Electrical & Engine Control - Specifications (Xc): Other Volvo XC70 I facelift

Engine Control Systems 2 illustrations ~133 words

Heated oxygen sensors (HO2S), removing

  1. For B5xx4T -2004, see «Heated oxygen sensors (HO2S), replacing»(ref-430985-S33960067052011101900000)
  2. For B5xx4T 2005-, see «Heated oxygen sensor (HO2S), replacing»(ref-430985-S28241031382011101900000) .

Scheme 182

Scheme 182: Installing the adapter cable
Scheme 182: Installing the adapter cable

Note. Ensure that the ends of the protective sheath on the adapter cable point downwards so that water does not gather in the protective sheath.

Install

  1. the adapter cable between the existing 4-pin connectors
  2. a tie strap as shown in the illustration.

Scheme 183

Scheme 183
Scheme 183

Install the adapter wiring between the existing 6-pin connectors.

Note. Ensure that the ends of the protective sheath on the adapter cable point downwards so that water does not gather in the protective sheath.

Install

  1. the inlet hose between the air cleaner (ACL) and turbocharger (TC) on the turbocharger (TC)
  2. the air cleaner (ACL) housing.
