Scheme 1
Type
Oil pressure sensor: Linear Piezo resistive pressure sensor, bridge connected.
Oil temperature sensor: Temperature dependent resistor (Thermistor) of the negative temperature coefficient (NTC) type.
The sensors are integrated in the same component.
characteristic
Oil pressure sensor
Oil temperature sensor: The resistance between terminal #1 and #4 must be 5.7 kohms at +20 °C. the resistance drops with ascending temperature.
Scheme 2
| Terminal connector | Control module terminal | Signal type |
|---|---|---|
| #1 | #C3:1 | Signal, oil temperature |
| #2 | #C3:2 | Power supply, +5 V (common) |
| #3 | #C3:3 | Signal, oil pressure |
| #4 | #C3:4 | Ground |
DESCRIPTION
All the values that are given are measured between the respective connection given in column 1 and #2 or #4 (ground).
Pins 3, 5 and 6 are not used.
| U= | DC voltage in volts (V) | U bat = | Battery voltage in volts (V) |
|---|---|---|---|
| I = | Current in amperes (A) | U low = | Voltage approximately 0 V |
| F = | Frequency in Hertz (Hz) |
Scheme 3
| ECU | Signal type | Ignition on | Other |
|---|---|---|---|
| #C1:1 | Power supply | U=U bat | Protected with a 10 A fuse |
| #C1:2 | Signal ground 1 | U=U low | |
| #C1:3 | |||
| #C1:4 | Signal ground 2 | U=U low | |
| #C1:5 | |||
| #C1:6 | |||
| #C1:7 | Communication lead, control modules (CAN H) | U=2.5-4.0 V | |
| #C1:8 | Communication lead, control modules (CAN L) | U=1, 0-2, 5 V |
CONNECTOR C1
All the values that are given are measured between the respective connection given in column 1 and #2 (ground)
Scheme 4
| ECU | Signal type | Ignition on | Other |
|---|---|---|---|
| #C2:1 | Power supply | U=U bat | |
| #C2:2 | Signal ground | U=U low |
CONNECTOR C2
All the values that are given are measured between the respective connection given in column 1 and #2 or #4 (ground).
Pins 3, 5 and 6 are not used.
| U= | DC voltage in volts (V) | U bat = | Battery voltage in volts (V) |
|---|---|---|---|
| I = | Current in amperes (A) | U low = | Voltage approximately 0 V |
| F = | Frequency in Hertz (Hz) |
| ECU | Signal type | Ignition on | Miscellaneous |
|---|---|---|---|
| #C1:1 | Power supply | U=U bat | Protected with a 10 A fuse |
| #C1:2 | Signal ground 1 | U=U low | |
| #C1:3 | |||
| #C1:4 | Signal ground 2 | U=U low | |
| #C1:5 | |||
| #C1:6 | |||
| #C1:7 | Control modules communication cable (CAN H) | U=2.5-4.0 V | |
| #C1:8 | Control modules communication cable (CAN L) | U=1, 0-2, 5 V |
CONNECTOR C1
All the values that are given are measured between the respective connection given in column 1 and #2 (ground)
| ECU | Signal type | Ignition on | Miscellaneous |
|---|---|---|---|
| #C2:1 | Power supply | U=U bat | |
| #C2:2 | Signal ground | U=U low |
CONNECTOR C2
