Removing engine compartment components Volvo V40 I рестайлинг

Transmission - Removal, Replacement and Installation 1 illustration

Removing engine compartment components

Note. When removing the battery lead, see Note when disconnecting and connecting the battery lead .

Remove

  1. the air cleaner (ACL) housing assembly with the intake pipe
  2. the battery. See «Removing the air cleaner (ACL) housing»(ref-441339-S17663049282011121500000)
  3. the battery shelf.

Scheme 141

Scheme 141: Detach the gear selector cable from the lever (A)
Scheme 141: Detach the gear selector cable from the lever (A)
  1. Remove the two nuts for cable mounting B
  2. Lift the cable to the side.
CAUTIONTake care not to damage the cable or sleeve by bending it excessively. Take care not to damage the cable boot.
