METHOD CONTENTS
This method consists of two different methods
Remove the drive shaft according to: DRIVE SHAFT RIGHT .
Scheme 366
Detach the seal ring from the crown wheel shaft.
Use a screwdriver/jimmy bar.
Scheme 367
Install the new drive shaft seal ring.
Lubricate the seal with wheel bearing grease.
Use see 9995654 . Tap in the ring until it stops.
Note. If the crown wheel shaft seal is be replaced as well, see .
Scheme 368
Mark the position of the set nut in relation to the housing with a chalk line.
Measure and note the height between the nut and the housing.
Remove the screw and catch of the nut.
Scheme 369
Remove the adjusting nut using see 9997178 .
Scheme 370
Tap out the seal ring.
Use a screwdriver.
Scheme 371
Install the set nut seal ring.
Lubricate the seal lip with wheel bearing grease.
Use see 9997191 . Tap in the seal until the face of the drift touches the nut.
Insert a new O-ring on the nut. Lubricate the O-ring and threads with wheel bearing grease.
