PREPARATORY WORK Volvo V50 I

PREPARATORY WORK

Remove the fuel tank. See: FUEL TANK (B5244S4), or FUEL TANK (B5254T3).

Scheme 39

Remove

1. the large plastic nut. Use tool: see «9997093»(ref-460875-S28648225322012033000000)
2. the level sensor.

Scheme 40

Note. Applies to vehicles equipped with auxiliary heater.

Remove the plug for the suction line from the underside of the level sensor, use a 9 mm socket.

Transfer the suction line to the new fuel pump.

Note. For tightening torques, see: TIGHTENING TORQUE .

Scheme 41

Install the level sensor.

Install the large plastic nut. Use tool: see 9997093 . Tighten according to: TIGHTENING TORQUE .

Note. Ensure that the level sensor marking is opposite the marking on the tank.
