Air Bag Restraint System Acura Integra III

DESCRIPTION & OPERATION

Supplemental Restraint System (SRS) is designed to protect the driver and front passenger by activating when vehicle receives a sufficient front-end impact. System includes driver-side air bag, passenger-side air bag, SRS unit (with internal impact-safing sensor and back-up power circuit), and cable reel. (Scheme 1)

Scheme 1

For air bag to deploy, impact-safing sensor (in SRS control unit) judges force of impact and, if necessary, transmits an ignitor signal to inflator inside air bag assembly, causing air bag to inflate.

Note. SRS wiring harness and connections are Yellow.

SERVICE PRECAUTIONS

Observe these precautions when working with air bag system

1. Disable SRS before servicing any SRS or steering column component. Failure to do this could result in accidental air bag deployment, possibly causing personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system) .
2. Wait about 3 minutes after disabling air bag system. A back-up power circuit capacitor (in SRS control unit) maintains system voltage for about 3 minutes after battery is disconnected. Servicing air bag system before 3 minutes may cause accidental air bag deployment, possibly causing personal injury.
3. After an accident, all SRS components, including wiring harness and brackets, must be inspected. If any components are damaged or bent, they must be replaced, even if air bag did not deploy. Check steering column, knee bolster, instrument panel steering column reinforcement plate and lower brace for damage. DO NOT service/repair any component or wiring. If components or wiring are damaged or defective, replacement is required.
4. Always wear safety glasses when servicing SRS or handling an air bag.
5. DO NOT attempt to disassemble air bag assembly. Neither component has any serviceable or reusable parts.
6. A replacement air bag assembly must be stored in its original special container until used for service. Special container must be stored in a clean, dry place, away from sources of extreme heat, sparks and high electrical energy.
7. When placing a live air bag assembly on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of air bag assembly if accidentally deployed.
8. After deployment, air bag assembly is very hot. Wait 30 minutes before handling.
9. After deployment, air bag surface may contain deposits of sodium hydroxide, which can irritate skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up, and wash hands using mild soap and water. Follow correct disposal procedures. See «DISPOSAL PROCEDURES»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disposal-procedures) .
10. DO NOT allow any electrical source near inflator on back of air bag assembly.
11. When carrying a live air bag assembly, trim cover pad should be pointed away from your body to minimize injury in case of accidental air bag deployment.
12. DO NOT probe any wire through insulator; this will damage wire and eventually cause failure due to corrosion.
13. When performing electrical tests, always use test harnesses recommended by manufacturer. See «SPECIAL TOOLS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__special-tools) . DO NOT connect tester probes directly to component connector pins or wires.
14. DO NOT use any type of electrical equipment other than that specified by manufacturer. See «SPECIAL TOOLS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__special-tools) .
15. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove any component or in any way disable system from operating normally. If SRS is not functional, park vehicle until repairs can be made.

SPECIAL TOOLS

To avoid accidental air bag deployment when testing or working around SRS, use recommended tools. See RECOMMENDED TOOLS table.

RECOMMENDED TOOLS

DISABLING & ACTIVATING AIR BAG SYSTEM

Note. Radio/cassette or radio/CD player contains an anti-theft protection circuit. Whenever battery is disconnected, radio will go into anti-theft mode. When battery is reconnected, radio will display CODE and will be inoperative until proper code NUMBER IS ENTERED BY VEHICLE OWNER.

SPRING-LOADED LOCK CONNECTORS

Note. Some SRS system connectors have a spring-loaded lock.

To disconnect, pull spring-loaded sleeves toward stop while holding opposite half of connector. Then pull halves apart. Be sure to pull on sleeve and not on connector half itself. (Scheme 2)

To connect, hold pawl-side connector half, and press on back of sleeve-side connector half in direction shown. (Scheme 2) As 2 connector halves are pressed together, sleeve is pushed back by pawl. Do NOT touch sleeve. When connector halves are completely connected, pawl is released, and spring-loaded sleeve locks connector.

Scheme 2

DISABLING SYSTEM

Note. When disconnected, air bag connector automatically shorted.

Driver-Side Air Bag

Turn ignition off. Disconnect negative cable, then positive battery cable. Wait at least 3 minutes. Remove access panel from steering wheel. (Scheme 3) Disconnect 2-pin connector between air bag and cable reel. Driver-side air bag is now disabled.

Scheme 3

Passenger-Side Air Bag

Turn ignition off. Disconnect negative battery cable, then positive battery cable. Wait at least 3 minutes. Remove glove box. Disconnect 2-pin connector between air bag and SRS main harness. (Scheme 4) Passenger-side air bag is now disabled.

Scheme 4

ACTIVATING SYSTEM

After new air bags have been installed, reconnect air bag connectors disconnected during DISABLING SYSTEM . Install glove box or access panel to steering wheel as necessary. Reconnect positive battery cable, then negative battery cable. Ensure system is functioning properly. See SYSTEM OPERATION CHECK .

POST-COLLISION INSPECTION

When a vehicle has been involved in a collision, certain components of the passive restraint system must be inspected or replaced. See PASSIVE RESTRAINT SYSTEM INSPECTION article in the GENERAL INFORMATION section for post-collision inspection information.

CABLE REEL CENTERING

With cable reel installed, rotate cable reel clockwise until it stops. Rotate cable reel counterclockwise about two and a half turns until arrow mark on cable reel label points straight up. (Scheme 5) New replacement cable reels come centered.

Scheme 5

DISPOSAL PROCEDURES

AIR BAG DEPLOYMENT

Note. If vehicle is to be scrapped, perform on-vehicle air bag deployment procedure.

Scheme 6

1. Before proceeding, read service precautions. See «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Ensure air bag assembly is securely mounted to steering wheel. Disconnect both battery cables. Ensure Deployment Tool (07HAZ-SG00400) is operating properly by connecting a 12-volt battery per instructions supplied with tool.
2. Press operation switch. If Green light on tool comes on, tool is okay. If Red light comes on, tool is faulty. Disconnect 12-volt battery from tool.
3. To deploy driver-side air bag, remove access panel from steering wheel. (Scheme 3) Disconnect driver-side air bag connector from cable reel connector. To deploy passenger-side air bag, remove glove box. Disconnect passenger-side air bag connector from SRS main harness. (Scheme 4)
4. To deploy either air bag, cut off air bag connector and strip back 1" of insulation from wire ends. Connect deployment tool's Yellow alligator clips to uninsulated wire ends. (Scheme 6) Place deployment tool about 30 feet away from air bag. Connect a 12-volt battery to deployment tool.
5. If Red light on deployment tool comes on, go to next step. If Green light on deployment tool comes on, ignitor circuit is faulty. Air bag will not deploy. Remove air bag and contact manufacturer for disposal instructions. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
6. Stand at least 30 feet away from air bag. Push tool's deployment switch, being prepared for rapid inflation of air bag and loud noise. If air bag deploys, remove and dispose of complete air bag assembly. Place it in a sturdy plastic bag and seal it securely. If air bag does not deploy, ignitor circuit is faulty. See «DAMAGED AIR BAG SPECIAL PROCEDURE»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__damaged-air-bag-special-procedure) under DISPOSAL PROCEDURES. Contact manufacturer for disposal instructions.

Scheme 7

1. Before proceeding, read service precautions. See «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Position air bag assembly face up, outdoors on flat ground and at least 30 feet from people or obstacles.
2. Ensure proper operation of Deployment Tool (07HAZ-SG00400) by connecting a 12-volt battery per instructions supplied with tool. Press operation switch. If Green light on tool comes on, tool is okay. If Red light comes on, tool is faulty. Disconnect 12-volt battery from tool.
3. Remove short connector from air bag connector. Cut off air bag connector, and strip back 1" of insulation from wire ends. Connect deployment tool's Yellow alligator clips to uninsulated wire ends. (Scheme 7) Place tool about 30 feet away from air bag. Connect 12-volt battery to deployment tool.
4. If Red light on deployment tool comes on, go to next step. If Green light on deployment tool comes on, ignitor circuit is faulty. Air bag will not deploy. Contact manufacturer for disposal instructions.
5. Push tool's deployment switch, being prepared for rapid inflation of air bag and loud noise. If air bag deploys, dispose of complete air bag assembly. Place it in a sturdy plastic bag and seal it securely. If air bag does not deploy, ignitor circuit is faulty. See «DAMAGED AIR BAG SPECIAL PROCEDURE»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__damaged-air-bag-special-procedure) under DISPOSAL PROCEDURES. Contact manufacturer for disposal instructions.

DAMAGED AIR BAG SPECIAL PROCEDURE

1. If air bag is installed in a car, follow removal procedure. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. In all cases, make sure a short connector is properly installed on air bag connector.
2. Package air bag in exactly same packaging that replacement part came in. Mark outside of box "DAMAGED AIR BAG NOT DEPLOYED" so it is not confused in your parts stock. Contact manufacturer for disposal instructions.

REMOVAL & INSTALLATION

Note. Radio/cassette or radio/CD player contains an anti-theft protection circuit. When battery is disconnected, radio will go into anti-theft mode. When battery is reconnected, radio will display CODE and will be inoperative until proper code number is entered by vehicle owner.

Scheme 8

1. Before proceeding, read air bag service precautions section. See «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Disable air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system).
2. Remove covers from steering wheel. (Scheme 8) Using Torx T30 bit, remove Torx bolts securing air bag assembly to steering wheel. Remove air bag assembly.
3. To install, reverse removal procedure. Secure air bag assembly with new Torx bolts. (Scheme 8) Tighten Torx bolts to 84 INCH lbs. (10 N.m). Activate air bag system. Connect battery positive cable, then negative cable. See information under «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system).

Scheme 9

1. Before proceeding, read air bag service precautions. See «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Disable air bag system. See information under «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system). Remove glove box. Disconnect 2-pin connector between air bag and SRS main harness. Remove 4 air bag mounting nuts. (Scheme 4)and (Scheme 9). Carefully lift air bag assembly out of dashboard.
2. To install, reverse removal procedure. Loosely install all 4 mounting nuts. Tighten upper 2 nuts first and then lower 2 nuts, to 84 INCH lbs. (10 N.m). (Scheme 9) Adjust lower mounting bracket if necessary. Activate air bag system. See information under «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system).

CABLE REEL

Removal

1. Be sure you have anti-theft code for radio. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Disable air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system). On driver-side, remove access panel from steering wheel, then disconnect 2-pin connector between air bag and cable reel. (Scheme 3) On passenger-side, remove glove box, then disconnect 2-pin connector between air bag and SRS main harness. (Scheme 4) NOTE: When disconnected, air bag connector is automatically shorted.
2. Ensure front wheels face straight ahead. Remove dashboard lower cover and knee blocker. Remove 2 Torx bolts and remove air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Disconnect connectors at center of steering wheel. Remove steering wheel nut. Remove steering wheel. Remove upper and lower steering column covers. Disconnect 3-pin cable reel connector from main wire harness. (Scheme 10) Remove 2-pin cable reel connector from main harness. Remove cable reel and cancel sleeve.

Scheme 10

Scheme 11

1. Ensure front wheels face straight ahead. Install cancel sleeve, ensuring grooves on cancel sleeve are aligned with projections on cable reel. (Scheme 11) Install cable reel.
2. Connect 2-pin connector to SRS main harness, and connect 3-pin connector to main wire harness. (Scheme 10) Install steering column covers. Center cable reel. See «ADJUSTMENTS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system).
3. Install steering wheel, routing cable reel harness and connectors through steering wheel hole. Connect electrical connectors at center of steering wheel. Install NEW steering wheel nut and tighten to 432 INCH lbs. (49 N.m).
4. Install air bag assembly. Tighten Torx bolts to 84 INCH lbs. (10 N.m). Attach 2-pin and 3-pin connectors to connector holder and install knee blocker and dashboard lower cover. Reconnect driver-side air bag 2-pin connector to cable reel 2-pin connector. Install access panel on steering wheel. Reconnect passenger-side air bag 2-pin connector to SRS main harness. Active air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system).

1. Before proceeding, read service precautions section. See «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Disable air bag system. See information under «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system). On driver-side, remove access panel from steering wheel, and disconnect 2-pin connector between air bag and cable reel. On passenger-side, remove glove box, then disconnect 2-pin connector between air bag and SRS main harness.
2. Remove cover from each side of SRS control unit. (Scheme 12) Disconnect SRS main harness 18-pin connector from SRS unit. Remove 4 Torx bolts securing SRS control unit. Remove SRS control unit from driver-side of console.

Scheme 12

Installation

To install, reverse removal procedure. Tighten Torx bolts to 84 INCH lbs. (10 N.m). Ensure click is felt or heard when connecting SRS main harness connector. Activate air bag system. See information under DISABLING & ACTIVATING AIR BAG SYSTEM .

SYSTEM OPERATION CHECK

When ignition is turned on, SRS indicator light should come on for about 6 seconds and then go off. While vehicle is driven, light should not come on or flash. If SRS indicator light does not operate as specified, system must be inspected/repaired as soon as possible. See DIAGNOSIS & TESTING .

WIRE REPAIR

DO NOT repair any SRS wiring or harness connectors. If SRS wiring or harness connectors are faulty, replace complete wiring harness.

DIAGNOSIS & TESTING

SELF-DIAGNOSTIC SYSTEM

Note. Radio/cassette or radio/CD player contains an anti-theft protection circuit. Whenever battery is disconnected, radio will go into anti-theft mode. When battery is reconnected, radio will display CODE and will be inoperative until proper code number is entered by vehicle owner.

SRS includes a self-diagnostic function that checks system for faults in SRS components and related wiring. A fault is present if SRS indicator light on instrument cluster

1. Continues to glow after ignition is turned on and more than 6 seconds have elapsed.
2. Glows or flashes while vehicle is driven.

DIAGNOSTIC TROUBLE CODE (DTC)

SRS indicator light indicates DTC by number of blinks when SCS service connector is connected to service check connector.

1. DTC consists of a main code and a sub-code.
2. Including most recent problem, up to three different malfunctions can be indicated.
3. In case of a continuous failure, DTC will be indicated repeatedly.
4. In case of an intermittent failure, SRS indicator light will indicate DTC 1 time, then it will stay on.
5. If both a continuous and an intermittent failure occur, only DTC of continuous failure will be indicated.
6. In case system is normal (no DTC), SRS indicator light will stay on.

Scheme 13

1. Turn ignition off. Wait 10 seconds. Connect SCS service connector to service check connector. (Scheme 13) NOTE: If you do not wait 10 seconds, SRS unit will not be completely reset and will not output DTCs.
2. Turn ignition. SRS indicator light comes on for about 6 seconds and goes off. DTC will be indicated next. Record DTC.

TROUBLESHOOTING OF INTERMITTENT FAILURES

Note. If there was a malfunction, but it does not recur, it will be stored in memory as an intermittent failure, and SRS indicator light comes on.

1. Record DTC. Remove SCS service connector from service check connector. Erase DTC memory base. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory) .
2. With car in neutral, start engine and let it idle. SRS indicator light comes on for about 6 seconds then goes off. Shake wire harness and connector and/or take a test drive to determine cause of intermittent failure. If problem recurs, SRS indicator light will stay on. If intermittent failure is not duplicated, system is OK.

ERASING DIAGNOSTIC TROUBLE CODE MEMORY

Note. Use SCS service connector instead of a jumper wire. Otherwise, you may not erase memory since it is difficult to connect and disconnect a jumper wire quickly enough.

1. Turn ignition switch off. Wait 10 seconds to ensure DTC memory is erased. Disconnect SCS service connector from service check connector, then connect SCS service connector to MES connector. (Scheme 14)
2. Turn ignition switch. SRS indicator light will come on for about 6 seconds then go off. Remove SCS service connector from MES connector within 4 seconds after SRS indicator light went off.
3. SRS indicator light comes on again. Reconnect SCS service connector to MES connector within 4 seconds after SRS indicator light comes on.
4. SRS indicator light goes off. Remove SCS service indicator from MES connector within 4 seconds. SRS indicator light indicates that memory is erased by blinking 2 times.

Scheme 14

DIAGNOSTIC TROUBLE CODE (DTC) CHART

SRS INDICATOR DOES NOT GLOW

Note. Radio/cassette or radio/CD player contains an anti-theft protection circuit. Whenever battery is disconnected, radio will go into anti-theft mode. When battery is reconnected, radio will display CODE and will be inoperative until proper code number is entered by vehicle owner.

Scheme 15

Scheme 16

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition on, and check whether other indicator lights come on or not (brake system, etc.). If brake system indicator light operates, go to step 3). If brake system indicator light does not operate, check fuse No. 15 in fuse block in under-dash fuse/relay box. (Scheme 15) Replace fuse if blown. If fuse is okay, go to next step.
2. Check for open Yellow wire between fuse and gauge assembly, and repair. If SRS indicator light does not come on, go to next step.
3. Turn ignition off. Remove gauge assembly. Check for blown SRS indicator light bulb. If light bulb is OK, go to next step. If bulb is faulty, replace it and reconnect gauge assembly connectors. Turn ignition on. If SRS indicator light still does not come on, go to next step.
4. Disconnect dashboard wiring harness 5-pin connector from gauge assembly. (Scheme 16) Connect a voltmeter between No. 5 terminal (+) of 5-pin connector and ground. (Scheme 16)and (Scheme 19). Turn ignition on and measure voltage. If 8.5 V or less is NOT present for 6 seconds after ignition has been turned on, go to next step. If 8.5 V or less is present, there is a faulty SRS indicator light circuit in gauge assembly. Replace SRS printed circuit board in gauge assembly.
5. Turn ignition off. Disconnect main wire harness 16-pin connector from dashboard wire harness. (Scheme 15)and (Scheme 19). Connect a voltmeter between No. 15 terminal (+) of main wire harness 16-pin connector and ground. Turn ignition on and measure voltage. If 8.5 V or less is NOT present for 6 seconds after ignition has been turned on, go to next step. If 8.5 V or less is present, there is a short to power in BLU wire of dashboard wire harness. Repair harness.
6. Turn ignition off. Disconnect SRS main harness 3-pin connector from main wire harness. (Scheme 15)and (Scheme 19). Connect a voltmeter between No. 1 terminal (+) of SRS main harness 3-pin connector and ground. (Scheme 15)and (Scheme 19). Turn ignition on and measure voltage. If 8.5 V or less is NOT present for 6 seconds after ignition has been turned on, go to next step. If 8.5 V or less is present, there is a short to power in BLU wire of main wire harness. Repair main wire harness.
7. Turn ignition off. Disable air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__disabling-activating-air-bag-system). Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Connect a voltmeter between No. 6 terminal (+) of SRS main harness 18-pin connector and ground. (Scheme 15) Turn ignition on and measure voltage. There should be 0.5 V or less present. If specified voltage is NOT present, there is a short to power in BLU wire of SRS main harness. Replace harness. If specified voltage is present, SRS unit is faulty. Replace unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.

Scheme 17

RETRIEVAL OF DTC

Scheme 18

Scheme 19

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) DO NOT disconnect passenger-side air bag connector. Connect SRS service connector (2 ohm) to cable reel 2-pin connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC.

DTC 1-1 & DTC 1-2

Scheme 20

Scheme 21

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) DO NOT disconnect passenger-side air bag connector. Connect SRS service connector (2 ohm) to cable reel 2-pin connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 1-1 or DTC 1-2 is indicated, go to next step. If a DTC 1-1 or DTC 1-2 is NOT indicated, there is open or increased resistance in driver-side air bag inflator. Replace air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery negative cable, then positive cable. Wait at least 3 minutes. Disconnect SRS service connector (2 ohm) from cable reel 2-pin connector. (Scheme 18) Remove dashboard lower cover. Disconnect cable reel 2-pin connector from SRS main harness. (Scheme 21) Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. Reconnect battery cables. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 1-1 or DTC 1-2 is indicated, go to next step. If a DTC 1-1 or DTC 1-2 is NOT indicated, there is open or increased resistance in cable reel. Replace cable reel. See «CABLE REEL»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__cable-reel) under REMOVAL & INSTALLATION.
4. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag 2-pin connector. (Scheme 4) Remove SRS service connector (2 ohm) from SRS main harness 2-pin connector. (Scheme 21) Disconnect SRS main harness 18-pin connector. (Scheme 18) Check resistance between terminals No. 1 and No. 13 of SRS main harness 18-pin connector. (Scheme 15) There should be approximately 0-1.0 ohm present. If resistance is as specified, there is poor contact at SRS main harness 18-pin connector; go to next step. If resistance is NOT as specified, there is an open or increased resistance in SRS main harness. Replace harness.
5. Check SRS main harness 18-pin connector. If connector is OK, substitute a known-good SRS unit and recheck. If problem is still present, replace SRS main harness.

DTC 1-3

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) DO NOT disconnect passenger-side air bag connector. Connect SRS service connector (2 ohm) to cable reel 2-pin connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 1-3 is indicated, go to next step. If a DTC 1-3 is NOT indicated, there is a short in driver-side air bag inflator. Replace driver-side air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery negative cable, then positive cable. Wait at least 3 minutes. Disconnect SRS service connector (2 ohm) from cable reel 2-pin connector. (Scheme 18) Remove dashboard lower cover. Disconnect cable reel 2-pin connector from SRS main harness. (Scheme 21) Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. Reconnect battery cables. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off, then disconnect SCS service connector from MES connector. Connect SCS service connector to service check connector. Turn ignition on, and record most recent DTC. If a DTC 1-3 is indicated, go to next step. If a DTC 1-3 is NOT indicated, there is a short in cable reel. Replace cable reel. See «CABLE REEL»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__cable-reel) under REMOVAL & INSTALLATION.
4. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag 2-pin connector from SRS main harness. (Scheme 22) Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Do NOT disconnect SRS service connector (2 ohm). Check resistance between terminals No. 1 and No. 13 of SRS main harness 18-pin connector. (Scheme 19) There should be approximately 2.0-3.0 ohm present. If resistance is as specified, SRS unit is faulty. Replace SRS unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. If resistance is NOT as specified, there is a short in SRS main harness. Replace SRS main harness.

Scheme 22

DTC 1-4

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) DO NOT disconnect passenger-side air bag connector. Connect SRS service connector (2 ohm) to cable reel 2-pin connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 1-4 is indicated, go to next step. If a DTC 1-4 is NOT indicated, there is a short to power in driver-side air bag inflator. Replace driver-side air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery negative cable, then positive cable. Wait at least 3 minutes. Disconnect SRS service connector (2 ohm) from cable reel 2-pin connector. (Scheme 18) Remove dashboard lower cover, and disconnect cable reel 2-pin connector from SRS main harness. Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. (Scheme 21) Reconnect battery cables. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 1-4 is indicated, go to next step. If a DTC 1-4 is NOT indicated, there is a short to power in cable reel. Replace cable reel. See «CABLE REEL»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__cable-reel) under REMOVAL & INSTALLATION.
4. Turn ignition off. Remove SRS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag 2-pin connector from SRS main harness. (Scheme 22) Remove SRS service connector (2 ohm) from SRS main harness 2-pin connector. (Scheme 20) Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Connect a voltmeter between No. 1 (+) terminal of SRS main harness 18-pin connector and body ground. (Scheme 19) Turn ignition on and measure voltage. There should be approximately 0-0.5 V present. Turn ignition off. Connect a voltmeter between No. 13 (+) terminal of SRS main harness 18-pin connector and body ground. (Scheme 19) Turn ignition on and measure voltage. There should be approximately 0-0.5 V present. If voltage is as specified, SRS unit is faulty. Replace SRS unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. If voltage is NOT as specified, there is a short to power in SRS main harness. Replace SRS main harness.

DTC 1-5

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) DO NOT disconnect passenger-side air bag connector. Connect SRS service connector (2 ohm) to cable reel 2-pin connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 1-5 is indicated, go to next step. If a DTC 1-5 is NOT indicated, there is a short to ground in driver-side air bag inflator. Replace driver-side air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect SRS service connector (2 ohm) from cable reel 2-pin connector. (Scheme 18) Remove dashboard lower cover, and disconnect cable reel 2-pin connector from SRS main harness. Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. (Scheme 21) Reconnect battery cables. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off, then disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 1-5 is indicated, go to next step. If a DTC 1-5 is NOT indicated, there is a short to ground in cable reel. Replace cable reel. See «CABLE REEL»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__cable-reel) under REMOVAL & INSTALLATION.
4. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag 2-pin connector from SRS main harness. (Scheme 22) Remove SRS service connector (2 ohm) from SRS main harness 2-pin connector. (Scheme 22) Disconnect harness 18 pin connector from SRS Unit. Check resistance between terminal No. 1 and No. 13 of SRS main harness 18-pin connector and ground. (Scheme 19) There should be 1.0M ohm or more present. If resistance is as specified, SRS unit is faulty. Replace SRS unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. If resistance is NOT as specified, there is a short in SRS main harness. Replace SRS main harness.

DTC 2-1 and 2-2

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag connector from SRS main harness. (Scheme 22) Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. DO NOT disconnect driver-side air bag connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 2-1 or DTC 2-2 is indicated, go to next step. If a DTC 2-1 or DTC 2-2 is NOT indicated, there is open or increased resistance in passenger-side air bag inflator. Replace passenger-side air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) Remove SRS 2 ohm service connector (07TAZ-SZ50200) from SRS main harness 2-pin connector, then connect SRS service connector (07SAZ-SW50200) to SRS main harness 2-pin connector. (Scheme 23) Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Check resistance between terminal No. 10 and terminal No. 14 of SRS main harness 18-pin connector. (Scheme 19) There should be approximately 0-1.0 ohm present. If resistance is as specified, there is poor contact at SRS main harness 18-pin connector; go to next step. If resistance is NOT as specified, there is open or increased resistance in SRS main harness; replace harness.
4. Check SRS main harness 18-pin connector. If connector is OK, substitute a known-good SRS unit, and recheck. If problem is still present, replace SRS main harness.

Scheme 23

DTC 2-3

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag connector from SRS main harness. (Scheme 22) Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. DO NOT disconnect driver-side air bag connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 2-3 is indicated, go to next step. If a DTC 2-3 is NOT indicated, there is a short to another wire or decreased resistance in passenger-side air bag inflator. Replace passenger-side air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Do NOT disconnect SRS service connector (2 ohm). Check resistance between terminal No. 10 and terminal No. 14 of SRS main harness 18-pin connector. (Scheme 19) There should be approximately 2.0-3.0 ohm present. If resistance is as specified, SRS unit is faulty; replace unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. If resistance is NOT as specified, there is a short to another wire or decreased resistance in SRS main harness; replace harness.

DTC 2-4

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag connector from SRS main harness. (Scheme 22) Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. DO NOT disconnect driver-side air bag connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 2-4 is indicated, go to next step. If a DTC 2-4 is NOT indicated, there is a short to power in passenger-side air bag inflator. Replace passenger-side air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Remove SRS service connector (2 ohm) from SRS main harness 2-pin connector. Reconnect battery cables. Connect a voltmeter between No. 10 (+) terminal of SRS main harness 18-pin connector and ground. (Scheme 19) Turn ignition on, and measure voltage. There should be approximately 0-0.5 V or less. Connect a voltmeter between No. 14 (+) terminal of SRS main harness 18-pin connector and ground, and measure voltage. (Scheme 19) There should be approximately 0-0.5 V or less. If voltage is as specified, SRS unit is faulty; replace unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. If voltage is NOT as specified, there is a short to power in SRS main harness; replace harness.

DTC 2-5

1. Before proceeding, see «SERVICE PRECAUTIONS»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__service-precautions). Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect passenger-side air bag connector from SRS main harness. (Scheme 22) Connect SRS service connector (2 ohm) to SRS main harness 2-pin connector. DO NOT disconnect driver-side air bag connector. Reconnect battery cables.
2. Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off. Disconnect SCS service connector from MES connector. (Scheme 14) Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 2-5 is indicated, go to next step. If a DTC 2-5 is NOT indicated, there is a short to ground in passenger-side air bag inflator. Replace passenger-side air bag assembly. See «AIR BAG ASSEMBLY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
3. Turn ignition off. Remove SCS service connector. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Remove SRS service connector (2 ohm) from SRS main harness 2-pin connector. Check resistance between No. 10 terminal of SRS main harness 18-pin connector and ground, and between No. 14 terminal of SRS main harness 18-pin connector and ground. (Scheme 19) There should be 1M ohm or more. If resistance is as specified, SRS unit is faulty; replace unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. If resistance is NOT as specified, there is a short to ground in SRS main harness; replace harness.

DTC 9-1 OR NO CODE

Scheme 24

1. Turn ignition off. Connect SCS service connector to MES connector. (Scheme 14) Erase DTC memory. See «ERASING DIAGNOSTIC TROUBLE CODE MEMORY»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__erasing-diagnostic-trouble-code-memory). Turn ignition off, then disconnect SCS service connector from MES connector. Connect SCS service connector to service check connector. (Scheme 20) Turn ignition on, and record most recent DTC. If a DTC 9-1 is indicated, SRS unit is faulty; replace unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION. If a DTC 9-1 is NOT indicated, go to next step.
2. Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag 2-pin connector from cable reel 2-pin connector. (Scheme 18) Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Reconnect battery cables. Turn ignition on, then connect SRS main harness 18-pin connector terminals No. 6 and No. 7 with a jumper wire and backprobe adapters. (Scheme 24) If SRS indicator light goes off, there is poor contact at SRS main harness 18-pin connector; go to next step. If SRS indicator light does NOT go off, go to step 4).
3. Check SRS main harness 18-pin connector. If connector is OK, substitute a known-good SRS unit, and recheck. If problem is still present, replace SRS main harness.
4. Turn ignition off. Remove gauge assembly. (Scheme 16)and (Scheme 19). DO NOT disconnect dashboard wire harness 5-pin connector from gauge assembly. Turn ignition on. Connect dashboard wire harness 5-pin connector terminals No. 5 and No. 1 with a jumper wire. (Scheme 16)and (Scheme 19). If indicator light goes off, go to next step. If indicator light does NOT go off, SRS indicator light circuit in gauge assembly is faulty; replace SRS printed circuit board in gauge assembly.
5. Turn ignition off. Disconnect dashboard wire harness 5-pin connector from gauge assembly. (Scheme 16)and (Scheme 19). Check resistance between No. 5 terminal of dashboard wire harness 5-pin connector and ground. (Scheme 16)and (Scheme 19). There should be 1M ohm or more present. If resistance is as specified, got to next step. If resistance is NOT as specified, go to step 10).
6. Check resistance between No. 6 terminal of SRS main harness 18-pin connector and No. 5 terminal of dashboard wire harness 5-pin connector. (Scheme 19) There should be approximately 0-1.0 ohm present. If resistance is as specified, go to next step. If resistance is NOT as specified, go to step 8).
7. Reconnect SRS main harness 18-pin connector to SRS unit. (Scheme 17) Connect a voltmeter between No. 5 terminal (+) of dashboard 5-pin connector and ground. (Scheme 19) Turn ignition on, and measure voltage. If there is 8.5 V or more 6 seconds after ignition has been turned off, problem has disappeared due to disconnecting and connecting connectors. Be sure all terminals make good contact, and recheck system. See «TROUBLESHOOTING OF INTERMITTENT FAILURES»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__troubleshooting-of-intermittent-failures). If there is NOT 8.5 V or more 6 seconds after ignition has been turned off, there is poor contact at SRS main harness 18-pin connector. Check connector. If connector is OK, substitute a known-good SRS unit, and recheck. If problem is still present, replace SRS main harness.
8. Disconnect dashboard wire harness 16-pin connector from main wire harness. (Scheme 15) Check resistance between No. 6 terminal of SRS main harness 18-pin connector and No. 15 terminal of main wire harness 16-pin connector. (Scheme 19) Resistance should be approximately 0-1.0 ohm. If resistance is as specified, there is an open in BLU wire of dashboard wire harness; repair dashboard wire harness. If resistance is NOT as specified, go to next step.
9. Disconnect SRS main harness 3-pin connector from main wire harness. (Scheme 15) Check resistance between No. 6 terminal of SRS main harness 18-pin connector and No. 1 terminal of SRS main harness 3-pin connector. (Scheme 15)and (Scheme 19). Resistance should be approximately 0-1.0 ohm. If resistance is as specified, there is an open in BLU wire of main wire harness; repair main wire harness. If resistance is NOT as specified, there is an open in SRS main harness; replace SRS main harness.
10. Disconnect dashboard wire harness 16-pin connector from main wire harness. (Scheme 15) Check for continuity between No. 15 terminal of main wire harness 16-pin connector and ground. (Scheme 15)and (Scheme 19). Resistance should be 1M ohm or more. If resistance is as specified, there is a short to ground in dashboard wire harness; repair harness. If resistance is NOT as specified, go to next step.
11. Disconnect SRS main harness 3-pin connector from main wire harness. (Scheme 15) Check resistance between No. 1 terminal of SRS main harness 3-pin connector and ground. (Scheme 15)and (Scheme 19). Resistance should be 1M ohm or more. If resistance is as specified, there is a short to ground in main wire harness; repair main wire harness. If resistance is NOT as specified, there is a short to ground in SRS main wire harness; replace SRS main wire harness.

DTC 9-2

1. Turn ignition off. Check for blown No. 25 (10 A) fuse in under-dash fuse/relay box. (Scheme 15) If fuse is OK, go to step 5). If fuse is NOT OK, go to next step.
2. Replace fuse. Turn ignition on, and check that fuse doesn't blow. If fuse blows, go to next step. If fuse does NOT blow, problem has disappeared. Test-drive car and see «TROUBLESHOOTING OF INTERMITTENT FAILURES»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system__troubleshooting-of-intermittent-failures).
3. Turn ignition off. Disconnect battery cables. Wait at least 3 minutes before proceeding. Disconnect driver-side and passenger-side air bag connectors. (Scheme 18)and (Scheme 22). Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Check resistance between No. 3 terminal and ground. (Scheme 19) Resistance should be 1M ohm or more. If resistance is NOT as specified, go to next step. If resistance is as specified, SRS unit is faulty; replace unit. See «SRS UNIT»(/acura/integra/iii-1993-2001/remont/airbag/#air-bag-restraint-system) under REMOVAL & INSTALLATION.
4. Disconnect SRS main harness 2-pin connector from under-dash fuse/relay box. (Scheme 15) Check resistance between No. 3 terminal of SRS main harness 18-pin connector and ground. (Scheme 19) Resistance should be 1M ohm or more. If resistance is as specified, there is a short to ground in under-dash fuse/relay box; replace fuse/relay box. If resistance is NOT as specified, there is a short to ground in SRS main harness; replace SRS main harness.
5. Turn ignition off. Disconnect battery cables. Wait at least 3 minutes. Disconnect driver-side air bag and passenger-side 2-pin connectors. (Scheme 18)and (Scheme 22). Disconnect SRS main harness 18-pin connector from SRS unit. (Scheme 17) Reconnect battery cables. Connect a voltmeter between No. 3 terminal of SRS main harness 18-pin connector and ground. (Scheme 19) Turn ignition on, and measure voltage. There should be approximately 0-0.5 V. If voltage is a specified, there is poor contact at SRS main harness 18-pin connector, go to next step. If voltage is NOT as specified, there is an open in SRS main harness; replace SRS main harness.
6. Check SRS main harness connector. (Scheme 17) If connector is OK, substitute a known-good SRS unit, and recheck. If problem is still present, replace SRS main harness.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

SRS Wiring Diagram. Scheme 25

See also:
• SERVICE PRECAUTIONS
• DISABLING & ACTIVATING AIR BAG SYSTEM
• DISPOSAL PROCEDURES
• SPECIAL TOOLS
• DISABLING SYSTEM
• SYSTEM OPERATION CHECK
• AIR BAG ASSEMBLY
• DAMAGED AIR BAG SPECIAL PROCEDURE
• DIAGNOSIS & TESTING
• ERASING DIAGNOSTIC TROUBLE CODE MEMORY
• No Code
• 1-1
• 1-3
• 1-4
• 1-5
• 2-1
• 2-3
• 2-4
• 2-5
• 9-2
• CABLE REEL
• TROUBLESHOOTING OF INTERMITTENT FAILURES
