REPLACING CABLE TERMINALS
Expose the central electrical unit.
Scheme 1115
Remove the insulating plate from the central electrical unit by releasing the catch at the same time as the insulating plate is slid out.
HINT: Use a radio screwdriver.
Scheme 1116
Release the catch and slide out the lock mechanism.
HINT: Use a radio screwdriver.
Scheme 1117
Separate the connector.
HINT: Use a radio screwdriver.
Press in the locking tab on the cable terminal and carefully pull out the cable and the cable terminal.
HINT: Use tool see 9512812 or see 9512637 .
Scheme 1118
Remove the connector from the central electrical unit by releasing the catches at the same time the connector is slid out on the cable side.
HINT: Use a radio screwdriver.
Open the secondary lock.
Remove the cable terminal.
HINT: Use tool see 9512631 .
