REMOVING COMPONENTS Volvo V50 I facelift

REMOVING COMPONENTS

Remove

  1. the tunnel compartment. See «FLOOR CONSOLE»(ref-466638-S15268726802012042500000) (2005-2007) or «FLOOR CONSOLE»(ref-466638-S27395458302012042500000) (2008-2011).
  2. the gear selector knob. See «KNOB, GEAR SHIFT SELECTOR»(ref-466711-S27256011982012042500000) .

Scheme 96

Scheme 96: REMOVING THE TOP PANEL ASSEMBLY

Disconnect

  1. the contact for the cable harness and disconnect the connector
  2. the contact for the solenoid.

Scheme 97

Scheme 97

Carefully release the catches. Raise the panel slightly.

Scheme 98

Scheme 98

Carefully release the catches.

Remove the top panel assembly with wiring and printed circuit board.

Scheme 99

Scheme 99: INSTALLING THE TOP PANEL ASSEMBLY

Check that the guard over the transmission side piece is correctly positioned.

Scheme 100

Scheme 100

Position the panel in and press the catches, 4 pcs, securely in place at each corner. Install the electrical connector and connect the contact to the cable harness. Connect the contact to the solenoid.

Install

  1. the gear selector knob. See «KNOB, GEAR SHIFT SELECTOR»(ref-466711-S27256011982012042500000)
  2. the center console. See «FLOOR CONSOLE»(ref-466638-S15268726802012042500000) (2005-2007) or «FLOOR CONSOLE»(ref-466638-S27395458302012042500000) (2008-2011).

Note. Calibrate the integrated position sensor, which is in the gear lever assemble, once the unit has been replaced or has been disconnected.

When replacing the position sensor, the new position sensor must be calibrated. Carry out calibration according to VIDA Vehicle communication, Function area 4 transmission control module (TCM).
