Installing the rear engine pad Volvo V70 II facelift

Installing the rear engine pad

Finishing

1. Install a new screw and nut on the lower torque rod. Tighten to 35 Nm . Angle-tighten 90° . Use bevel protractor «9512050»(ref-403953-S36645634772011061000000) .

1. Tighten the lower engine pad screw. Tighten to 50 Nm
2. Install the splash guard under the engine. Tighten to 25 Nm
3. Install both the screws for the mountings for the three-way catalytic converter (TWC). Tighten to 10 Nm
4. Lower the car.

Install

1. a new nut in the upper mounting for the engine pad. Tighten to 50 Nm .

Scheme 246

Install

1. the engine stabilizer brace between the suspension turrets. Tighten the four screws. Tighten to 50 Nm
2. the screw for the engine stabilizer brace mounting at the torque control arm on the engine. Tighten to 80 Nm .

See Engine mount, front, replacing

See Engine mount, front, replacing

See Bushing sub-frame, replacing
