HEADLAMPS, ALIGNING
Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.
| CAUTION | Cars equipped with Bi-Xenon lamps or halogen lamps are adjusted in the same way. Ensure that the position sensor for the Bi-Xenon lamps is correctly calibrated. |
PREPARATORY WORK
| CAUTION | Always adjust the headlamp beam according to the legal requirements of the market. |
Scheme 10
- Ensure that there is sufficient battery voltage.
- Check the button that controls the lighting level. Set the button to the 0 position.
- Ignition and low beam on.
Note. Always adjust the beam with low beam switched on.
Scheme 11
- Adjust the beam vertically (Y) by turning the Allen screw. See the illustration
- Adjust the beam horizontally (X) by turning the Allen screw. See the illustration.
HINT: Use a 6 mm Allen screw.
Note. Adjust according to the illustration for the applicable market.
Scheme 12
USA.
