OXYGEN SENSOR WARNING LIGHT RESET - PROCEDURE 1

1. Warning light in dash will illuminate every 30,000 miles as a reminder to replace oxygen sensor. After replacing sensor, reset mileage counter.
2. To reset mileage counter on 1980-84 models, locate mileage counter in-line with speedometer cable. Press reset button. (Scheme 1) Ensure reminder light is out.
3. To reset counter on 1985 models and 1986 760 GLE models, locate unit under dash (follow wires or small cable from back of speedometer to unit). Remove retaining screw and switch cover. Press reset button. Ensure reminder light is out. Install switch cover.

Scheme 1

Note. The brake pedal must not be depressed when accessing ignition modes I or II .

1. Ignition Mode 0: Insert the remote key in the ignition slot.
2. Ignition Mode I: Press the remote key into the ignition slot and press START/STOP ENGINE .
3. Ignition Mode II: Press the remote key into the ignition slot and press START/STOP ENGINE for approx. 2 seconds.
4. Ignition Mode III: Engine Start: Start the engine Stopping The Engine: Press START/STOP ENGINE (If the engine is running and the vehicle is moving, keep the button depressed until the engine stops).
5. Return To Ignition Mode 0: Press START/STOP ENGINE to return from I , II , or III to ignition mode 0 .

SERVICE REMINDER LIGHT RESET - PROCEDURE 1

To reset counter, locate reset lever behind instrument cluster and push reset lever upward. (Scheme 3)

Scheme 2

SERVICE REMINDER LIGHT RESET - PROCEDURE 2

To reset counter, locate button behind right center of instrument cluster and press button. (Scheme 4)

Scheme 3

SERVICE REMINDER LIGHT RESET - PROCEDURE 3

Remove rubber grommet to left of odometer. Using a small screwdriver, depress reset knob. (Scheme 5)

Scheme 4

SERVICE REMINDER LIGHT RESET - PROCEDURE 4

The Service Reminder Indicator (SRI) is triggered at the appropriate interval is reached. On US and Canadian cars, with or without turbocharger, this will be 10,000 miles (15,000 km), 750 operating hours or 12 calendar months.

Once triggered, the SRI comes on each time the engine is started. The light goes out after about 2 minutes. After service is performed and the SRI counter reset, the SRI will not light again until shortly before the next service is due.

1. Identify type of instrument cluster used in vehicle. (Scheme 6)
2. Turn ignition on. Locate on-board diagnostic unit on right side of engine compartment. Connect diagnostic lead to terminal No. 7 on diagnostic unit. see scheme 7
3. Depress button 4 times, briefly but firmly. System is now in DTM 4 mode. When LED comes on and stays on, the system is ready for entering codes.
4. Code to be entered is 1-5-1. Enter first digit (1) with LED on. Wait until it comes on and stays on again, then enter the second digit (5). Repeat procedure for the third digit (1).
5. Wait for diagnostic unit confirmation (LED flashing several times in succession). If LED emits a couple of rapid flashes and service reminder light is turned off, reset procedure is complete. If service reminder light remains on, repeat procedure.

SERVICE REMINDER LIGHT RESET - PROCEDURE 5

Vehicles with VDO Instrument Cluster

Identify type of instrument cluster used in vehicle. (Scheme 6)

The service reminder indicator is lit for two minutes each time the engine is started until it is reset after the next service. Reset is performed using a Volvo scan tool, or equivalent aftermarket scan tool.

Connect scan tool to Data Link Connector (DLC) in center console, in front of shift lever. see scheme 8 Turn ignition on, with engine off. Follow scan tool menus as follows

1. Select LANGUAGE, press ENTER
2. Select 800 SERIES, press ENTER
3. Select SERVICE, press ENTER
4. Select RESET SRI, press EXIT

Scheme 5

SERVICE REMINDER LIGHT RESET - PROCEDURE 6

Vehicles with Yazaki Instrument Cluster

The service reminder indicator comes on when 10,000 mile (15,000 km) service interval is reached.

1. Vehicle is equipped with Yazaki instrument cluster. see scheme 9
2. The service reminder reset knob is located on front of instrument cluster, underneath a rubber grommet. (Scheme 5)
3. To reset, remove rubber grommet. Use a small screwdriver to depress the knob.

Scheme 6

SERVICE REMINDER LIGHT RESET - PROCEDURE 7

The service reminder light will illuminate at 10,000 miles, 750 hours of driving or 12 months, whichever comes first to remind driver that service interval has been exceeded. Service reminder light is reset using Volvo Scan Tool, or equivalent aftermarket scan tool. Follow scan tool manufacturer's instructions. Diagnostic connector is located in center console.

SERVICE REMINDER LIGHT RESET - PROCEDURE 8

Note. Depending on application, Service Reminder Indicator (SRI) may be turned off by one of two methods.

SERVICE REMINDER LIGHT RESET - PROCEDURE 9

1. Turn ignition off.
2. Press in trip odometer reset button.
3. Switch ignition on, while continuing to press trip odometer reset button.
4. Continue pressing in the reset button for 10 seconds.
5. Release reset button within 4 seconds.

SERVICE REMINDER LIGHT RESET - PROCEDURE 11

Note. If equipped with a push button start/stop ignition, see PUSH BUTTON START/STOP IGNITION SWITCH POSITIONS for ignition switch positions.

The SRI lights the first time the ignition is switched on after the service interval has been reached. The SRI will continue to illuminate, and remain illuminated, for 2 minutes every time the ignition is switched on or until it is reset. The SRI can be programmed for distance traveled, time since last service and engine hours since last service. Programming is done using the Volvo factory scan tool.

Starting from the 2002 model year, the need for service is indicated partly by the lamp and partly by a text message, TIME FOR SERVICE or TIME FOR REGULAR SERVICE. The SRI can be reset using the Volvo factory scan tool (or equivalent aftermarket scan tool), or using the following method.

Note. The service indicator message can also be reset using VIDA vehicle communication.

The service reminder indicator (SRI) informs the driver that it is time for the vehicle to be serviced. The text message is displayed for 120 seconds each time the ignition is switched on.

1. Ignition position I
2. Press and hold in the reset button for the trip odometer.
3. Turn the key to position II within 2 seconds, while continuing to press trip odometer reset button.
4. Hold the reset button for the trip meter pressed in until the original value has been reset and the general yellow lamp comes on.
5. Release the reset button for the trip odometer within 4 seconds. The instrument gives an audible signal when resetting has succeeded. NOTE: The odometer reset button must be released within 4 seconds to reset the service indication message.
6. If the trip meter is already reset, the reset button should be held in for a minimum of 10 seconds and a maximum of 14 seconds.

SERVICE REMINDER LIGHT RESET - PROCEDURE 12

Note. The S40 information applies to late production 2004 cars. In mid-2004, Volvo introduced a redesigned S40. For early production cars, the 4th character of the VIN is V. For late production cars, the 4th character of the VIN is M. Early production S40 models are equipped with 1.9L 4-cylinder engines. Late production S40 models are equipped with 5-cylinder engines.

1. Turn ignition to position I.
2. Press and hold the reset button for the trip odometer.
3. Turn key to position II within 2 seconds, while continuing to press trip odometer reset button.
4. Hold the reset button for the trip meter until the original value has been reset.
5. Release the reset button for the trip odometer within 4 seconds. The instrument cluster will give an audible signal when resetting is completed. NOTE: If the reset button for the trip odometer will not released within 4 seconds, the light is not reset.
6. If the trip meter is already reset, the reset button should be held in for a minimum of 10 seconds and a maximum of 14 seconds.

SERVICE REMINDER LIGHT RESET - PROCEDURE 13

Note. If equipped with a push button start/stop ignition, see PUSH BUTTON START/STOP IGNITION SWITCH POSITIONS for ignition switch positions.

Note. The lamp can also be reset using VIDA vehicle communication.

The service reminder indicator (SRI) informs the driver that it is time for the vehicle to be serviced. The text message is displayed for 120 seconds each time the ignition is switched on.

1. Turn ignition to position I.
2. Press and hold in the reset button for the trip odometer.
3. Turn the key to position II within 2 seconds, while continuing to press trip odometer reset button.
4. Hold the reset button for the trip odometer pressed in until the original value has been reset.
5. The information lamp lights when the reset button must be released.
6. Release the reset button for the trip odometer within 4 seconds. The instrument gives an audible signal when resetting has succeeded. NOTE: If the reset button for the trip odometer is not released within 4 seconds, the service reminder indicator (SRI) is not reset.
7. If the trip odometer is already reset, the reset button must be held in for a minimum of 10 seconds and a maximum of 14 seconds.

SERVICE REMINDER LIGHT RESET - PROCEDURE 14

Note. The S40 information applies to early production 2004 cars. In mid-2004, Volvo introduced a redesigned S40. For early production cars, the 4th character of the VIN is V. For late production cars, the 4th character of the VIN is M. Early production S40 models are equipped with 1.9L 4-cylinder engines. Late production S40 models are equipped with 5-cylinder engines.

1. Turn ignition off.
2. Press and hold in the reset button for the trip odometer.
3. Turn ignition on, while continuing to press trip odometer reset button.
4. The service reminder indicator (SRI) starts flashing when the reset button for the trip odometer has been pressed for 10 seconds.
5. Release the reset button for the trip odometer within 4 seconds. The instrument gives an audible signal when the reset has succeeded. The SRI indicator lamp goes out. NOTE: If the reset button for the trip odometer is not released within 4 seconds, the light is not reset. However it will stop flashing.

SERVICE REMINDER LIGHT RESET - PROCEDURE 15

Note. The service indicator message can also be reset using VIDA vehicle communication.

TPMS RESET - PROCEDURE 1

Note. Volvo vehicles do not require a formal reset procedure for any of the TPM system functions. Tire pressure sensor IDs are automatically programmed while driving.

Note. This system may not function properly if vehicle is equipped with a temporary spare tire or winter wheel/tire, as this tire does not have a TPM system sensor.

Tire Pressure Warning

There are two warning levels that generate different warning messages, one warning for low pressure and a warning for very low pressure. A message is also displayed if a sensor stops transmitting or receives insufficient battery voltage. A warning lamp also lights in the Driver information module (DIM) at the same time as the warning message appears.

The easiest way to reset a warning is to fill the underinflated tire to specification. The warning in the Driver information module (DIM) disappears the next time the ignition is switched on. If air is filled in a tire that has warned of low pressure and the ignition is on during the entire process, the warning will go out as soon as the pressure in the tire exceeds the specified level.

Tire Sensor Learning

If a sensor must be replaced, the system must "learn" the new sensor ID. This can be carried out in 2 different ways

Note. The vehicle must be parked for longer than 15 minutes to learn the new ID.

1. Drive the vehicle faster than 25 mph (40 km/h) for longer than 10 minutes. The warning for low pressure remains in the Driver information module (DIM) until the Central electronic module (CEM) has identified the new sensor.
2. Programming "by hand". This is carried out using the appropriate Volvo tire sensor activation tool, or Low Frequency (LF) initiator (sensor activation tool). Activating the tire pressure sensors this way replaces driving. NOTE: The Volvo tire sensor activation tool does not work with the sensors on S40 (04-)/V50/C30/C70 (06-)
