Scheme 161
Integrated atmospheric pressure sensor
Scheme 162
Damper motor integrated with electronic unit
Scheme 163
Two signals. Pulse width modulated and lineal signal (digital / analog)
Scheme 164
Line pressure 380 kPa
Scheme 165
Mass air flow (MAF) sensor resistive film. Measurement range 12- 640 kg/h.
| Q (kg/h) | 12.0 | 15.0 | 30.0 | 60.0 |
|---|---|---|---|---|
| V (Volt) | 1.31 | 1.39 | 1.69 | 2.11 |
Scheme 166
Pump capacity at a line pressure of 380 kPa and 13 V > 125 l/min.
Power consumption at a line pressure of 380 kPa and 13 V max 7.5 A
Scheme 167
Coil resistance should be approximately 12ohms(at 20°C).
Scheme 168
Piezo resistive lineal pressure sensor. Measurement range 20.0 -250 kPa.
| P (kPa) | 90.0 | 101.3 | 150.0 | 200.0 |
|---|---|---|---|---|
| V /(Volt) | 1.69 | 1.90 | 2.80 | 3.71 |
Scheme 169
Frequency controlled valve. Resistance 29.7ohms
Scheme 170
Frequency controlled valve. Resistance 3.7 ohms
Scheme 171
NTC resistance.
| Temperature (°C) | 0 | 10 | 20 | 30 | 40 |
|---|---|---|---|---|---|
| R (ohms) | 15931 | 9672 | 6068 | 3923 | 2603 |
| V (Volt) | 4.30 | 3.94 | 3.50 | 3.00 | 2.50 |
Scheme 172
NTC resistance.
| Temperature (°C) | 0 | 10 | 20 | 40 | 80 | 100 |
|---|---|---|---|---|---|---|
| R (ohms) | 5740 | 3700 | 2450 | 1150 | 318 | 184 |
| V (Volt) | 2.65 | 2.10 | 1.62 | 0.92 | 0.29 | 0.17 |
Scheme 173
Piezoelectric crystal.
Scheme 174
Magnetic resistive sensor with permanent magnet
Scheme 175
Inductive sensor with permanent magnet Resistance 125.5 17 ohms
Scheme 176
Linear probe
