Contents Wiring diagrams Section: Auxiliary Emission Control Systems All sections

EGR System Acura MDX I

Auxiliary Emission Control Systems 24 illustrations ~3596 words

Scheme 98

Scheme 98: Component Location Index
Scheme 98: Component Location Index

DTC CODES

DTCDescription
DTC P0401EGR Insufficient Flow
DTC P0403EGR Control Circuit Malfunction
DTC P0404EGR Control Circuit Range/Performance Problem
DTC P0406EGR Valve Position Sensor Circuit High Voltage
DTC P2413EGR System Malfunction

DTC CHARTS

DTC P0401: EGR Insufficient Flow

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the test result OK? YES - Go to step 5. NO - Go to step 7 .
  5. Test-drive under these conditions: Engine coolant temperature above 158 °F (70 °C) A/T in D5 position Vehicle speed at 30 mph (48 km/h) or more, and engine speed between 1,100 RPM and 2,300 RPM During the drive, decelerate (with the throttle fully closed) for 5 seconds
  6. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Remove the EGR pipe (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(/acura/mdx/i-2000-2006/remont/exhaust/#intake-manifold-and-exhaust-system) ), and clean the intake manifold port with carburetor cleaner, then go to step 9 . NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. If the screen indicates EXECUTING, keep the driving condition continually until a result comes on. If the screen indicates OUT OF CONDITION, go to step 5 and recheck.
  7. Turn the ignition switch OFF.
  8. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ).
  9. Turn the ignition switch ON (II).
  10. Reset the PCM with the HDS.
  11. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  12. Test-drive under these conditions: Engine coolant temperature above 158 °F (70 °C) A/T in D5 position Vehicle speed at 30 mph (48 km/h) or more, and engine speed between 1,100 RPM and 2,300 RPM During the drive, decelerate (with the throttle fully closed) for 5 seconds
  13. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0401 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM. If connections are OK, go to step 15 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Go to step 14.
  14. Monitor the OBD STATUS for DTC P0401 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, go to step 1 and recheck. If the screen indicates EXECUTING, keep the driving condition continually until a result comes on. If the screen indicates OUT OF CONDITION, go to step 12 and recheck.
  15. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__pcm-updating-and-substitution-for-testing) ).
  16. Test-drive under these conditions: Engine coolant temperature above 158 °F (70 °C) A/T in D5 position Vehicle speed at 30 mph (48 km/h) or more, and engine speed between 1,100 RPM and 2,300 RPM During the drive, decelerate (with the throttle fully closed) for 5 seconds
  17. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0401 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0403: EGR Control Circuit Malfunction

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 99

Scheme 99: DTC P0403: EGR Control Circuit Malfunction
Scheme 99: DTC P0403: EGR Control Circuit Malfunction

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the EGR SYSTEM OK? YES - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM. NO - Go to step 5.
  5. Turn the ignition switch OFF.
  6. Disconnect the EGR valve 6P connector.
  7. At the EGR valve side, measure resistance between EGR valve 6P connector terminals No. 4 and No. 6. Is there about 6.3 - 6.7 ohm? YES - Go to step 8. NO - Go to step 14 .
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector A (73P).
  10. Check for continuity between PCM connector terminal A15 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A15) and the EGR valve, then go to step 15 . NO - Go to step 11.
  11. Connect EGR valve 6P connector terminal No. 4 to body ground with a jumper wire.
  12. Check for continuity between PCM connector terminal A15 and body ground. Is there continuity? YES - Go to step 13. NO - Repair open in the wire between the PCM (A15) and the EGR valve, then go to step 15 .
  13. Check for continuity between EGR valve 6P connector terminal No. 6 and body ground. Is there continuity? YES - Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__pcm-updating-and-substitution-for-testing) ), then go to step 15 . NO - Repair open in the wire between the EGR valve and G101, then go to step 15 .
  14. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ).
  15. Turn the ignition switch ON (II).
  16. Reset the PCM with the HDS.
  17. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  18. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  19. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0403 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.

DTC P0404: EGR Control Circuit Range/Performance Problem

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 104

Scheme 104: DTC P0404: EGR Control Circuit Range/Performance Problem
Scheme 104: DTC P0404: EGR Control Circuit Range/Performance Problem

Scheme 105

Scheme 105
Scheme 105

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the test result OK? YES - Intermittent failure system is OK at this time. Clean any carbon build-up on the EGR valve with carburetor cleaner. NO - Go to step 5.
  5. Turn the ignition switch OFF.
  6. Disconnect the EGR valve 6P connector.
  7. At the sensor side, measure resistance between EGR valve 6P connector terminals No. 1 and No. 2. Is there 100 kohm or more? YES - Go to step 25 . NO - Go to step 8.
  8. Measure resistance between EGR valve 6P connector terminals No. 1 and No. 3. Is there 100 kohm or more? YES - Go to step 25 . NO - Go to step 9.
  9. Check for continuity between EGR valve 6P connector terminal No. 6 and body ground. Is there continuity? YES - Go to step 10. NO - Repair open in the wire between the EGR valve and G101, then go to step 26 .
  10. Jump the SCS line with the HDS.
  11. Disconnect PCM connector A (73P).
  12. Check for continuity between PCM connector terminal A15 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A15) and the EGR valve, then go to step 26 . NO - Go to step 13.
  13. Check for continuity between PCM connector terminal A15 and EGR valve 6P connector terminal No. 4. Is there continuity? YES - Go to step 14. NO - Repair open in the wire between the PCM (A15) and the EGR valve, then go to step 26 .
  14. Remove the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ).
  15. Clean the intake manifold port with carburetor cleaner. Also, clean the passage inside the EGR valve with carburetor cleaner.
  16. Install the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ).
  17. Reconnect the EGR valve 6P connector.
  18. Reconnect PCM connector A (73P).
  19. Turn the ignition switch ON (II).
  20. Reset the PCM with the HDS.
  21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  22. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  23. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Go to step 31 . NO - Go to step 24.
  24. Turn the ignition switch OFF.
  25. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ).
  26. Reconnect all connectors.
  27. Turn the ignition switch ON (II).
  28. Reset the PCM with the HDS.
  29. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  30. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  31. Do the EGR TEST in the INSPECTION MENU with the HDS.
  32. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0404 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM. If the connections and terminals are OK, go to step 34 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Go to step 33.
  33. Monitor the OBD STATUS for DTC P0404 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, then go to step 1 , and recheck. If the screen indicates, EXECUTING, keep the driving condition continually until a result comes on. If the screen indicates OUT OF CONDITION, go to step 31 and recheck.
  34. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__pcm-updating-and-substitution-for-testing) ).
  35. Do the EGR TEST in the INSPECTION MENU with the HDS.
  36. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0404 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#pgm-fi-system) ).

DTC P0406: EGR Valve Position Sensor Circuit High Voltage

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 109

Scheme 109: DTC P0406: EGR Valve Position Sensor Circuit High Voltage
Scheme 109: DTC P0406: EGR Valve Position Sensor Circuit High Voltage

Scheme 110

Scheme 110
Scheme 110
  1. Turn the ignition switch ON (II).
  2. Check the EGR VLS in the DATA LIST with the HDS. Is 4.88 V or more indicated? YES - Go to step 3. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect the EGR valve 6P connector.
  5. Turn the ignition switch ON (II).
  6. Measure voltage between EGR valve 6P connector terminals No. 2 and No. 3. Is there about 5 V? YES - Go to step 11 . NO - Go to step 7.
  7. Turn the ignition switch OFF.
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector A (73P).
  10. Check for continuity between PCM connector terminal A28 and EGR valve 6P connector terminal No. 2. Is there continuity? YES - Go to step 18 . NO - Repair open in the wire between the EGR valve and the PCM (A28), then go to step 13 .
  11. Turn the ignition switch OFF.
  12. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ).
  13. Reconnect all connectors.
  14. Turn the ignition switch ON (II).
  15. Reset the PCM with the HDS.
  16. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  17. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0406 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.
  18. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__pcm-updating-and-substitution-for-testing) ).
  19. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0406 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#pgm-fi-system) ).

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). If DTC P0651 is indicated at the same time as DTC P2413, troubleshoot DTC P0651 first, then recheck for P2413.

Scheme 111

Scheme 111: DTC P2413: EGR System Malfunction
Scheme 111: DTC P2413: EGR System Malfunction

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117

Scheme 118

Scheme 118
Scheme 118

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120
  1. Turn the ignition switch ON (II).
  2. Reset the PCM with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the EGR TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EGR valve and the PCM. NO - Go to step 5.
  5. Turn the ignition switch OFF.
  6. Turn the ignition switch ON (II).
  7. Check the EGR VLS in the DATA LIST with the HDS. Is about 0 V indicated? YES - Go to step 8. NO - Go to step 29 .
  8. Turn the ignition switch OFF.
  9. Disconnect the EGR valve 6P connector.
  10. Turn the ignition switch ON (II).
  11. Measure voltage between EGR valve 6P connector terminal No. 3 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 12.
  12. Turn the ignition switch OFF.
  13. Jump the SCS line with the HDS.
  14. Disconnect PCM connector A (73P).
  15. Check for continuity between PCM connector terminal A27 and EGR valve 6P connector terminal No. 3. Is there continuity? YES - Go to step 52 . NO - Repair open in the wire between the EGR valve and the PCM (A27), then go to step 45 .
  16. Turn the ignition switch OFF.
  17. Jump the SCS line with the HDS.
  18. Disconnect PCM connector A (73P).
  19. Check for continuity between EGR valve 6P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A42) and the EGR valve, then go to step 45 . NO - Go to step 20.
  20. Check for continuity between PCM connector terminal A42 and EGR valve 6P connector terminal No. 1. Is there continuity? YES - Go to step 21. NO - Repair open in the wire between the PCM (A42) and the EGR valve, then go to step 45 .
  21. Turn the ignition switch OFF.
  22. Disconnect the EGR valve 6P connector.
  23. Check for continuity between EGR valve 6P connector terminal No. 4 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A15) and the EGR valve, then go to step 45 . NO - Go to step 24.
  24. Check for continuity between PCM connector terminal A15 and EGR valve 6P connector terminal No. 4. Is there continuity? YES - Go to step 25. NO - Repair open in the wire between the PCM (A15) and the EGR valve, then go to step 45 .
  25. Check for continuity between EGR valve 6P connector terminal No. 6 and body ground. Is there continuity? YES - Go to step 26. NO - Repair open in the wire between the EGR valve and G101, then go to step 45 .
  26. Reconnect PCM connector A (73P).
  27. Connect the battery positive terminal to EGR valve 6P connector terminal No. 4 with a jumper wire.
  28. Start the engine and let it idle, then connect the battery negative terminal to EGR valve 6P connector terminal No. 6 with a jumper wire. Does the engine stall or run rough? YES - Go to step 52 . NO - Go to step 33 .
  29. Turn the ignition switch OFF.
  30. Disconnect the EGR valve 6P connector.
  31. At the sensor side, measure resistance between EGR valve 6P connector terminals No. 1 and No. 2. Is there continuity or resistance of 100 kohm or more? YES - Go to step 44 . NO - Go to step 32.
  32. Measure resistance between EGR valve 6P connector terminals No. 1 and No. 3. Is there 100 kohm or more? YES - Go to step 44 . NO - Go to step 33.
  33. Remove the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ) and the EGR pipe (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(/acura/mdx/i-2000-2006/remont/exhaust/#intake-manifold-and-exhaust-system) ).
  34. Clean the intake manifold EGR port with carburetor cleaner. Also, clean the passage inside the EGR valve with carburetor cleaner.
  35. Install the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ) and the EGR plate.
  36. Reconnect PCM connector A (73P).
  37. Reconnect the EGR valve 6P connector.
  38. Turn the ignition switch ON (II).
  39. Reset the PCM with the HDS.
  40. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  41. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  42. Do the EGR TEST in the INSPECTION MENU with the HDS. Is EGR system OK? YES - Go to step 49 . NO - Go to step 43.
  43. Turn the ignition switch OFF.
  44. Replace the EGR valve (see «EGR VALVE REPLACEMENT»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#egr-system) ).
  45. Turn the ignition switch ON (II).
  46. Reset the PCM with the HDS.
  47. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#idle-control-system__pcm-idle-learn-procedure) ).
  48. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  49. Test-drive the vehicle under load for about 10 minutes. Try to keep the engine speed in the 1,700-2,500 RPM range.
  50. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2413 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Go to step 51.
  51. Monitor the OBD STATUS for DTC P2413 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, then go to step 1 , and recheck. If the screen indicates EXECUTING, keep the driving condition continually until a result comes on. If the screen indicates OUT OF CONDITION, go to step 48 and recheck.
  52. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(/acura/mdx/i-2000-2006/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__pcm-updating-and-substitution-for-testing) ).
  53. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  54. Test-drive the vehicle under load for about 10 minutes. Try to keep the engine speed in the 1,700-2,500 RPM range.
  55. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2413 is indicated, check for poor connections or loose terminals at the EGR valve and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(/acura/mdx/i-2000-2006/remont/testing-diagnostics/#pgm-fi-system) ).

Scheme 121

Scheme 121: EGR Valve Replacement
Scheme 121: EGR Valve Replacement
  1. Remove the intake manifold cover and the ignition coil cover (see «IGNITION COIL REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/ignition-system/#ignition-system) ).
  2. Disconnect the EGR valve 6P connector (A).
  3. Remove the EGR valve (B).
  4. Install the valve in the reverse order of removal with a new gasket (C).
  5. Install the ignition coil cover and the intake manifold cover (see «IGNITION COIL REMOVAL/INSTALLATION»(/acura/mdx/i-2000-2006/remont/ignition-system/#ignition-system) ).
