Special tools
9511351
9511428
9813195
Scheme 376
To facilitate fault-tracing there is a breakout box 9511428 and various cables with connectors (adapters) for connecting the breakout box to the different control systems and to the combined instrument panel.
Breakout box
Breakout box 9511428 consists of a case with 60 measurement terminals and a cable with a connector.
The measurement terminals are numbered from 1-60 as shown in the illustration.
Scheme 377
To connect the breakout box to AW, LH and EZK control systems with 30+30-pin (A+B) connectors
Connector A (engine side) uses measuring terminals 1-30 which correspond to #A1-#A30 on the control module.
Connector B (car side) uses measuring terminals 31-60 which correspond to #B1-#B30 on the control module.
To connect the breakout box use adapter 9813195 .
Scheme 378
To connect the breakout box to the Fenix and Motronic control systems which have 43+43-pin connectors (A+B)
Use two breakout boxes (A and B) with adapter 9511351 . The adapter is fitted with two connectors marked A and B.
Connector A (engine side) uses measurement terminals 1-43 on the breakout box A which correspond to #A1-#A43 on the control module.
Connector B (car side) uses measurement terminals 1-43 on the breakout box B which correspond to #B1-#B43 on the control module.
Scheme 379
Using the breakout box
1
Taking readings with the control module in circuit (circuit in operation)
Breakout box(es) and adapter 9813195 or 9511351 connected between control module and connector in control module box. This allows voltage readings to be taken with the engine running.
2
Taking readings with the control module disconnected (split circuit)
Breakout box(es) and adapter 9813195 or 9511351 connected either to the control module connector or the connector in the control module box. This allows resistance readings to be taken in each circuit without them being affected by other systems.
