Automatic Transmission Overhaul - s4xa Acura Integra III

APPLICATION

TRANSAXLE APPLICATIONS

IDENTIFICATION

Transaxle model and serial number are stamped on the transaxle. (Scheme 54) Model and serial number may be required when ordering replacement components.

Scheme 54

DESCRIPTION

Automatic transaxle provides 4 forward speeds and one reverse. Transaxle consists of clutches, mainshaft, countershaft, sub-shaft, shift control solenoid valves, lock-up control solenoid valves and lock-up torque converter. (Scheme 55)

Valve bodies consists of main valve body, secondary valve body, servo body, lock-up valve body and regulator valve body. Valve bodies are attached to torque converter housing. Transaxle shifting and torque converter lock-up are controlled by the Transmission Control Module (TCM).

The Throttle Valve (T.V.) is controlled by a throttle cable. Throttle cable adjustment is essential for proper operation of transaxle. Misadjustment not only affects the shift points but also the shift quality and lock-up clutch operation. If cable is adjusted too long, it will result in throttle pressure being too low for the amount of engine torque input into transaxle and may cause clutch slippage. A cable adjusted too short will result in too high throttle pressure which may cause harsh shifts, erratic shifts and torque converter hunting.

Scheme 55

OPERATION

When in "D" position in 3rd gear or "D4" position in 2nd, 3rd or 4th gear, torque converter lock-up exists and transaxle mainshaft rotates at the same speed as engine crankshaft. Under certain conditions, torque converter lock-up clutch is applied during deceleration when in 3rd and 4th gears. Torque converter lock-up is controlled by the TCM. The TCM receives various input signals and operates lock-up control solenoid valves. Operation of lock-up control solenoid valves controls the modulator pressure.

The TCM contains a grade logic control system which controls transaxle shifting while vehicle is ascending or descending on a slope or reducing vehicle speed. For more information on grade logic control system, see ACURA S4XA ELECTRONIC CONTROLS article.

The Throttle Valve (T.V.) is controlled by a throttle cable. If cable is adjusted too long, it will result in throttle pressure being too low for the amount of engine torque input into transaxle and may cause clutch slippage. A cable adjusted too short will result in too high throttle pressure which may cause harsh shifts, erratic shifts and torque converter hunting.

The TCM contains self-diagnostic system, which stores Diagnostic Trouble Code (DTC) if failure or problem exists in transaxle electronic control system. The DTC code can be retrieved to determine transaxle problem area. For information on electronic transaxle components, see ACURA S4XA ELECTRONIC CONTROLS article.

Transaxle is equipped with shift and key interlock systems. Shift interlock system prevents shift lever from being moved from "P" position unless brake pedal is depressed and accelerator pedal is in idle position. In case of a malfunction, shift lever can be released by placing ignition key in release slot near shift lever. Key interlock system prevents ignition key from being removed from ignition switch unless shift lever is in "P" position. For additional information on interlock systems, see ACURA/HONDA SHIFT INTERLOCK SYSTEMS article.

The A/T gear position indicator contains lights to indicate which position A/T gear position switch on shift lever is in. For information and testing of A/T gear position indicator, see ACURA S4XA ELECTRONIC CONTROLS article.

Shift lever has 7 positions. When shift lever is moved, manual valve on main valve body is moved by the shift cable. When certain transaxle gear combinations are engaged by clutches, power is transmitted from the mainshaft to the countershaft through the sub-shaft to provide different gears. Shift lever positions operate as follows.

"P" (Park)

Front wheels locked as parking pawl engages with parking gear on countershaft. All clutches are released. Neutral position switch, incorporated in A/T gear position switch, allows engine starting in this position.

"R" (Reverse)

Reverse selector engages with countershaft reverse gear and 4th gear clutch is applied. Backup light switch, incorporated in A/T gear position switch, allows back-up lights to operate.

"N" (Neutral)

All clutches are released. Neutral position switch, incorporated in A/T gear position switch, allows engine starting in this position.

"D4" (Drive/4th Gear)

Transaxle starts in 1st gear and upshifts automatically to 2nd, 3rd and 4th gears. Transaxle will downshift through 3rd, 2nd and 1st gears until vehicle stops. When in 2nd, 3rd or 4th gear in "D4" position, TCM sends signal to operate torque converter lock-up.

"D" (Drive/3rd Gear)

Transaxle starts off in 1st gear and upshifts automatically to 2nd gear and 3rd gear. On deceleration, transaxle will downshift through 2nd gear to 1st gear. When in 3rd gear in "D" position, TCM sends signal to operate torque converter lock-up.

"2" (Second Gear)

Transaxle starts off and remains in 2nd gear for engine braking and better traction.

"1" (First Gear)

Transaxle starts off and remains in 1st gear for engine braking.

LUBRICATION & ADJUSTMENTS

See appropriate AUTOMATIC TRANSMISSION SERVICING article in TRANSMISSION SERVICING.

AXLE SHAFTS

See appropriate AXLE SHAFTS article in AXLE SHAFTS & TRANSFER CASES.

OIL COOLER FLUSHING

1. Attach Oil Cooler Flusher (J38405-A) to oil cooler lines. (Scheme 56) Fill oil cooler flusher tank 2/3 full with Flushing Fluid (J35944-20). DO NOT use any other flushing fluid.
2. Ensure water and air valves on oil cooler flusher are off. Apply 80-120 psi (550-829 kPa) air pressure to oil cooler flusher. Turn oil cooler flusher water valve on so water will flow through oil cooler for 10 seconds. Shut water valve off. Replace oil cooler if water will not flow through oil cooler.
3. Depress and hold mixing trigger on oil cooler flusher downward. Turn water valve on and flush oil cooler for 2 minutes. Turn air valve on for 5 seconds every 15-20 seconds to create a surging action.
4. Turn water valve off. Release mixing trigger. Disconnect oil cooler flusher and reverse hoses so oil cooler can be flushed in the opposite direction.
5. Repeat steps 2 and 3. Turn water valve off. Release mixing trigger. Turn water valve on and rinse oil cooler for at least one minute. Once oil cooler is flushed in both directions, turn water off. Turn air valve on for 2 minutes or until no moisture is visible from drain hose. CAUTION: Ensure no moisture exists in oil cooler, as it can damage transaxle.
6. Turn air off. Disconnect oil cooler flusher. Reconnect inlet line on oil cooler. Once transaxle is installed, attach drain hose on return line and place in oil container. Ensure transaxle is in "P" position. Fill transaxle with Dexron-II ATF.
7. Start engine and operate for about 30 seconds or until one quart (.9L) of ATF is discharged from return line. Turn engine off. Remove drain hose. Reinstall return line. Fill transaxle to proper level.

Scheme 56

TROUBLE SHOOTING

Transaxle malfunctions may be caused by poor engine performance, improper adjustments, or failure of hydraulic, mechanical or electronic components. Always begin by checking fluid level, fluid condition and cable adjustments. Perform road test to determine if problem has been corrected. If problem still exists, several tests must be performed on transaxle. See TESTING .

Excessive Drag In Transaxle

1. Binding Oil Pump

Excessive Idle Vibration

1. Defective Torque Converter
2. Incorrect Idle RPM

Excessive Vibration (RPM Related)

1. Torque Converter Not Fully Seated In Oil Pump

Flares On 1-2 Upshift

1. Clutch Pressure Control Valve Stuck
2. Throttle Valve "B" Stuck
3. Throttle Valve (T.V.) Cable Adjusted Too Long

Flares On 2-3 Upshift

1. Clutch Pressure Control Valve Stuck
2. Defective Seal Rings Or Guide
3. Throttle Valve "B" Stuck
4. Throttle Valve (T.V.) Cable Adjusted Too Long
5. 2-3 Orifice Control Valve Stuck

Flares On 3-4 Upshift

1. Clutch Pressure Control Valve Stuck
2. Defective Seal Rings Or Guide
3. Orifice Control Valve Stuck
4. Throttle Valve "B" Stuck
5. Throttle Valve (T.V.) Cable Adjusted Too Long

Gear Whine That Changes With Shifts

1. Defective 1st Clutch
2. Defective 3rd Gears
3. Mainshaft Worn Or Damaged

Gear Whine That Changes With Speed

1. Defective Differential Gears
2. Shift Fork Bent

Harsh Downshift At Closed Throttle

1. Clutch Pressure Control Valve Stuck
2. Throttle Valve "B" Stuck
3. Throttle Valve (T.V.) Cable Adjusted Too Short

Harsh Kickdown Shifts

1. Clutch Pressure Control Valve Stuck
2. Throttle Valve "B" Stuck
3. Throttle Valve (T.V.) Cable Adjusted Too Short
4. 3-2 Kickdown Valve Stuck
5. 4-3 Kickdown Valve Stuck
6. 4th Exhaust Valve Stuck

Harsh Shift When Manually Shifting To "1"

1. Defective 1st-Hold Accumulator

Harsh Upshifts & Downshifts

1. Check Balls Missing
2. Clutch Pressure Control Valve Stuck
3. Improper Type ATF
4. Incorrect Clutch Clearance
5. Orifice Control Valve Stuck
6. Throttle Valve "B" Stuck
7. Throttle Valve (T.V.) Cable Adjusted Too Short
8. 2-3 Orifice Control Valve Stuck
9. 3-2 Kickdown Valve Stuck
10. 4-3 Kickdown Valve Stuck

Harsh 1-2 Upshift

1. Clutch Pressure Control Valve Stuck
2. Defective 2nd Clutch
3. Throttle Valve "B" Stuck
4. Throttle Valve (T.V.) Cable Adjusted Too Short

Harsh 2-1 Kickdown Shift

1. Defective One-Way Clutch

Harsh 2-3 Upshift

1. Clutch Pressure Control Valve Stuck
2. Defective 3rd Clutch
3. Throttle Valve "B" Stuck
4. Throttle Valve (T.V.) Cable Adjusted Too Short
5. 2-3 Orifice Control Valve Stuck

Harsh 3-4 Upshift

1. Clutch Pressure Control Valve Stuck
2. Defective 4th Clutch
3. Orifice Control Valve Stuck
4. Throttle Valve "B" Stuck
5. Throttle Valve (T.V.) Cable Adjusted Too Short

Lock-Up Clutch Does Not Lock-Up Smoothly

1. Defective Torque Converter
2. Lock-Up Control Valve Stuck
3. Lock-Up Shift Valve Stuck

Lock-Up Clutch Does Not Operate Properly

1. Improperly Adjusted Throttle Valve (T.V.) Cable
2. Lock-Up Control Valve Stuck
3. Lock-Up Shift Valve Stuck
4. Lock-Up Timing Valve "B" Stuck
5. Modulator Valve Stuck
6. Throttle Valve "B" Stuck
7. Torque Converter Check Valve Stuck

No Engine Braking In "1"

1. Defective 1st-Hold Clutch

Noise From Transaxle In All Gears

1. Defective Oil Pump
2. Defective Torque Converter

Noise From Transaxle With Wheels Rolling

1. Damaged Reverse Gears
2. Defective Differential Gears
3. Reverse Selector Hub Installed Upside Down

Popping Noise When Taking Off In "R"

1. Damaged Reverse Gears
2. Shift Fork Bent
3. Worn Reverse Selector

Ratcheting Noise When Shifting To "R"

1. Damaged Reverse Gears
2. Defective Oil Pump
3. Pressure Regulator Stuck
4. Shift Fork Bent
5. Worn Reverse Selector

Ratcheting Noise When Shifting From "R" To "P" Or "N"

1. Damaged Reverse Gears
2. Damaged 4th Gears
3. Shift Fork Bent
4. Worn Reverse Selector

Shifts Erratically

1. Modulator Valve Stuck
2. Throttle Valve (T.V.) Cable Adjusted Too Short
3. 3-2 Kickdown Valve Stuck

Slips In All Gears

1. Defective Oil Pump
2. Fluid Strainer Clogged
3. Pressure Regulator Stuck

Slips In 1st Gear

1. Defective One-Way Clutch
2. Defective 1st Clutch Or 1st Accumulator
3. Feed Pipe "O" Ring Damaged

Slips In Reverse

1. Defective 4th Clutch Or 4th Accumulator
2. Feed Pipe "O" Ring Damaged
3. Servo Valve Stuck

Slips In 2nd Gear

1. Clutch Pressure Control Valve Stuck
2. Defective Seal Rings Or Guide
3. Defective 2nd Clutch Or 2nd Accumulator
4. 2-3 Shift Valve Stuck

Slips In 3rd Gear

1. Clutch Pressure Control Valve Stuck
2. Defective Seal Rings Or Guide
3. Defective 3rd Clutch Or 3rd Accumulator
4. 3-4 Shift Valve Stuck

Slips In 4th Gear

1. Clutch Pressure Control Valve Stuck
2. Defective 4th Clutch Or 4th Accumulator
3. Feed Pipe "O" Ring Damaged

Upshifts Late

1. Modulator Valve Stuck

Vehicle Locks In "R"

1. Parking Brake Lever Installed Upside Down
2. Shift Fork Retaining Bolt Not Installed

Vehicle Moves In All Gears Except "R"

1. Defective Or Improperly Adjusted Shift Cable
2. Defective Or Worn Reverse Gears
3. Defective 4th Clutch
4. Servo Control Valve Stuck
5. Servo Valve Stuck
6. Shift Fork Bent
7. Worn Reverse Selector

Vehicle Moves In All Gears Except "2"

1. Defective Seal Rings Or Guide
2. Defective 2nd Clutch Or 2nd Accumulator

Vehicle Moves In "N"

1. Defective Or Improperly Adjusted Shift Cable
2. Defective 1st, 2nd, 3rd Or 4th Clutch
3. Incorrect Gear Or Clutch Clearance

Vehicle Moves In "R" & "2" Only

1. Defective One-Way Clutch
2. Defective 1st Clutch Or 1st Accumulator
3. Feed Pipe "O" Ring Damaged

Vehicle Will Not Move

1. Defective Oil Pump
2. Defective Or Improperly Adjusted Shift Cable
3. Fluid Strainer Clogged
4. Pressure Regulator Stuck

Vehicle Will Not Move In "D" Or "D4"

1. One-Way Clutch Installed Upside Down

Will Not Downshift To 1st Gear

1. Defective 1st-Hold Clutch
2. 1-2 Shift Valve Stuck

Will Not Shift Into 4th Gear When In "D4"

1. Defective Or Improperly Adjusted Shift Cable
2. 3-4 Shift Valve Stuck
3. 4th Accumulator Stuck
4. 4th Exhaust Valve Stuck

Will Not Upshift (Stays In 1st Gear)

1. Clutch Pressure Control Valve Stuck
2. Modulator Valve Stuck
3. 1-2 Shift Valve Stuck

TESTING

ROAD TEST

Note. If shift lever cannot be moved from "P" position with brake pedal depressed and accelerator at idle position, check shift interlock system. See ACURA/HONDA SHIFT INTERLOCK SYSTEMS article.

1. Warm engine to normal operating temperature. Apply parking brake, and block wheels. Start engine. Move shift lever to "D4" position while depressing brake pedal. Depress accelerator pedal and release it suddenly. Engine should not stall.
2. Repeat step 1 with shift lever in "D3" position. Ensure engine does not stall. Manufacturer recommends monitoring of throttle position sensor voltage when performing road test to ensure proper throttle opening for verifying shift points and lock-up of torque converter.
3. Using Backprobe Adapter Set (07SAZ-001000A), connect backprobe adapter to TCM harness connector terminals A13 or A26 and B4. Connect DVOM to backprobe adapter. (Scheme 57)
4. Road test vehicle on a flat road surface with transaxle in "D4" position. Check that shift points occur at approximate speeds. Check for abnormal noise and clutch slippage. See «CLUTCH APPLICATION»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table for clutch engagement. Ensure upshift and downshift points, and lock-up of torque converter are correct in relation to TP sensor voltage or throttle opening and vehicle speed. (Scheme 58) CAUTION: DO NOT downshift from "D4" or "D3" to "2" or "1" position at speeds greater than 100 MPH. Transaxle damage will occur.
5. Place transaxle in "D4" position. Accelerate to about 35 MPH so transaxle is in 4th gear, then shift from "D4" to "2" position. Vehicle should immediately begin slowing down from engine braking.
6. Place transaxle in "1" position. Accelerate from a full stop at full throttle. Check for abnormal noise or clutch slippage. Upshifts should not occur with shift lever in this position.
7. Place transaxle in "2" position. Accelerate from a full stop at full throttle. Check for abnormal noise or clutch slippage. Upshift or downshifts should not occur with shift lever in this position.
8. Place transaxle in "R" position. Accelerate from full stop at full throttle. Check for abnormal noise or clutch slippage.
9. Position vehicle on a slope. Apply parking brakes. Place transaxle in Park. Release parking brake. Vehicle should not move. If vehicle moves, check for defective shift cable or parking components.

CLUTCH APPLICATION

Scheme 57

Scheme 58

TORQUE CONVERTER STALL SPEED TEST

1. Apply parking brake and block all wheels. Connect tachometer. Start engine. Ensure A/C is off. Warm engine to normal operating temperature. Place shift lever in "2" position.
2. Fully depress brake pedal. Fully depress accelerator for 6-8 seconds and note engine speed. This is torque converter stall speed.
3. Allow transaxle to cool for 2 minutes. Repeat test procedure with shift lever in "D4", "1" and "R" positions.
4. Torque converter stall speed should be the same in "D4", "2", "1" and "R" positions and within specification. See «TORQUE CONVERTER STALL SPEED SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. If torque converter stall speed does not fall within specification, for possible causes, see «TORQUE CONVERTER STALL SPEED TROUBLE SHOOTING»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.

TORQUE CONVERTER STALL SPEED SPECIFICATIONS

TORQUE CONVERTER STALL SPEED TROUBLE SHOOTING

Pressure Test Preparation

Ensure transaxle fluid level is correct. Warm engine to normal operating temperature. Apply parking brake, and block rear wheels. Raise and support vehicle so front wheels can rotate.

Line Pressure Test

1. With engine off, remove pressure tap plug from line pressure tap on transaxle. (Scheme 59) Attach Pressure Gauge Set (07406-0020400) to line pressure tap using NEW seal washer. Tighten hose fitting to 13 ft. lbs. (18 N.m).
2. With shift lever in "P" or "N" position, start and operate engine at 2000 RPM. Note line pressure. Line pressure should be within specification. See «HYDRAULIC PRESSURE TEST SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.
3. If line pressure is not within specification, see «HYDRAULIC PRESSURE TROUBLE SHOOTING»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. Shut engine off.
4. Using NEW seal washer, install and tighten pressure tap plug to specification. See «TORQUE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__torque-specifications).

Clutch Pressure Test

1. Clutch pressure should be checked at each clutch pressure tap on transaxle. (Scheme 59)
2. With engine off, remove pressure plug from appropriate clutch pressure tap on transaxle. (Scheme 59) Attach Pressure Gauge Set (07406-0020400) to appropriate pressure tap using NEW seal washer. Tighten hose fitting to 13 ft. lbs. (18 N.m). NOTE: On some applications clutch pressure may vary with position of throttle control lever on transaxle. Throttle Valve (T.V.) cable is connected to throttle control lever on transaxle. T.V. cable may need to be disconnected from throttle control lever for some tests. Ensure shift lever is in proper position when checking clutch pressures.
3. Start and operate engine at 2000 RPM. Note clutch pressure reading with shift lever in proper location. Refer to specifications in «HYDRAULIC PRESSURE TEST SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.
4. Clutch pressure should be within specification. If not within specification, see «HYDRAULIC PRESSURE TROUBLE SHOOTING»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. Shut engine off.
5. Using NEW seal washer, install and tighten pressure tap plug to specification. See «TORQUE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__torque-specifications).

Clutch Low/High Pressure Test

1. Clutch low/high pressure is tested at 2nd, 3rd and 4th clutch pressure taps on transaxle. (Scheme 59) Disconnect Throttle Valve (T.V.) cable from throttle control lever on transaxle. NOTE: When disconnecting T.V. cable, unhook cable from throttle control lever. DO NOT loosen lock nuts used for cable adjustment.
2. With engine off, remove pressure tap plug from appropriate clutch pressure tap on transaxle. Attach Pressure Gauge Set (07406-0020400) to appropriate pressure tap using NEW seal washer. Tighten hose fitting to 13 ft. lbs. (18 N.m).
3. Start engine and allow to idle. Move shift lever to "D4" position. Slowly increase engine speed until pressure is indicated on pressure gauge. Release throttle. Allow engine to idle and note clutch low pressure reading.
4. With engine idling, lift throttle control lever on transaxle upward approximately 1/2 the distance of throttle control lever travel. Increase engine speed and note highest pressure reading. This is the clutch high pressure.
5. Repeat procedure on remaining clutches. The clutch low/high pressure should be within specification. See «HYDRAULIC PRESSURE TEST SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. If low/high pressure is not within specification, see «HYDRAULIC PRESSURE TROUBLE SHOOTING»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.
6. Shut engine off. Remove pressure gauge set. Using NEW seal washer, install and tighten pressure tap plug to specification. See «TORQUE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__torque-specifications). Reconnect T.V. cable.

Throttle "B" Pressure Test

1. Disconnect Throttle Valve (T.V.) cable from throttle control lever/drum on transaxle. NOTE: When disconnecting T.V. cable, unhook cable from throttle control lever. DO NOT loosen lock nuts used for cable adjustment.
2. With engine off, remove pressure tap plug from throttle "B" pressure tap on transaxle. (Scheme 59)
3. Attach Pressure Gauge Set (07406-0020400) to throttle "B" pressure tap using NEW seal washer. Tighten hose fitting to 13 ft. lbs. (18 N.m).
4. Start and operate engine at 1000 RPM with shift lever in "D" or "D4" position. Note pressure with throttle control lever closed (released position). Throttle "B" pressure should be within specification. See «HYDRAULIC PRESSURE TEST SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.
5. Lift throttle control lever on transaxle to fully open position with engine at 1000 RPM. Note throttle "B" pressure reading.
6. Throttle "B" pressure should be within specification. See «HYDRAULIC PRESSURE TEST SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. If pressure is not within specification, see «HYDRAULIC PRESSURE TROUBLE SHOOTING»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. Shut engine off. Remove pressure gauge set.
7. Using NEW seal washer, install and tighten pressure tap plug to specification. See «TORQUE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__torque-specifications). Reconnect T.V. cable.

HYDRAULIC PRESSURE TEST SPECIFICATIONS

HYDRAULIC PRESSURE TROUBLE SHOOTING

Scheme 59

ELECTRICAL COMPONENTS

See ACURA S4XA ELECTRONIC CONTROLS article.

TRANSAXLE

See appropriate AUTOMATIC TRANSMISSION REMOVAL article in TRANSMISSION SERVICING.

TORQUE CONVERTER

Torque converter consists of pump, turbine and stator assembled as a unit. Torque converter cannot be serviced and must be replaced if defective.

Note. For torque converter stall speed test, see TORQUE CONVERTER STALL SPEED TEST under TESTING.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Remove bolts, right side cover protector, right side cover and gasket. (Scheme 60) Install Mainshaft Holder (07GAB-PF50101) on mainshaft to secure mainshaft. (Scheme 61)
2. Engage parking pawl with parking gear. Align hole in sub-shaft 1st gear with hole in transaxle housing. Install pin in sub-shaft 1st gear and transaxle housing to prevent sub-shaft 1st gear from rotating. (Scheme 62)
3. Using hammer and chisel, cut lock tabs on countershaft and sub-shaft lock nuts. Pry lock tabs on mainshaft lock nut upward. Remove all lock nuts and spring washers from countershaft, mainshaft and sub-shaft. (Scheme 62) NOTE: Mainshaft and countershaft lock nuts contain left-hand threads.
4. Remove mainshaft holder once all lock nuts are removed. Remove pin securing sub-shaft 1st gear. Remove 1st clutch assembly, mainshaft 1st gear, thrust washer and mainshaft 1st gear collar from mainshaft. (Scheme 60)
5. Remove sub-shaft 1st gear. Remove parking pawl. Using puller, remove parking gear, one-way clutch and countershaft 1st gear from countershaft. Remove needle bearing and countershaft 1st gear collar from countershaft. (Scheme 60)
6. Remove parking brake lever and parking brake lever spring from control shaft. Remove throttle control lever and throttle control lever spring from throttle control shaft. (Scheme 60)
7. Remove dipstick, vehicle speed sensor, joint bolts and cooler pipes. Remove mount bracket from transaxle housing. (Scheme 64) Remove transaxle housing bolts and transaxle hanger.
8. Align spring pin on control shaft with groove in transaxle housing by rotating control shaft. Using Puller (07HAC-PK4010A), remove transaxle housing. (Scheme 63) Remove gasket for transaxle housing.
9. Remove countershaft reverse gear collar, needle bearing and countershaft reverse gear from countershaft. (Scheme 64) Remove bolt and bolt lock from reverse shift fork. Remove reverse shift fork with reverse selector from countershaft.
10. Remove countershaft and mainshaft together from torque converter housing. Remove differential assembly. Remove bolts, reverse idler gear shaft holder, reverse idler gear and needle bearing from transaxle housing (if necessary).
11. Remove oil feed pipes from servo body, servo detent base, accumulator cover, lock-up valve body and main valve body. (Scheme 65) Remove bolts and accumulator cover. Remove bolts, fluid strainer and servo detent base.
12. Remove bolts, servo body and separator plate. (Scheme 65) Remove bolt, secondary valve body and separator plate. DO NOT lose check balls in secondary valve body.
13. Remove bolts, lubrication plate, lock-up valve body and separator plate. Remove regulator valve body. Remove stopper shaft and stator shaft. Remove detent spring from detent arm. Remove control shaft from torque converter housing.
14. Remove detent arm shaft and detent arm from main valve body. Remove bolts and main valve body. DO NOT lose check balls in main valve body. (Scheme 65)
15. Remove oil pump driven gear shaft and oil pump gears. (Scheme 65) Remove separator plate for main valve body and dowel pins. Remove magnet. Remove lock-up control solenoid valve assembly (if necessary).

Scheme 64

Scheme 65

MAIN VALVE BODY

Disassembly

Disassemble main valve body. (Scheme 66) Use care when removing valve caps or spring seat, as they are under spring pressure.

Cleaning & Inspection

1. Clean components with solvent and dry with compressed air. Replace main valve body if any parts are worn or damaged.
2. Ensure all valves slide freely in their bores. If valves do not slide freely, polish burrs or rough areas using No. 600 sandpaper soaked in ATF for at least 30 minutes. Thoroughly clean main valve body and components if polishing was needed.
3. Ensure spring free length is within specification. See «SPRING SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. Replace springs if not within specification.

Note. Oil pump clearance must be checked in main valve body. See OIL PUMP .

Reassembly

Coat all components and bores with Dexron-II ATF. To reassemble, reverse disassembly procedure. Ensure all components are installed in correct location. (Scheme 66)

SPRING SPECIFICATIONS

Scheme 66

Note direction of oil pump gear installation in main valve body. Remove oil pump driven gear shaft and oil pump gears from main valve body (if not previously removed).

1. Clean components with solvent and dry with compressed air. Inspect components and replace if damaged.
2. Install oil pump gears in main valve body. Ensure chamfered and grooved side of oil pump driven gear is facing upward (toward separator plate side of main valve body).
3. Place straightedge across main valve body surface. Using feeler gauge, measure thrust clearance between oil pump driven gear and straightedge. (Scheme 67) Replace oil pump gears and/or main valve body if thrust clearance is not within specification. See «OIL PUMP SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.
4. Install oil pump driven gear shaft in oil pump driven gear. Using feeler gauge, measure side clearance of both gears between tip of gear teeth and main valve body. (Scheme 67) Replace oil pump gears and/or main valve body if side clearance is not within specification. See «OIL PUMP SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.

OIL PUMP SPECIFICATIONS

Coat components with Dexron-II ATF. To reassemble, reverse disassembly procedure. Ensure chamfered and grooved side of oil pump driven gear is facing of oil pump driven gear faces upward (toward separator plate side of main valve body).

Scheme 67

REGULATOR VALVE BODY

Note direction of valve cap installation before removing from regulator valve body. Hold regulator spring cap down, and remove stopper bolt. Slowly remove regulator spring cap and components from regulator valve body. (Scheme 68)

1. Clean components with solvent and dry with compressed air. Replace regulator valve body assembly if any parts are worn or damaged.
2. Ensure all valves slide freely in their bores. If valves do not slide freely, polish burrs or rough areas using No. 600 sandpaper soaked in ATF for at least 30 minutes. Thoroughly clean regulator valve body and components if polishing was needed.
3. Ensure spring free length is within specification. See «SPRING SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table under MAIN VALVE BODY. Replace springs if not within specification.

Coat all components and bores with Dexron-II ATF. To reassemble, reverse disassembly procedure. Ensure all components are installed in correct location. (Scheme 68) Tighten stopper bolt to specification. See TORQUE SPECIFICATIONS.

Scheme 68

Note direction of valve cap installation before removing from lock-up valve body. Disassemble lock-up valve body. (Scheme 69) Use care when removing valve caps, as they are under spring pressure.

1. Clean components with solvent and dry with compressed air. Replace lock-up valve body assembly if any parts are worn or damaged.
2. Ensure all valves slide freely in their bores. If valves do not slide freely, polish burrs or rough areas using No. 600 sandpaper soaked for 30 minutes in ATF. Thoroughly clean lock-up valve body and components if polishing was needed.
3. Ensure spring free length is within specification. See «SPRING SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table under MAIN VALVE BODY. Replace springs if not within specification.

Coat all components and bores with Dexron-II ATF. To reassemble, reverse disassembly procedure. (Scheme 69)

Scheme 69

SECONDARY VALVE BODY

Disassemble secondary valve body. (Scheme 70) Use care when removing valve caps or spring seats, as they are under spring pressure.

1. Clean components with solvent and dry with compressed air. Replace secondary valve body assembly if any parts are worn or damaged.
2. Ensure all valves slide freely in their bores. If valves do not slide freely, polish burrs or rough areas using No. 600 sandpaper soaked for 30 minutes in ATF. Thoroughly clean secondary valve body and components if polishing was needed.
3. Ensure spring free length is within specification. See «SPRING SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table under MAIN VALVE BODY. Replace springs if not within specification.

Coat all components and bores with Dexron-II ATF. To reassemble, reverse disassembly procedure. Install NEW filter. Ensure all components are installed in correct location. (Scheme 70)

Scheme 70

Disassemble servo body. (Scheme 71) DO NOT loosen or remove throttle adjusting bolt.

1. Clean components with solvent and dry with compressed air. Replace servo body assembly if any parts are worn or damaged. Ensure all valves slide freely in their bores.
2. Ensure spring free length is within specification. See «SPRING SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table under MAIN VALVE BODY. Replace springs if not within specification.

Coat all components and bores with Dexron-II ATF. To reassemble, reverse disassembly procedure using NEW "O" rings. Tighten throttle cam stopper bolt to specification. See TORQUE SPECIFICATIONS .

Scheme 71

Remove snap ring, 1st-hold accumulator cover, "O" ring, accumulator spring and 1st-hold accumulator piston from right side cover. (Scheme 60)

Clean components with solvent and dry with compressed air. Replace components if worn or damaged. Ensure accumulator spring free length is 2.823" (71.70 mm). Replace accumulator spring if not within specification.

Coat all components and bores with Dexron-II ATF. To reassemble, reverse disassembly procedure using NEW "O" rings.

Note location of mainshaft components. (Scheme 72) Remove mainshaft components.

Clean components with solvent and dry with compressed air. Inspect splines for excessive wear and bearing surfaces for scoring or wear. Inspect all bearings for galling and rough movement.

Scheme 72

Note. Mainshaft 2nd gear-to-3rd gear clearance must be checked during reassembly.

1. To check mainshaft 2nd gear-to-3rd gear clearance, install proper components, except "O" rings and mainshaft 4th gear on mainshaft. (Scheme 73)
2. Install used mainshaft lock nut on mainshaft. Tighten mainshaft lock nut to 22 ft. lbs. (30 N.m). Hold mainshaft 2nd gear against 2nd clutch.
3. Using feeler gauge, measure clearance between mainshaft 2nd gear and mainshaft 3rd gear. (Scheme 74) If mainshaft 2nd gear-to-3rd gear clearance is not.002-.005" (.05-.13 mm), replace thrust washer, located between mainshaft 2nd gear and 2nd clutch. Different thickness thrust washers are available. See «THRUST WASHER SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. Replace thrust washer and recheck mainshaft 2nd gear-to-3rd gear clearance.
4. Once correct thickness thrust washer is obtained, lubricate all components with Dexron-II ATF. Reassemble mainshaft.
5. Ensure thrust needle bearings are installed with unrolled edge of bearing retainer facing washer. (Scheme 72) Before installing NEW "O" rings on mainshaft, wrap splines with tape.

THRUST WASHER SPECIFICATIONS

Scheme 73

Scheme 74

COUNTERSHAFT

Note. Reverse selector hub is press-fit on countershaft. Countershaft must be pressed from reverse selector hub.

1. Note location of countershaft components. (Scheme 64) Remove all components from countershaft down to the reverse selector hub.
2. Place countershaft in hydraulic press while supporting countershaft 4th gear. Threaded end of countershaft must be facing upward (toward ram of press). Place a protective cap between hydraulic press and countershaft to prevent damage to countershaft.
3. Press countershaft from reverse selector hub and countershaft 4th gear. Separate remaining components from countershaft. (Scheme 64)

Clean components with solvent and dry with compressed air. Inspect splines for excessive wear. Check bearing surfaces for scoring or wear. Inspect all needle bearings for galling and rough movement.

Note. Countershaft 2nd gear clearance must be checked during reassembly.

1. To check countershaft 2nd gear clearance, install all components on countershaft up to the reverse selector hub. (Scheme 64) DO NOT install "O" rings on countershaft at this time.
2. Install reverse selector hub on countershaft in proper direction. Support countershaft in press. Press reverse selector hub onto countershaft.
3. Install countershaft reverse gear collar on countershaft. (Scheme 64) DO NOT install reverse selector, countershaft reverse gear and needle bearing on countershaft at this time.
4. Install transaxle housing bearing on countershaft. Install countershaft 1st gear collar, needle bearing and countershaft 1st gear with one-way clutch and parking gear on countershaft. (Scheme 60)
5. Install spring washer and used countershaft lock nut on countershaft. Tighten countershaft lock nut to 22 ft. lbs. (30 N.m).
6. Using feeler gauge, measure countershaft 2nd gear clearance between distance collar and countershaft 2nd gear. (Scheme 75) Measure countershaft 2nd gear clearance in 3 areas. Determine the average of the measurements. Countershaft 2nd gear clearance should be.004-.007" (.10-.18 mm).
7. If countershaft 2nd gear clearance is not within specification, install different length distance collar between countershaft 2nd gear and countershaft 4th gear and recheck clearance. See «DISTANCE COLLAR SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.
8. If shortest distance collar is installed and clearance still exceeds specification, check components for wear. During final reassembly, lubricate all components with Dexron-II ATF.
9. Before installing NEW "O" rings on countershaft, wrap splines with tape. Ensure NEW "O" rings are installed on countershaft.
10. Ensure reverse selector hub is installed on countershaft in proper direction. (Scheme 64) Ensure thrust needle bearings and needle bearings are installed with unrolled edge of bearing retainer facing washer surface.

DISTANCE COLLAR SPECIFICATIONS

Scheme 75

1. To separate parking gear from countershaft 1st gear, hold countershaft 1st gear with parking gear facing upward. Rotate parking gear counterclockwise and remove from countershaft 1st gear.
2. Note direction of one-way clutch installation in countershaft 1st gear. To remove one-way clutch from countershaft 1st gear, using screwdriver, gently pry between one-way clutch and countershaft 1st gear.

Clean components with solvent and dry with compressed air. Inspect components for damage.

1. Lubricate all components with Dexron-II ATF. Install one-way clutch in countershaft 1st gear with large flange area on one-way clutch toward countershaft 1st gear. (Scheme 76)
2. Install parking gear. To check one-way clutch operation, hold countershaft 1st gear with parking gear facing upward. Ensure parking gear rotates freely counterclockwise.

Scheme 76

1. Note sub-shaft and components. (Scheme 64) Remove oil guide cap from transaxle housing by using hammer and driver and tapping on end of sub-shaft. Remove sub-shaft, sub-shaft 4th gear, 1st-hold clutch and components.
2. If removing needle bearing from transaxle housing, remove needle bearing stopper bolt and needle bearing stopper. Using hammer and drift, tap needle bearing from transaxle housing.
3. If removing transaxle housing bearing, expand snap ring. Using press, press bearing from transaxle housing. Remove snap ring (if necessary).

1. Clean components with solvent and dry with compressed air. Inspect splines on sub-shaft for excessive wear and bearing surfaces for scoring or wear.
2. Inspect all needle bearings for galling and rough movement. Inspect sub-shaft 4th gear for damage.

1. Lubricate all components with Dexron-II ATF. If installing needle bearing in transaxle housing, use press, press needle bearing into transaxle housing.
2. Install needle bearing stopper. Tighten needle bearing stopper bolt to specification. See «TORQUE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__torque-specifications) .
3. If installing transaxle housing bearing in transaxle housing, expand snap ring. Using press, press bearing part way into transaxle housing. CAUTION: Ensure transaxle housing bearing is installed with groove facing toward outside of transaxle housing so snap ring will engage with bearing.
4. Release snap ring. Continue pressing bearing into transaxle housing until snap ring engages in bearing. Ensure snap ring is fully seated.
5. Before installing "O" rings on sub-shaft, wrap splines with tape. Use NEW "O" rings on sub-shaft. Reassemble sub-shaft.
6. Ensure thrust needle bearings are installed with unrolled edge of bearing retainer facing washer. Install NEW oil guide cap.

1. Remove snap ring, clutch end plate, clutch discs and clutch plates. (Scheme 77) Note direction of disc spring installation. Remove disc spring.
2. Using spring compressor, compress return spring. Remove snap ring. Release and remove spring compressor. Remove spring retainer and return spring.
3. Wrap shop towel around clutch drum. Apply light air pressure to oil passage on clutch drum to remove clutch piston. Remove "O" rings.

1. Clean metal components with solvent and dry with compressed air. Ensure check valve on rear of clutch piston (except 1st-hold clutch) is thoroughly cleaned and secured tightly on clutch piston.
2. Inspect components for damage. Replace as necessary. Ensure no rough edges exist on "O" ring sealing areas.

1. Lubricate all components with Dexron-II ATF. Install NEW "O" rings. Install clutch piston in clutch drum. Slightly rotate clutch piston back and forth during installation to prevent damaging "O" rings. CAUTION: DO NOT apply excessive force on clutch piston, or "O" rings will be damaged.
2. Install return spring and spring retainer in clutch drum. Place snap ring on spring retainer. Using spring compressor, compress return spring. Install snap ring. Remove spring compressor. CAUTION: Disc spring on 2nd clutch is opposite all other clutch assemblies. Ensure clutch discs are soaked in Dexron-II ATF for at least 30 minutes before installing.
3. Install disc spring. Ensure disc spring is installed in proper direction. (Scheme 77)
4. Alternately install clutch plates and clutch discs starting with clutch plate. Install clutch end plate with flat side toward clutch disc. Install snap ring.
5. Using dial indicator, measure clutch clearance between clutch end plate and top clutch disc. (Scheme 78) Zero dial indicator with clutch end plate lowered. Lift clutch end plate upward against snap ring. Distance measured is clutch clearance.
6. Measure clutch clearance at 3 different locations. Clutch clearance should be within specification. See «CLUTCH CLEARANCE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.
7. If clutch clearance is not within specification, install different thickness clutch end plate. See «CLUTCH END PLATE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table.

Note. If thickest clutch end plate is installed and clutch clearance still exceeds specification, replace clutch discs and clutch plates.

CLUTCH CLEARANCE SPECIFICATIONS

CLUTCH END PLATE SPECIFICATIONS

Scheme 77

Scheme 78

1. Remove countershaft bearing from torque converter housing using slide hammer (if necessary). Remove oil guide plate from torque converter housing. (Scheme 65)
2. Remove mainshaft bearing and oil seal using hammer and driver. Using hammer and drift, tap differential oil seal from torque converter housing.

Clean components with solvent and dry with compressed air. Inspect torque converter housing for cracks and damage in bearing areas. Replace torque converter housing if damaged.

1. Coat components with Dexron-II ATF. To install mainshaft bearing, using hammer and driver, drive mainshaft bearing in torque converter housing until bearing bottoms in torque converter housing.
2. Using hammer and oil seal installer, install mainshaft oil seal in torque converter housing. Oil seal should be flush with surface of torque converter housing.
3. To install countershaft bearing, install NEW oil guide plate in countershaft bearing bore of torque converter housing. Ensure oil guide plate is installed with tab in center facing upward (away from torque converter housing surface). (Scheme 65)
4. Using hammer and driver, drive countershaft bearing into torque converter housing. Ensure surface of countershaft bearing is flush with surface of torque converter housing. CAUTION: If any differential components, transaxle housing, torque converter housing, snap rings or differential bearings are replaced, differential bearing side clearance must be checked. See «DIFFERENTIAL BEARING SIDE CLEARANCE»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__differential-bearing-side-clearance) under TRANSAXLE REASSEMBLY.
5. Once correct differential bearing side clearance is obtained, install differential oil seal. Using hammer and oil seal installer, drive oil seal into torque converter housing until oil seal is fully seated.

1. To remove countershaft, mainshaft and sub-shaft bearings, expand snap ring retaining bearing in transaxle housing. Press bearings from transaxle housing.
2. DO NOT remove snap ring from transaxle housing unless necessary to clean groove in transaxle housing. Using hammer and drift, tap differential oil seal from transaxle housing.

Clean components with solvent and dry with compressed air. Inspect transaxle housing for cracks and damage in bearing areas. Replace transaxle housing if damaged.

1. Coat components with Dexron-II ATF. To install bearings, expand snap ring. Using press and driver, press bearing part way into transaxle housing. CAUTION: Ensure bearing is installed with groove facing toward outside of transaxle housing so snap ring will engage with bearing.
2. Release snap ring. Continue pressing bearing into transaxle housing until snap ring engages in bearing. Ensure snap ring is fully seated. CAUTION: If differential carrier, differential bearings, transaxle housing, torque converter housing or snap rings are replaced, differential bearing side clearance must be checked. See «DIFFERENTIAL BEARING SIDE CLEARANCE»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__differential-bearing-side-clearance) under TRANSAXLE REASSEMBLY.
3. Once correct differential bearing side clearance is obtained, install differential oil seal using hammer and oil seal installer until oil seal is fully seated.

1. Before disassembling differential assembly, check side gear backlash. Place differential assembly on "V" blocks with both axle shafts installed.
2. Install dial indicator with stem resting against pinion gear. (Scheme 79) Check side gear backlash. Side gear backlash should be.002-.006" (.05-.15 mm). If side gear backlash is not within specification, replace differential carrier.
3. If replacing differential bearings, use bearing puller to remove differential bearings from differential carrier. Remove bolts and ring gear. NOTE: Ring gear bolts have left-hand threads.
4. If removing speedometer drive gear, remove snap ring, speedometer drive gear and roller. (Scheme 80)

Clean components with solvent and dry with compressed air. Inspect components for wear and damage. Replace components as necessary.

1. Install roller for speedometer drive gear in differential carrier. Install speedometer drive gear with chamfered side on inside of gear toward differential carrier. (Scheme 80) Ensure cutout area on speedometer drive gear is aligned with roller. CAUTION: Ensure speedometer drive gear is installed with chamfered side on inside of gear toward differential carrier.
2. Aligned hooked end of snap ring with pinion shaft on differential carrier and install snap ring. Ensure snap ring is installed so hooked end of snap ring is facing in proper direction. (Scheme 81) CAUTION: Ensure ring gear is installed with chamfered side on inside of ring gear toward differential carrier.
3. Install ring gear on differential carrier with chamfered side on inside of ring gear toward differential carrier. (Scheme 80) Install and tighten ring gear bolts to specification. Refer to «TORQUE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__torque-specifications) table. Using press, install NEW differential bearings on differential carrier (if removed).

Scheme 79

Scheme 80

Scheme 81

DIFFERENTIAL BEARING SIDE CLEARANCE

1. Install.098" (2.50 mm) thick snap ring in transaxle housing. This is the snap ring that differential bearing seats against. Ensure snap ring is fully seated.
2. Tap differential assembly into torque converter housing using Driver (07746-0030100). Refer to illustration for step procedures. Perform STEP 1. (Scheme 82) Ensure differential bearing on differential carrier is fully seated on torque converter housing.
3. Install gasket and transaxle housing on torque converter housing. Install and tighten transaxle housing bolts to 33 ft. lbs. (45 N.m) in 2 steps using proper sequence. (Scheme 83)
4. Using driver, tap on transaxle housing side of differential assembly to fully seat differential bearings. Perform STEP 2. (Scheme 82) Ensure differential bearings are fully seated in both housing.
5. Using feeler gauge, measure differential bearing side clearance between snap ring and bearing on the transaxle housing. (Scheme 84) Replace snap ring if differential bearing side clearance exceeds.006" (.15 mm). Different thickness snap rings are available. See the «SNAP RING SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) table. Recheck differential bearing side clearance. Remove transaxle housing and differential assembly.

SNAP RING SPECIFICATIONS

Scheme 82

Scheme 83

Scheme 84

VALVE BODIES & INTERNAL COMPONENTS

Note. Coat all components with Dexron-II ATF before reassembly.

1. Install needle bearing on end of reverse idler gear shaft holder. Install reverse idler gear in transaxle housing (if removed). Install reverse idler gear shaft holder on transaxle housing. Install and tighten reverse idler gear shaft holder bolts to specification. See «TORQUE SPECIFICATIONS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa__torque-specifications).
2. Install magnet and suction pipe collar on torque converter housing. (Scheme 65) Install dowel pins and separator plate for main valve on torque converter housing. CAUTION: Ensure oil pump driven gear is installed with groove and chamfered side facing downward (toward main separator plate).
3. Install oil pump drive gear, oil pump driven gear and oil pump driven gear shaft. Install main valve body. Install and tighten main valve body bolts to specification. CAUTION: Ensure oil pump gears rotate smoothly and oil pump driven gear shaft moves freely once main valve body is installed. If components do not operate correctly, loosen bolts, and realign oil pump gears and oil pump driven gear shaft. Failure to align oil pump driven gear shaft may result in seized oil pump gears or shaft.
4. Ensure check balls are installed in main valve body. (Scheme 66) Install separator plate, dowel pins and secondary valve body on main valve body. Install and tighten bolts to specification. Ensure check balls and 1st accumulator choke are installed in secondary valve body. (Scheme 70)
5. Install control shaft on torque converter housing so control shaft engages manual valve on main valve body. Install detent arm and detent arm shaft on main valve body. Hook detent spring on detent arm.
6. Install separator plate and servo body. Install and tighten bolts to specification. Using NEW "O" ring, install accumulator cover. Install and tighten bolts to specification.
7. Install servo detent base and fluid strainer. Install NEW bolt locks on servo detent base bolts. Install and tighten bolts to specification. Bend over tabs on bolt locks.
8. Install stator shaft, NEW "O" ring and stopper shaft. Install stopper shaft support on secondary valve body. Install regulator valve body. Install and tighten bolt to specification.
9. Install cooler check valve and torque converter check valve and springs on regulator valve body. (Scheme 68) Install separator plate, dowel pins, lock-up valve body and lubrication plate on regulator valve body. Install and tighten bolts to specification.
10. Install oil feed pipes in accumulator cover, servo detent base, servo body, lock-up valve body and main valve body. (Scheme 65)
11. Install sub-shaft and components in transaxle housing (if removed). See «SUB-SHAFT & COMPONENTS»(/acura/integra/iii-1993-2001/remont/automatic-trans/#automatic-transmission-overhaul-s4xa) under COMPONENT DISASSEMBLY & REASSEMBLY.
12. Install differential assembly in torque converter housing. Using Driver (07746-0030100), tap differential assembly into torque converter housing. Perform STEP 1. (Scheme 82) Ensure differential bearing on differential carrier is fully seated on torque converter housing.
13. Install mainshaft and countershaft as an assembly on torque converter housing. Rotate shift fork shaft on servo body so large chamfered hole aligns with hole in reverse shift fork.
14. Install reverse shift fork and reverse selector. (Scheme 64) Install reverse shift fork bolt and NEW bolt lock. Tighten bolt to specification. Bend over tabs on bolt lock.
15. Install countershaft reverse gear, needle bearing and countershaft reverse gear collar on countershaft. (Scheme 64) Install dowel pins and NEW gasket on torque converter housing.
16. Align spring pin on control shaft with groove on transaxle housing by rotating control shaft. (Scheme 63)
17. Install transaxle housing on torque converter housing. Install and tighten transaxle housing bolts to specification in 2 steps using proper sequence. (Scheme 83)
18. Install mount bracket on transaxle housing. (Scheme 64) Install and tighten mount bracket bolts to specification.
19. Install mainshaft holder on mainshaft. (Scheme 61) Install parking brake lever with parking brake stopper and parking brake lever spring on control shaft. (Scheme 60)
20. Install mainshaft 1st gear collar and thrust washer on mainshaft. Install countershaft 1st gear collar, needle bearing and countershaft 1st gear with one-way clutch and parking gear on countershaft.
21. Install parking pawl stopper, parking pawl shaft, parking pawl spring and parking pawl on transaxle housing.
22. Engage parking pawl with parking gear. Install old spring washer and lock nut on countershaft. Tighten nut to 76 ft. lbs. (103 N.m) to seat parking gear and countershaft 1st gear on countershaft. Remove old lock nut and spring washer from countershaft.
23. Install sub-shaft 1st gear on sub-shaft. Wrap splines on mainshaft with tape. Install NEW "O" rings on mainshaft. Install mainshaft 1st gear on mainshaft. (Scheme 60) Install needle bearing, thrust needle bearing, thrust washer and 1st clutch assembly on mainshaft.
24. Align hole in sub-shaft 1st gear with hole in transaxle housing. Install pin in sub-shaft 1st gear and transaxle housing to prevent sub-shaft 1st gear from rotating. (Scheme 62) CAUTION: Ensure spring washers are installed in correct direction. (Scheme 62)
25. Install NEW spring washers and NEW lock nuts on mainshaft, countershaft and sub-shaft. Ensure spring washers are installed with large area against the gear. (Scheme 62) NOTE: Mainshaft and countershaft contain left-hand threads.
26. Tighten lock nuts on mainshaft, countershaft and sub-shaft to specification. Remove pin from sub-shaft 1st gear. Remove mainshaft holder.
27. Stake flange area of mainshaft lock nut against 1st clutch assembly. Stake threaded area of countershaft lock nut against threads on countershaft. Stake threaded area of sub-shaft lock nut against threads of sub-shaft. CAUTION: Ensure all lock nuts are securely staked.
28. Place parking brake lever in "P" position. Ensure parking pawl engages parking gear. Measure parking brake stopper distance between parking pawl shaft and pin on the parking brake lever. (Scheme 85)
29. Parking brake stopper distance should be 2.87-2.91" (72.9-73.9 mm). If parking brake stopper distance is not within specification install different size parking brake stopper, and recheck parking brake stopper distance. Parking brake stopper is available in 3 different sizes. Consult parts department for parking brake stopper sizes.
30. Once correct parking brake stopper distance is obtained, install NEW bolt lock on bolt for parking brake stopper. Tighten parking brake stopper bolt to specification. Bend over tabs on bolt lock.
31. Using NEW gasket, install right side cover and right side cover protector. Install and tighten bolts to specification. Install throttle control lever with spring on throttle control shaft. Install and tighten bolt to specification.
32. To install remaining components, reverse removal procedure. Use NEW seal washers when installing joint bolts for cooler pipes. Use NEW "O" ring when installing mainshaft or countershaft speed sensors. Tighten all fasteners to specification.

Scheme 85

TRANSAXLE SPECIFICATIONS

TRANSAXLE SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

See also:
• TESTING
• CLUTCH APPLICATION
• TORQUE SPECIFICATIONS
• TORQUE CONVERTER STALL SPEED TEST
• DIFFERENTIAL BEARING SIDE CLEARANCE
• OIL COOLER FLUSHING
