Installing the C-Post Panel Volvo V70 II facelift

Interior - Removal, Replacement and Installation 2 illustrations

Installing the C-Post Panel

Install

In reverse order.

Scheme 377

Scheme 377: Removing the D-Post Panel
Scheme 377: Removing the D-Post Panel

Remove

  1. The cover for the side panel. See «Side Panel, Cargo Compartment, Replacing»(ref-406997-S25937864812011070100000)
  2. the central panel. See «panel, Cantrail, Replacing»(ref-406997-S25965666552011070100000) .
CAUTIONDetach the panel in the following order. Otherwise the panel may be damaged.
  1. Grasp the edge. Pull inwards so that the clips release (1)
  2. Detach the upper edge at the window so that the panel can pass the gas strut (2)
  3. Pull inwards so that the clips in the opening release (3)
  4. Lift upwards.

Scheme 378

Scheme 378: Installing the D-post panel
Scheme 378: Installing the D-post panel

Install

In reverse order.

Note. Align against the sill trim panel and the load securing eyes.
