Preheating, front heated oxygen sensor (HO2S)
Resistance approximately 3 ohms (at 20°C)
Scheme 135
Binary probe
Preheating, rear heated oxygen sensor (HO2S)
Resistance approximately 10 ohms (at 20°C)
Scheme 136
Individually mounted ignition coil with an integrated power driver
Scheme 137
Multi electron
Scheme 138
NTC resistance.
| Temperature (°C) | 0 | 10 | 20 | 25 | 30 |
|---|---|---|---|---|---|
| R (ohms) | 6318 | 3857 | 2424 | 1941 | 1513 |
| V (Volts) | 4.32 | 3.97 | 3.54 | 3.30 | 3.00 |
Scheme 139
Linear pressure sensor. Measurement range 0-3100 kPa.
| V (Volts) | 0.25 | 1.00 | 2.00 | 3.00 | 4.75 |
|---|---|---|---|---|---|
| P (kPa) | 0 | 517 | 1206 | 1894 | 3100 |
Scheme 140
Pulse width modulated valve. Resistance 29.7 1.4 ohms
Scheme 141
Solenoid valve. Resistance 17 1 ohms
Scheme 142
Piezo electric lineal pressure sensor.
| P (kPa) | 2.0 | 1.5 | 0 | 0.5 |
|---|---|---|---|---|
| V (Volts) | 1.70 | 2.10 | 3.30 | 3.70 |
Scheme 143
Mechanical relay. Resistance coil 96 ohms between terminals #2 and #4
Scheme 144
PWM controlled discharge module with variable output voltage and diagnostics
Scheme 145
Mechanical relay. Resistance 80 ohms
Scheme 146
Self-adjusting.
| Position (mm) | 0 | 25 | 50 | 100 |
|---|---|---|---|---|
| R (ohms) | 1500-2500 | 1000-2000 | 750-1750 | 500-1000 |
Scheme 147
Self-adjusting.
| Position (mm) | 0 | 20 | 30 | 50 |
|---|---|---|---|---|
| R (ohms) | 1300-2100 | 1000-1800 | 900-1700 | 600-1400 |
Scheme 148
Two separate switches.
Scheme 149
Level indicator
Scheme 150
Pressure controlled switch.
