Air conditioning 2.5l turbo

# 2.5l turbo, automatic a/c circuit

# 2.5l turbo, automatic a/c circuit (1 of 2)

Air conditioning 2.5l turbo — 2.5l turbo, automatic a/c circuit — 2.5l turbo, automatic a/c circuit (1 of 2). Volvo V70 II facelift (2004-2007)

Components on the diagram

# 2.5l turbo, automatic a/c circuit (2 of 2)

Air conditioning 2.5l turbo — 2.5l turbo, automatic a/c circuit — 2.5l turbo, automatic a/c circuit (2 of 2). Volvo V70 II facelift (2004-2007)

Components on the diagram
