Activating Components
This function allows a number of components to be activated so that their functions can be checked. The following components can be activated
Pump Motor
Activating hydraulic modulator pump motor.
The pump motor should "hum".
Inlet Valve Left Front
Activating left front wheel inlet valve.
"Clicking sound" in hydraulic modulator.
Right Front Inlet Valve
Activating right front wheel inlet valve.
"Clicking sound" in hydraulic modulator.
Inlet Valve Left Rear
Activating left rear wheel inlet valve.
"Clicking sound" in hydraulic modulator.
Inlet Valve Right Rear
Activating right rear wheel inlet valve.
"Clicking sound" in hydraulic modulator.
Outlet Valve Left Front
Activating left front wheel outlet valve.
"Clicking sound" in hydraulic modulator.
Outlet Valve Right Front
Activating right front wheel outlet valve.
"Clicking sound" in hydraulic modulator.
Outlet Valve Left Rear
Activating left rear wheel outlet valve.
"Clicking sound" in hydraulic modulator.
Outlet Valve Right Rear
Activating right rear wheel outlet valve.
"Clicking sound" in hydraulic modulator.
TRACS/STC Inlet Valve
Activating the TRACS/STC inlet valve.
"Clicking sound" in hydraulic modulator.
Explanation
Not all the parameters described need to be implemented in the control module. This varies from system to system.
Frozen values are parameter values that are stored when a diagnostic trouble code (DTC) is stored.
Battery Voltage, Value
Measurement range: 0-12 V.
Normal value when the generator (GEN) is charging: 13.0-14.5 V.
Distance, Value
Measurement range: 0-1048575 km.
The value indicates the total mileage of the car at the time the diagnostic trouble code (DTC) was stored.
Passenger Compartment Temperature, Value
Measurement range: -60-195 °C.
The combined instrument panel obtains the value via the control area network (CAN).
Outside Temperature, Value
Measurement range: -128-127.75 °C.
The combined instrument panel obtains the value via the control area network (CAN).
Engine Running, Status
The status displays whether the engine was running when the diagnostic trouble code (DTC) was stored.
No = the engine was not running
Yes = the engine was running
Time, Value
The value displays the time that has passed since the diagnostic trouble code (DTC) was stored.
Scheme 10
The value indicates the stop (brake) warning lamp status.
OFF: The warning lamp is out
ON (cont): The warning lamp is lit
ON (audible): The warning lamp flashes
Scheme 11
The value indicates ABS warning lamp status.
OFF: The warning lamp is out
ON (cont): The warning lamp is lit
ON (audible): The warning lamp flashes
Scheme 12
The value indicates the spin warning lamp status.
OFF: The warning lamp is out
ON (cont): The warning lamp is lit
ON (audible): The warning lamp flashes
Scheme 13
The value indicates the stop (brake) lamp switch status.
OFF: The stop (brake) lamp switch is not activated
ON: The stop (brake) lamp switch is activated
STC Switch
The value indicates the STC switch status.
OFF: The STC switch is not activated
ON: The STC switch is activated
STC Switch Indicator
OFF: The lamp is not activated
ON (cont): The lamp is lit constantly
ON (audible): The lamp flashes
The value indicates the status of the STC switch indicator.
Scheme 14
Measurement range: 0- 653.8 km/h.
The engine control module (ECM) derives wheel speed from the relevant wheel sensor signal.
Extrapolation Counter
Measurement range: 0- 255
The normal value if the car is driven should be 0. The extrapolation counter calculates if the number of wheel speed changes are higher than the number allowed.
If the signal from the wheel sensor is affected by electromagnetic interference, varies too much or is affected by short intermittent open-circuit/short circuits, the control module can interpret it as a speed change and the counter will begin updating. When the control module registers that speed changes are within the permitted values the counter value will reduce again.
Wheel Acceleration
Measurement range: -1.28 - +1.27g
Positive value: acceleration
Negative value: deceleration
The control module derives the wheel acceleration/deceleration from the relevant wheel sensor signal.
The value can vary a great deal depending on the road surface An uneven road gives greater variation.
Vehicle Reference Speed
Measurement range: 0-653.8 km/h
The control module derives the reference speed from all the wheel sensor signals.
Vehicle Speed CAN Signal
Measurement range: 0.60- 653.80 km/h
The control module derives the vehicle speed based on the wheel sensor signal and transmits it over the Control area network (CAN).
The vehicle speed signal which is transmitted over the Control area network (CAN).
The Vehicle Acceleration
Measurement range: -1.28 - +1.27g
Positive value: acceleration
Negative value: deceleration
The control module derives the reference acceleration/deceleration from the relevant wheel sensor signal.
The Brake Disc Temperature
Front brake disc temperature.
Measurement range: 0.0-450°C (32-842°F)
The control module derives the brake disc temperature depending on the length of time the anti-spin system has been operating or the ABS has been activated.
Power Supply
ABS control module power supply.
Measurement range: 0-16 V
High Beam Flash, Status
The value is displayed if the high beam flash is activated.
Not activated
Flash
Rocker position high beam / low beam
The value indicates if the read button is pressed in.
Not activated
Activated
The value indicates if the reset button is pressed in.
Not activated
Activated
Right-Hand Indicator Lamps, Status
This value indicates whether the right-hand indicator lamps are activated.
Not activated
Activated
Left-Hand Indicator Lamps, Status
This value indicates whether the left-hand indicator lamps are activated.
Not activated
Activated
This value indicates whether the cruise control on / off button is pressed in.
Not activated
Activated
This value indicates whether the +button is pressed in.
Not activated
Activated
The value indicates whether the -button is pressed in.
Not activated
Activated
This value indicates whether the cruise control resume button is pressed in.
Not activated
Activated
This value indicates whether the cruise control disengage button is pressed in.
Not activated
Activated
This value indicates whether the audio / carphone search+ button is pressed in.
Not activated
Activated
This value indicates whether the audio / carphone search- button is pressed in.
Not activated
Activated
The value indicates whether the audio / carphone volume+ button is pressed in.
Not activated
Activated
This value indicates whether the audio / carphone volume- button is pressed in.
Not activated
Activated
This value indicates whether the carphone YES button is pressed in.
Not activated
Activated
This value indicates whether the carphone NO button is pressed in.
Not activated
Activated
This value indicates whether the road traffic information (RTI) right-hand button is pressed in.
Not activated
Activated
This value indicates whether the road traffic information (RTI) left-hand button is pressed in.
Not activated
Activated
This value indicates whether the road traffic information (RTI) up button is depressed.
Not activated
Activated
This value indicates whether the RTI down button is pressed in.
Not activated
Activated
This value indicates whether the road traffic information (RTI) enter button is pressed in.
Not activated
Activated
This value indicates whether the road traffic information (RTI) reset button is depressed.
Not activated
Activated
Windscreen Washer, Status
This value indicates whether the windscreen wiper lever is activated in the washer position.
Not activated
Activated
High Speed Position, Status
This value indicates whether the windscreen wiper lever is activated in the high speed position.
Not activated
Activated
Low Speed Position, Status
This value indicates whether the windscreen wiper lever is activated in the low speed position.
Not activated
Activated
Intermittent Position, Status
This value indicates whether the windscreen wiper lever is activated in the intermittent position.
Not activated
Activated
Single Sweep Position, Status
This value indicates whether the windscreen wiper lever is activated in the single sweep position.
Not activated
Activated
Not all the parameters described need to be implemented in the control module. This varies from system to system.
Frozen values are parameter values that are stored when a diagnostic trouble code (DTC) is stored.
Measurement range: 0-28.4 V
Normal value when the generator (GEN) is charging: 13.0-14.5 V
The value indicates the voltage at the steering wheel module.
Measurement range: 0-1048575 km
The value indicates the total mileage of the car at the time the diagnostic trouble code (DTC) was stored.
Measurement range: -60 to +195 °C
The value indicates the passenger compartment temperature at the time the diagnostic trouble code (DTC) was stored.
Measurement range: -128 to +127.75 °C
The value indicates the outside temperature at the time the diagnostic trouble code (DTC) was stored.
The status displays whether the engine was running when the diagnostic trouble code (DTC) was stored.
Yes = the engine was running
No = the engine was not running
The value displays the time that has passed since the diagnostic trouble code (DTC) was stored.
Not all the parameters described need to be implemented in the control module. This varies from system to system.
Frozen values are parameter values that are stored when a diagnostic trouble code (DTC) is stored.
Measurement range: 0-28.4 V
Normal value when the generator (GEN) is charging: 13.0-14.5 V
The value indicates the voltage at the steering wheel module.
Measurement range: 0-1048575 km
The value indicates the total mileage of the car at the time the diagnostic trouble code (DTC) was stored.
Measurement range: -60 to +195 °C
The value indicates the passenger compartment temperature at the time the diagnostic trouble code (DTC) was stored.
Measurement range: -128 to +127.75 °C
The value indicates the outside temperature at the time the diagnostic trouble code (DTC) was stored.
The status displays whether the engine was running when the diagnostic trouble code (DTC) was stored.
Yes = the engine was running
No = the engine was not running
The value displays the time that has passed since the diagnostic trouble code (DTC) was stored.
Identifying Upgraded Software ECM/ETM
Upgraded software for the engine control module (ECM) and electronic throttle module (ETM), available during 2006 or later, can be identified. The updated software has the diagnostic number/software number as set out in the table below. The diagnostic number/software number can be read using appropriate scan tool.
See USA/Canada market
See All markets except USA/Canada
| CAUTION | For the USA/Canada market, with turbocharged and 6-cylinder normally aspirated engines the software of the engine control module (ECM) can be identified using the software number or diagnostic number, depending on the version of the software involved. |
The differences between the first version , which is identified by the software number, and the second version , which is identified by the diagnostic number, include the following
- Improved driveability after engine control module (ECM) reset. The start values for some system adaptations are adjusted to facilitate handling of aged/worn systems/components after diagnostic trouble code deletion or when the control module has been without power.
- Increased hardiness to certain combinations of aging/wear in the system. The work areas for some adaptations are adjusted to better match the aging of certain components.
- Supplements as to which faults are to generate a message to the driver.
- Improved serviceability (diagnostic trouble code generation) for some intermittent faults that generate driveability problems.
The diagnostic number and the software number can be read out via appropriate scan tool to identify. The electronic throttle module (ETM) is identified solely by the diagnostic number.
If the diagnostic number/software number is within the following series, it is the latest software downloaded
- 5-cyl non-turbo engines B5244SG/B5244SG2 (Bifuel) , (all markets excluding USA/Canada): Engine control module (ECM) diagnostic number 31219965 - 31219968 or 30788502 and Electronic throttle module (ETM) diagnostic number 30785387.
- Other 5-cyl non-turbo engines , (all markets): Engine control module (ECM) diagnostic number 30785129 - 30785132 or 30785667 and electronic throttle module (ETM) 30785387.
- Turbocharged and 6-cylinder normally aspirated engines (USA/Canada market): First version, engine control module (ECM) software number 30785203 - 30785240 and electronic throttle module (ETM) diagnostic number 30785388. Second version, engine control module (ECM) diagnostic number 30785372 - 30785378 and electronic throttle module (ETM) diagnostic number 30785388.
- Turbo engines and 6-cylinder non-turbo engines , (all markets except the USA/Canada market): Engine control module (ECM) software number 30785372 - 30785378 and electronic throttle module (ETM) diagnostic number 30785388.
USA/Canada Market
| Turbo engines and 6 cyl non turbo engines ECM (Bosch)/ETM (Magneti Marelli) NOTE: The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. | |
|---|---|
| Model | Diagnostic number/software number |
| S70/V70 (-00)/V70 XC (-00)/C70 (-05) | ETM, 1999- : 30785388 (diagnostic number) ECM, 1999: 30785205 (software number) 30785206 (software number) 30785207 (software number) 30785208 (software number) 30785209 (software number) 30785372 (diagnostic number) ECM, 2000: 30785212 (software number) 30785213 (software number) 30785214 (software number) 30785215 (software number) 30785216 (software number) 30785217 (software number) 30785218 (software number) 30785221 (software number) 30785222 (software number) 30785223 (software number) 30785224 (software number) ECM, 2000- : 30785373 (diagnostic number) ECM, 2001: 30785235 (software number) 30785236 (software number) 30785237 (software number) ECM, 2002: 30785238 (software number) 30785239 (software number) 30785240 (software number) |
| V70 (00-)/V70 XC/ XC70 (01-) | ETM, 1999- : 30785388 (diagnostic number) 5 cyl turbo engines: ECM, -2000: 30785225 (software number) 30785226 (software number) 30785227 (software number) 30785228 (software number) 30785375 (diagnostic number) ECM, 2000- : 30785229 (software number) 30785230 (software number) 30785231 (software number) 30785232 (software number) 30785376 (diagnostic number) 6 cyl engines: ECM, 1999: 30785203 (software number) 30785204 (software number) 30785210 (software number) 30785211 (software number) 30785377 (diagnostic number) ECM, 2000: 30785219 (software number) 30785220 (software number) 30785378 (diagnostic number) ECM, 2000- : 30785233 (software number) 30785234 (software number) |
| NOTE |
|---|
| The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. |
| 5 cyl non turbo engines ECM (Denso) /ETM (Magneti Marelli) NOTE: The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. | |
|---|---|
| Model | Diagnostic number |
| S70/V70 (-00)/C70 (-05) | ETM, 1999- : 30785387 (diagnostic number) ECM, 1999: 30785131 (diagnostic number) ECM, 2000- : 30785132 (diagnostic number) |
| V70 (00-) | ETM, 1999- : 30785387 (diagnostic number) ECM, 1999-2000: 30785667 (diagnostic number) ECM, 2001 : 30785129 (diagnostic number) ECM, 2002 : 30785130 (diagnostic number) |
| NOTE |
|---|
| The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. |
All Markets Except USA/Canada
| Turbo engines and 6 cyl non turbo engines ECM (Bosch)/ETM (Magneti Marelli) NOTE: The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. | |
|---|---|
| Model | Diagnostic number |
| S70/V70 (-00)/V70 XC (-00)/C70 (-05) | ETM, 1999- : 30785388 (diagnostic number) ECM, 1999: 30785372 (diagnostic number) ECM, 2000- : 30785373 (diagnostic number) |
| V70 (00-)/V70 XC/ XC70 (01-) | ETM, 1999- : 30785388 (diagnostic number) 5 cyl turbo engines: ECM, 1999: 30785374 (diagnostic number) ECM, 2000: 30785375 (diagnostic number) ECM 2000- : 30785376 (diagnostic number) 6 cyl engines: ECM, 1999: 30785377 (diagnostic number) ECM, 2000: 30785378 (diagnostic number) |
| NOTE |
|---|
| The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. |
| 5-cyl non-turbo engines (not B5244SG/B5244SG2) ECM (Denso)/ETM (Magneti Marelli) NOTE: The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. | |
|---|---|
| Model | Diagnostic number |
| S70/V70 (-00)/C70 (-05) | ETM, 1999- : 30785387 (diagnostic number) ECM, 1999: 30785131 (diagnostic number) ECM, 2000- : 30785132 (diagnostic number) |
| V70 (00-) | ETM, 1999- : 30785387 (diagnostic number) ECM, 1999-2000: 30785667 (diagnostic number) ECM, 2001: 30785129 (diagnostic number) ECM 2002- : 30785130 (diagnostic number) |
| NOTE |
|---|
| The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. |
| 5-cyl non-turbo engines B5244SG/B5244SG2 (Bifuel) ECM (Denso)/ETM (Magneti Marelli) NOTE: The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. | |
|---|---|
| Model | Diagnostic number |
| S70/V70 (-00) V70 (00-) | ETM, 2000- : 30785387 (diagnostic number) ECM: 30788502 (diagnostic number) 31219965 (diagnostic number) 31219966 (diagnostic number) 31219967 (diagnostic number) 31219968 (diagnostic number) |
| NOTE |
|---|
| The version letters at the end of the diagnostic number are not accounted for and should be ignored during identification. |
