GENERATOR SPECIFICATIONS
| Application | Specifications |
|---|
| Slip Rings Min. Diameter | .53" (14 mm) |
| Max. Runout |
| Slip Rings | .001" (.03 mm) |
| Rotor Body | .002" (.05 mm) |
| Brushes Min. Length | .19" (5 mm) |
| 80-amp |
| Rotor Winding Resistance | 2.6 ohms |
| Stator Winding Resistance | .027 ohms |
| 100-amp |
| Rotor Winding Resistance | 2.6 ohms |
| Stator Winding Resistance | .02 ohms |
| 115-amp |
| Rotor Winding Resistance | 2.6 ohms |
| Stator Winding Resistance | .051 ohms |
BOSCH GENERATOR SPECIFICATIONS (C70, S70 & V70)
| Application | Specifications |
|---|
| Slip Rings Min. Diameter |
| 55/65/80/90-amp | 1.03" (26.8 mm) |
| 100-amp | 1.03" (27 mm) |
| 100/120-amp | .54" (14 mm) |
| Max. Runout |
| Slip Rings | .001" (.03 mm) |
| Rotor Body | (1) .002" (.05 mm) |
| Brushes Min. Length | .19" (5 mm) |
| 55-amp |
| Rotor Winding Resistance | 3.4-3.7 ohms |
| Stator Winding Resistance | .14-.15 ohms |
| 65-amp |
| Rotor Winding Resistance | 2.8 ohms |
| Stator Winding Resistance | .10 ohms |
| 80-amp |
| Rotor Winding Resistance | 2.9 ohms |
| Stator Winding Resistance | .09 ohms |
| 90-amp |
| Rotor Winding Resistance | 2.9 ohms |
| Stator Winding Resistance | .09 ohms |
| 100-amp |
| Rotor Winding Resistance | 2.6 ohms |
| Stator Winding Resistance | .05 ohms |
| 120-amp |
| Rotor Winding Resistance | 2.6 ohms |
| Stator Winding Resistance | .02 ohms |
| (1) .001" (.03 mm) on 100-amp generators. |
| (1) | .001" (.03 mm) on 100-amp generators. |
BOSCH GENERATOR SPECIFICATIONS (S90 & V90)
| Application | Specification |
|---|
| Slip Rings Min. Diameter (80-amp) | .49" (12.8 mm) |
| Max. Runout |
| Slip Rings | .001" (.03 mm) |
| Rotor Body | .002" (.05 mm) |
| Brushes Min. Length | .21" (5.5 mm) |
| 80-amp |
| Rotor Winding Resistance | 2.9 ohms |
| Stator Winding Resistance | .03 ohms |
NIPPONDENSO GENERATOR SPECIFICATIONS (C70, S70 & V70)
| Application | Specification |
|---|
| Slip Rings Min. Diameter |
| 80-amp | .49" (12.8 mm) |
| 100-amp | .49" (12.8 mm) |
| Brushes Min. Length | .21" (5.5 mm) |
| 80-amp |
| Rotor Winding Resistance | 2.9 ohms |
| Stator Winding Resistance | .04 ohms |
| 100-amp |
| Rotor Winding Resistance | 2.3 ohms |
| Stator Winding Resistance | .03 ohms |
NIPPONDENSO GENERATOR SPECIFICATIONS (S90 & V90)
Charging System Wiring Diagram (C70, S70 & V70). Scheme 1
Scheme 1: Charging System Wiring Diagram (C70, S70 & V70)
Charging System Wiring Diagram (S90 & V90). Scheme 2
Scheme 2: Charging System Wiring Diagram (S90 & V90)
