Maintenance Information: Overview Volvo V70 I

Fuse & Circuit Breaker Identification

1. 1 - 60 Amp Electric Cooling Fan
2. 2 - 50 Amp Fuses In Supplementary Fuse Box
3. 3 - 50 Amp Starter Motor, Air Pump
4. 4 - 50 Amp ABS
5. 5 - 50 Amp Headlights
6. 6 - 60 Amp Fuses In Supplementary Fuse Box
7. 7 - 60 Amp Fuses In Supplementary Fuse Box
8. 8 - 60 Amp Control Modules - Engine/Automatic Transmission
9. 9 - Not Used
10. 10 - 10 Amp Ignition Switch, Control Modules - Engine/Automatic Transmission
11. 11 - 10 Amp Fuel Injectors
12. 12 - 20 Amp Fuel Pump
13. 13 - 10 Amp Control Module - Automatic Transmission
14. 14 - 10 Amp A/C Relay
15. 15 - Relay System Relay
16. 16 - Relay Air Pump Relay
17. 17 - Relay Starter Motor
18. 18 - Relay Air Conditioning

Scheme 1

1. 1 - Not Used
2. 2 - 10 Amp Central Locking, Driving Mode Selectors (Auto. Trans.)
3. 3 - 10 Amp ABS
4. 4 - 10 Amp Immobilizer (Canada Only)
5. 5 - 15 Amp Climate Systems, Onboard Diagnostics OBDII
6. 6 - Not Used
7. 7 - 15 Amp Audio System
8. 8 - 15 Amp Immobilizer (Canada Only), Trip Computer, Headlight Switch
9. 9 - 20 Amp Electronically Heated Rear Seat (If Equipped)
10. 10 - 15 Amp Ignition Switch
11. 11 - 10 Amp Brake Lights
12. 12 - Not Used
13. 13 - 15 Amp Hazard Flashers, Headlight Flashers, Remote Operated Central Locking System
14. 14 - 30 Amp Heated Rear Window & Door Mirrors
15. 15 - 10 Amp Courtesy Lights, Door Open Warning Lights, Trunk/Cargo Space Light, Seat Belt Reminder, Glove Compartment Light
16. 16 - 30 Amp Power Antenna, Electrical Connector For Trailer, Accessories
17. 17 - 20 Amp Front Fog Lamps
18. 18 - 10 Amp Key Reminder
19. 19 - 15 Amp Left High Beam
20. 20 - 15 Amp Right High Beam, High Beam Indicator Light
21. 21 - 15 Amp Left Low Beam
22. 22 - 15 Amp Right Low Beam
23. 23 - 10 Amp Left Front/Rear Parking Light, Left Tail Light, License Plate Light
24. 24 - 10 Amp Right Front/Rear Parking Light, Right Tail Light
25. 25 - 10 Amp Rear Fog Light, Rear Fog Light Indicator Light
26. 26 - 15 Amp Headlight Switch
27. 27 - 15 Amp Back-Up Lights, Direction Indicators
28. 28 - 25 Amp Heated Seats, Front & Rear (If Equipped)
29. 29 - 10 Amp Heated Rear Window, Shiftlock, Seat Belt Reminder, Cruise Control, Heated Door Mirrors, Bulb Failure Warning Sensor
30. 30 - Not Used
31. 31 - 25 Amp Passenger Compartment Blower Climate Systems
32. 32 - 10 Amp Audio System
33. 33 - 15 Amp Tailgate Wiper/Washer
34. 34 - 25 Amp Windshield Wiper/Washer, Horn
35. 35 - 10 Amp Instrument Panel Lights, Accessories, Power Sun Roof
36. 36 - 15 Amp Rear Auxiliary Socket, Power Seats
37. 37 - Circuit Breaker (Automatic) Power Windows, Power Sun Roof
38. 38 - Not Used
39. 39 - Circuit Breaker (Automatic) Drivers Power Seat
40. 40 - Circuit Breaker (Automatic) Passengers Power Seat
