Ignition and Engine Control Systems - Component Location Volvo V50 I facelift

Engine Control Systems 3 illustrations

Scheme 1

Scheme 1: LOCATION OF COMPONENTS, ENGINE COMPARTMENT

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentLocated at/on
1Injectors (5x)The intake manifold.
2Intake camshaft reset valveEngine, timing belt side, the by camshaft.
3A/C pressure sensorAir conditioning (A/C) system high pressure pipe (thin pipe).
4Air conditioning (A/C) pressure switchAir conditioning (A/C) system low pressure pipe (thick pipe).
5Ignition coil (5x)The cylinder head.
6Evaporative emission system (EVAP) valveCylinder block, by cowl panel.
7Camshaft position (CMP) sensor, intakeEngine, flywheel side, by the camshaft.
8Integrated relay/fusebox
9Engine speed (RPM) sensorAbove the flywheel.
10Mass air flow (MAF) sensor and intake air temperature (IAT) sensor, intakeThe intake manifold.
11Engine coolant temperature (ECT) sensorThe thermostat housing.
12Pressure sensor, intakeEngine, flywheel side.
13Engine control module (ECM)The air cleaner (ACL) module.
14Knock sensor (KS)The cylinder block, under the air cleaner (ACL) module.
15Engine cooling fan (FC) control module
16Oil pressure switchLower front edge of the engine.
17Throttle unitThe intake manifold.
18Fuel pressure/fuel temperature sensorFuel rail right face

Scheme 2

Scheme 2: LOCATION OF COMPONENTS, ENGINE COMPARTMENT

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentLocated at/on
1Injectors (5x)The intake manifold.
2Intake camshaft reset valveEngine, timing belt side, the by camshaft.
3A/C pressure sensorAir conditioning (A/C) system high pressure pipe (thin pipe).
4Air conditioning (A/C) pressure switchAir conditioning (A/C) system low pressure pipe (thick pipe).
5Ignition coil (5x)The cylinder head.
6Evaporative emission system (EVAP) valveCylinder block, by cowl panel.
7Camshaft position (CMP) sensor, intakeEngine, flywheel side, by the camshaft.
8Integrated relay/fusebox
9Engine speed (RPM) sensorAbove the flywheel.
10Mass air flow (MAF) sensor + intake air temperature (IAT) sensor, intakeThe intake manifold.
11Engine coolant temperature (ECT) sensorThe thermostat housing.
12Pressure sensor, intakeEngine, flywheel side.
13Engine control module (ECM)The air cleaner (ACL) module.
14Knock sensor (KS)The cylinder block, under the air cleaner (ACL) module.
15Engine cooling fan (FC) control module
16Oil level sensorPlaced in the oil sump
17Oil pressure switchLower front edge of the engine.
18Throttle unitThe intake manifold.
19Fuel pressure/fuel temperature sensorFuel rail right face

Scheme 3

Scheme 3: LOCATION OF COMPONENTS, ENGINE COMPARTMENT

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentLocated at/on
1Injectors (5x)Intake manifold.
2Intake camshaft reset valveEngine, timing belt side, by camshaft.
3Exhaust camshaft reset valveEngine, timing belt side, by camshaft.
4A/C pressure sensorAir conditioning (A/C) system high pressure pipe (thin pipe).
5Air conditioning (A/C) pressure switchAir conditioning (A/C) system low pressure pipe (thick pipe).
6Turbocharger (TC) control valveThe turbocharger (TC).
7Ignition coil (5x)The cylinder head.
8Evaporative emission system (EVAP) valveIntake manifold.
9Camshaft position (CMP) sensor, intakeEngine, flywheel side, by the camshaft.
10Camshaft position (CMP) sensor, exhaustEngine, flywheel side, by the camshaft.
11Integrated relay/fusebox
12Engine speed (RPM) sensorAbove the flywheel.
13Mass air flow (MAF) sensorThe air cleaner (ACL) module.
14Engine coolant temperature (ECT) sensorThe thermostat housing.
15Engine control module (ECM)The air cleaner (ACL) module.
16Knock sensor (KS)The cylinder block under the air cleaner (ACL) module.
17Engine cooling fan (FC) control module
18Oil pressure switchLower front edge of the engine.
19Boost pressure sensorThe charge air cooler (CAC) upper right-hand section.
20Throttle unitThe engine intake manifold.
21Fuel pressure sensor/fuel temperature sensorFuel rail right face.
