Headlamp Control Module (Hcm) - Specifications, Electrical/electronic: Overview Volvo XC70 II

Headlights 2 illustrations

Scheme 2

Scheme 2: GENERAL
Scheme 2: GENERAL

Type

Resistance sensor.

characteristic

Resistance between #C1:1 and #C1:4 changes linearly depending on angle.

Scheme 3

Scheme 3: TERMINAL
Scheme 3: TERMINAL

Position sensor 7/119

Connector terminalControl module terminalSignal type
#C1:1#C1:9Ground
#C1:2
#C1:3
#C1:4#C1:20Signal, position sensor
#C1:5#C1:19Power supply, +5V

Position sensor 7/121

Connector terminalControl module terminalSignal type
#C1:1#C1:8Ground
#C1:2
#C1:3
#C1:4#C1:18Signal, position sensor
#C1:5#C1:17Power supply, +5V
