Climate Control Module Diagnostic Trouble Codes: Diagnosis Volvo S80 II

Automatic HVAC System 12 illustrations ~8522 words

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102E09

Condition

Climate control module (CCM) checks the status of the Air quality sensor (AQS).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Air quality sensor (AQS) is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Scheme 242

Scheme 242
Scheme 242

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Air quality sensor (AQS).

Fault symptom[s]

  1. Poor air quality in the passenger compartment

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102E09

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102E11

Condition

Climate control module (CCM) checks the status of the Air quality sensor (AQS).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Air quality sensor (AQS) is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Air quality sensor (AQS) is short-circuited to ground.

Fault symptom[s]

  1. Poor air quality in the passenger compartment

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102E11

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102E12

Condition

Climate control module (CCM) checks the status of the Air quality sensor (AQS).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Air quality sensor (AQS) is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Open circuit or short circuit to battery voltage.

Fault symptom[s]

  1. Poor air quality in the passenger compartment

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102E12

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102F23

Condition

Climate control module (CCM) checks the status for the bottom row's keys on the keypad.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Some button has been pressed in for more than 120 seconds.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Scheme 243

Scheme 243
Scheme 243

Substitute Value

  1. None.

Possible Source

  1. One or more function buttons are stuck in the pressed-in position.

Fault symptom[s]

  1. Spot lamps/auxiliary lights/Does not work
  2. Alarm/Sensors cannot be turned off using button in center console
  3. Front/rear park assist/Does not work
  4. Stability function/Does not work
  5. Door mirrors/Folding does not work
  6. Blind spot information system (BLIS)/Does not work
  7. Front monitoring/Active safety/City Safety does not work
  8. Front monitoring/Active safety/Lane Departure Warning does not work
  9. Rear seat/Head restraint folding does not work
  10. Headlights/Vertical adjustment not influenced by steering wheel
  11. Buttons/control knobs on center console (Climate)/No/reduced/incorrect function

Condition

The Climate control module (CCM) checks the status of the buttons in the lower part of the control panel.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Some button has been pressed in for more than 120 seconds.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Scheme 244

Scheme 244
Scheme 244

Substitute Value

  1. None.

Possible Source

  1. One or more function buttons are stuck in the pressed-in position.

Fault symptom[s]

  1. Front monitoring/Active safety/Lane Departure Warning does not work
  2. Front monitoring/Active safety/City Safety does not work
  3. Blind spot information system (BLIS)/Does not work
  4. Buttons/control knobs on center console (Climate)/No/reduced/incorrect function

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B102F4A

Condition

Climate control module (CCM) checks the status for the bottom row's keys on the keypad.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The button is not included in the vehicle configuration file.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. The vehicle's configuration is incorrect.

Fault symptom[s]

  1. Front monitoring/Active safety/Lane Departure Warning does not work
  2. Front monitoring/Active safety/City Safety does not work
  3. Blind spot information system (BLIS)/Does not work
  4. Buttons/control knobs on center console (Climate)/No/reduced/incorrect function

Condition

Climate control module (CCM) checks the status for the bottom row's keys on the keypad.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The button is not included in the vehicle configuration file.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. The vehicle's configuration is incorrect.

Fault symptom[s]

  1. Switches on the lower part of the climate control unit does not work
  2. Buttons/control knobs on center console (Climate)/No/reduced/incorrect function

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103009

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Internal components do not work.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Scheme 245

Scheme 245
Scheme 245

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103009

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10304B

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) has too high temperature.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10304B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103087

Condition

Seat heating module (SHM), in left front seat, sends information about status to Climate control module (CCM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) does not answer.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Lost voltage feed or problem with ground connection.
  2. Failure of the part of LIN-bus 1 that connects Climate control module (CCM) to Seat heating module (SHM) in left front seat, and the connector on the climate module.
  3. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103087

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103109

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Internal components do not work.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103109

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10314B

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) has too high temperature.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10314B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103187

Condition

Seat heating module (SHM), in left rear seat, sends information about status to Climate control module (CCM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) does not answer.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Lost voltage feed or problem with ground connection.
  2. Failure of the part of LIN-bus 1 that connects Climate control module (CCM) to Seat heating module (SHM) in left rear seat, and the connector on the climate module.
  3. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103187

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103209

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Internal components do not work.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103209

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10324B

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) has too high temperature.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10324B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103287

Condition

Seat heating module (SHM), in right front seat, sends information about status to Climate control module (CCM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) does not answer.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Lost voltage feed or problem with ground connection.
  2. Failure of the part of LIN-bus 2 that connects Climate control module (CCM) to Seat heating module (SHM) in right front seat, and the connector on the climate module.
  3. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103287

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103309

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Internal components do not work.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103309

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10334B

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) has too high temperature.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10334B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103387

Condition

Seat heating module (SHM), in right rear seat, sends information about status to Climate control module (CCM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Seat heating module (SHM) does not answer.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Lost voltage feed or problem with ground connection.
  2. Failure of the part of LIN-bus 2 that connects Climate control module (CCM) to Seat heating module (SHM) in right rear seat, and the connector on the climate module.
  3. Internal fault in Seat heating module (SHM).

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103387

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103401

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The heating coil in the seat is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Scheme 246

Scheme 246
Scheme 246

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the heating coil.
  2. The cable between seat heating module (SHM) and heating coil is short-circuited to ground.
  3. The cable between seat heating module (SHM) and heating coil is short-circuited to voltage.

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103401

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103501

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The heating coil in the seat is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Scheme 247

Scheme 247
Scheme 247

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the heating coil.
  2. The cable between seat heating module (SHM) and heating coil is short-circuited to ground.
  3. The cable between seat heating module (SHM) and heating coil is short-circuited to voltage.

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103501

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103601

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The heating coil in the seat is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the heating coil.
  2. The cable between seat heating module (SHM) and heating coil is short-circuited to ground.
  3. The cable between seat heating module (SHM) and heating coil is short-circuited to voltage.

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103601

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103701

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The heating coil in the seat is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the heating coil.
  2. The cable between seat heating module (SHM) and heating coil is short-circuited to ground.
  3. The cable between seat heating module (SHM) and heating coil is short-circuited to voltage.

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103701

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103801

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Sensor seat heating not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Scheme 248

Scheme 248
Scheme 248

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the sensor.
  2. The cable between seat heating module (SHM) and sensor is short-circuited to ground.
  3. The cable between seat heating module (SHM) and sensor is short-circuited to voltage.

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103801

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103901

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Sensor seat heating not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the sensor.
  2. The cable between seat heating module (SHM) and sensor is short-circuited to ground.
  3. The cable between seat heating module (SHM) and sensor is short-circuited to voltage.

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103901

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103A01

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Sensor seat heating not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the sensor.
  2. The cable between seat heating module (SHM) and sensor is short-circuited to ground.
  3. The cable between seat heating module (SHM) and sensor is short-circuited to voltage.

Fault symptom[s]

  1. Front seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103A01

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103B01

Condition

Seat heating module (SHM) sends information to Climate control module (CCM) about status and current temperature.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Sensor seat heating not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the cable between seat heating module (SHM) and the sensor.
  2. The cable between seat heating module (SHM) and sensor is short-circuited to ground.
  3. The cable between seat heating module (SHM) and sensor is short-circuited to voltage.

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103B01

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103F87

Condition

Climate control module (CCM) checks status of switch rear seat heating.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Communication with switch rear seat heating lost.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Communication interference.

Fault symptom[s]

  1. Rear seat heating does not operate

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103F87

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B103F96

Condition

Climate control module (CCM) checks status of switch rear seat heating.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Signal from switch rear seat heating is incorrect.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Internal error in switch rear seat heating.

Fault symptom[s]

  1. Rear seat heating does not operate

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105609

Condition

There are ventilation fans mounted in the seat cushions and in the backrests. Climate control module (CCM) checks the status of the seats' ventilation fans.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The fan is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Scheme 249

Scheme 249
Scheme 249

Substitute Value

  1. None.

Possible Source

  1. Internal fault in seat ventilation fan.

Fault symptom[s]

  1. Seat Ventilation; No functionality

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105609

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105709

Condition

There are ventilation fans mounted in the seat cushions and in the backrests. The ventilation fans are connected to seat heating module (SHM). Climate control module (CCM) checks the status of the seats' ventilation fans.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The fan is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in seat ventilation fan.

Fault symptom[s]

  1. Seat Ventilation; No functionality

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105709

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105809

Condition

There are ventilation fans mounted in the seat cushions and in the backrests. The ventilation fans are connected to seat heating module (SHM). Climate control module (CCM) checks the status of the seats' ventilation fans.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The fan is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in seat ventilation fan.

Fault symptom[s]

  1. Seat Ventilation; No functionality

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105809

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105909

Condition

There are ventilation fans mounted in the seat cushions and in the backrests. The ventilation fans are connected to seat heating module (SHM). Climate control module (CCM) checks the status of the seats' ventilation fans.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The fan is not working.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in seat ventilation fan.

Fault symptom[s]

  1. Seat Ventilation; No functionality

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105909

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105A11

Condition

In order that the passenger compartment temperature sensor shall not be affected by surrounding electronics, a fan blows air from the passenger compartment at the sensor. Climate control module (CCM) checks the status of the fan and temperature sensor in the passenger compartment. The status is determined by the frequency of one electric signal.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The signal's frequency exceeds 200 Hz.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Scheme 250

Scheme 250
Scheme 250

Substitute Value

  1. None.

Possible Source

  1. Short-circuit to ground in the power supply.

Fault symptom[s]

  1. Temperature control/A/C does not work

Condition

Climate control module (CCM) checks the status of the fan and temperature sensor in the passenger compartment. In order that the passenger compartment temperature sensor shall not be affected by surrounding electronics, a fan blows air from the passenger compartment at the sensor.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The signal from the fan is low.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Scheme 251

Scheme 251
Scheme 251

Substitute Value

  1. None.

Possible Source

  1. The fan is short-circuited to ground.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105A15

Condition

Climate control module (CCM) checks the status of the fan and temperature sensor in the passenger compartment. In order that the passenger compartment temperature sensor shall not be affected by surrounding electronics, a fan blows air from the passenger compartment at the sensor.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The signal from the fan is high.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on the line for voltage feed to the fan, or the voltage supply is short-circuited to voltage.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105A71

Condition

Climate control module (CCM) checks the status of the fan and temperature sensor in the passenger compartment.

In order that the passenger compartment temperature sensor shall not be affected by surrounding electronics, a fan blows air from the passenger compartment at the sensor.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The fan blades do not move.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Blower fan for the passenger compartment temperature sensor is blocked.
  2. The fan is not working.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B105A96

Condition

In order that the passenger compartment temperature sensor shall not be affected by surrounding electronics, a fan blows air from the passenger compartment at the sensor. Climate control module (CCM) checks the status of the fan and temperature sensor in the passenger compartment. The status is determined by the frequency of one electric signal.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The signal's frequency falls below 30 Hz for longer than two minutes.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Blocked or binding fan or fan motor.
  2. Open-circuit in the power supply cable.

Fault symptom[s]

  1. Temperature control/A/C does not work

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108109

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature left via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) temperature left has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Scheme 252

Scheme 252
Scheme 252

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) temperature left.
  2. Incorrect calibration due to loss of power.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108109

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108177

Condition

Climate control module (CCM) checks end-positions for Damper motor module (DMM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. End-positions do not match with the expected positions.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Calibrating the damper motors.

Substitute Value

  1. None.

Possible Source

  1. Blocked damper.
  2. Climate control unit calibrated at incorrect temperature.
  3. Internal fault in Damper motor module (DMM) temperature left.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108177

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108187

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature left via LIN-bus 1.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Communication with Damper motor module (DMM) temperature left is lost.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on LIN-bus 1.
  2. Contact resistance, oxidation or loose connections in the connectors.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108187

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108192

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature left via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) temperature left has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) temperature left.

Fault symptom[s]

  1. Temperature control/A/C does not work

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108194

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature left via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) temperature left transmits an incorrect response.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) temperature left.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set
  2. Temperature control/A/C does not work

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108194

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108209

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature right via LIN-bus 2. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) temperature right has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) temperature right.
  2. Incorrect calibration due to loss of power.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108209

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108277

Condition

Climate control module (CCM) checks end-positions for Damper motor module (DMM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. End-positions do not match with the expected positions.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Blocked damper.
  2. Climate control unit calibrated at incorrect temperature.
  3. Internal fault in Damper motor module (DMM) temperature right.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108277

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108287

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature right via LIN-bus 2.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Communication with Damper motor module (DMM) temperature right is lost.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on LIN-bus 2.
  2. Contact resistance, oxidation or loose connections in the connectors.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108287

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108292

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature right via LIN-bus 2. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) temperature right has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) temperature right.

Fault symptom[s]

  1. Temperature control/A/C does not work

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108294

Condition

Climate control module (CCM) communicates with Damper motor module (DMM) temperature right via LIN-bus 2. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) temperature right transmits an incorrect response.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) temperature right.

Fault symptom[s]

  1. Cabin temperature does not correspond to value set
  2. Temperature control/A/C does not work

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108294

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108309

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) recirculation via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) recirculation has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in the Damper motor module (DMM) recirculation.
  2. Incorrect calibration due to loss of power.

Fault symptom[s]

  1. No recirculation

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108309

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108377

Condition

Climate control module (CCM) checks end-positions for Damper motor module (DMM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. End-positions do not match with the expected positions.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Blocked damper.
  2. Climate control unit calibrated at incorrect temperature.
  3. Internal fault in the Damper motor module (DMM) recirculation.

Fault symptom[s]

  1. No recirculation

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108377

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108387

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) recirculation via LIN-bus 1.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Communication with Damper motor module (DMM) recirculation is lost.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on LIN-bus 1.
  2. Contact resistance, oxidation or loose connections in the connectors.

Fault symptom[s]

  1. No recirculation

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108387

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108392

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) recirculation via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) recirculation has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in the Damper motor module (DMM) recirculation.

Fault symptom[s]

  1. Temperature control/A/C does not work

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108394

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) recirculation via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) recirculation transmits an incorrect response.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in the Damper motor module (DMM) recirculation.

Fault symptom[s]

  1. Airflow recirculation does not work.
  2. Temperature control/A/C does not work

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108394

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108509

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) defroster via the LIN bus 2. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) defroster has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) defroster.
  2. Incorrect calibration due to loss of power.

Fault symptom[s]

  1. Mist on rear window and door mirrors

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108509

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108577

Condition

Climate control module (CCM) checks end-positions for Damper motor module (DMM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. End-positions do not match with the expected positions.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Blocked damper.
  2. Climate control unit calibrated at incorrect temperature.
  3. Internal fault in Damper motor module (DMM) defroster.

Fault symptom[s]

  1. Mist on rear window and door mirrors

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108577

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108587

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) defroster via the LIN bus 2.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Communication with Damper motor module (DMM) defroster is lost.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on LIN-bus 2.
  2. Contact resistance, oxidation or loose connections in the connectors.

Fault symptom[s]

  1. Mist on rear window and door mirrors

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108587

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108592

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) defroster via the LIN bus 2. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) defroster has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) defroster.

Fault symptom[s]

  1. Defog/defrost/Door mirrors defog/defrost/Does not work
  2. Defog/defrost/Side window defog/defrost/Does not work
  3. Defog/defrost/Windshield defog/defrost/Does not work

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108594

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) defroster via the LIN bus 2. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) defroster transmits an incorrect response.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in Damper motor module (DMM) defroster.

Fault symptom[s]

  1. Defog/defrost/Windshield defog/defrost/Does not work

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108594

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108609

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) air distribution via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) air distribution has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in the Damper motor module (DMM) air distribution.
  2. Incorrect calibration due to loss of power.

Fault symptom[s]

  1. Air flow problem

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108609

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108677

Condition

Climate control module (CCM) checks end-positions for Damper motor module (DMM).

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. End-positions do not match with the expected positions.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Blocked damper.
  2. Climate control unit calibrated at incorrect temperature.
  3. Internal fault in the Damper motor module (DMM) air distribution.

Fault symptom[s]

  1. Mist on rear window and door mirrors
  2. Air flow problem

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108677

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108687

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) air distribution via LIN-bus 1.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Communication with Damper motor module (DMM) air distribution is lost.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Open circuit on LIN-bus 1.
  2. Contact resistance, oxidation or loose connections in the connectors.

Fault symptom[s]

  1. Air flow problem

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108687

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108692

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) air distribution via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) air distribution has a malfunction.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in the Damper motor module (DMM) air distribution.

Fault symptom[s]

  1. Temperature control/A/C does not work

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108694

Condition

The climate control module (CCM) communicates with the damper motor module (DMM) air distribution via LIN-bus 1. The damper motor module (DMM) transmits information to the climate control module (CCM) about status.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Damper motor module (DMM) air distribution transmits an incorrect response.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Internal fault in the Damper motor module (DMM) air distribution.

Fault symptom[s]

  1. No function on air distribution knob
  2. Temperature control/A/C does not work

see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108694

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B10874A

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left only applies if there is no seat heating module (SHM) ventilation.
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The configuration-id for some control module connected to the bus does not match the expected value.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Incorrect configuration ID (the control module is not intended for this vehicle, for example it is a used control module with different software/hardware).

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left only applies if there is no seat heating module (SHM) ventilation.
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The configuration-id for some control module connected to the bus does not match the expected value.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Scheme 253

Scheme 253
Scheme 253

Substitute Value

  1. None.

Possible Source

  1. Incorrect configuration ID (the control module is not intended for this vehicle, for example it is a used control module with different software/hardware).

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108754

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks status of LIN-bus 1 and 2. After repair, software downloading or replacement of components, the system must be calibrated.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. New software is downloaded to the control module. Calibration not completed.

Note. For frozen values, from original read-out, to show correct values after a software download the control module has to be calibrated.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Calibration not performed.

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks status of LIN-bus 1 and 2. After repair, software downloading or replacement of components, the system must be calibrated.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. New software is downloaded to the control module. Calibration not completed.

Note. For frozen values, from original read-out, to show correct values after a software download the control module has to be calibrated.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Calibration not performed.

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108783

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Received message does not correspond with expected message.
  2. Two or more LIN nodes have the same network ID.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Communication interference.
  2. There are two LIN nodes with the same ID installed in the vehicle. For example, Damper motor module (DMM) recirculation can be installed in the location of Damper motor module (DMM) air distribution.

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Received message does not correspond with expected message.
  2. Two or more LIN nodes have the same network ID.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Communication interference.
  2. There are two LIN nodes with the same ID installed in the vehicle. For example, Damper motor module (DMM) recirculation can be installed in the location of Damper motor module (DMM) air distribution.

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108786

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left only applies if there is no seat heating module (SHM) ventilation.
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Received message does not correspond with expected message.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Communication interference.
  2. There are two master nodes in LIN bus A.

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left only applies if there is no seat heating module (SHM) ventilation.
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Received message does not correspond with expected message.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position II.

Substitute Value

  1. None.

Possible Source

  1. Communication interference.
  2. There are two master nodes in LIN bus A.

Fault symptom[s]

  1. Air flow problem
  2. No recirculation
  3. Temperature control/Uneven temperature
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION CCM-B108788

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left only applies if there is no seat heating module (SHM) ventilation.
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Open circuit on LIN-bus 1.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Short-circuit to ground.
  2. Short-circuit to supply voltage.

Fault symptom[s]

  1. Air flow problem
  2. Temperature control/Uneven temperature
  3. No recirculation
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

Condition

Climate control module (CCM) both sends and receives information via standardized serial communication - LIN (Local Interconnect Network). Climate control module (CCM) checks the status of LIN-bus 1. The following components communicate on LIN bus 1

  1. Damper motor module (DMM) air distribution.
  2. Damper motor module (DMM) temperature left.
  3. Damper motor module (DMM) recirculation.
  4. Seat heating module (SHM), front left only applies if there is no seat heating module (SHM) ventilation.
  5. Seat heating module (SHM), left ventilation option/accessory
  6. Seat heating module (SHM), rear left option/accessory
  7. Switch, rear seat heating. Option/accessory

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Open circuit on LIN-bus 1.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Ignition switch position I and II.

Substitute Value

  1. None.

Possible Source

  1. Short-circuit to ground.
  2. Short-circuit to supply voltage.

Fault symptom[s]

  1. Air flow problem
  2. Temperature control/Uneven temperature
  3. No recirculation
  4. Poor heating in compartment
  5. Front seat heating does not operate
  6. Rear seat heating does not operate

More articles — Climate Control Module Diagnostic Trouble Codes
