Scheme 1
COOLANT TEMPERATURE GAUGE
Pointer should remain in the White (Normal) range. If gauge registers at the Red (Hot) end, stop vehicle immediately and let engine cool. Check engine coolant level.
OIL PRESSURE WARNING LIGHT
This light will flash to indicate a very low lubricant level barely sufficient for proper lubrication. If light glows during operation, oil level or oil pressure is low. If this occurs, stop vehicle immediately and check oil level.
HEADLIGHT MOTOR WARNING LIGHT
This light will come on if either headlight motor malfunctions during operation. If light comes on and remains on, have headlight motors checked as soon as possible.
CHARGING SYSTEM WARNING LIGHT
Light indicates a problem with the electrical charging system. If light comes on while driving, stop vehicle and check alternator belt. If belt has proper tension and light remains on, have system serviced as soon as possible.
BRAKE WARNING LIGHT
If this light comes on while driving, it indicates that either the parking brake is on or brake fluid level is low.
BRAKELIGHT WARNING LIGHT
Light indicates that a brakelight is not functioning correctly. Havebrakelights checked as soon as possible.
PGM-FI/CHECK ENGINE WARNING LIGHT
If light comes on while driving, it indicates a malfunction in the fuel injection system. If light is on, avoid driving at high speed and have system serviced as soon as possible.
