Steering Wheel - Position Adjustment: Other Volvo V50 I рестайлинг

Steering Column 2 illustrations ~355 words

ADJUSTING THE POSITION OF THE STEERING WHEEL

Special tools

see 9988695

CAUTIONCars with DSTC systems. When working on the steering or wheel alignment, the adaptation of the steering wheel angle must be set to zero using the diagnostic tool. Test drive. See TEST DRIVE FORM (DSTC (DYNAMIC STABILITY AND TRACTION CONTROL) /BRAKE CONTROL MODULE), DESCRIPTION .

CHECKING THE STEERING WHEEL POSITION

  1. Drive the car straight forward and check that the steering wheel is in the "straight ahead" position
  2. If the steering wheel position is incorrect adjust as follows.

ZERO THE CONTACT REEL

Zero the contact reel. See CONTACT REEL DRIVER AIRBAG MODULE, RESETTING .

Scheme 21

Scheme 21: INSTALL THE STEERING WHEEL AND CHECK THE STEERING WHEEL POSITION
Scheme 21: INSTALL THE STEERING WHEEL AND CHECK THE STEERING WHEEL POSITION

Note. Ensure that front wheels are pointing straight ahead.

  1. Pull the connectors from the contact reel through the steering wheel
  2. Install the steering wheel carefully so that both catches on the contact reel are seated in the two recesses in the steering wheel hub
  3. Install the steering wheel screw. Use a new screw . Finger tighten. CAUTION: Do not turn the steering wheel when it is on the steering shaft. Since the contact reel is locked, it will be damaged beyond repair if the wheel is turned in this situation.
  4. Remove the locking screw holding the contact reel. Install the contact reel in the parking hole in the steering wheel
  5. Connect tool see «9988695»(ref-460875-S04579506492012033000000) to the contact reel cable
  6. Drive the car straight forward and check that the steering wheel is in the "straight ahead" position
  7. If the steering wheel position is incorrect repeat the adjustment.

TIGHTEN THE SCREW IN THE CENTER OF THE STEERING WHEEL

  1. Remove tool 998 8695
  2. Tighten the screw in the center of the steering wheel. Tighten to 35 Nm
  3. Check that the SRS light is extinguished, i. e. that no DTCs are present.

Scheme 22

Scheme 22: INSTALL THE STEERING WHEEL MODULE
Scheme 22: INSTALL THE STEERING WHEEL MODULE
  1. Turn the ignition key to position I to unlock the steering wheel
  2. Position the lower section of the steering wheel module against the steering wheel
  3. Connect the connector
  4. Fold in the steering wheel module. Ensure that wiring lies free and is not trapped
  5. Secure the steering wheel module with the Torx screws from the side
  6. Tighten the steering wheel module screws. Tighten to 10 Nm .

CHECK THE FUNCTION

Ensure that the steering wheel turns easily and that the steering lock functions.

Check that no diagnostic trouble codes (DTCs) have been stored while the repair was carried out.
