Removal
| WARNING | The supplemental restraint system (SRS) is active for a certain length of time after the power supply has been disconnected. Wait for a minimum of 3 minutes before disconnecting or removing any SRS components. |
Scheme 1347
Scheme 1348
Scheme 1349
| WARNING | Make sure that the vehicle electrical system is fully de-powered and no other power source is connected. |
Scheme 1350
Scheme 1351
| WARNING | When switching the ignition on first time after a battery disconnect and connect, stand outside the vehicle and reach into the vehicle keeping clear of the air bags operating areas. |
Set the clock.
Replacement of cable terminal in socket housing
Note. For equivalent pin housing, see Example 2B .
Scheme 1352
If the connector is intact then first remove the socket housing (female) from the pin housing (male). See illustration.
- Undo the locking screw. (Some connectors have no locking screw).
- Turn the connector housing retaining ring (outer ring) counterclockwise .
- Separate the two halves of the connector.
Scheme 1353
Extract socket housing from the connector housing as follows
- Remove retaining ring from the connector by inserting a small screwdriver from the rear of the ring and pry open the 3 catches.
- Pull back rubber seal on the cables.
Scheme 1354
- Open the socket housing secondary locking by turning the two rings shown in the illustration. A "click" indicates that the secondary locking has disengaged.
Scheme 1355
No terminal removal tool is required.
- Extract the cable terminal from the rear of the housing by tugging on the cable.
Replacement of cable terminals in pin housing
Note. For equivalent socket housing, see Example 2A .
Scheme 1356
If the connector is intact
- First disconnect the socket housing from the pin housing as in «Separate the connector pin and socket housings»(ref-461676-S37830255552012040200000) .
Scheme 1357
- Turn the retaining ring on the connector counterclockwise until a "click" indicates it has disengaged.
- Remove the retaining ring and pull back on the cables.
- Release the two catches on the sides using a narrow screwdriver.
- Withdraw the inner tube and pull back on the cables.
Scheme 1358
- First remove the pin housing from the outer shell.
- Open the pin housing secondary locking by turning the two rings as shown. A "click" indicates that the secondary locking has disengaged.
Scheme 1359
No terminal removal tool is required.
- Extract the cable terminal from the rear of the housing by pulling on the cable.
