Engine Control Module (ECM) - Component Location: Component Locations Volvo XC70 II

Engine Control Systems 2 illustrations ~144 words

LOCATION OF COMPONENTS

see LOCATION OF COMPONENTS

Scheme 3

Scheme 3: LOCATION OF COMPONENTS
Scheme 3: LOCATION OF COMPONENTS

Location of components

  1. Knock sensor (KS), 2 x
  2. Injectors, 6 x
  3. Cam profile valve, 2 x
  4. Reset valve camshaft (CVVT).
  5. Engine control module (ECM).
  6. Camshaft sensor, 2 x.
  7. Mass airflow sensor/air temperature sensor
  8. Evaporative emission system (EVAP) valve.
  9. Throttle unit.
  10. Engine speed (RPM) sensor.
  11. Engine cooling fan (FC).
  12. Oil level sensor
  13. Intake pressure sensor.
  14. Actuator variable intake, 2 x

Scheme 4

Scheme 4: LOCATION OF COMPONENTS
Scheme 4: LOCATION OF COMPONENTS

Location of components

  1. Knock sensor (KS), 2 x
  2. Injectors, 6 x
  3. Reset valve camshaft (CVVT).
  4. Engine control module (ECM).
  5. Camshaft sensor, 2 x.
  6. Mass airflow sensor/air temperature sensor
  7. Evaporative emission system (EVAP) valve.
  8. Throttle unit.
  9. Engine speed (RPM) sensor.
  10. Radiator temperature sensor.
  11. Engine cooling fan (FC).
  12. Oil level sensor
  13. Intake pressure sensor.
  14. Actuator variable intake, 2 x

see LOCATION OF COMPONENTS

see LOCATION OF COMPONENTS
