GENERAL
| B5244S4 | B5244S5 | B5244S7 | |
|---|---|---|---|
| Engine code | 38 | 66 | 39 |
| Power (kw / rpm) | 125/6000 | 103/6000 | 123/6000 |
| Max torque (Nm / rpm) | 230/1500-4800 | 220/4000 | 230/4000 |
| Max rpm | 6500/6800 | 6500/6800 | 6500/6800 |
| Idling (rpm) | 720 | 720 | 720 |
| Cylinder bore (mm) | 83 | 83 | 83 |
| Stroke (mm) | 90 | 90 | 90 |
| Swept volume (liters) | 2.435 | 2.435 | 2.435 |
| Firing sequence | 1-2-4-5-3 | 1-2-4-5-3 | 1-2-4-5-3 |
| Engine control system | Denso | Denso | Denso |
| Weight, complete, including oil (kg) | 150 | 150 | 150 |
GENERAL DATA
Scheme 172
The engine serial number and type are stamped on the left side of the cylinder block at the top of the mounting for the water pump.
There is also a decal on the timing casing with the engine type, manufacturing number, and serial number.
Scheme 173
The marking is stamped into the engine block and crankshaft. The classification marking is in the engine block above the oil cooler and crankshaft. The classification shall be read from the digit 1 to 6. The first letter after the digit 1 corresponds to the classification of main bearing 1. The bearing positions are numbered starting at the engine's leading edge.
- Classification cylinder block
- Classification crankshaft
- Cylinder block
- Intermediate section
Scheme 174
| Standard | |
|---|---|
| C-marked........ mm | 83.000-83.010 |
| D-marked........ mm | 83.010-83.020 |
| E-marked........ mm | 83.020-83.030 |
CYLINDER BORE (D)
Scheme 175
| Length........ mm | 0.7-1.0 |
Scheme 176
| Standard | The diameter is measured 12 mm from the bottom of the piston |
|---|---|
| C-marked 1 ........ mm | 82.950-82.960 |
| D-marked 1 ........ mm | 82.960-82.970 |
| E-marked 1 ........ mm | 82.970-82.980 |
| 1 Classification is marked on the top of the piston. | |
PISTONS
| Tolerance piston/cylinder - top........ mm | 0.010 - 0.030 |
PISTON RUNNING CLEARANCE
| Top ring........ mm | 1.2 -0.01/-0.03 |
|---|---|
| 1st ring........ mm | 1.5 -0.01/-0.03 |
| Oil ring........ mm | 2 -0.01/-0.136 |
PISTON RINGS
| Diameter........ mm | 21.000 0.000/-0.004 |
|---|---|
| Length........ mm | 57.0 0.0/+0.2 |
PISTON PIN
Scheme 177
| Intake | |
|---|---|
| Length (A)........ mm | 102.00 ±0.07 |
| Diameter on crown (B)........ mm | 31 ±0.15 |
| Diameter on shaft (C)........ mm | 5.94 ±0.07 |
| Valve angle (D)........° | 45.5 ±0.17 |
| Clearance in guide........μm | 50 - 70 |
| Valve clearance........ mm | 0.20 ±0.03 |
| Exhaust | |
| Length (A)........ mm | 101.05 ±0.07 |
| Diameter on crown (B)........ mm | 27 ±0.15 |
| Diameter on shaft (C)........ mm | 5.94 ±0.07 |
| Valve angle (D)........° | 45.5 ±0.17 |
| Clearance in guide........μm | 50 - 70 |
| Valve clearance........ mm | 0.40 ±0.03 |
VALVES
| Seat angle........° | 45.5 ±0.17 |
VALVE SEATS
ENGINE TAPPETS
| Diameter........ mm | 32 -0.025/-0.040 |
|---|---|
| Length........ mm | 2.950 - 3.685 ±0.01 |
TAPPETS
CAMSHAFTS
| Max. lift height inlet........ mm | 8.68 |
|---|---|
| Max. lift height exhaust........ mm | 9.05 |
CAMSHAFTS
CYLINDER HEAD
| Max. distortion........ mm | 0.5 |
|---|---|
| Max. distortion, transverse........ mm | 0.2 |
| Height........ mm | 149.4 ±0.15 |
CYLINDER HEAD
CRANKSHAFT
| Radial run-out main bearing journal........ mm | Max. 0.040 |
|---|---|
| Axial play (Measured in the engine with the intermediate section tightened)........ mm | 0.08-0.19 |
| Main bearing journal, radial runout........ mm | 0.020-0.043 |
CRANKSHAFT
JOURNALS
| Diameter, standard 1 ........ mm | 50.000 0.000/-0.016 |
|---|---|
| Bearing recess width........ mm | 26.0 ±0.1 |
| Maximum out-of-round........ mm | 0.004 |
| Maximum taper........ mm | 0.004 |
| 1 The variation in diameter for each bearing journal must not exceed 0.008 mm. | |
BIG END JOURNALS
MAIN BEARING JOURNALS
| Diameter, standard 1 ........ mm | 65.000 +0.003/-0.016 |
|---|---|
| Axial bearing width........ mm | 26.00 0.00/-0.04 |
| Maximum out-of-round........ mm | 0.004 |
| Maximum taper........ mm | 0.004 |
| 1 The variation in diameter for each bearing journal must not exceed 0.008 mm. | |
MAIN BEARING JOURNALS
CONNECTING RODS
| Diameter, bearing recesses | |
|---|---|
| Big end........ mm | 53.000 0.000/+0.013 |
| Small-end........ mm | 21.000 +0.005/+0.011 |
| Maximum ovality in the bearing recesses........ mm | 0.006 |
| Length | |
| Big end - Small end........ mm | 147 |
CONNECTING RODS
OIL PRESSURE
| Oil pressure (min.) | |
|---|---|
| 13.3 r/s (800 rpm)........ Mpa 1 | 0.10 |
| 14.2 r/s (850 rpm)........ Mpa 1 | 0.10 |
| 66.7 r/s (4000 rpm)........ Mpa 1 | 0.35 |
| Maximum oil pressure (the relief valve opens)........ Mpa 1 | 0.48 |
| 1 The oil pressure given is for an oil temperature of 100 °C, which is reached after 10-15 minutes driving. | |
OIL PRESSURE
FUEL LINE PRESSURE
| Desired value | |
|---|---|
| Relative pressure | 380 kPa |
| Absolute pressure | 480 kPa |
FUEL LINE PRESSURE
THERMOSTAT
| Begins to open at | 90°C |
|---|---|
| Fully open at | 105°C |
THERMOSTAT
ENGINE COMPONENTS
| B5254T3 | |
|---|---|
| Engine code | 68 |
| Power (kw / rpm) | 162/5000 |
| Max torque (Nm / rpm) | 320/1500-4800 |
| Max rpm | 6500/6800 |
| Idling (rpm) | 720 |
| Cylinder bore (mm) | 83 |
| Stroke (mm) | 93.2 |
| Swept volume (liters) | 2.521 |
| Firing sequence | 1-2-4-5-3 |
| Engine control system | Bosch ME 9 |
| Weight, complete, including oil (kg) | 170 |
GENERAL DATA
ENGINE MANUFACTURE NUMBER, ENGINE SERIAL NUMBER AND TYPE
The engine serial number and type are stamped on the left side of the cylinder block at the top of the mounting for the water pump.
There is also a decal on the timing casing with the engine type, manufacturing number, and serial number.
CLASSIFICATION OF MAIN BEARINGS
The marking is stamped into the engine block and crankshaft. The classification marking is in the engine block above the oil cooler and crankshaft. The classification shall be read from the digit 1 to 6. The first letter after the digit 1 corresponds to the classification of main bearing 1. The bearing positions are numbered starting at the engine's leading edge.
- Classification cylinder block
- Classification crankshaft
- Cylinder block
- Intermediate section
CYLINDER BLOCK
| Standard | |
|---|---|
| C-marked........ mm | 83.000-83.010 |
| D-marked........ mm | 83.010-83.020 |
| E-marked........ mm | 83.020-83.030 |
CYLINDER BORE (D)
COOLING DUCT, ENGINE BLOCK
| Length........ mm | 0.7-1.0 |
PISTONS
| Standard | The diameter is measured 12 mm from the bottom of the piston |
|---|---|
| C-marked 1 ........ mm | 82.950-82.960 |
| D-marked 1 ........ mm | 82.960-82.970 |
| E-marked 1 ........ mm | 82.970-82.980 |
| 1 Classification is marked on the top of the piston. | |
PISTONS
| Tolerance piston/cylinder - top........ mm | 0.010 - 0.030 |
PISTON RUNNING CLEARANCE
| Top ring........ mm | 1.2 -0.01/-0.03 |
|---|---|
| 1st ring........ mm | 1.5 -0.01/-0.03 |
| Oil ring........ mm | 2 -0.01/-0.136 |
PISTON RINGS
| Diameter........ mm | 21.000 0.000/-0.004 |
|---|---|
| Length........ mm | 57.0 0.0/+0.2 |
PISTON PIN
ENGINE VALVES
| Intake | |
|---|---|
| Length (A)........ mm | 102.00 ±0.07 |
| Diameter on crown (B)........ mm | 31 ±0.15 |
| Diameter on shaft (C)........ mm | 5.94 ±0.07 |
| Valve angle (D)........° | 45.5 ±0.17 |
| Clearance in guide........μm | 50 - 70 |
| Valve clearance........ mm | 0.20 ±0.03 |
| Exhaust | |
| Length (A)........ mm | 101.05 ±0.07 |
| Diameter on crown (B)........ mm | 27 ±0.15 |
| Diameter on shaft (C)........ mm | 5.94 ±0.07 |
| Valve angle (D)........° | 45.5 ±0.17 |
| Clearance in guide........μm | 50 - 70 |
| Valve clearance........ mm | 0.40 ±0.03 |
VALVES
| Seat angle........° | 45.5 ±0.17 |
VALVE SEATS
| Diameter........ mm | 32 -0.025/-0.040 |
|---|---|
| Length........ mm | 2.950 - 3.685 ±0.010 |
TAPPETS
| Max. lift height inlet........ mm | 8.68 |
|---|---|
| Max. lift height exhaust........ mm | 9.05 |
CAMSHAFTS
| Max. distortion........ mm | 0.5 |
|---|---|
| Max. distortion, transverse........ mm | 0.2 |
| Height........ mm | 149.4 ±0.15 |
CYLINDER HEAD
| Radial run-out main bearing journal........ mm | Max. 0.040 |
|---|---|
| Axial play (Measured in the engine with the intermediate section tightened)........ mm | 0.08-0.19 |
| Main bearing journal, radial runout........ mm | 0.020-0.043 |
CRANKSHAFT
BIG END JOURNALS
| Diameter, standard 1 ........ mm | 50.000 0.000/-0.016 |
|---|---|
| Bearing recess width........ mm | 26.0 ±0.1 |
| Maximum out-of-round........ mm | 0.004 |
| Maximum taper........ mm | 0.004 |
| 1 The variation in diameter for each bearing journal must not exceed 0.008 mm. | |
BIG END JOURNALS
| Diameter, standard 1 ........ mm | 65.000 +0.003/-0.016 |
|---|---|
| Axial bearing width........ mm | 26.00 0.00/-0.04 |
| Maximum out-of-round........ mm | 0.004 |
| Maximum taper........ mm | 0.004 |
| 1 The variation in diameter for each bearing journal must not exceed 0.008 mm. | |
MAIN BEARING JOURNALS
| Diameter, bearing recesses | |
|---|---|
| Big end........ mm | 53.000 0.000/+0.013 |
| Small-end........ mm | 21.000 +0.005/+0.011 |
| Maximum ovality in the bearing recesses........ mm | 0.006 |
| Length | |
| Big end - Small end........ mm | 147 |
CONNECTING RODS
| Oil pressure (min.) | |
|---|---|
| 13.3 r/s (800 rpm)........ Mpa 1 | 0.10 |
| 14.2 r/s (850 rpm)........ Mpa 1 | 0.10 |
| 66.7 r/s (4000 rpm)........ Mpa 1 | 0.35 |
| Maximum oil pressure (the relief valve opens)........ Mpa 1 | 0.48 |
| 1 The oil pressure given is for an oil temperature of 100 °C, which is reached after 10-15 minutes driving. | |
OIL PRESSURE
| Desired value | |
|---|---|
| Relative pressure | 300 kPa |
| Absolute pressure | 400 kPa |
FUEL LINE PRESSURE
THEMOSTAT
| Begins to open at | 90°C |
|---|---|
| Fully open at | 105°C |
THERMOSTAT
