PREPARATIONS Volvo V50 I рестайлинг

PREPARATIONS

1. Turn the ignition key to position 0.
2. Disconnect the battery negative lead.

Note. Wait at least five minutes before disconnecting the connectors or removing other electrical equipment.

Scheme 510

1. Remove the three screws in the soundproofing panel on the left-hand side.
2. Push the carpet on the left-hand side of the center console to one side.
3. Carefully pry off the soundproofing panel from the top edge of the dashboard. Use a weatherstrip tool. The panel is secured by two clips at the top edge.

Scheme 511

1. Disconnect the connector for lighting (1) and remove the soundproofing panel.

Scheme 512

1. Fold the carpet to one side on the left-hand side.

Scheme 513

1. Place the fuse holder and connector for the alcolock on the member and secure them with tie straps.
2. Place the ground connection for the cable harness at the front ground terminal in the A post.

Scheme 514

1. Install the ground lead, use new screws from the kit. Tighten the M6 screw to 10 Nm .
2. Fold back the carpet.

Scheme 515

1. Disconnect the existing connector from the ignition switch.
2. Connect the connectors from the new cable harness to the corresponding connector in the ignition switch and the existing disconnected cable.

1. Connect the connectors from the new cable harness to the corresponding connector for lighting (1), which was previously disconnected.
2. Reinstall the soundproofing panel.

Scheme 516

Scheme 517

Connector for alcolock

1. 30+ feed (battery supply)
2. 15+ feed (ignition supply)
3. Start-in (kl50)
4. Start-out (kl50)
5. Preheat, act-low
6. Ground-, (31)
7. 30+ feed, controlled

Note. 30+ battery supply (1) must only be used in exceptional cases when log function for disconnection of the alcolock is required. In all other cases, 30+ battery supply (7) should be used, to prevent shortening the service life of the battery.
