TIMING CHAIN, ASSEMBLING

Scheme 824

Scheme 825

Note. Make sure that these components are installed to the noted removal position.

Scheme 826

Torque: M8

24 Nm

Scheme 827

Torque: M6

10 Nm

Scheme 828

Note. Make sure that the mating faces are clean and free of foreign material.

Note. The component must be installed within 5 minutes of applying the sealant.

Use: Liquid gasket, 30757050

Scheme 829

Scheme 830

Torque: M8

24 Nm

Scheme 831

Torque: Center nut vibration damper (crankshaft)

Stage 1: 120 Nm

Stage 2: Loosen the screw 360 degree

Stage 3: 50 Nm

Stage 4: 90 degree

1. Step 1:120 Nm
2. Step 2: Slacken the screw 360 degrees
3. Step 3:50 Nm
4. Step 4: 90 degrees

Scheme 832

Scheme 833

Scheme 834

Scheme 835
