Cabin Air Filter Acura MDX I

REMOVAL & INSTALLATION

Note. Manufacturer's terminology for this filter is dust and pollen filter.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. While holding the glove box (A), remove the glove box stop (B) on each side. (Scheme 1) Detach the lock (C) from the damper (D).
2. Remove the bolts, then remove the glove box (A). (Scheme 2)
3. Remove the bolts, then remove the damper. (Scheme 3)
4. If necessary, cut the plastic cross brace in the glove box opening with diagonal cutters in the area shown, and discard it. (Scheme 4)
5. Remove the bolts, the screws and the glove box frame. (Scheme 5)
6. Remove the filter lid (A) from the evaporator, then pull out the dust and pollen filter (B). (Scheme 6)
7. To install filter, reverse removal procedure.
