Engine Control - Symptom Related Diagnostic Procedures: Other Volvo V40 I рестайлинг

Engine Control Systems 43 illustrations ~9136 words

Checking the response code for the brake valves

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Depress the brake pedal. Check that the brake valve is OK by checking that response code 1-1-3 is returned. Is response code 1-1-3 returned? Yes, response code 1-1-3 is returned (manual transmission). Refer to «Checking the response code for the clutch valve»(ref-441369-S39600088452011121500000) . Yes, response code 1-1-3 is returned (automatic transmission). Troubleshooting has been completed. No, response code 1-1-3 is not returned. Refer to «Checking brake valves»(ref-441369-S02471245292011121500000) . No, response code 3-1-1 is returned instead. Refer to «Checking response code 3-1-1»(ref-441369-S34740563872011121500000)

Scheme 25

Scheme 25: Checking brake valves
Scheme 25: Checking brake valves

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Ignition off.
  2. Brake valve disconnected.
  3. Connect the selector switch.
  4. Selector switch in the OFF position. Connect an ohmmeter between the terminal pins on the brake valve.

The ohmmeter should read approximately 0 ohms when the brake pedal is unaffected. The ohmmeter should read infinite resistance when the pedal is depressed more than 8 mm.

  1. OK Refer to «Checking for a short-circuit»(ref-441369-S15072440382011121500000)
  2. NOT OK Refer to «Adjusting the brake valve»(ref-441369-S14853564142011121500000)

Checking for a short-circuit

  1. Ignition off. Check the cable between the selector switch and the clutch valve. Check the cable between the brake valve and the control module. Check for short-circuits according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) and «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Checking the response code for the clutch valve

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Depress the clutch pedal Check that the brake valve is OK by checking that response code 1-1-3 is returned. Is response code 1-1-3 returned? Yes, response code 1-1-3 is returned. Troubleshooting has been completed. No, response code 1-1-3 is not returned. Refer to «Checking the clutch valve»(ref-441369-S16204814122011121500000) . No, response code 3-1-1 is returned instead. Refer to «Checking response code 3-1-1»(ref-441369-S05549162052011121500000) .

Checking response code 3-1-1

A response code is transmitted when the control module receives several signals from the same component or wiring circuit within 8 milliseconds. The cause of the fault may be loose connections in the terminals or a defective system component.

Scheme 29

Scheme 29: Checking response code 3-1-1
Scheme 29: Checking response code 3-1-1
  1. Continue Refer to «Checking the response code for the clutch valve»(ref-441369-S39600088452011121500000)

A response code is transmitted when the control module receives several signals from the same component or wiring circuit within 8 milliseconds. The cause of the fault may be loose connections in the terminals or a defective system component.

  1. Continue Refer to «Checking the clutch valve»(ref-441369-S16204814122011121500000)

A response code is transmitted when the control module receives several signals from the same component or wiring circuit within 8 milliseconds. The cause of the fault may be loose connections in the terminals or a defective system component.

  1. Continue Refer to «Checking the voltage to the selector switch»(ref-441369-S21809531392011121500000)

Checking the clutch valve

  1. Ignition off.
  2. Clutch valve disconnected.
  3. Selector switch in the OFF position. Connect an ohmmeter between the terminal pins on the clutch valve.

The ohmmeter should read approximately 0 ohms when the brake pedal is unaffected. The ohmmeter should read infinite resistance when the pedal is depressed more than 8 mm.

  1. OK Refer to «Checking for a short-circuit»(ref-441369-S01244380902011121500000)
  2. NOT OK Refer to «Adjusting the clutch valve»(ref-441369-S19319453192011121500000)

Adjusting the clutch valve

  1. Ignition off.
  2. Clutch valve disconnected.
  3. Depress the pedal so that it is not in contact with the valve.
  4. Pull out the piston as far as possible. Slowly release the pedal. Connect an ohmmeter between the terminal pins on the clutch valve.

The ohmmeter should read approximately 0 ohms when the brake pedal is unaffected. The ohmmeter should read infinite resistance when the pedal is depressed more than 8 mm.

  1. OK Troubleshooting has been completed.
  2. NOT OK Refer to «Replacing the component»(ref-441369-S27282278232011121500000)
  1. Ignition off. Check the cable between the brake valve and the clutch valve. Check the cable between the clutch valve and the control module. Check for short-circuits according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) and «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Ignition off.
  2. Selector switch connected.
  3. Ignition on. Connect a voltmeter between terminal #1 on the selector switch connector and ground.

The voltmeter should read battery voltage.

  1. OK Refer to «Checking the selector switch»(ref-441369-S01946239922011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S17599861202011121500000)

Scheme 33

Scheme 33
Scheme 33
  1. Ignition off. Check the cable between fuse 5 and terminal #1 on the selector switch connector for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Scheme 34

Scheme 34
Scheme 34
  1. Selector switch connected.
  2. Ignition on.
  3. Disconnect the brake valve. Connect a voltmeter between terminal #2 on the selector switch connector and ground. The voltmeter should read battery voltage when the selector switch is in the ON position. The voltmeter should read approximately 0 V when the selector switch is in the OFF position. The value is OK. Refer to «Checking the cable between the selector switch and the brake valve»(ref-441369-S04054109802011121500000) . The voltage is constantly 12 V. Refer to «Checking for a short-circuit»(ref-441369-S01722468612011121500000) . The voltage is constantly 0 V. Refer to «Checking the connector for the selector switch»(ref-441369-S00939714292011121500000) .

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Ignition off.
  2. Check terminals #1 and #2 on the selector switch connector for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the selector switch.
  4. Ignition on.
  5. Selector switch on. Connect a voltmeter between terminal #2 on the selector switch connector and ground.

The voltmeter should read battery voltage.

  1. OK Troubleshooting has been completed.
  2. NOT OK Refer to «Replacing the component»(ref-441369-S40412710542011121500000)

Replacing the component

  1. Ignition off. Replace the selector switch according to «Replacement of selector switch (turn indicator)»(ref-441369-S23439415732012032900000) .

Scheme 37

Scheme 37
Scheme 37
  1. Ignition off.
  2. Disconnect the brake valve.
  3. Selector switch connected.
  4. Ignition on.
  5. Selector switch in the OFF position. Connect a voltmeter between brake valve connector terminal #1 and ground.

The voltmeter should read approximately 0 V.

  1. OK Refer to «Checking the cable between the selector switch and the brake valve»(ref-441369-S04054109802011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S01722468612011121500000)

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Ignition off. Check the cable between selector switch connector terminal #2 and brake valve connector terminal #1 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Checking the cable between the selector switch and the brake valve

  1. Ignition off.
  2. Brake valve disconnected.
  3. Disconnect the selector switch. Connect an ohmmeter between selector switch connector terminal #2 and the brake valve connector (terminal #1).

The ohmmeter should read 0 ohms.

  1. OK Refer to «Checking brake valves»(ref-441369-S05259644142011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S33729019202011121500000)

Checking for an open-circuit

  1. Ignition off. Check the cable between selector switch connector terminal #2 and brake valve connector terminal #1 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Checking brake valves

  1. Ignition off.
  2. Brake valve disconnected.
  3. Connect the selector switch.
  4. Selector switch in the OFF position. Connect an ohmmeter between the terminal pins on the brake valve.

The ohmmeter should read approximately 0 ohms when the brake pedal is unaffected. The ohmmeter should read infinite resistance when the pedal is depressed more than 8 mm.

  1. OK Refer to «Fault-tracing information»(ref-441369-S03950101282011121500000)
  2. NOT OK Refer to «Adjusting the brake valve»(ref-441369-S14853564142011121500000)

Fault-tracing information

  1. Only cars with manual transmissions have a clutch valve. Specify the type of transmission before continuing with fault-tracing.

Does the car have a manual transmission?

  1. YES Refer to «Checking the power supply for the clutch valve»(ref-441369-S02214072482011121500000)
  2. NO FAULT NOT FOUND: Troubleshooting has been completed.

Adjusting the brake valve

  1. Ignition off.
  2. Brake valve disconnected.
  3. Depress the pedal so that it is not in contact with the valve.
  4. Pull out the piston as far as possible. Slowly release the pedal. Connect an ohmmeter between the terminal pins on the brake valve.

The ohmmeter should read approximately 0 ohms when the brake pedal is unaffected. The ohmmeter should read infinite resistance when the pedal is depressed more than 8 mm.

  1. OK Troubleshooting has been completed.
  2. NOT OK Refer to «Replacing the component»(ref-441369-S08984276612011121500000)
  1. Ignition off. Replace the brake valve according to «Replacement of brake pedal vacuum valve»(ref-441369-S03547040982012031600000) .

Checking the power supply for the clutch valve

  1. Ignition off.
  2. Remove the clutch valve.
  3. Ignition on.
  4. Selector switch in the OFF position. Connect a voltmeter between clutch valve connector terminal #1 and ground.

The voltmeter should read approximately 0 V.

  1. OK Refer to «Checking the cable between the brake valve and the clutch valve»(ref-441369-S10912098812011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S10022037342011121500000)
  1. Ignition off. Check the cable between brake valve connector terminal #2 and clutch valve connector terminal #1 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Checking the cable between the brake valve and the clutch valve

  1. Ignition off.
  2. Clutch valve disconnected.
  3. Brake valve disconnected. Connect an ohmmeter between brake valve connector terminal #2 and clutch valve terminal #1.

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the clutch valve»(ref-441369-S12383044152011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S23146354122011121500000)
  1. Ignition off. Check the cable between brake valve connector terminal #2 and clutch valve terminal #1 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .
  1. Ignition off.
  2. Clutch valve disconnected.
  3. Selector switch in the OFF position. Connect an ohmmeter between the terminal pins on the clutch valve.

The ohmmeter should read approximately 0 ohms when the brake pedal is unaffected. The ohmmeter should read infinite resistance when the pedal is depressed more than 8 mm.

  1. OK Refer to «Adjusting the clutch valve»(ref-441369-S17710774472011121500000)
  2. NOT OK Refer to «Checking the power supply for the control module»(ref-441369-S39238801572011121500000)
  1. Ignition off.
  2. Clutch valve disconnected.
  3. Depress the pedal so that it is not in contact with the valve.
  4. Pull out the piston as far as possible. Slowly release the pedal. Connect an ohmmeter between the terminal pins on the clutch valve.

The ohmmeter should read approximately 0 ohms when the brake pedal is unaffected. The ohmmeter should read infinite resistance when the pedal is depressed more than 8 mm.

  1. OK Refer to «Checking the power supply for the control module»(ref-441369-S39238801572011121500000)
  2. NOT OK Refer to «Replacing the component»(ref-441369-S27282278232011121500000)
  1. Ignition off. Replace the clutch valve according to «Replacement of clutch pedal vacuum valve»(ref-441369-S23974180992012032900000) .

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. Ignition off.
  2. Disconnect the control module.
  3. Connect the brake valve.
  4. Connect the clutch valve (manual transmissions).
  5. Ignition on.
  6. Pedals unaffected. Connect a voltmeter between control module connector terminal #3 and ground. The voltmeter should read approximately 0 V when the selector switch is in the OFF position. The voltmeter should read battery voltage when the selector switch is in the ON position. The value is OK. Refer to «Checking the control module connectors»(ref-441369-S08687782252011121500000) The voltage is constantly 0 V. Refer to «Checking the cable between the brake valve/clutch valve and the control module»(ref-441369-S23325551382011121500000) . The voltage is constantly 12 V. Refer to «Checking for a short-circuit»(ref-441369-S10491971662011121500000) .

Scheme 42

Scheme 42
Scheme 42
  1. Ignition off. Check the cable between brake valve connector terminal 2 and control module connector terminal 3 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) . Cars with manual transmissions: Check the cable between clutch valve connector terminal #2 and control module terminal #3 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Scheme 43

Scheme 43
Scheme 43
  1. Ignition off.
  2. Control module disconnected.
  3. Disconnect the brake valve.
  4. Clutch valve connected (manual transmissions). Connect an ohmmeter between control module connector terminal #3 and brake valve connector terminal #2. Cars with manual transmissions: the ohmmeter must be connected to clutch valve terminal #2.

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the control module connectors»(ref-441369-S08687782252011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S39715455622011121500000)
  1. Ignition off. Check the cable between brake valve connector terminal #2 and control module terminal #3 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Cars with manual transmissions: check the cable between control module terminal #3 and clutch valve terminal #2 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Scheme 44

Scheme 44
Scheme 44
  1. Ignition off.
  2. Check control module connector terminal #3 for loose connections and for contact resistance. Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) . Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) .
  3. Connect the brake valve/clutch valve.
  4. Connect the control module.
  5. Connect the Volvo Scan Tool (ST) to the data link connector (DLC).
  6. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the switch from ON to OFF or from OFF to ON. Check whether response code 1-1-3 is returned.

Is response code 1-1-3 returned?

  1. YES Refer to «Fault-tracing information»(ref-441369-S19510998252011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S10265195212011121500000)
  1. The response code was not returned because there was a loose connection in the control module connectors.
  1. Ignition off. Replace the control module according to «Replacement of control module»(ref-441369-S15062999982012032800000) .
  1. Continue Refer to «Information»(ref-441369-S10092095832011121500000)

Scheme 45

Scheme 45: Replacement of brake pedal vacuum valve
Scheme 45: Replacement of brake pedal vacuum valve
  1. Remove connector from vacuum valve.
  2. Remove hose from vacuum valve.
  3. Press in both catches and remove vacuum valve from support.

Reinstall in reverse order.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9988686

Condition

  1. The fault is permanent.
  2. The control module is correctly connected.

Possible Source

Scheme 46

Scheme 46
Scheme 46
  1. Open-circuit in the cable between fuse 5 in the integrated relay/fusebox and control module connector terminal 3.
  2. Short-circuit to ground or supply voltage in the cable between fuse 5 and control module connector terminal 3.
  3. Defective switch, brake or clutch valve.

Fault symptom[s]

  1. The cruise control does not engage.
  2. The cruise control does not disengage when the selector switch is switched to OFF or when the brake or clutch pedals are depressed.

Checking the ON/OFF selector switch, brake and clutch valves

See Checking the ON/OFF selector switch, brake and clutch valves

See Fault-tracing information

See Checking the ON/OFF selector switch, brake and clutch valves

See Fault-tracing information

Checking the response code

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Set the switch to the ON position. Move the gear selector from D to N or from N to D. Check that the Park/Neutral position (PNP) switch is OK by checking whether response code 2-2-3 is obtained. Is response code 2-2-3 obtained? Yes, response code 2-2-3 is obtained. Troubleshooting has been completed. No, response code 2-2-3 is not obtained. Refer to «Checking the function of the Park/Neutral position (PNP) switch»(ref-441369-S06245784772011121500000) . No, response code 3-1-1 is obtained instead. Refer to «Checking response code 3-1-1»(ref-441369-S25483095632011121500000) .

The response code is obtained when the control module receives numerous input signals within 8 ms from the same component or circuit. The fault may be due to loose connections in the terminals or a faulty component.

  1. Continue Refer to «Checking the function of the Park/Neutral position (PNP) switch»(ref-441369-S06245784772011121500000)

Checking the function of the Park/Neutral position (PNP) switch

  1. Check that the car can be started with the gear selector in positions N and P.
  2. Check that the car cannot be started with the gear selector in any other position.

Scheme 47

Scheme 47
Scheme 47

Does the Park/Neutral position (PNP) switch function?

  1. YES Refer to «Checking the power supply to the control module»(ref-441369-S38949581622011121500000)
  2. NO Refer to «Checking components»(ref-441369-S08621481252011121500000)

Checking components

Fault-trace the Park/Neutral position (PNP) switch and the associated circuit.

Checking the power supply to the control module

  1. Ignition off.
  2. Disconnect the control module.
  3. Ignition on. Connect a voltmeter between control module connector terminal 2 and ground.

The voltmeter should read battery voltage with the gear selector in position D. The voltmeter should read 0 V with the gear selector in positions N and P.

  1. OK Refer to «Checking the control module connectors»(ref-441369-S23157299892011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S14683627372011121500000)
  1. Ignition off. Check the cable between the connector 24/32 terminal #10 and control module connector terminal #2 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Checking the control module connectors

  1. Ignition off.
  2. Check control module connector terminal #2 for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the control module.
  4. Connect the Volvo Scan Tool (ST) to the data link connector (DLC).
  5. Ignition on. Activate the Scan Tool (ST) in MODE 2. Set the switch to the ON position. Move the gear selector from D to N or from N to D. Check whether response code 2-2-3 is obtained.

Is response code 2-2-3 obtained?

  1. YES Refer to «Fault-tracing information»(ref-441369-S12786583062011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S39392805672011121500000)
  1. Ignition off. This response code was not obtained because of loose connections in the control module connector.
  1. Ignition off. Replace with a new control module according to «Replacement of control module»(ref-441369-S15062999982012032800000) .
  1. Continue Refer to «Information»(ref-441369-S04447579282011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9988686

Condition

  1. The fault is permanent.
  2. The control module is correctly connected.

Possible Source

  1. Open-circuit in the cable between control module connector terminal 2 and ground.
  2. Short-circuit to ground or supply voltage in the cable between control module connector terminal 2 and ground.
  3. Defective Park/Neutral position (PNP) switch in the automatic transmission.

Fault symptom[s]

  1. The cruise control does not disengage when the gear selector is moved from D to N.
  2. The cruise control does not engage.
  3. Car will not start.

Checking the Park/Neutral position (PNP) switch (automatic transmissions)

See Checking the Park/Neutral position (PNP) switch (automatic transmissions)

See Fault-tracing information

See Checking the Park/Neutral position (PNP) switch (automatic transmissions)

See Fault-tracing information

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the selector switch from ON to RESUME or from RESUME to ON. Check that the RESUME function is OK by check that response code 1-2-3 is returned. Is response code 1-2-3 returned? Yes, response code 1-2-3 is returned. Troubleshooting has been completed. No, response code 1-2-3 is not returned. Refer to «Checking other response codes»(ref-441369-S07211883852011121500000) . No, response code 3-1-1 is returned instead. Refer to «Checking response code 3-1-1»(ref-441369-S26482591682011121500000) .

A response code is transmitted when the control module receives several signals from the same component or wiring circuit within 8 milliseconds. The cause of the fault may be loose connections in the terminals or a defective system component.

  1. Continue Refer to «Checking other response codes»(ref-441369-S07211883852011121500000)

Checking other response codes

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Activate the SET- switch Check that the SET+ function is OK by checking that response code 1-3-1 is returned.

Is response code 1-3-1 returned?

  1. YES Refer to «Checking the selector switch»(ref-441369-S00600938792011121500000)
  2. NO Refer to «Checking the voltage to the selector switch»(ref-441369-S24470104602011121500000)

Checking the voltage to the selector switch

  1. Selector switch connected.
  2. Ignition on. Connect a voltmeter between selector switch connector terminal #1 and ground.

The voltmeter should read battery voltage.

  1. OK Refer to «Checking the selector switch»(ref-441369-S00600938792011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S00688069722011121500000)
  1. Ignition off. Check the cable between fuse 5 and terminal #1 on the selector switch connector for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Checking the selector switch

  1. Ignition off.
  2. Selector switch connected.
  3. Ignition on. Connect a voltmeter between terminal #5 on the selector switch connector and ground.

The voltmeter should read battery voltage when the RESUME switch is activated. The voltmeter should read approximately 0 V when the RESUME switch is not activated.

  1. OK Refer to «Checking the power supply for the control module»(ref-441369-S09367836472011121500000)
  2. NOT OK Refer to «Checking the connector for the selector switch»(ref-441369-S21697789342011121500000)

Checking the connector for the selector switch

  1. Ignition off.
  2. Check terminals #1 and #5 on the selector switch connector for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the selector switch.
  4. Ignition on. Connect a voltmeter between terminal #5 on the selector switch connector and ground.

The voltmeter should read battery voltage when the RESUME switch is activated. The voltmeter should read approximately 0 V when the RESUME switch is not activated.

  1. OK Refer to «Checking the power supply for the control module»(ref-441369-S09367836472011121500000)
  2. NOT OK Refer to «Replacing the component»(ref-441369-S42459546302011121500000)
  1. Ignition off. Replace the selector switch according to «Replacement of selector switch (turn indicator)»(ref-441369-S23439415732012032900000) .

Checking the power supply for the control module

  1. Ignition off.
  2. Disconnect the control module.
  3. Selector switch connected.
  4. Ignition on. Connect a voltmeter between control module connector terminal #4 and ground. The voltmeter should read battery voltage when the RESUME switch is activated. The voltmeter should read 0 V when the RESUME switch is not activated. The value is OK. Refer to «Checking the control module connectors»(ref-441369-S14116668362011121500000) . The voltmeter reads 0 V. Refer to «Checking the cable between the selector switch and the control module»(ref-441369-S15898910172011121500000) . The voltmeter reads battery voltage when the RESUME switch is not activated. Refer to «Checking for a short-circuit»(ref-441369-S22503182622011121500000) .

Scheme 48

Scheme 48
Scheme 48
  1. Ignition off. Check the cable between selector switch connector terminal #5 and control module connector terminal #4 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Checking the cable between the selector switch and the control module

  1. Ignition off.
  2. Control module disconnected.
  3. Disconnect the selector switch. Connect an ohmmeter between selector switch connector terminal #5 and control module connector terminal #4.

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the control module connectors»(ref-441369-S14116668362011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S29084794312011121500000)
  1. Ignition off. Check the cable between selector switch connector terminal #5 and control module connector terminal #4 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .
  1. Ignition off.
  2. Check control module terminal #4 for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the selector switch.
  4. Connect the control module.
  5. Connect the Volvo Scan Tool (ST) to the data link connector (DLC).
  6. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the selector switch from ON to RESUME or from RESUME to ON. Check whether response code 1-2-3 is returned.

Is response code 1-2-3 returned?

  1. YES Refer to «Fault-tracing information»(ref-441369-S22086884082011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S34547570942011121500000)
  1. The response code was not returned because there were loose connections in the control module connectors.
  1. Ignition off. Replace the control module according to «Replacement of control module»(ref-441369-S15062999982012032800000) .
  1. Continue Refer to «Information»(ref-441369-S03673456502011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9988686

Condition

  1. The fault is permanent.
  2. The control module is correctly connected.

Possible Source

  1. Open-circuit in the cable between fuse 5 in the integrated relay/fusebox and control module connector terminal 4.
  2. Short-circuit to ground or supply voltage in the cable between fuse 5 and control module connector terminal 4.
  3. Defective switch.

Fault symptom[s]

  1. The cruise control will not return to the previously set speed when RESUME is activated.

Checking the RESUME switch

See Checking the RESUME switch

See Fault-tracing information

See Checking the RESUME switch

See Fault-tracing information

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Activate the SET switch. Check that the SET-function is OK by checking that response code 2-1-3 is returned. Is response code 2-1-3 returned? Yes, response code 2-1-3 is returned. Troubleshooting has been completed. No, response code 2-1-3 is not returned. Refer to «Checking other response codes»(ref-441369-S38942076452011121500000) . No, response code 3-1-1 is returned instead. Refer to «Checking response code 3-1-1»(ref-441369-S24100657162011121500000) .

A response code is transmitted when the control module receives several signals from the same component or wiring circuit within 8 milliseconds. The cause of the fault may be loose connections in the terminals or a defective system component.

  1. Continue Refer to «Checking other response codes»(ref-441369-S38942076452011121500000)
  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Activate the SET+ switch. Check that the SET+ function is OK by checking that response code 1-3-1 is returned.

Is response code 1-3-1 returned?

  1. YES Refer to «Checking the selector switch»(ref-441369-S42472198102011121500000)
  2. NO Refer to «Checking the voltage to the selector switch»(ref-441369-S16739220502011121500000)
  1. Ignition off.
  2. Selector switch connected.
  3. Ignition on. Connect a voltmeter between selector switch connector terminal #1 and ground.

The voltmeter should read battery voltage.

  1. OK Refer to «Checking the selector switch»(ref-441369-S42472198102011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S21480920192011121500000)
  1. Ignition off. Check the cable between fuse 5 and terminal #1 on the selector switch connector for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .
  1. Ignition off.
  2. Selector switch connected.
  3. Ignition on.
  4. Selector switch on. Connect a voltmeter between selector switch connector terminal #4 and ground.

The voltmeter should read battery voltage when the SET- switch is activated. The voltmeter should read 0 V when the SET- switch is not activated.

  1. OK Refer to «Checking the power supply for the control module»(ref-441369-S01853036562011121500000)
  2. NOT OK Refer to «Checking the connector for the selector switch»(ref-441369-S01888015282011121500000)
  1. Ignition off.
  2. Check selector switch connector terminals #1 and #4 for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the selector switch.
  4. Ignition on.
  5. Selector switch on. Connect a voltmeter between selector switch connector terminal #4 and ground.

The voltmeter should read battery voltage when the SET- switch is activated. The voltmeter should read 0 V when the SET- switch is not activated.

  1. OK Refer to «Checking the power supply for the control module»(ref-441369-S01853036562011121500000)
  2. NOT OK Refer to «Replacing the component»(ref-441369-S20912414602011121500000)
  1. Ignition off. Replace the selector switch according to «Replacement of selector switch (turn indicator)»(ref-441369-S23439415732012032900000) .
  1. Ignition off.
  2. Disconnect the control module.
  3. Selector switch connected.
  4. Ignition on.
  5. Selector switch on. Connect a voltmeter between control module connector terminal #5 and ground. The voltmeter should read battery voltage when the SET- switch is activated. The voltmeter should read 0 V when the SET- switch is not activated. The value is OK. Refer to «Checking the control module connectors»(ref-441369-S20118674432011121500000) . The voltmeter reads 0 V. Refer to «Checking the cable between the selector switch and the control module»(ref-441369-S23004170792011121500000) . The voltmeter reads battery voltage when the SET+ switch is not activated. Refer to «Checking for a short-circuit»(ref-441369-S22534375722011121500000) .
  1. Ignition off. Check the cable between selector switch connector terminal #4 and control module connector terminal #5 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .
  1. Ignition off.
  2. Control module disconnected.
  3. Disconnect the selector switch. Connect an ohmmeter between selector switch connector terminal #4 and control module connector terminal #5.

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the control module connectors»(ref-441369-S20118674432011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S03917651212011121500000)
  1. Ignition off. Check the cable between selector switch connector terminal #4 and control module connector terminal #5 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .
  1. Ignition off.
  2. Check control module terminal #5 for contact resistance and oxidation. Remedy according to «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) .
  3. Connect the control module.
  4. Connect the selector switch.
  5. Selector switch on.
  6. Connect the Volvo Scan Tool (ST) to the data link connector (DLC).
  7. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Activate the SET- switch. Check whether response code 2-1-3 is returned.

Is response code 2-1-3 returned?

  1. YES Refer to «Fault-tracing information»(ref-441369-S21840018152011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S17550327172011121500000)
  1. The response code was not returned because there was a loose connection in the control module connectors.
  1. Ignition off. Replace the control module according to «Replacement of control module»(ref-441369-S15062999982012032800000) .
  1. Continue Refer to «Information»(ref-441369-S20456189522011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9988686

Condition

  1. The fault is permanent.
  2. The control module is correctly connected.

Possible Source

  1. Open-circuit in the cable between fuse 5 in the integrated relay/fusebox and control module connector terminal 5.
  2. Short-circuit to ground or supply voltage in the cable between fuse 5 and control module connector terminal 5.
  3. Defective switch.

Fault symptom[s]

  1. The vehicle speed does not decrease when SET- is activated.
  2. The cruise control does not engage.
  3. The vehicle speed decreases constantly.

Checking the SET- switch

See Checking the SET- switch

See Fault-tracing information

See Checking the SET- switch

See Fault-tracing information

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Activate the SET- switch Check that the SET+ function is OK by checking that response code 1-3-1 is returned. Is response code 1-3-1 returned? Yes, response code 1-3-1 is returned. Troubleshooting has been completed. No, response code 1-3-1 is not returned. Refer to «Checking other response codes»(ref-441369-S16872873612011121500000) . No, response code 3-1-1 is returned instead. Refer to «Checking response code 3-1-1»(ref-441369-S21397318842011121500000) .

A response code is transmitted when the control module receives several signals from the same component or wiring circuit within 8 milliseconds. The cause of the fault may be loose connections in the terminals or a defective system component.

  1. Continue Refer to «Checking other response codes»(ref-441369-S16872873612011121500000)
  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the switch from ON to OFF or from OFF to ON. Check that the ON/OFF switch is OK by checking that response code 1-1-3 is returned.

Is response code 1-1-3 returned?

  1. YES Refer to «Checking the selector switch»(ref-441369-S37918595542011121500000)
  2. NO Refer to «Checking the voltage to the selector switch»(ref-441369-S22323161162011121500000)
  1. Selector switch connected.
  2. Ignition on. Connect a voltmeter between terminal #1 on the selector switch connector and ground.

The voltmeter should read battery voltage.

  1. OK Refer to «Checking the selector switch»(ref-441369-S37918595542011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S38297990492011121500000)
  1. Ignition off. Check the cable between fuse 5 and terminal #1 on the selector switch connector for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .
  1. Ignition off.
  2. Selector switch connected.
  3. Ignition on.
  4. Selector switch on. Connect a voltmeter between terminal #3 on the selector switch connector and ground.

The voltmeter should read battery voltage when the SET+ switch is activated. The voltmeter should read approximately 0 V when the SET switch is not activated.

  1. OK Refer to «Checking the power supply for the control module»(ref-441369-S09395098052011121500000)
  2. NOT OK Refer to «Checking the connector for the selector switch»(ref-441369-S30019353882011121500000)
  1. Ignition off.
  2. Check terminals #1 and #3 on the selector switch connector for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the selector switch.
  4. Ignition on.
  5. Selector switch on. Connect a voltmeter between selector switch connector terminal #3 and ground.

The voltmeter should read battery voltage when the SET+ switch is activated. The voltmeter should read approximately 0 V when the SET switch is not activated.

  1. OK Refer to «Checking the power supply for the control module»(ref-441369-S09395098052011121500000)
  2. NOT OK Refer to «Replacing the component»(ref-441369-S19665433642011121500000)
  1. Ignition off. Replace the selector switch according to «Replacement of selector switch (turn indicator)»(ref-441369-S23439415732012032900000) .
  1. Ignition off.
  2. Disconnect the control module.
  3. Selector switch connected.
  4. Ignition on.
  5. Selector switch on. Connect a voltmeter between control module connector terminal #6 and ground. The voltmeter should read battery voltage when the SET- switch is activated. The voltmeter should read 0 V when the SET- switch is not activated. The value is OK. Refer to «Checking the control module connectors»(ref-441369-S24253173892011121500000) . The voltmeter reads 0 V. Refer to «Checking the cable between the selector switch and the control module»(ref-441369-S21711350122011121500000) . The voltmeter reads battery voltage when the SET+ switch is not activated. Refer to «Checking for a short-circuit»(ref-441369-S04100379862011121500000) .
  1. Ignition off. Check the cable between selector switch connector terminal #3 and control module connector terminal #6 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .
  1. Ignition off.
  2. Control module disconnected.
  3. Disconnect the selector switch. Connect an ohmmeter between selector switch connector terminal #3 and control module connector terminal #6.

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the control module connectors»(ref-441369-S24253173892011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S28453651612011121500000)
  1. Ignition off. Check the cable between selector switch connector terminal #3 and control module connector terminal #6 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .
  1. Ignition off.
  2. Check control module terminal #6 for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the control module.
  4. Connect the selector switch.
  5. Connect the Volvo Scan Tool (ST) to the data link connector (DLC).
  6. Ignition on. Activate the Scan Tool (ST) in MODE 2. Move the ON/OFF switch to the ON position. Activate the SET- switch Check whether response code 1-3-1 is returned.

Is response code 1-3-1 returned?

  1. YES Refer to «Fault-tracing information»(ref-441369-S39021572432011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S31355523272011121500000)
  1. The response code was not returned because there was a loose connection in the control module connectors.
  1. Ignition off. Replace the control module according to «Replacement of control module»(ref-441369-S15062999982012032800000) .
  1. Continue Refer to «Information»(ref-441369-S21472707402011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9988686

Condition

  1. The fault is permanent.
  2. The control module is correctly connected.

Possible Source

  1. Open-circuit in the cable between fuse 5 in the integrated relay/fusebox and control module connector terminal 6.
  2. Short-circuit to ground or supply voltage in the cable between fuse 5 and control module connector terminal 6.
  3. Defective switch.

Fault symptom[s]

  1. The vehicle speed does not increase when SET+ is activated.
  2. The cruise control does not engage.
  3. The vehicle speed increases constantly.

Checking the SET+ switch

See Checking the SET+ switch

See Fault-tracing information

See Checking the SET+ switch

See Fault-tracing information

  1. Ignition on. Activate the Scan Tool (ST) in MODE 2. Set the switch to the OFF position. Depress the brake pedal. Check that the stop (brake) lamp switch is OK by checking whether response code 1-3-2 is obtained. Is response code 1-3-2 obtained? Yes, response code 1-3-2 is obtained. Troubleshooting has been completed. No, response code 1-3-2 is not obtained. Refer to «Checking the stop (brake) lamp»(ref-441369-S24404611082011121500000) . No, response code 3-1-1 is obtained instead. Refer to «Checking response code 3-1-1»(ref-441369-S12214692032011121500000) .

The response code is obtained when the control module receives numerous input signals within 8 ms from the same component or circuit. The fault may be due to loose connections in the terminals or a faulty component.

  1. Continue Refer to «Checking the stop (brake) lamp»(ref-441369-S24404611082011121500000)

Scheme 49

Scheme 49
Scheme 49
  1. Ignition on.
  2. Depress the brake pedal.

Does the stop (brake) lamp light?

  1. YES Refer to «Checking the power supply to the control module»(ref-441369-S16182387412011121500000)
  2. NO Refer to «Checking fuses»(ref-441369-S01296196212011121500000)

Checking fuses

  1. Check that fuse 10 the integrated relay/fusebox in the engine compartment is intact.

Scheme 50

Scheme 50
Scheme 50

Is the fuse intact?

  1. YES Refer to «Checking the 30-supply to the fuse»(ref-441369-S38137868542011121500000)
  2. NO Refer to «Checking for a short-circuit»(ref-441369-S00265935602011121500000)

Scheme 51

Scheme 51
Scheme 51
  1. Ignition off. Check the cable between: fuse 10 and stop (brake) lamp switch connector terminal 1 stop (brake) lamp switch connector terminal 3 (terminal 2 on cars with shift lock) and the stop (brake) lamp bulbs stop (brake) lamp connector terminal #3 (terminal #2 on cars with shift lock) and control module connector terminal #7 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Checking the 30-supply to the fuse

  1. Ignition on. Connect a voltmeter between the rear socket on the fuse holder for fuse 10 in the integrated relay/fusebox in the engine compartment and ground.

The voltmeter should read battery voltage.

  1. OK Refer to «Checking the voltage to the stop (brake) lamp switch»(ref-441369-S28145082282011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S26681122862011121500000)
  1. Ignition off. Check the cable between the battery positive terminal and fuse 10 the integrated relay/fusebox in the engine compartment for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Scheme 52

Scheme 52
Scheme 52
  1. Ignition off.
  2. Disconnect the stop (brake) lamp switch.
  3. Ignition on. Connect a voltmeter between stop (brake) lamp switch connector terminal 1 and ground.

The voltmeter should read battery voltage.

  1. OK Refer to «Checking the stop (brake) lamp switch»(ref-441369-S35964856352011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S02265751692011121500000)
  1. Ignition off. Check the cable between fuse no. 10 the integrated relay/fusebox in the engine compartment and stop (brake) lamp switch connector terminal #1 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Checking the stop (brake) lamp switch

  1. Ignition off.
  2. Connect the stop (brake) lamp switch.
  3. Ignition on. Connect a voltmeter between stop (brake) lamp switch connector terminal 3 (terminal 2 on cars with shift lock) and ground.

The voltmeter should read battery voltage when the brake pedal is pressed down more than 5 mm.

  1. OK Refer to «Checking the stop (brake) lamp bulbs»(ref-441369-S02867332882011121500000)
  2. NOT OK Refer to «Replacing the component»(ref-441369-S06546521082011121500000)

Scheme 53

Scheme 53
Scheme 53
  1. Ignition off. Replace with a new stop (brake) lamp switch according to «Replacement of brake light switch»(ref-441369-S10288424732012031600000) .

Checking the stop (brake) lamp bulbs

  1. Ignition off.
  2. Check that the stop (brake) lamp bulbs are intact. Replace if necessary.
  3. Disconnect the stop (brake) lamp switch. Connect an ohmmeter between stop (brake) lamp switch connector terminal 3 (terminal 2 on cars with shift lock) and ground.

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the response code»(ref-441369-S28700569912011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S05920807892011121500000)
  1. Ignition off. Check the cable between stop (brake) lamp switch connector terminal #3 (terminal #2 on cars with shift lock) and the stop (brake) lamp bulbs for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) . Replace the bulb failure warning sensor if no fault is found.
  1. Ignition off.
  2. Connect the stop (brake) lamp switch
  3. Connect the Volvo Scan Tool (ST) to the data link connector (DLC).
  4. Ignition on. Activate the Scan Tool (ST) in MODE 2. Set the switch to the OFF position. Depress the brake pedal. Check whether response code 1-3-2 is obtained.

Is response code 1-3-2 obtained?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Replacing the component»(ref-441369-S35982552602011121500000)

Scheme 54

Scheme 54
Scheme 54
  1. Ignition off. Replace with a new bulb failure warning sensor.
  1. Ignition off.
  2. Stop (brake) lamp switch connected.
  3. Brake pedal unaffected.
  4. Disconnect the control module.
  5. Ignition on. Connect a voltmeter between control module connector terminal 7 and ground.

The voltmeter should read approximately 0 V.

  1. OK Refer to «Checking the resistance in the signal cable»(ref-441369-S24391787132011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S33923899712011121500000)

Scheme 55

Scheme 55
Scheme 55
  1. Ignition off. Check the cable between stop (brake) lamp switch connector terminal #3 (terminal #2 on cars with shift lock) and control module connector terminal #7 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Checking the resistance in the signal cable

  1. Ignition off.
  2. Control module disconnected.
  3. Disconnect the stop (brake) lamp switch. Connect an ohmmeter between stop (brake) lamp switch connector terminal 3 (terminal 2 on cars with shift lock) and control module connector terminal 7.

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the control module connectors»(ref-441369-S17443234602011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S29816577742011121500000)
  1. Ignition off. Check the cable between stop (brake) lamp switch connector terminal #3 (terminal #2 on cars with shift lock) and control module connector terminal #7 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .
  1. Ignition off.
  2. Check control module connector terminal #7 for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  3. Connect the control module.
  4. Connect the stop (brake) lamp switch
  5. Connect the Volvo Scan Tool (ST) to the data link connector (DLC).
  6. Ignition on. Activate the Scan Tool (ST) in MODE 2. Set the switch to the OFF position. Depress the brake pedal. Check whether response code 1-3-2 is obtained.

Is response code 1-3-2 obtained?

  1. YES Refer to «Fault-tracing information»(ref-441369-S19156105502011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S16328668782011121500000)
  1. Ignition off. This response code was not obtained because of loose connections in the control module connector.
  1. Ignition off. Replace with a new control module according to «Replacement of control module»(ref-441369-S15062999982012032800000) .
  1. Continue Refer to «Information»(ref-441369-S20402336922011121500000)

Scheme 56

Scheme 56: Replacement of brake light switch
Scheme 56: Replacement of brake light switch

The switch is mounted on the pedal support.

Preparations

  1. Remove dashboard panel.

Remove

  1. Disconnect connector.
  2. Twist out switch (to left).

Install

  1. Press switch into clip as far as possible (keep pedal raised).
  2. Reconnect connector.

Adjust

  1. Adjust by twisting switch in or out.

Brake lights should light with a pedal movement of 5 mm.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Checking the stop (brake) lamp switch

See Checking the stop (brake) lamp switch

Checking the ground lead. Checking the power supply

  1. Ignition on. Power up the Volvo Scan Tool (ST). Try to establish communication with the cruise control module.

Is communication with the cruise control module established?

  1. YES Refer to «Checking the function of the governor»(ref-441369-S03289463762011121500000)
  2. NO FAULT NOT FOUND: Troubleshooting has been completed.

Scheme 57

Scheme 57
Scheme 57
  1. Ignition off.
  2. Disconnect the control module.
  3. Ignition on. Connect the single wire cable between terminals #1 and #11 on the control module connector. Connect the other cable with the double flat pins to control module connector terminal #10. Connect one cable to control module connector terminal 12. The governor should click.

Did the governor click?

  1. YES Refer to «Checking the function of the vacuum pump»(ref-441369-S11620623792011121500000)
  2. NO Refer to «Checking the cable for the governor»(ref-441369-S19047601252011121500000)

Scheme 58

Scheme 58
Scheme 58
  1. Ignition off.
  2. Control module disconnected.
  3. Disconnect the vacuum pump. Connect a voltmeter between vacuum pump connector terminal #1 and ground.

The ohmmeter should read infinite resistance.

  1. OK Refer to «Checking the power supply for the governor»(ref-441369-S02711057182011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S19854627472011121500000)

Scheme 59

Scheme 59
Scheme 59
  1. Ignition off. Check the cable between vacuum pump connector terminal #1 and control module connector terminal #12 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Scheme 60

Scheme 60
Scheme 60
  1. Ignition off.
  2. Control module connected.
  3. Vacuum pump removed.
  4. Ignition on. Connect a voltmeter between vacuum pump connector terminal #1 and ground.

The voltmeter should read approximately 10 V.

  1. OK Refer to «Checking the cable to the vacuum pump»(ref-441369-S09161265552011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S11697186542011121500000)
  1. Ignition off. Check the cable between vacuum pump connector terminal #1 and control module connector terminal #12 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Checking the cable to the vacuum pump

  1. Ignition off.
  2. Disconnect the control module.
  3. Vacuum pump removed. Connect a voltmeter between vacuum pump connector terminal #3 and ground.

The ohmmeter should read infinite resistance.

  1. OK Refer to «Checking the voltage to the vacuum pump»(ref-441369-S18821770262011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S41500955902011121500000)
  1. Ignition off. Check the cable between vacuum pump connector terminal #3 and control module connector terminal #1 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

Checking the voltage to the vacuum pump

  1. Ignition off.
  2. Connect the control module.
  3. Vacuum pump removed.
  4. Ignition on. Connect a voltmeter between vacuum pump connector terminal #3 and ground.

The voltmeter should read approximately 0 V.

  1. OK Refer to «Checking the resistance in the cable»(ref-441369-S41792105702011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S24765509972011121500000)
  1. Ignition off. Check the cable between vacuum pump connector terminal #3 and control module connector terminal #1 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .

Checking the resistance in the cable

  1. Ignition off.
  2. Disconnect the control module.
  3. Vacuum pump removed. Connect an ohmmeter between vacuum pump connector terminal #3 and control module connector terminal #1.

The ohmmeter should read approximately 0 ohms

  1. OK Refer to «Checking the governor»(ref-441369-S29931633812011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S40004878672011121500000)
  1. Ignition off. Check the cable between vacuum pump connector terminal #3 and control module connector terminal #1 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Scheme 61

Scheme 61
Scheme 61
  1. Ignition off.
  2. Vacuum pump removed. Temporarily connect a cable between vacuum pump pin terminal #3 and the battery positive terminal. Connect a cable between vacuum pump pin terminal #1 and the battery negative terminal. The governor should click. Remove the temporarily connected cables.

Did the governor click?

  1. YES Refer to «Checking for contact resistance and oxidation»(ref-441369-S01588698902011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S35626105842011121500000)

Checking for contact resistance and oxidation

  1. Ignition off. Check the control module terminal and vacuum pump connectors for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .

Scheme 62

Scheme 62
Scheme 62
  1. Ignition off. Replace the vacuum pump according to «Replacement of vacuum pump and regulator»(ref-441369-S07388334862012031600000) .

Checking the function of the vacuum pump

  1. Ignition on.
  2. Control module disconnected.
  3. Connect the single wire cable between terminals #1 and #11 on the control module connector. Connect the other cable with the double flat pin to control module connector terminal #10. Connect one of the other ends to control module connector terminal #12. Connect the other cable to control module connector terminal #9. The vacuum pump should start. The vacuum regulator should compress. Remove the cable from terminal #9 when the vacuum regulator is fully compressed. The vacuum pump should stop.

Is the vacuum pump operating normally?

  1. YES FAULT NOT FOUND: Troubleshooting has been completed.
  2. NO Refer to «Checking the cable to the vacuum pump»(ref-441369-S07304477912011121500000)

Checking that the vacuum system is air tight

  1. Ignition off.
  2. Control module disconnected.
  3. Vacuum pump connected.
  4. Ignition on.
  5. Connect the single wire cable between terminals #11 and #1 on the control module connector. Connect the other cable with the double flat pin to control module connector terminal #10. Connect one of the other ends to control module connector terminal #12. Connect the other cable to control module connector terminal #9. The vacuum pump should start. The vacuum regulator should compress. Remove the cable from terminal #9 when the vacuum regulator is fully compressed. The vacuum pump should stop. The vacuum system is airtight if the vacuum regulator has not released the throttle mechanism after 30 seconds. Disconnect the cable connected to control module connector terminal #12. The vacuum regulator will then release the throttle mechanism.

Is the vacuum system airtight?

  1. YES Refer to «Checking brake valves»(ref-441369-S17540156452011121500000)
  2. NO Refer to «Checking for leaks»(ref-441369-S42427999792011121500000)

Checking for leaks

  1. Check that there are no leaks in the hoses to the vacuum pump and the vacuum regulator.
  1. Continue Refer to «Checking brake valves»(ref-441369-S17540156452011121500000)
  1. Ignition off.
  2. Disconnect the vacuum pump.
  3. Control module disconnected. Connect a voltmeter between vacuum pump connector terminal #2 and ground.

The ohmmeter should read infinite resistance.

  1. OK Refer to «Checking the voltage to the vacuum pump»(ref-441369-S01600330812011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S15714314232011121500000)
  1. Ignition off. Check the cable between vacuum pump connector terminal #2 and control module connector terminal #9 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .
  1. Ignition off.
  2. Control module connected.
  3. Vacuum pump removed.
  4. Ignition on. Connect a voltmeter between vacuum pump connector terminal #2 and ground.

The voltmeter should read approximately 0 V.

  1. OK Refer to «Checking the resistance in the cable»(ref-441369-S04158843442011121500000)
  2. NOT OK Refer to «Checking for a short-circuit»(ref-441369-S25580659152011121500000)
  1. Ignition off. Check the cable between vacuum pump connector terminal #2 and control module connector terminal #9 for a short-circuit to supply voltage according to «Short-circuit to supply voltage. Permanent faults»(ref-441291-S37119086802011121500000) .
  1. Ignition off.
  2. Disconnect the control module.
  3. Vacuum pump removed. Connect an ohmmeter between vacuum pump connector terminal #2 and control module connector terminal #9.

The ohmmeter should read approximately 0 ohms

  1. OK Refer to «Checking the vacuum pump»(ref-441369-S28767174852011121500000)
  2. NOT OK Refer to «Checking for an open-circuit»(ref-441369-S40633137112011121500000)
  1. Ignition off. Check the control module terminal and vacuum pump connectors for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  1. Ignition off. Check the cable between vacuum pump connector terminal #2 and control module connector terminal #9 for an open-circuit according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) .

Checking the vacuum pump

  1. Ignition off.
  2. Vacuum pump removed. Temporarily connect a cable between vacuum pump pin terminal #3 and the battery positive terminal. Connect a cable between vacuum pump pin terminal #2 and the battery negative terminal. The vacuum pump should start. Remove the temporarily connected cables.

Did the vacuum pump start?

  1. YES Refer to «Checking for contact resistance and oxidation»(ref-441369-S21580031972011121500000)
  2. NO Refer to «Replacing the component»(ref-441369-S16034055522011121500000)
  1. Ignition off. Check the control module terminal and vacuum pump connectors for contact resistance and oxidation and for loose connections. Remedy «Contact resistance and oxidation»(ref-441291-S41448420802011121500000) . Remedy loose connections according to «Loose connections (terminals)»(ref-441291-S22081329982011121500000) .
  1. Ignition off. Replace the vacuum pump according to «Replacement of vacuum pump and regulator»(ref-441369-S07388334862012031600000) .
  1. Ignition off.
  2. Control module disconnected.
  3. Vacuum pump connected.
  4. Ignition on.
  5. Connect the single wire cable between terminals #11 and #1 on the control module connector.
  6. Connect the other cable with the double flat terminal pins to control module connector terminal #10. Connect one end of the cable to control module connector terminal #12. Connect the other end of the cable to control module connector terminal #9. The vacuum pump should start. The vacuum regulator should open the throttle mechanism fully. Stop the vacuum pump when the vacuum regulator has reached its limit position: Remove the cable from control module connector terminal #9. Depress the brake pedal.

Does the brake valve release air into the system so that the vacuum regulator deploys?

  1. YES Refer to «Fault-tracing information»(ref-441369-S37095533062011121500000)
  2. NO Refer to «Adjusting the brake valve»(ref-441369-S32487235072011121500000)
  1. Only cars with manual transmissions have a clutch valve. Specify the type of transmission before continuing with fault-tracing.

Does the car have a manual transmission?

  1. YES Refer to «Checking the clutch valve»(ref-441369-S00216488552011121500000)
  2. NO FAULT NOT FOUND: Troubleshooting has been completed.
  1. Ignition off.
  2. Control module disconnected.
  3. Vacuum pump connected.
  4. Detach the hose connectors so that the vacuum regulator deploys.
  5. Depress the pedal so that it is not in contact with the valve.
  6. Pull out the piston as far as possible. Slowly release the pedal. The plastic snap fastener in the valve should then retain the piston in the correct position.
  7. Ignition on.
  8. Connect the single wire cable between terminals #11 and #1 on the control module connector.
  9. Connect the other cable with the double flat terminal pins to control module connector terminal #10. Connect one end of the cable to control module connector terminal #12. Connect the other end of the cable to control module connector terminal #9. The vacuum pump should start. The vacuum regulator should open the throttle mechanism fully. Stop the vacuum pump when the vacuum regulator has reached its limit position: Remove the cable from control module connector terminal #9. Depress the brake pedal.

Does the brake valve release air into the system so that the vacuum regulator deploys?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Replacing the component»(ref-441369-S39843398922011121500000)
  1. Manual transmissions: Checking the clutch valve. Refer to «Checking the clutch valve»(ref-441369-S00216488552011121500000)
  2. Automatic transmissions: The vacuum system check is now complete. Troubleshooting has been completed.
  1. Ignition off. Try a new brake valve.
  1. Ignition off.
  2. Control module disconnected.
  3. Vacuum pump connected.
  4. Ignition on.
  5. Connect the single wire cable between terminals #11 and #1 on the control module connector.
  6. Connect the other cable with the double flat terminal pins to control module connector terminal #10. Connect one end of the cable to control module connector terminal #12. Connect the other end of the cable to control module connector terminal #9. The vacuum pump should start. The vacuum regulator should open the throttle mechanism fully. Stop the vacuum pump when the vacuum regulator has reached its limit position: Remove the cable from control module connector terminal #9. Depress the clutch pedal.

Does the brake valve release air into the system so that the vacuum regulator deploys?

  1. YES FAULT NOT FOUND: Troubleshooting has been completed.
  2. NO Refer to «Adjusting the clutch valve»(ref-441369-S13195376252011121500000)
  1. Ignition off.
  2. Disconnect the wiring.
  3. Detach the hose connectors so that the vacuum regulator deploys.
  4. Depress the pedal so that it is not in contact with the valve.
  5. Pull out the piston as far as possible. Slowly release the pedal. The plastic snap fastener in the valve should then retain the piston in the correct position.
  6. Control module disconnected.
  7. Vacuum pump connected.
  8. Ignition on.
  9. Connect the single wire cable between terminals #11 and #1 on the control module connector.
  10. Connect the other cable with the double flat terminal pins to control module connector terminal #10. Connect one end of the cable to control module connector terminal #12. Connect the other end of the cable to control module connector terminal #9. The vacuum pump should start. The vacuum regulator should open the throttle mechanism fully. Stop the vacuum pump when the vacuum regulator has reached its limit position: Remove the cable from control module connector terminal #9. Depress the clutch pedal.

Does the brake valve release air into the system so that the vacuum regulator deploys?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Replacing the component»(ref-441369-S24563897642011121500000)
  1. Ignition off. Replace the clutch valve according to «Replacement of clutch pedal vacuum valve»(ref-441369-S23974180992012032900000) .

Scheme 63

Scheme 63: Replacement of vacuum pump and regulator
Scheme 63: Replacement of vacuum pump and regulator
  1. Remove connector from vacuum pump.
  2. Remove two mounting bolts and remove vacuum pump and regulator.
  3. Remove vacuum hose.
  4. Pull the three rubber boots from support and remove vacuum pump and regulator.

Reinstall in reverse order.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9988686

Condition

WARNINGDo not start the engine during this test under any circumstances.
  1. The fault is permanent.
  2. The control module is correctly connected.

Scheme 64

Scheme 64
Scheme 64

Test the function of the vacuum motor and regulator. Check that the valves are able to maintain a vacuum in the vacuum servo.

The test is performed by operating the vacuum motor and regulator with extra cables connected to the control module connector.

Take care not to damage any components: Connect the cables correctly.

Carry out a visual inspection of the boots and seals at the joints.

Make two cables

One should be a single cable with narrow blade terminals at both ends. The other is doubled at one end with a narrow tab terminal on each end.

Possible Source

  1. Open-circuit in the wiring between the control module and the vacuum pump/regulator.
  2. Short-circuit to ground or supply in the cables between the control module and the vacuum pump/regulator.
  3. Defective vacuum pump/regulator.
  4. The vacuum pump, regulator, vacuum servo, hoses or connections are not airtight.

Fault symptom[s]

  1. The cruise control does not engage.
  2. The cruise control does not disengage when the brake or clutch pedals are depressed.
  3. The vehicle speed increases constantly.

Checking the vacuum system

See Checking the vacuum system

See Fault-tracing information

See Checking the vacuum system

See Fault-tracing information

Scheme 65

Scheme 65: Replacement Of Control Module
Scheme 65: Replacement Of Control Module
  1. Remove trim panel under dashboard at right-hand side.
  2. Remove connector of the control module.
  3. Remove the two screws.
  4. Remove control module.

Reinstall in reverse order.

Scheme 66

Scheme 66: Replacement Of Selector Switch (Turn Indicator)
Scheme 66: Replacement Of Selector Switch (Turn Indicator)
  1. Remove steering column cover (3 screws).
  2. Remove switch mounting screws.
  3. Push in safety lip.
  4. Remove switch and disconnect connector.

Reinstall in reverse order.

Scheme 67

Scheme 67: Replacement Of Clutch Pedal Vacuum Valve
Scheme 67: Replacement Of Clutch Pedal Vacuum Valve
  1. Remove connector of vacuum valve.
  2. Remove hose from vacuum valve.
  3. Press in both catches and remove vacuum valve from support.

Reinstall in reverse order

More articles — Engine Control - Symptom Related Diagnostic Procedures
