Engine Control Module (ECM) Diagnostic Trouble Codes - 10 of 13: Other Volvo XC90 I рестайлинг

FAULT TRACING

see FAULT TRACING

see FAULT TRACING

see FAULT TRACING

CHECKING COMPONENTS

Check the rear heated oxygen sensor connector (bank 1). Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

Scheme 352

Scheme 353

1. Continue Refer to «VERIFICATION»(ref-476781-S34072198302012060500000)

VERIFICATION

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

Scheme 354

Scheme 355

1. Test-drive the vehicle on road and make sure that a fuel shut-off is performed. Easiest to do this by driving approx. 80 km/h and suddenly release the accelerator pedal for at least 5 seconds.
2. Connect VCT2000 (or appropriate scan tool) to the data link connector without turning off the engine. NOTE: If the engine is turned off, the stored trouble status will be erased and the test-drive will have to be repeated. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S18458519902012060500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

Check the cable between the Engine Control Module (ECM) terminal #A41 (#A41) and rear heated oxygen sensor terminal #4 (bank 1). Check for an open-circuit. Check for a short-circuit to ground.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S41250500732012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S04542903632012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

CHECKING THE STATUS

1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".

1. Continue Refer to «CHECKING COMPONENTS»(ref-476781-S20988088842012060500000)

Check the cable between the Engine Control Module (ECM) terminal #A41 (#A41) and rear heated oxygen sensor terminal #4 (bank 1). Check for a short-circuit to supply voltage.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S40104364882012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S24788592432012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".

1. Continue Refer to «CHECKING COMPONENTS»(ref-476781-S25960774142012060500000)

Check the front heated oxygen sensor (HO2S) connector (bank 2). Check for contact resistance and oxidation.

Try a new rear heated oxygen sensor if the above measure does not remedy the fault.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S30437390172012060500000)
2. see «SIGNAL SPECIFICATION»(ref-476694-S14228516802012060500000)
3. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-476768-S18546887202012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17655503092012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S37066736822012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S08452979822012060500000)

see FAULT TRACING

1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".

1. Continue Refer to «CHECKING COMPONENTS»(ref-476781-S20522496282012060500000)

Check the front heated oxygen sensor (HO2S) connector (bank 2). Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S34624564222012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S09117944202012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT TRACING

see FAULT TRACING

see FAULT TRACING

Check the connector for the rear heated oxygen sensor (bank 2) for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S42543178582012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Test-drive the vehicle on road and make sure that a fuel shut-off is performed. Easiest to do this by driving approx. 80 km/h and suddenly release the accelerator pedal for at least 5 seconds.
2. Connect VCT2000 (or appropriate scan tool) to the data link connector without turning off the engine. NOTE: If the engine is turned off, the stored trouble status will be erased and the test-drive will have to be repeated. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S19984002762012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine to perform the diagnosis. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent.

1. Continue Refer to «CHECKING COMPONENTS»(ref-476781-S20699862822012060500000)

Check the cable between the Engine Control Module (ECM) terminal #A40 (#A40) and rear heated oxygen sensor terminal #4 (bank 2). Check for an open-circuit. Check for a short-circuit to ground.

If the above troubleshooting does not solve the problem, try a new heated oxygen sensor.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S29591699292012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S13280281382012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine to perform the diagnosis. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent.

1. Continue Refer to «CHECKING COMPONENTS»(ref-476781-S14478208502012060500000)

Check the cable between the Engine Control Module (ECM) terminal #A40 (#A40) and rear heated oxygen sensor terminal #4 (bank 2). Check for a short-circuit to supply voltage.

If the above troubleshooting does not solve the problem, try a new heated oxygen sensor.

Remedy as necessary.

Other information

1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S22686392612012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S11689450072012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

PREPARATORY CHECKS

Check and note which adaption area for bank 1 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING SYSTEM»(ref-476781-S04575346742012060500000)

Scheme 356

HINT: If the fuel adaptations indicate too lean fuel/air mixture (adaptation value above 1.0) at idle, this indicates an air leak.

HINT: To find the problem, proceed as follows

1. Check the inlet system and exhaust system for leaks.
2. Engine running.
3. Check fuel pressure to, see if it is low.
4. Ignition on
5. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

Other information

1. see «CHECKING FOR AIR LEAKAGE IN THE EXHAUST SYSTEM»(ref-494824-S07275287112012081600000)

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S28363986482012060500000)

CHECKING MASS AIR FLOW SENSOR

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S42396714772012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S07864107602012060500000)

READOUT OF TOTAL FUEL COMPENSATION

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S07864107602012060500000)

START ADAPTATIONS

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S08480115482012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

Check and note which adaption area for bank 1 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING ETHANOL CONTENT»(ref-476781-S01508502372012060500000)

CHECKING THE SYSTEM

HINT: If the fuel adaptations indicate too lean fuel/air mixture (adaptation value above 1.0) at idle, this indicates an air leak.

HINT: To find the problem, proceed as follows

1. Check the inlet system and exhaust system for leaks.
2. Engine running.
3. Check fuel pressure to, see if it is low.
4. Ignition on
5. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

Other information

1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-476750-S38054557722012060500000)
2. see «CHECKING FOR AIR LEAKAGE IN THE EXHAUST SYSTEM»(ref-494824-S07275287112012081600000)

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S16297219282012060500000)

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S27474613742012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S06580203552012060500000)

Scheme 357

1. Turn off the engine.
2. Ignition on Reset adaptations to zero using the VCT2000 (or appropriate scan tool). This is done to give the system a normal starting point. Thus it can be seen faster if the adaptations run off up or down.

1. Continue Refer to «START ADAPTATIONS»(ref-476781-S22327264632012060500000)

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S06580203552012060500000)

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S24331268962012060500000)

CHECKING ETHANOL CONTENT

HINT: The cause of the symptom and/or diagnostic trouble code may be that the vehicle has been refuelled with incorrect fuel for that vehicle. The fuel system contains fuel with too high ethanol content.

The energy content in ethanol-diluted fuel is lower than in pure gasoline. This means that the control module compensates for the lower energy content, by increasing the injection volume, to be able to reach lambda=1 at the front heated oxygen sensor. This compensation is normally called "Front lambda control slow" or "Lambda integrator", and varies to compensate for the vehicle's status in the form of component spread, small air leaks, wear, etc. The value of this compensation in the ideal case is 1.0 for pure gasoline. Increased ethanol content of the fuel increases the compensation by approx. 0.05 per 10% ethanol dilution.

The control module is designed to handle an ethanol dilution up to 25%. In combination with other deviations from the ideal case, however, lower ethanol content may be enough to cause customer symptoms. This mainly occurs at engine start with cool engine at outdoor temperatures below 0 °C. Then the diagnostic trouble code may also be set for the engine running on too lean mixture.

Note. In a vehicle intended for gasoline, only pure gasoline shall be used. Even if engine start/operation works, other fuel-related components in the vehicle may be damaged by too high ethanol content.

1. Measure the ethanol content of the fuel according to the instructions below. If measured ethanol content is above 25%, then ethanol dilution is the likely cause of the symptom and/or to the diagnostic trouble code being stored. If measured ethanol content is below 25%, symptoms and/or diagnostic trouble code may have been caused by earlier occurrence of incorrect fuel in the system for that vehicle. HINT: Check refuelling history by talking to customer. If nothing indicates incorrect fuel, neither now nor earlier, continue troubleshooting to check other possible causes of faults.

Other information

1. see «MEASURING THE ETHANOL CONTENT»(ref-476691-S40487988662012060500000)

1. Continue Refer to «CHECKING THE SYSTEM»(ref-476781-S31794196262012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check and note which adaption area for bank 1 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING SYSTEM»(ref-476781-S36291095662012060500000)

CHECKING SYSTEM

1. Check the air filter. Check for blockage.

HINT: If the fuel adaptations indicate too rich fuel/air mixture (adaptation value below 1.0) in several adaptation ranges, this indicates a fuel malfunction, e. g., too high fuel pressure.

HINT: To find the problem, proceed as follows

1. Check that the engine's oil level is not too high. HINT: The adaptations may show rich if several cold starts have been performed with short subsequent driving time, e. g., moving of vehicles, and the engine oil has thus been contaminated by gasoline. This affect on the adaptations disappears after a period of driving due to combustion of the fuel vapors by the engine. Check the EVAP-valve for leakage. HINT: A valve that does not seal constantly leaks fuel vapors, which thus affect the adaptations.
2. Engine running.
3. Check fuel pressure for high fuel pressure.
4. Ignition on
5. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

HINT: If the residual pressure is too low, one malfunction cause may be leaking (non-sealing) injectors, for example.

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S24790436842012060500000)

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S09151116502012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S10295806922012060500000)

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S10295806922012060500000)

Test-drive the vehicle on road and drive variably for 20 minutes, this is to perform as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S10972147302012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

Check and note which adaption area for bank 1 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING SYSTEM»(ref-476781-S09769109702012060500000)

1. Check the air filter. Check for blockage.

HINT: If the fuel adaptations indicate too rich fuel/air mixture (adaptation value below 1.0) in several adaptation ranges, this indicates a fuel malfunction, e. g., too high fuel pressure.

HINT: To find the problem, proceed as follows

1. Check that the oil level is between the minimum and maximum markings
2. Check the induction system for clogs and loose components (such as a loose air guide in the air filter holder).
3. HINT: The adaptations may show rich if several cold starts have been performed with short subsequent driving time, e. g., moving of vehicles, and the engine oil has thus been contaminated by gasoline. This affect on the adaptations disappears after a period of driving due to combustion of the fuel vapors by the engine. Check the EVAP-valve for leakage. HINT: A valve that does not seal constantly leaks fuel vapors, which thus affect the adaptations.
4. Engine running.
5. Check fuel pressure for high fuel pressure.
6. Ignition on
7. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

HINT: If the residual pressure is too low, one malfunction cause may be leaking (non-sealing) injectors, for example.

Other information

1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-476750-S38054557722012060500000)

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S28420582842012060500000)

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S30463328012012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S37061327962012060500000) .

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S37061327962012060500000)

Test-drive the vehicle on road and drive variably for 20 minutes, this is to perform as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S12677103262012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check and note which adaption area for bank 2 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING SYSTEM»(ref-476781-S16114542452012060500000)

HINT: If the fuel adaptations indicate too lean fuel/air mixture (adaptation value above 1.0) at idle, this indicates an air leak.

HINT: To find the problem, proceed as follows

1. Check the inlet system and exhaust system for leaks.
2. Engine running.
3. Check fuel pressure to, see if it is low.
4. Ignition on
5. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

Other information

1. see «CHECKING FOR AIR LEAKAGE IN THE EXHAUST SYSTEM»(ref-494824-S07275287112012081600000)

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S20089252462012060500000)

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S40165675362012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S14230128582012060500000) .

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affects the read-out. Squeeze the hose between the EVAP-valve and inlet pipe to minimize the addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S14230128582012060500000)

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S34436406602012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

Check and note which adaption area for bank 2 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING ETHANOL CONTENT»(ref-476781-S01320210132012060500000)

HINT: If the fuel adaptations indicate too lean fuel/air mixture (adaptation value above 1.0) at idle, this indicates an air leak.

HINT: To find the problem, proceed as follows

1. Check the inlet system and exhaust system for leaks.
2. Engine running.
3. Check fuel pressure to, see if it is low.
4. Ignition on
5. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

Other information

1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-476750-S38054557722012060500000)
2. see «CHECKING FOR AIR LEAKAGE IN THE EXHAUST SYSTEM»(ref-494824-S07275287112012081600000)

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S39217980872012060500000)

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S34693281792012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S17816952372012060500000) .

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affects the read-out. Squeeze the hose between the EVAP-valve and inlet pipe to minimize the addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S17816952372012060500000)

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S00438992362012060500000)

HINT: The cause of the symptom and/or diagnostic trouble code may be that the vehicle has been refuelled with incorrect fuel for that vehicle. The fuel system contains fuel with too high ethanol content.

The energy content in ethanol-diluted fuel is lower than in pure gasoline. This means that the control module compensates for the lower energy content, by increasing the injection volume, to be able to reach lambda=1 at the front heated oxygen sensor. This compensation is normally called "Front lambda control slow" or "Lambda integrator", and varies to compensate for the vehicle's status in the form of component spread, small air leaks, wear, etc. The value of this compensation in the ideal case is 1.0 for pure gasoline. Increased ethanol content of the fuel increases the compensation by approx. 0.05 per 10% ethanol dilution.

The control module is designed to handle an ethanol dilution up to 25%. In combination with other deviations from the ideal case, however, lower ethanol content may be enough to cause customer symptoms. This mainly occurs at engine start with cool engine at outdoor temperatures below 0 °C. Then the diagnostic trouble code may also be set for the engine running on too lean mixture.

Note. In a vehicle intended for gasoline, only pure gasoline shall be used. Even if engine start/operation works, other fuel-related components in the vehicle may be damaged by too high ethanol content.

1. Measure the ethanol content of the fuel according to the instructions below. If measured ethanol content is above 25%, then ethanol dilution is the likely cause of the symptom and/or to the diagnostic trouble code being stored. If measured ethanol content is below 25%, symptoms and/or diagnostic trouble code may have been caused by earlier occurrence of incorrect fuel in the system for that vehicle. HINT: Check refuelling history by talking to customer. If nothing indicates incorrect fuel, neither now nor earlier, continue troubleshooting to check other possible causes of faults.

Other information

1. see «MEASURING THE ETHANOL CONTENT»(ref-476691-S40487988662012060500000)

1. Continue Refer to «CHECKING SYSTEM»(ref-476781-S41673602592012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check and note which adaption area for bank 2 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING SYSTEM»(ref-476781-S40331260062012060500000)

1. Check the air filter. Check for blockage.

HINT: If fuel adaptations indicate too rich fuel/air mixture (adaptation value below 1.0) in several adaptation ranges, this indicates a fuel malfunction. The fault may be caused by too high fuel pressure for example.

HINT: To find the problem, proceed as follows

1. Check that the engine's oil level is not too high. HINT: Adaptations may show rich fuel/air mixture if several cold starts with short subsequent driving time have been performed (e. g., moving cars) and thus the engine oil has been contaminated by gasoline. This affect on the adaptations disappears after driving for some time since the fuel vapors are combusted by the engine. Check the EVAP-valve for leakage. HINT: A valve that does not seal constantly leaks fuel vapors, which thus affect the adaptations.
2. Engine running.
3. Check fuel pressure for high fuel pressure.
4. Ignition on
5. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

HINT: If the residual pressure is too low, one malfunction cause may be leaking (non-sealing) injectors, for example.

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S21522175682012060500000)

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S13482590102012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S36281280722012060500000) .

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S36281280722012060500000)

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S07234917662012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

Check and note which adaption area for bank 2 is faulty by going through the list of adaption areas.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates RPM range and the second load range.

HINT: Thus, range 1.1 designates a case with low RPM with low load, and 6.6 a case with high RPM and high load.

1. Continue Refer to «CHECKING SYSTEM»(ref-476781-S27760451382012060500000)

1. Check the air filter. Check for blockage.

HINT: If fuel adaptations indicate too rich fuel/air mixture (adaptation value below 1.0) in several adaptation ranges, this indicates a fuel malfunction. The fault may be caused by too high fuel pressure for example.

HINT: To find the problem, proceed as follows

1. Check that the oil level is between the minimum and maximum markings
2. Check the induction system for clogs and loose components (such as a loose air guide in the air filter holder). HINT: Adaptations may show rich fuel/air mixture if several cold starts with short subsequent driving time have been performed (e. g., moving cars) and thus the engine oil has been contaminated by gasoline. This affect on the adaptations disappears after driving for some time since the fuel vapors are combusted by the engine. Check the EVAP-valve for leakage. HINT: A valve that does not seal constantly leaks fuel vapors, which thus affect the adaptations.
3. Engine running.
4. Check fuel pressure for high fuel pressure.
5. Ignition on
6. Check residual pressure for too low residual pressure.

Remedy as necessary.

HINT: Normal fuel pressure at idle and warm engine shall be approx. 480 kPa.

HINT: The residual pressure when the engine is off and the ignition is on shall be approx. 100 kPa lower than during idle.

HINT: If the residual pressure is too low, one malfunction cause may be leaking (non-sealing) injectors, for example.

Other information

1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-476750-S38054557722012060500000)

1. Continue Refer to «CHECKING MASS AIR FLOW SENSOR»(ref-476781-S06908764312012060500000)

1. Engine running. Check and compare the calculated air mass with the actual air mass readout from the mass air flow sensor. Try by measuring at different RPM. HINT: Differences of more than approx. 20% between the signals indicate a malfunction of the mass air flow sensor. HINT: Remedy as necessary. NOTE: When replacing mass air flow sensor, repeat the check to verify that the problem has been solved with the replacement.

1. For more information about current fuel compensation, refer to «READOUT OF TOTAL FUEL COMPENSATION»(ref-476781-S40561460152012060500000) .
2. To continue, refer to «RESET ADAPTATIONS»(ref-476781-S20195854402012060500000) .

1. Engine running.
2. For reading out total fuel compensation at every given moment, use the VCT2000 (or appropriate scan tool). HINT: The readout value shows the short-term fuel trim's and the long-term fuel trim's total compensation of the injection time in real time. HINT: Positive values indicate additional fuel, negative values indicate reduction of additional fuel. Try by measuring at different RPM with different engine load. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affect the readout. For example, squeeze the hose between the EVAP-valve and inlet pipe to minimize addition of fuel from the EVAP-system.

1. Continue Refer to «RESET ADAPTATIONS»(ref-476781-S20195854402012060500000)

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect by scrolling through the list with adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 or higher than 1.15.

HINT: Also, perform a few full throttle accelerations to perform the adaptations that are not affected by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. Engine speed > or = 600 RPM.
2. Engine temperature between 80-110°C.
3. Adaptation active = executed.
4. EVAP-valve not active = 0 μs.

HINT: At high fuel vaporization the EVAP-valve is active longer time and then it may be necessary to disconnect the hose between the EVAP-valve and the canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S34250939462012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine. Check whether the fault is permanent or intermittent by reading the signal of the fuel temperature sensor. Check that the value is feasible. HINT: The signal is measured in the injector delivery pipe and is thus affected by engine temperature. If the value is not feasible, the fault is permanent. If the value is feasible, the fault is intermittent and not currently active.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S00033297392012060500000)

Scheme 358

Scheme 359

1. Ignition off HINT: The fuel temperature sensor is integrated in the fuel pressure sensor. Check the fuel pressure sensor connectors and connections for contact resistance and oxidation. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-476691-S30437390172012060500000) see «SIGNAL SPECIFICATION»(ref-476694-S14228516802012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17655503092012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S37870767492012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Read off the fuel temperature sensor signal using the VCT2000 (or appropriate scan tool). Check that the signal is within its permitted range. The signal is measured in the injector delivery lines as the signal is affected by the engine temperature.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S38460924472012060500000)

see FAULT TRACING

1. Start the engine. Check whether the fault is permanent or intermittent by reading the signal of the fuel temperature sensor. Check that the value is feasible. HINT: The signal is measured in the injector delivery pipe and is thus affected by engine temperature. If the value is not feasible, the fault is permanent. If the value is feasible, the fault is intermittent and not currently active.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S24002896872012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Read off the fuel temperature sensor signal using the VCT2000 (or appropriate scan tool). Check that the signal is within its permitted range. The signal is measured in the injector delivery lines as the signal is affected by the engine temperature.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S07251659832012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine. Check whether the fault is permanent or intermittent. Read off the fuel temperature sensor signal. Check that the value is within its permitted range. HINT: The signal is measured in the delivery line of the injectors and the signal is therefore affected by the engine temperature. The fault is permanent if the value is not within its permitted range. If the value is within its permitted range, the fault is intermittent and not presently active.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S30692307142012060500000)

Scheme 360

1. Ignition off
2. Disconnect the engine control module (ECM). HINT: The fuel temperature sensor is integrated in the fuel pressure sensor. Check the signal cable. Check for a short-circuit to ground. Take readings between control module terminal #A46 (#A46) and fuel pressure sensor terminal #2. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000) see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000) see «FUEL PRESSURE AND TEMPERATURE SENSOR, REPLACING»(ref-476695-S41579193842012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S25611365262012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Read off the fuel temperature sensor signal using the VCT2000 (or appropriate scan tool). Check that the signal is within its permitted range. The signal is measured in the injector delivery lines as the signal is affected by the engine temperature.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S06747047122012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine. Check whether the fault is permanent or intermittent. Read off the fuel temperature sensor signal. Check that the value is within its permitted range. HINT: The signal is measured in the delivery line of the injectors and the signal is therefore affected by the engine temperature. The fault is permanent if the value is not within its permitted range. If the value is within its permitted range, the fault is intermittent and not presently active.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S26973229332012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Read off the fuel temperature sensor signal using the VCT2000 (or appropriate scan tool). Check that the signal is within its permitted range. The signal is measured in the injector delivery lines as the signal is affected by the engine temperature.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S23388565092012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

CHECKING THE CONNECTORS

Check the fuel pressure sensor's connector and connections for contact resistance and oxidation.

Remedy as necessary.

Other information

1. see «CONTROL MODULE FUEL PUMP (FP), REPLACING»(ref-476695-S09602766612012060500000)
2. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17655503092012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S37463229372012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is reasonable. Normal value is 480 ± 5 kPa at idle. Read off the signal from the fuel pressure sensor when the ignition is on and check that the fuel pressure has dropped. Normally, the pressure shall drop by approx. 100 kPa from the value at idle. NOTE: The signal indicates absolute pressure.

Is the signal reasonable?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S04368053452012060500000)

see FAULT-TRACING

Check the fuel pressure sensor's connector and connections for contact resistance and oxidation.

Remedy as necessary.

Other information

1. see «FUEL PRESSURE AND TEMPERATURE SENSOR, REPLACING»(ref-476695-S41579193842012060500000)
2. see «FUEL PUMP DRIVER MODULE»(ref-476695-S02740070142012060500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S17560464652012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is reasonable. Normal value is 480 ± 5 kPa at idle. Read off the signal from the fuel pressure sensor when the ignition is on and check that the fuel pressure has dropped. Normally, the pressure shall drop by approx. 100 kPa from the value at idle. NOTE: The signal indicates absolute pressure.

Is the signal reasonable?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S42495457402012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the fuel pressure sensor's connector and connections for contact resistance and oxidation.

Remedy as necessary.

Other information

1. see «FUEL PRESSURE AND TEMPERATURE SENSOR, REPLACING»(ref-476695-S41579193842012060500000)
2. see «CONTROL MODULE FUEL PUMP (FP), REPLACING»(ref-476695-S09602766612012060500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S19114071522012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is reasonable. Normal value is 480 ± 5 kPa at idle. Read off the signal from the fuel pressure sensor when the ignition is on and check that the fuel pressure has dropped. Normally, the pressure shall drop by approx. 100 kPa from the value at idle. NOTE: The signal indicates absolute pressure.

Is the signal reasonable?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S12644697172012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start and run the engine to operating temperature. Check whether the fault is permanent or intermittent by reading off the signal from the fuel pressure sensor. Check that the value is within its permitted range. The value must be 480 ±5 kPa when idling, with the engine at operating temperature and in neutral. The pressure must drop with the ignition off. The fault is permanent if the value is not within its permitted range. If the value is within its permitted range, this indicates that the fault is intermittent and not presently active.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S26666189262012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start and warm up the engine.
4. Read off the fuel pressure sensor's signal. Check that the fuel pressure sensor's signal is correct. The value shall be 480 ± 5 kPa at idle, neutral and warm engine. The pressure shall drop at ignition off.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S02203478092012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start and run the engine to operating temperature. Check whether the fault is permanent or intermittent by reading off the signal from the fuel pressure sensor. Check that the value is within its permitted range. The value must be 480 ±5 kPa when idling, with the engine at operating temperature and in neutral. The pressure must drop with the ignition off. The fault is permanent if the value is not within its permitted range. If the value is within its permitted range, this indicates that the fault is intermittent and not presently active.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S36985867092012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start and warm up the engine.
4. Read off the fuel pressure sensor's signal. Check that the fuel pressure sensor's signal is correct. The value shall be 480 ± 5 kPa at idle, neutral and warm engine. The pressure shall drop at ignition off.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S25214691542012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Activate the injector to which the diagnostic trouble code refers using the VCT2000 (or appropriate scan tool). The injector should make a clicking noise upon activation.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S17920252632012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

1. Ignition on Check if the malfunction is permanent or intermittent by activating readout of the accelerator pedal position sensor's signals. Check that the value for both signals at unaffected accelerator pedal is approx. 8% and when the pedal is fully pressed down approx. 82%. If the signal is incorrect, this indicates that the malfunction is permanent. If the signal is correct, this indicates that the malfunction is intermittent and not active right now.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S12436881972012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Activate readout of the accelerator pedal position sensor's signals. Check that the value for both signals at unaffected accelerator pedal is approx. 8% and when the pedal is fully pressed down approx. 82%.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S42931658462012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on Check if the malfunction is permanent or intermittent by activating readout of the accelerator pedal position sensor's signals. Check that the value for both signals at unaffected accelerator pedal is approx. 8% and when the pedal is fully pressed down approx. 82%. If the signal is incorrect, this indicates that the malfunction is permanent. If the signal is correct, this indicates that the malfunction is intermittent and not active right now.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S36996452042012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Activate readout of the accelerator pedal position sensor's signals. Check that the value for both signals at unaffected accelerator pedal is approx. 8% and when the pedal is fully pressed down approx. 82%.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S27107491322012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on Check if the malfunction is permanent or intermittent by activating readout of the accelerator pedal position sensor's signals. Check that the value for both signals at unaffected accelerator pedal is approx. 8% and when the pedal is fully pressed down approx. 82%. If the signal is incorrect, this indicates that the malfunction is permanent. If the signal is correct, this indicates that the malfunction is intermittent and not active right now.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S22944560612012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on Activate readout of the accelerator pedal position sensor's signals. Check that the value for both signals at unaffected accelerator pedal is approx. 8% and when the pedal is fully pressed down approx. 82%.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S29930735312012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

CHECKING THE FUEL INJECTION SYSTEM, IGNITION SYSTEM AND COMPONENTS

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: Engine cylinders are counted starting from the right side of the vehicle, that is, the cylinder farthest from the engine's flywheel.

HINT: The cause of misfiring does not necessarily have to be associated to the specific identified cylinder. The cause may sometimes be traced to previous cylinder/cylinders (counted in firing order) or to components connected per bank and thus to several cylinders.

Check the fuel level in the tank.

Check that the engine oil level is correct.

Check for moisture in the electrical terminals for the ignition coils and in the spark plug well.

Check the spark plugs. Search for damage to the insulation and other damage.

Check cam profile solenoid and valve depressor for dirt and damages.

Check the engine intake system for air leakage.

Check the function of the crankcase ventilation.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

HINT: Read off the misfire counter using the VCT2000 (or appropriate scan tool).

Remedy as necessary.

Other information

1. see «CONTROL MODULE FUEL PUMP (FP), REPLACING»(ref-494826-S05872105882012081600000)
2. see «IGNITION COIL»(ref-476695-S09903760182012060500000)
3. see «CYLINDER LEAKAGE TEST»(ref-476762-S05706523772012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S24569237742012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Check that the misfiring counter does not count up and that the engine runs on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S37506840772012060500000)

see FAULT-TRACING

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: The engine cylinders are counted from the cylinder furthest away from the flywheel.

1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7.
2. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.

Check the fuel level in the tank.

Check that the engine oil level is correct.

Check for moisture in the electrical terminals for the ignition coils and in the spark plug well.

Check the spark plugs. Search for damage to the insulation and other damage.

Check the engine intake system for air leakage.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

HINT: Read off the misfire counter using the VCT2000 (or appropriate scan tool).

Remedy as necessary.

Other information

1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-476750-S38054557722012060500000)
2. see «IGNITION COIL, REPLACING»(ref-476695-S24091388902012060500000)
3. see «CONTROL MODULE FUEL PUMP (FP), REPLACING»(ref-494826-S05872105882012081600000)
4. see «CYLINDER LEAKAGE TEST»(ref-476762-S05706523772012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S38206105742012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Check that the misfiring counter does not count up and that the engine runs on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S03617838442012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Test drive the car on the road in different driving conditions with high and low loads so that the engine control module (ECM) can carry out diagnostics.
5. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
6. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S41464803862012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Test drive the car on the road in different driving conditions with high and low loads so that the engine control module (ECM) can carry out diagnostics.
5. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
6. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S23529602172012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Test drive the car on the road in different driving conditions with high and low loads so that the engine control module (ECM) can carry out diagnostics.
5. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
6. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S29143344752012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the diagnosis is "Completed". Check whether the fault is permanent or intermittent by reading the fault status of the trouble code when the diagnostic status is "Completed". If the fault status is "Fault found", the fault is permanent. If the fault status is "No fault found", the fault is intermittent and not currently active. NOTE: The fault status cannot switch from "Fault found" to "No fault found" within the same operating cycle.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S40976953162012060500000)

Scheme 361

1. Ignition off
2. Disconnect the engine control module (ECM). Check the signal cables for open-circuit or short-circuit to ground or supply voltage. Check between: Control module terminal #A30 (#A30) and engine speed sensor connector #1, signal cable (+). Control module terminal #A6 (#A6) and engine speed sensor connector #2, signal cable (-). Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000) see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000) see «ENGINE SPEED (RPM) SENSOR, REPLACING»(ref-476695-S29520554312012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

1. Continue Refer to «VERIFICATION»(ref-476781-S02293494452012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S33699596112012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the diagnosis is "Completed". Check whether the fault is permanent or intermittent by reading the fault status of the trouble code when the diagnostic status is "Completed". If the fault status is "Fault found", the fault is permanent. If the fault status is "No fault found", the fault is intermittent and not currently active. NOTE: The fault status cannot switch from "Fault found" to "No fault found" within the same operating cycle.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S21235104842012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S27498031342012060500000)

see FAULT-TRACING

1. Start the engine. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the diagnosis is "Completed". Check whether the fault is permanent or intermittent by reading the fault status of the trouble code when the diagnostic status is "Completed". If the fault status is "Fault found", the fault is permanent. If the fault status is "No fault found", the fault is intermittent and not currently active. NOTE: The fault status cannot switch from "Fault found" to "No fault found" within the same operating cycle.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S12456720802012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S14728497812012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active. NOTE: The fault status cannot change from "Fault found" to "No fault found" in the same operating cycle.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S39372609342012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S22285873032012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active. NOTE: The fault status cannot change from "Fault found" to "No fault found" in the same operating cycle.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S31508281742012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S33916326912012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

1. Start the engine. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active. NOTE: The fault status cannot change from "Fault found" to "No fault found" in the same operating cycle.

1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476781-S28208347682012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine.
4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-476781-S37041082942012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING
