B), and wire tie (C) ('03-'04 models) from the cushion frame spring (8-way Power Seat).
4. Remove the center anchor bolt (D), and remove the seat belt buckle (E).
5. Remove the seat belt switch harness (F) from under the seat cushion.
6. Install the buckle in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolt before reinstallation. Tighten the bolts by hand first, then tighten to specification with a torque wrench. Assemble the washers and collar of the center anchor bolt as shown. Move the seat up and down to make sure the buckle harness is not pinched. Center Anchor Bolt Installation

Second Row Seat Belt Replacement

Note. Check the second row seat belts for damage, and replace them if necessary.

Scheme 14

Scheme 15

1. Remove the rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE LOWER AREA»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-lower) ).
2. Remove the upper anchor cap (A), the upper anchor bolt (B), the lower anchor bolt (C), and the retractor bolt (D), then remove the second row seat belt (E) and retractor (F).
3. Install the second row seat belt and retractor in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolt before reinstallation. Tighten the bolts by hand first, then tighten to specification with a torque wrench. Check that the retractor locking mechanism functions (see «RETRACTOR»(/acura/mdx/i-2000-2006/remont/restraints-control-systems/#seat-belts) ). Assemble the washers, collars, and bushing of the upper anchor bolt (Scheme 15) Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt.

Scheme 16

Scheme 17

1. Detach the clips (A) and remove the seat belt cover (B).
2. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
3. Remove the upper anchor mounting ET screw (A), the upper anchor bolts (B), the retractor mounting ET screw (C), the retractor bolt (D), then remove the upper anchor (E), center seat belt (F), and retractor (G).
4. Install the center second row seat belt and retractor in the reverse order of removal, and note these items: Replace any damaged clips. Apply liquid thread lock to the anchor bolts before reinstallation. Tighten the bolts by hand first, then tighten to specification with a torque wrench. Check that the retractor locking mechanism functions (see «RETRACTOR»(/acura/mdx/i-2000-2006/remont/restraints-control-systems/#seat-belts) ). Before installing the upper anchor bolt, make sure there are no twists or kinks in the seat belt.

Left Seat Belt Buckle and Center Seat Belt Detachable Anchor

Note. Take care not to tear the seams or damage the seat covers.

Scheme 18

Scheme 19

Scheme 20

1. Remove the anchor cover (A) and center anchor bolt (B).
2. Remove the left second row seat (see «SECOND ROW SEAT REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/seats/#seats__second-row-seat-removalinstallation) ).
3. Remove the left seat belt buckle from the elastic strap.
4. Release the hooks (A), then remove the seat belt buckle pocket (B).
5. Cut the zip tie (C), and remove it from under the seat cushion.
6. Remove the left second row seat belt buckle (D) and center second row seat belt detachable anchor (E).
7. Install the buckle and the detachable anchor in the reverse order of removal, and note these items: Replace the zip tie with a new one. Assemble the washers of the center anchor bolt (Scheme 20) Apply liquid thread lock to the anchor bolt before reinstallation. Tighten the bolt by hand first, then tighten to specification with a torque wrench.

Center Seat Belt Buckle/Right Seat Belt Buckle

Note. The center seat belt buckle is shown, and the right seat belt buckle is similar.

Scheme 21

1. Remove the second row seat (see «SECOND ROW SEAT REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/seats/#seats__second-row-seat-removalinstallation) ).
2. Remove the buckle from the elastic strap.
3. Remove the pivot bolt cover, and using a T30 Torx bit, remove the pivot bolt from both sides: Left second row seat (see «LEFT SECOND ROW SEAT DISASSEMBLY/REASSEMBLY»(/acura/mdx/i-2000-2006/remont/seats/#seats__left-second-row-seat-disassemblyreassembly) ) Right second row seat '03 model (see «'03 MODEL»(/acura/mdx/i-2000-2006/remont/seats/#seats) ) '04-06 models (see «'04-06 MODELS»(/acura/mdx/i-2000-2006/remont/seats/#seats) )
4. Lift the seat cushion up, and remove the inner slide cover: Left second row seat (see «LEFT SECOND ROW SEAT DISASSEMBLY/REASSEMBLY»(/acura/mdx/i-2000-2006/remont/seats/#seats__left-second-row-seat-disassemblyreassembly) ) Right second row seat '03 model (see «'03 MODEL»(/acura/mdx/i-2000-2006/remont/seats/#seats) ) '04-06 models (see «'04-06 MODELS»(/acura/mdx/i-2000-2006/remont/seats/#seats) )
5. Remove the center anchor bolt (A), and remove the seat belt buckle (B).
6. Install the buckle in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolt before reinstallation. Tighten the bolt by hand first, then tighten to specification with a torque wrench. NOTE: Check the third row seat belts for damage, and replace them if necessary.

Scheme 22

Scheme 23

Scheme 24

1. Remove the upper anchor cap (A) and the upper anchor bolt (B).
2. Remove the rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE LOWER AREA»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-lower) ).
3. Remove the bolts (A) and remove the seat belt guide (B).
4. Remove the retractor bolts (C), then remove the third row seat belt (D) and retractor (E).
5. Install the third row seat belt and retractor in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolts before reinstallation. Tighten the bolts by hand first, then tighten to specification with a torque wrench. Check that the retractor locking mechanism functions (see «RETRACTOR»(/acura/mdx/i-2000-2006/remont/restraints-control-systems/#seat-belts) ). Assemble the washers, collars, and bushing of the upper anchor bolt (Scheme 24) Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt.

Seat Belt Buckle/Seat Belt Detachable Anchor

Note. The seat belt buckle is shown, and the seat belt detachable anchor is similar.

Scheme 25

Scheme 26

1. Remove the third row seat (see «THIRD ROW SEAT REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/seats/#seats__third-row-seat-removalinstallation) ).
2. Remove the screw (A) and release the hook (B), then remove the bracket cover (C).
3. Remove the center anchor bolt (D), then remove the seat belt buckle (E).
4. Install the buckle in the reverse order of removal, and note these items: Assemble the washers, spring, bracket, collar, and bushing of the center anchor bolt as shown. Apply liquid thread lock to the anchor bolt before reinstallation. Tighten the bolt by hand first, then tighten to specification with a torque wrench.

Inspection

For front seat belt retractor with seat belt tensioner, review the SRS component locations for the appropriate year

1. '03 model (see «2003 MODEL»(/acura/mdx/i-2000-2006/remont/airbag/#srs-supplemental-restraint-system) )
2. '04-06 models (see «2004-2006 MODELS»(/acura/mdx/i-2000-2006/remont/airbag/#srs-supplemental-restraint-system) )

Also review the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or service.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Before installing the retractor, check that the seat belt can be pulled out freely.
2. Make sure that the seat belt does not lock when the retractor (A) is leaned slowly up to 15° from the mounted position. The seat belt should lock when the retractor is leaned over 40°. Do not attempt to disassemble the retractor.
3. Replace the seat belt with a new assembly if there is any abnormality. Do not disassemble any part of the seat belt for any reason.

In-vehicle

1. Check that the seat belt is not twisted or caught on anything.
2. After installing the anchors, check for free movement on the anchor bolts. If necessary, remove the anchor bolts and check that the washers and other parts are not damaged or improperly installed.
3. Check the seat belts for damage or discoloration. Clean with a shop towel if necessary. Use only soap and water to clean. NOTE: Dirt buildup in the loops of the upper anchors can cause the seat belts to retract slowly. Wipe the inside of the loops with a clean cloth dampened in isopropyl alcohol.
4. Check that the seat belt does not lock when pulled out slowly. The seat belt is designed to lock only during a sudden stop or impact.
5. Make sure that the seat belt will retract automatically when released.
6. For each passenger's seat belt, check the seat belt retractor locking mechanism ALR (automatic locking retractor). This function is for securing child seats. -1 Pull the seat belt all the way out to engage the ALR. The seat belt should retract with a soft, ratcheting sound, but not extend. This is normal. -2 To disengage the ALR, release the seat belt and allow it to fully retract, then pull the seat belt out part-way. The seat belt should retract and extend normally.
7. Replace the seat belt with a new assembly if there is any abnormality. Do not disassemble any part of the seat belt for any reason.

Scheme 31

1. Remove the rear trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE LOWER AREA»(/acura/mdx/i-2000-2006/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-lower) ).
2. Remove the screw (A) and remove the third row child seat tether anchor (B).
3. Install the anchor in the reverse order of removal.
