ALARM, BASIC KIT Volvo V50 I facelift

ALARM, BASIC KIT

Note. This accessory is connected to the car's electrical system. It requires software unique to the car.

1. Turn the ignition key to position 0.

Scheme 359

1. Remove the windshield wipers.

Scheme 360

1. Remove the four clips (1) in the panel over the wiper motor.
2. Rotate the two clips (2) 90° towards each other.

1. Detach the panel over the wiper motor on the right side and pull it up from the right wiper shaft.
2. Pull the panel up from the left-hand wiper shaft. NOTE: The panel has little space on the left-hand side. Pull carefully so that the clips on the underneath/rear edge do not break.
3. Remove the panel carefully. Pull it up at the front edge and then pull it forwards.

Scheme 361

Scheme 362

1. Take two nuts from the kit and install the alarm siren at the windshield's leading edge. The alarm siren should be installed on the right side.
2. Slide the alarm siren as far as possible in the bracket's groove. It should be slid to the left.
3. Torque-tighten the nuts with 10 Nm (7 lbf. ft.) .
4. Plug in the pre-wired connector to the alarm siren.

1. Reinstall the panel above the wiper motor.
2. Reinstall the windscreen wipers and set them in the correct position.

Scheme 363

1. Remove the five clips (1) by pressing in their center and pull.
2. Remove the two screws (2).

Scheme 364

1. Remove the five screws securing the bumper casing and air baffle at the wheel housing's leading edge, on right and left sides.

Scheme 365

1. Carefully remove the cover for the nozzle for the headlights' high-pressure washer, and pull it out until its lock catch is accessible, on right and left side.

Scheme 366

1. Press up the catches and remove the covers. Do not damage the painted surfaces or the high-pressure washer nozzles.

Scheme 367

1. Detach the ends of the bumper casing on the left and right sides, by grabbing the end of the bumper casing inside the wing liner. Pull carefully so that the two catches on the inside release.
2. Remove the bumper casing with air baffle, by pulling them forward until the remaining catch under the lights release.
3. Disconnect the connectors for the fog lamps if applicable.

Scheme 368

1. Remove the two screws in the intake manifold.
2. Remove the intake manifold.

Scheme 369

1. Remove the two screws for the panel over the bonnet catch.
2. Remove the panel. Lift it up at the rear edge and then pull it backwards.

Scheme 370

1. Pull loose the wire sleeve and the wire from the mounting in the hood lock.

Scheme 371

1. Remove the bonnet catch screws
2. Remove the bonnet catch.

Scheme 372

1. Unplug the pre-routed connector from the parking module in the bonnet catch by pressing in the catch and pulling.
2. Place the bonnet catch to one side, it shall not be used again.

Scheme 373

1. Take the new bonnet catch from the kit and secure it with the existing screws.
2. Torque tighten the screws to 24 Nm (18 lbf. ft.) .
3. Plug the bonnet catch's connector (1) into the pre-routed connector (2).
4. Secure the wire and the sleeve in the new bonnet catch.
5. Reinstall the panel above the bonnet catch.
6. Reinstall the intake manifold.
7. Reinstall the bumper cover using the five clips and the two screws in the upper edge.
8. Reconnect the connectors for the fog lamps if applicable.
9. Make sure that the air baffle ends up correctly in its mounting.
10. Press the end faces for the bumper cover into the body and reinstall the five screws at the front edge of the wheel housing (on the right and left-hand sides).

1. Program the software in accordance with the service information in VIDA (Volvo scan tool).
