Scheme 7
| Component | Note | Resistance (ohms) |
|---|---|---|
| Gear shift solenoid S1, S2 | Resistance between the solenoid pins and the solenoid casing/transmission housing. | +20 °C= 11-16 ohms |
Other values, see diagram. When measuring at other temperature than +20 °C the check-measurement shall be performed at +20 °C. This is to ensure if the resistance is correct or not.
Scheme 8
| Component | Note | Resistance (ohms) |
|---|---|---|
| Lock-up solenoid (SLU) Line pressure solenoids (SLT), (SLB1),(SLC1),(SLC2),(SLC3) | Resistance between solenoid pins. | +20 °C= 5.0-5.6 ohms |
Other values, see diagram. When measuring at other temperature than +20 °C the check-measurement shall be performed at +20 °C. This is to ensure if the resistance is correct or not.
Scheme 9
| Component | Note | Resistance (ohms) |
|---|---|---|
| Oil temperature sensor | Resistance between the temperature sensor terminals. | +10 °C = 5620-7310 ohms |
| +25 °C = 3500 ohms | ||
| +110 °C = 220-270 ohms |
Resistance decreases with increasing temperature.
A test measurement must be taken at both temperatures. This is to establish if the resistance is correct or not.
Scheme 10
| Component | Note | Resistance (ohms) |
|---|---|---|
| Solenoid p-position lockout | Resistance between the solenoid's connections | +20 °C= 24.5 - 29.3 ohms |
