ENGINE COMPRESSION
Note. Difference between cylinders must not exceed 25%.
Compression ratio is 9.0:1.
Check engine compression at normal operating temperature with all spark plugs removed. Compression should be 160-189 psi (1100-1300 kPa). Maximum compression difference between cylinders is 29 psi (200 kPa). For engine compression inspection procedure, see BASIC DIAGNOSTIC PROCEDURES - S40 & V40 .
VALVE CLEARANCE
For valve adjustment procedure and specifications, see ON-VEHICLE ADJUSTMENTS - S40 & V40 article.
IGNITION COIL
Connect an ohmmeter between the ignition coil terminals No. 1 and 2 (ignition coil side). The ohmmeter should read approximately .5 ohms. If not okay, replace ignition coil.
SPARK PLUGS
| Application | Specification |
|---|---|
| Part Number | Champion RC8PYP or equivalent |
| Gap | .032" (.80 mm) |
| Torque | 18 Ft. Lbs. (25 N.m) |
SPARK PLUG SPECIFICATIONS
FIRING ORDER
(Scheme 1)for firing order.
Scheme 1
IGNITION TIMING
Ignition timing is 9-15 degrees BTDC. Ignition timing is computer-controlled and is not adjustable.
FUEL PUMP
| Application | Specification | |
|---|---|---|
| Pressure | ||
| At Fuel Rail, Engine Off | 42-45 PSI (290-310 kPa) | |
| Maximum Pump Pressure | 116 PSI (800 kPa) | |
| Residual Pressure | ||
| 20 Minutes After Engine Shut Off | 29 PSI (200 kPa) | |
| Volume | ||
| At 12.5 V | 0.66 Gal/Min. (2.5 L/Min.) | |
| At 12.0 V | 0.55 Gal/Min. (2.08 L/Min.) | |
FUEL PUMP PERFORMANCE
FUEL INJECTOR RESISTANCE
Resistance between injector terminals is 14-15 ohms.
FAST IDLE
Note. All idle speeds are controlled by electronic control unit. Specifications on fast idle are not available from manufacturer.
THROTTLE POSITION SENSOR
Note. Throttle Position (TP) sensor is not adjustable.
