Keyless Vehicle Module, Closing Velocity Module, Forward Sensing Module, and Parking Assistance Module - Specifications, Electrical/electronic: Other Volvo XC70 II

Collision/avoidance 1 illustration ~133 words

CHECK

Prerequisites (unless otherwise specified)

  1. Breakout box connected.
  2. Antenna connected

Check

Antenna

Measure the resistance between the antenna connections

The value should be 10-30 ohms.

The antennas can also be checked using a function in the control module.

Scheme 154

Scheme 154: INTERNAL ANTENNAS IN THE PASSENGER COMPARTMENT

Type

SPOL antennas

Characteristic

Resistance depends on outside temperature and the length of the cables in the vehicle. A guide value is approx. 10-30 ohms

Resistance in the antenna should be 0 ohms or infinite.

Other information

Option.

TERMINAL

Connector terminalControl module terminalSignal typeMiscellaneous
#C2#C1-2Antenna signal (-), inner antenna in cargo compartmentSignal only upon antenna activation.
#C4#C1-4Antenna signal (+), inner front antennaSignal only upon antenna activation.
#C16#C1-16Antenna signal (-), inner front antennaSignal only upon antenna activation.
#C18#C1-18Antenna signal (+), inner antenna in cargo compartmentSignal only upon antenna activation.
Connector terminalControl module terminalSignal typeMiscellaneous
#B37#C2-14Antenna signal (+), inner center antennaSignal only upon antenna activation.
#B40#C2-17Antenna signal (-), inner center antennaSignal only upon antenna activation.

Prerequisites (unless otherwise specified)

  1. Breakout box connected.
  2. Antenna connected

Check

Antenna

Measure the resistance between the antenna connections

The value should be 10-30 ohms.

The antennas can also be checked using a function in the control module.
