JACKING POINTS BODY
Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.
Lifting points of vehicle
Scheme 9
When lifting the vehicle, the lifting points indicated in the illustration must be used.
The jacking plate must have a rubber pad to prevent damage to the vehicle.
Do not lift at the front suspension, as there is a risk of the wheel alignment being altered.
SIDE MEMBERS REAR
Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.
Scheme 10
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Scheme 11
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess. See the illustration.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension in the illustration.
Scheme 12
J1 = 415 mm
J2 = 727 mm
J3 = 351 mm
J4 = 387 mm
Scheme 13
J5 = 1, 324 mm
J6 = 988 mm
J7 = 940 mm
J8 = 964 mm
J9 = 1042 mm
SIDE MEMBERS, FRONT
Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.
EXPLANATION OF DIMENSIONS
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess. See the illustration.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension in the illustration.
Scheme 14
B1 = 1, 012 mm
B2 = 826 mm
B3 = 945 mm
Scheme 15
B4 = 1, 198 mm
B5 = 1, 063 mm
Scheme 16
B6 = 1, 559 mm
B7 = 1, 400 mm
ROOF
Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess (see the illustration).
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension in the illustration.
Scheme 17
Scheme 18
M5 = 1125 mm
M6 = 987 mm
M7 = 998 mm
Scheme 19
C1 = 1157 mm
C2 = 1510 mm
C3 = 1473 mm
Scheme 20
BODY SIDE
Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess. See the illustration.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension in the illustration.
Scheme 21
D1 = 863 mm
D2 = 1082 mm
Scheme 22
D4 = 809 mm
D5 = 698 mm
D6 = 908 mm
Scheme 23
E1 = 1328 mm
Scheme 24
E3 = 1493 mm
E4 = 1435 mm
Scheme 25
E5 = 1402 mm
E6 = 1513 mm
E7 = 1415 mm
Scheme 26
E8 = 602 mm
Scheme 27
E9 = 225 mm
